Connecting the Dots: Using Runtime Paths for Macro Analysis

1
Connecting the DotsUsing Runtime Paths for
Macro Analysis

• Mike Chen
• mikechen_at_cs.berkeley.edu
• http//pinpoint.stanford.edu

2
Motivation

• Divide and conquer, layering, and replication are
  fundamental design principles
• e.g. Internet systems, P2P systems, and sensor
  networks
• Execution context is dispersed throughout the
  system
• gt difficult to monitor and debug
• Lots of existing low-level tools that help with
  debugging individual components, but not a
  collection of them
• Much of the system is in how the components are
  put together
• Observation a widening gap between the systems
  we are building and the tools we have

3
Current Approach
Apache
Apache
Java Bean
Java Bean
Java Bean
Database
Database
4
Current Approach
A1
A2

• Micro analysis tools, like code-level debuggers
  (e.g. gdb) and application logs, offers details
  of each individual component
• Scenario
• A user reports request A1 failed
• You try the same request, A2, but it works fine
• What to do next?

Apache
Apache
Java Bean
Java Bean
Java Bean
Database
Database
5
Macro Analysis

• Macro analysis exploits non-local context to
  improve reliability and performance
• Performance examples Scout, ILP, Magpie
• Statistical view is essential for large, complex
  systems
• Analogy micro analysis allows you to understand
  the details of individual honeybee macro
  analysis is needed to understand how the bees
  interact to keep the beehive functioning

6
Observation

• Systems have a single system-wide execution paths
  associated with each request
• E.g. request/response, one-way messages
• Scout, SEDA, Ninja use paths to specify how to
  service requests
• Our philosophy
• Use only dynamic, observed behavior
• Application-independent techniques

7
Our Approach

• Use runtime paths to connect the dots!
• dynamically captures the interactions and
  dependency between components
• look across many requests to get the overall
  system behavior
• more robust to noise
• Components are only partially known (gray
  boxes)

Apache
Apache
Java Bean
Java Bean
Java Bean
Database
Database
8
Our Approach

• Applicable to a wide range of systems.

9
Open Challenges in Systems Today

• Deducing system structure
• manual approach is error-prone
• static analysis doesnt consider resources
• Detecting application-level failures
• often dont exhibit lower-level symptoms
• Diagnosing failures
• failures may manifest far from the actual faults
• multi-component faults
• Goal reduce time to detection, recovery,
  diagnosis, and repair

10
Talk Outline

• Motivation
• Model and architecture
• Applying macro analysis
• Future directions

11
Runtime Paths

• Instrument code to dynamically trace requests
  through a system at the component level
• record call path the runtime properties
• e.g. components, latency, success/failure, and
  resources used to service each request
• Use statistical analysis detect and diagnose
  problems
• e.g. data mining, machine learning, etc.
• Runtime analysis tells you how the system is
  actually being used, not how it may be used
• Complements existing micro analysis tools

12
Architecture
request

• Tracer
• Tags each request with a unique ID, and carries
  it with the request throughout the system
• Report observations (component name resource
  performance properties) for each component
• Aggregator Repository
• Reconstructs paths and stores them
• Declarative Query Engine
• Supports statistical queries on paths
• Data mining and machine learning routines
• Visualization

Aggregator
Developers/ Operators
Query Engine
Visualization
Path Repository
13
Request Tracing

• Challenge maintaining an ID with each request
  throughout the system
• Tracing is platform-specific but can be
  application-generic and reusable across
  applications
• 2 classes of techniques
• Intra-thread tracing
• Use per-thread context to store request ID (e.g.
  ThreadLocal in Java)
• ID is preserved if the same thread is used to
  service the request
• Inter-thread tracing
• For extensible protocols like HTTP, inject new
  headers that will be preserved (e.g. REQ_ID xx)
• Modify RPC to pass request ID under the cover
• Piggyback onto messages

14
Talk Outline

• Motivation
• Model and architecture
• Applying macro analysis
• Inferring system structure
• Detection application-level failures
• Diagnosing failures
• Future directions

15
Inferring System Structure

• Key idea paths directly capture application
  structure

2 requests
16
Indirect Coupling of Requests

• Key idea paths associate requests with internal
  state
• Trace requests from web server to database
• Parse client-side SQL queries to get sharing of
  db tables
• Straightforward to extend to more fine-grained
  state (e.g. rows)

Database tables
Request types
17
Failure Detection and Diagnose

• Detecting application-level failures
• Key idea paths change under failures gt detect
  failures via path changes.
• Diagnosing failures
• Key idea bad paths touch root cause(s). Find
  common features.

18
Future Directions

• Key idea violation of macro invariants are signs
  of buggy implementation or intrusion
• Message paths in P2P and sensor networks
• a general mechanism to provide visibility into
  the collective behavior of multiple nodes
• micro or static approaches by themselves dont
  work well in dynamic, distributed settings
• e.g. algorithms have upper bounds on the of
  hops
• Although hop count violation can be detected
  locally, paths help identify nodes that route
  messages incorrectly
• e.g. detecting nodes that are slow or corrupt msgs

19
Conclusion

• Macro analysis fills the need when monitoring and
  debugging systems where local context is of
  insufficient use
• Runtime path-based approach dynamically traces
  request paths and statistically infer macro
  properties
• A shared analysis framework that is reusable
  across many systems
• Simplifies the construction of effective tools
  for other systems and the integration with
  recovery techniques like RR
• http//pinpoint.stanford.edu
• Paper includes a commercial example from Tellme!
  (thanks to Anthony Accardi and Mark Verber)

20
Backup Slides
21
Backup Slides
22
Current Approach

• Micro analysis tools, like code-level debuggers
  (e.g. gdb) and application logs, offers details
  of each individual component

Apache
Apache
Java Bean
Java Bean
X 1 Y 2
X 2 Y 4
gdb
Java Bean
Java Bean
Java Bean
Java Bean
Java Bean
X 1 Y 2
X 5 Y 2
X 3 Y 2
Database
Database
Java Bean
Java Bean
X 2 Y 3
X 7 Y 1
23
Related Work

• Commercial request tracing systems
• Announced in 2002, a few months after Pinpoint
  was developed
• PerformaSure and AppAssure focus on performance
  problems.
• IntegriTea captures and playback failure
  conditions.
• Focus on individual requests rather than overall
  behavior, and on recreating the failure
  condition.
• Extensive work in event/alarm correlation, mostly
  in the context of network management (i.e. IP)
• Dont directly capture relationship between
  events
• Rely on human knowledge or use machine learning
  to suppress alarms.
• Distributed debuggers
• PDT, P2D2, TotalView, PRISM, pdbx
• Aggregates views from multiple components, but do
  not capture relationship and interaction between
  components
• Comparative debuggers Wizard, GUARD
• Dependency models
• Most are statically generated and are likely to
  be inconsistent.
• Brown et al. takes an active, black box approach
  but is invasive. Candea et al. dynamically trace
  failures propagation.

24
1. Detecting Failures using Anomaly Detection

• Key idea paths change under failures gt detect
  failures via path changes
• Anomalies
• Unusual paths
• Changes in distribution
• Changes in latency/response time
• Examples
• Error paths are shorter.
• User behavior changes under failures
• Retries a few times then give up
• Implement as long running queries (i.e. diff)
• Challenges
• detecting application-level failures
• comparing sets of paths

25
2. Root-cause Analysis

• Key idea all bad paths touch root cause, find
  common features
• Challenge a small set of known bad paths and a
  large set of maybes
• Ideally want to correlate and rank all
  combinations of feature sets
• E.g. association rules mining
• May get false alarms because the root cause may
  not be one of the features
• Automatic generation of dynamic functional and
  state dependency graphs
• Helps developers and operators understand
  inter-component dependency and inter-request
  dependency
• Input to recovery algorithms that use dependency
  graphs

26
3. Verifying Macro Invariants

• Key idea violations of high-level invariants are
  signs of intrusion or bugs
• Example Peer auditing
• Problem A small number of faulty or malicious
  nodes can bring down the system
• Corruption should be statistically visible in
  your behavior
• look for nodes that delay or corrupt messages or
  route messages incorrectly
• Apply root-cause analysis to locate the
  misbehaving peers
• Some distributed auditing is necessary
• Example P2P implementation verification
• Problem are messages delivered as specified by
  the algorithms?
• Detect extra hops, loops, and verify that the
  paths are correct
• Can implement as a query
• select length from paths where (length gt log2(N))

27
4. Detecting Single Point of Failure

• Key idea paths converge on a single-point of
  failure
• Useful for finding out what to replicate to
  improve availability
• P2P example
• Many P2P systems rely on overlay networks, which
  typically are networks built on top of the IP
  infrastructure.
• Its common for several overlay links to fail
  together if they depend on a shared physical IP
  link that failed
• Implement as a query
• intersect edge.IP_links from paths

A
B
D
E
C
D
F
G
28
5. Monitoring of Sensor Networks

• An emerging area with primitive tools
• Key idea use paths to reconstruct topology and
  membership
• Example
• Membership
• select unique node from paths
• Network topology
• for directed information dissemination
• Challenge limited bandwidth
• Can record a (random) subset of the nodes for
  each path, then statistically reconstruct the
  paths

29
Macro Analysis

• Look across many requests to get the overall
  system behavior
• more robust to noise

Macro Analysis
Request 1 Request 2 Request 3 Request 4
Component A X X X
Component B X
Component C X X
30
Properties of Network Systems

• Web services, P2P systems, and sensor networks
  can have tens of thousands of nodes each running
  many application components
• Continuous adaptation provides high availability,
  but also makes it difficult to reproduce and
  debug errors
• Constant evolution of software and hardware

31
Motivation

• Difficult to understand and debug network systems
• e.g. Clustered Internet systems, P2P systems and
  sensor networks
• Composed of many components
• Systems are becoming larger, more dynamic, and
  more distributed
• Workload is unpredictable and impractical to
  simulate
• Unit testing is necessary but insufficient.
  Components break when used together under real
  workload
• Dont have tools that capture the interactions
  between components and the overall behavior
• Existing debugging tools and application-level
  logs only do micro analysis

32
Macro vs Micro Analysis
Macro Analysis Micro Analysis
Resolution Component. Complements micro analysis tools. Line or variable
Overhead Low. Can use it in actual deployment. High. Typically not used in deployment other than application logs.
33
Whats a dynamic path?

• A dynamic path is the (control flow runtime
  properties) of a request
• Think of it as a stack trace across
  process/machine boundaries with runtime
  properties
• Dynamically constructed by tracing requests
  through a system
• Runtime properties
• Resources (e.g. host, version)
• Performance properties (e.g. latency)
• Arguments (e.g. URL, args, SQL statement)
• Success/failure

request
Path
A
RequestID 1 Seq Num 1 Name A Host xx Latency
10ms Success true ..
A
B
D
C
D
E
E
F
34
Related Work

• Micro debugging tools
• RootCause provides extensible logging of method
  calls and arguments.
• Diduce look for inconsistencies in variable
  usage.
• Complements macro analysis tools.
• Languages for monitoring
• InfoSpect looks for inconsistencies in system
  state using a logic language
• Network flow-based monitoring
• RTFM and Cisco NetFlow classify and record
  network flows
• Statistical and data mining languages
• S, DMQL, WebML

35
Visualization Techniques

• Tainted paths mark all flows that have a certain
  property (e.g. failed or slow) with a distinct
  color and overlay it on the graph
• Detecting performance bottlenecks look for
  replicated nodes that have different colors
• Detecting anomaly look for missing edges and
  unknown paths

36
Pinpoint Framework
Components
Requests
1
2
Communications Layer (Tracing Internal F/D)
3
Detected Faults
Logs
37
Experimental Setup

• Demo app J2EE Pet Store
• e-commerce site w/30 components
• Load generator
• replay trace of browsing
• Approx. TPCW WIPSo load (50 ordering)
• Fault injection parameters
• Trigger faults based on combinations of used
  components
• Inject exceptions, infinite loops, null calls
• 55 tests with single-components faults and
  interaction faults
• 5-min runs of a single client (J2EE server
  limitation)

38
Application Observations

• large number of tightly coupled components that
  are always used together

• of components used in a dynamic web page
  request
• median 14, min 6, max 23

39
Metrics

• Precision C/P
• Recall C/A
• Accuracy whether all actual faults are correctly
  identified (recall 100)
• boolean measure

40
4 Analysis Techniques

• Pinpoint clusters of components that
  statistically correlate with failures
• Detection components where Java exceptions were
  detected
• union across all failed requests
• similar to what an event monitoring system
  outputs
• Intersection intersection of components used in
  failed requests
• Union union of all components used in failed
  requests

41
Results

• Pinpoint has high accuracy with relatively high
  precision

42
Pinpoint Prototype Limitations

• Assumptions
• client requests provide good coverage over
  components and combinations
• requests are autonomous (dont corrupt state and
  cause later requests to fail)
• Currently cant detect the following
• faults that only degrade performance
• faults due to pathological inputs
• Single-node only

43
Current Status

• Simple graph visualization

44
Proposed Research

• 3 classes of large network systems
• Clustered Internet systems
• Tiered architecture, high bandwidth, many
  replicas
• Peer-to-peer (P2P) systems, including sensor
  networks
• Widely distributed nodes, dynamic membership
• Sensor networks
• Limited storage, processing, and bandwidth.

45
P2P Systems Tracing

• Trace messages by piggybacking the current node
  name to the messages
• Tracing overhead
• Assume 32-bit per node name and a very
  conservative log2(N) hops for each msg and
• Data overhead is 40 for a 1500-byte message in a
  106-node system

46
P2P Systems Implementation Verification

• Current debugging techniques lots of printf()s
  on each node and manually correlate the paths
  taken by messages
• How do you know the messages are delivered as
  specified by the algorithms?
• Use message paths to check for routing invariants
• detect extra hops, loops, and verify that the
  paths are correct
• Can implement as a query
• select length from paths where (length gt log2(N))
