Water Use and Management

1
Water Use and Management
2
Outline

• Hydrologic Cycle
• Major Water Compartments
• Water Availability and Use
• Types of Water Use
• Freshwater Shortages
• Depleting Groundwater
• Increasing Water Supplies
• Water Management and Conservation
• Price Mechanisms

3
WATER RESOURCES

• Hydrologic Cycle
• Describes the circulation of water as it
• Evaporates from land, water, and organisms.
  (Transpires from plants.)
• Enters the atmosphere.
• Condenses and precipitates back to the earths
  surfaces.
• Moves underground by infiltration or overland
  runoff into rivers, lakes and seas.

4
Average Annual Precipitation
5
Hydrologic Cycle

• Solar energy drives the hydrologic cycle by
  evaporating surface water.
• Evaporation - Changing liquid to a vapor below
  its boiling point.
• Sublimation - Changing water between solid and
  gaseous states without ever becoming liquid.
• Freezer Burn

6
Hydrologic Cycle

• Humidity - Amount of water vapor in the air.
• Saturation Point - When a volume of air contains
  as much water vapor as it can hold at a given
  temperature.
• Relative Humidity - Amount of water vapor in the
  air expressed as a percentage of the maximum
  amount that can be held at that temperature.

7
Hydrologic Cycle

• Dew Point - Temperature at which condensation
  occurs for a given amount of water.
• Condensation Nuclei - Tiny particles that
  facilitate condensation.
• Smoke, dust, sea salt, spores.

8
Regions of Plenty and Regions of Deficit

• Three principal factors control global water
  deficits and surpluses.
• Global atmospheric circulation
• Prevailing Winds
• Topography

9
Regions of Plenty and Regions of Deficit

• Mountains act as cloud formers and rain catchers.
• Air sweeps up the windward side of a mountain,
  pressure decreases, and the air cools.
• Eventually saturation point is reached, and
  moisture in the air condenses.
• Rain falls on the mountaintop.
• Cool, dry air descends and warms, absorbing
  moisture from other sources. (Rain Shadow)

10
Rain Shadow
11
MAJOR WATER COMPARTMENTS

• Oceans
• Together, oceans contain more than 97 of all
  liquid water in the world.
• Contain 90 of worlds living biomass.
• Moderate earths temperature.
• Average residence time of water in the ocean is
  about 3,000 years.

12
Major Water Compartments

• Glaciers, Ice, and Snow
• 2.4 of worlds water is classified fresh.
• 90 in glaciers, ice caps, and snowfields.
• As recently as 18,000 years ago, one-third of
  continental landmass was covered by glacial ice
  sheets.
• Now, Antarctic glaciers contain nearly 85 of all
  ice in the world.
• Sea ice comes from ocean water, but salt is
  excluded during freezing.

13
Major Water Compartments

• Groundwater
• Second largest reservoir of fresh water.
• Infiltration - Process of water percolating
  through the soil and into fractures and permeable
  rocks.
• Zone of Aeration - Upper soil layers that hold
  both air and water.
• Zone of Saturation - Lower soil layers where all
  spaces are filled with water.
• Water Table - Top of Zone of Saturation.

14
Water Compartments
15
Groundwater

• Aquifers - Porous layers of sand, gravel, or rock
  lying below the water table.
• Artesian - Pressurized aquifer intersects the
  surface. (Water flows without pumping)
• Recharge Zones - Area where water infiltrates
  into an aquifer.
• Recharge rate is often very slow.
• Presently, groundwater is being removed faster
  than it can be replenished in many areas.

16
Groundwater
17
Major Water Compartments

• Rivers and Streams
• Precipitation that does not evaporate or
  infiltrate into the ground runs off the surface,
  back toward the sea.
• Best measure of water volume carried by a river
  is discharge.
• The amount of water that passes a fixed point in
  a given amount of time.
• Usually expressed as cubic feet per second.

18
Major Water Compartments

• Lakes and Ponds
• Ponds are generally considered small bodies of
  water shallow enough for rooted plants to grow
  over most of the bottom.
• Lakes are inland depressions that hold standing
  fresh water year-round.
• Both ponds and lakes will eventually fill with
  sediment, or be emptied by an outlet stream.

19
Major Water Compartments

• Wetlands
• Play a vital role in hydrologic cycle.
• Lush plant growth stabilizes soil and retards
  surface runoff, allowing more aquifer
  infiltration.
• Disturbance reduces natural water-absorbing
  capacity, resulting in floods and erosion in wet
  periods, and less water flow the rest of the year.

20
Major Water Compartments

• The Atmosphere
• Among the smallest water reservoirs.
• Contains lt 0.001 of total water supply.
• Has most rapid turnover rate.
• Provides mechanism for distributing fresh water
  over landmasses and replenishing terrestrial
  reservoirs.

21
WATER AVAILABILITY AND USE

• Renewable Water Supplies
• Made up of surface runoff and infiltration into
  accessible freshwater aquifers.
• About two-thirds of water carried in rivers and
  streams annually occurs in seasonal floods too
  large or violent to be stored effectively for
  human use.
• Readily accessible, renewable supplies are
  400,000 gal /person/year.

22
Drought Cycles

• Every continent has regions of scarce rainfall
  due to topographic effects or wind currents.
• Water shortages have most severe effect in
  semiarid zones where moisture availability is the
  critical factor in plant and animal
  distributions.
• U.S. seems to have 30 year drought cycle.
• Climatic changes such as global warming may alter
  cycles.

23
Types of Water Use

• Withdrawal - Total amount of water taken from a
  source.
• Consumption - Fraction of withdrawn water made
  unavailable for other purposes (Not returned to
  its source).
• Degradation - Change in water quality due to
  contamination making it unsuitable for desired
  use.

24
Types of Water Use

• Many societies have always treated water as an
  inexhaustible resource.
• Natural cleansing and renewing functions of
  hydrologic cycle do not work properly if systems
  are overloaded or damaged.

25
Quantities of Water Used

• Human water use has been increasing about twice
  as fast as population growth over the past
  century.
• Annual renewable water supply in U.S. amounts to
  an average of 2.4 million gallons/person/year.
• Now withdraw one-fifth of this amount.

26
Agricultural Water Use

• Worldwide, agriculture claims about two-thirds of
  total water withdrawal and 85 of consumption.
• In many developing countries, agricultural water
  use is extremely inefficient and highly
  consumptive.
• Drip irrigation is a promising technology.

27
Domestic and Industrial Water Use

• Worldwide, domestic water use accounts for about
  one-fifth of water withdrawals.
• Only about 10 of consumption.
• Grown in proportion with urban populations.
• Industry accounts for 20 of global freshwater
  withdrawals.
• Range from 5 to 70.
• Small proportion is consumed, but degradation is
  a problem.

28
FRESHWATER SHORTAGES

• Estimated 1.5 billion people lack access to an
  adequate supply of drinking water.
• Nearly 3 billion lack acceptable sanitation.
• A country where consumption exceeds more than 20
  of available, renewable supply is considered
  vulnerable to water stress.
• Globally, water supplies are abundant, but, along
  with capital resources, are unevenly distributed.

29
A Precious Resource

• Currently, 45 countries, most in Africa or Middle
  East, are considered to have serious water
  stress, and cannot meet the minimum essential
  water requirements of their citizens.
• More than two-thirds of worlds households have
  to retrieve water from outside the home.
• Sanitation levels decline when water is expensive.

30
Depleting Groundwater

• Groundwater is the source of nearly 40 of fresh
  water in the U.S..
• On a local level, withdrawing water faster than
  it can be replenished leads to a cone of
  depression in the water table,
• On a broader scale, heavy pumping can deplete an
  aquifer.
• Ogallala Aquifer
• Mining non-renewable resource.

31
Depleting Groundwater

• Withdrawing large amounts of groundwater in a
  small area causes porous formations to collapse,
  resulting in subsidence.
• Sinkholes form when an underground channel or
  cavern collapses.
• Saltwater intrusion can occur along coastlines
  where overuse of freshwater reservoirs draws the
  water table low enough to allow saltwater to
  intrude.

32
Sinkholes and Saltwater Intrusion
33
INCREASING WATER SUPPLIES

• Seeding Clouds
• Condensation Nuclei
• Towing Icebergs
• Cost
• Desalination
• Most common methods are distillation and reverse
  osmosis.
• Three to four times more expensive than most
  other sources.

34
Increasing Water Supplies

• Dams, Reservoirs, Canals and Aqueducts
• Common to trap excess water in areas of excess
  and transfer it to areas of deficit.
• Environmental Costs
• Upsets natural balance of water systems.
• Ecosystem Losses
• Loss of wildlife habitat.
• Reservoir Size
• Water Quality

35
Dams, Reservoirs, Canals and Aqueducts

• Displacement of People
• Three Gorges Dams in China is forcing relocation
  of over a million people.
• Evaporation, Leakage, Siltation
• Evaporative losses from Lake Mead and Lake Powell
  on the Colorado River is about 2 billion m3 per
  year.
• Dams slow water flow, allowing silt (nutrients)
  to drop out.
• Loss of Free-Flowing Rivers

36
WATER MANAGEMENT AND CONSERVATION

• Watershed Management
• Watershed - All the land drained by a stream or
  river.
• Retaining vegetation and ground cover helps
  retard rainwater and lessens downstream flooding.
• Additionally, retaining crop residue on fields
  reduces flooding and minimizing plowing and
  forest cutting on steep slopes protects
  watersheds.

37
Domestic Conservation

• Estimates suggest many societies could save as
  much as half of current domestic water usage
  without great sacrifice or serious change in
  lifestyle.
• Largest domestic use is toilet flushing.
• Small volume of waste in large volume of water.
• Significant amounts of water can be reclaimed and
  recycled.
• Purified sewage effluent.

38
Price Mechanisms and Water Policy

• Through most of U.S. history, water policies have
  generally worked against conservation.
• In well-watered eastern states, water policy was
  based on riparian use rights.
• In drier western regions where water is often a
  limiting resource, water law is based primarily
  on prior appropriation rights.
• Fosters Use it or Lose it policies.

39
Price Mechanisms and Water Policy

• In most federal reclamation projects, customers
  were only charged for immediate costs of water
  delivery.
• Dam and distribution system costs were
  subsidized.
• Growing recognition that water is a precious and
  finite resource has changed policies and
  encouraged conservation across the U.S..

40
Price Mechanisms and Water Policy

• Charging a higher proportion of real costs to
  users of public water projects has helped
  encourage conservation.
• In 1999, the Canadian government passed federal
  legislation banning bulk water export.
• Water is too precious to be treated like other
  commodities.

41
Summary

• Hydrologic Cycle
• Major Water Compartments
• Water Availability and Use
• Types of Water Use
• Freshwater Shortages
• Depleting Groundwater
• Increasing Water Supplies
• Water Management and Conservation
• Price Mechanisms

42
(No Transcript)
