1
DISTANCE AND MEASUREMENT
Prepared by Selçuk NAS
This presentation is required office XP
2
Ellipse which is tangent at the Pole
X 6108 feet Y 6046 feet
Ellipse which is tangent at the Equator
3
Stop it
4
DOKUZ EYLUL UNIVERSITYMARITIME BUSINESS AND
MANAGEMENTDEPARTMENT OF DECK
Mercator Projection
Imagine wrapping a sheet of paper around the
earth, with a light bulb in the center to project
the image of the earths surface. Unwrap the
paper, and you have a mercator projection chart.
5
DOKUZ EYLUL UNIVERSITYMARITIME BUSINESS AND
MANAGEMENTDEPARTMENT OF DECK
Great Circle - A circle formed on the surface
of the earth by the intersection of a
plane passing through the center of the
earth, thereby dividing the earth into two equal
parts.
6
Composite Track 2495 NM
San Diego
Great Circle Route
Rhumb Line 2730 NM
Oahu, HI
7
(No Transcript)
8
1 Deniz Mili (Nautical Miles) 1852,3 metre. 1
Deniz Mili 2000 yarda (Yards) 1 Deniz
Mili 10 gomina (Cables)
1 Fit (Feet) 30,48 cm. 1 Fit 12 Inç
(Inch) 1 Inç (Inch) 2,54 cm. 1 Kulaç
(Fathom) 183 cm. 1 Kulaç 6 Fit
9
Geographical Range
X
Z
Y
10
(No Transcript)
