Using Constructive Search in Resource Scheduling

1
Using Constructive Search in Resource Scheduling

• By Andrei Missine

2
Overview

• Brief Introduction to Constructive Search
• Running examples
• Basic Terms and Concepts in Resource Scheduling
• Some common propagators
• Disjunctive Constraint
• Edge Finding

3
Overview

• Scheduling Algorithms
• Branching by dynamic release dates
• Branching by assigning generalized precedence
  constraints
• Branching by assigning or delaying start times of
  activities
• Conclusion

4
Brief Intro to Constructive Search

• Complete
• Builds and systematically traverses the search
  tree
• Root node of the tree contains assumptions only
  from the problem statement
• At each node a decision is made

• If a child backtracks to the parent the parent
  considers the next decision
• If there are no more decisions to consider at a
  node, backtrack
• Terminate when backtracking out of the root node

5
Running Examples

• There will be two running examples, one for the
  unit-capacity resource and one for the
  capacitated resource.
• A unit capacity resource is a resource with a
  capacity of exactly 1 unit.
• A capacitated resource is a resource with a
  capacity that is greater than or equal to 1.

6
Running Example - Unit Capacity Resource (1)

• The resource is the classroom
• The activities are the 3 classes
• Class A and class B can start at 1200 and must
  finish by 1400
• Class C can start at 1200 and must finish by
  1600
• Each class runs for an hour
• Find a schedule with the smallest makespan such
  that all classes are scheduled and there are no
  clashes

7
Running Example - Capacitated Resource (2)

• A computer lab with 100 computers is the resource
• Classes are the activities
• Class A and B start at 1200 and must finish by
  1330
• Class C starts at 1200 and must finish by 1400
• Each class requires 50 computers for 1 hour
• Find a schedule with minimal makespan such that
  all classes can use the lab without going over
  the 100 computer limit

8
Resource Scheduling Terms and Concepts

• Time windows an activity must execute in a
  given time window defined by the earliest start
  time and the latest end time
• Generalized precedence constraints impose a
  minimum delay between the start times of A and B

9
Resource Scheduling Terms and Concepts

• EST - Earliest start time of an activity
• LST - Latest start time of an activity
• EET - Earliest end time of an activity
• LET - Latest end time of an activity

• Core execution interval - the time interval when
  the activity must execute, if any
• Makespan - the maximum of the latest end times of
  all activities

10
Resource Scheduling Terms and Concepts

• Distance matrix - an n by n matrix where the
  entry (i, j) is the delay between the start time
  of activity i and the start time of activity j

• Active / Dominating schedule - a schedule such
  that all activities are scheduled as early as
  possible without violating any of the constraints

11
Resource Scheduling Terms and Concepts

• Active / Dominating schedule - a schedule such
  that all activities are scheduled as early as
  possible without violating any of the constraints

12
Common Propagators Disjunctive Constraint

• When two activities combined capacity
  requirement exceeds the resource capacity the two
  activities are in disjunction
• If start time of one activity is fixed then
  propagator can prune the other activitys start
  time domain.

13
Common Propagators Edge-Finding (Baptiste et al,
2003)

• Edge-finding can be applied when resource usage
  of a subset of activities exceeds the resource
  capacity
• Considers activities one by one, trying to prune
  their start times.

• Pruning occurs when it is evident that given any
  feasible assignment of the remainder of the
  subset, the current domain of activity under
  consideration must be pruned.

14
Common Propagators Edge-Finding

• This is done by considering core execution
  intervals and overall resource usage in an
  interval
• Can be costly - O(n2)

15
Disjunctive Propagator versus Edge-Finding

• Edge-finding is overkill in unit-capacity
  resource problems
• Disjunctive propagator can be too weak on general
  capacitated resources

• Edge-finding is expensive - O(n2)
• Disjunctive propagator is cheap - O(1)
• Bottom line - use disjunctive whenever you can
  and edge finding only when necessary (e.g. for
  pre-processing)

16
Propagators applied to the Examples

• For the disjunctive propagator, note that it will
  not deduce any extra info on the capacitated
  example
• Edge-finding is more powerful than disjunctive
  constraint

• For the disjunctive case and example 1, assume
  that class A is already scheduled to start at
  1200
• The propagator can then deduce that B and C must
  start at 1300 or later, and after a second
  iteration that C must start at 1400 or later

17
Propagators applied to the Examples

• For edge-finding and example 2 it is possible to
  deduce that class C cannot start earlier than
  1300 even without any extra information
• The reasoning is because both A and B have a core
  execution interval 1230 - 1300)

• Thus C will not have any computers available if
  it starts any time before 1300
• Applying edge-finding to example 1 we note that
  edge finding will be able to deduce that C must
  start at 1400 or later, even without knowing any
  extra info

18
The Branch-and-Bound idea

• Search for a solution
• Once a solution is found, remember it
• Keep searching
• If it becomes evident at a node that nothing
  below it leads to a solution better than the
  current, backtrack

• In the algorithms that follow the bound is on the
  makespan
• Lower-bound avoids exploring overly optimistic
  branches
• Upper-bound avoids exploring overly pessimistic
  branches
• Good bounds can greatly improve performance

19
Branching by Dynamic Release Dates

• (Fest et al, 1998) introduce the idea of
  branching by selecting a set of activities to
  delay to fix broken resource utilization
  constraints
• Branches are formed by considering possible
  subsets to delay

• Overall structure of the algorithm
• Assign earliest start times to all activities
  such that precedence constraints are met
• Keep delaying activities until resource
  constraint is fixed
• Upon backtracking pick the next delaying
  alternative

20
Branching by Dynamic Release Dates

• The resulting tree is rather bushy because there
  can be exponentially many different subsets to
  consider
• Authors present some ideas how to optimize the
  algorithm
• The overall performance is still rather slow

21
Applying to the Examples

• Consider the unit-capacity case. At root 3
  possible delay subsets A, B, A, C and B, C
• Taking A, B results in backtracking since both
  are delayed to the 1300 - 1400 slot and cannot
  be scheduled

• Taking A, C produces the schedule B (1200), A
  (1300), C (1400)
• Taking B, C produces the schedule A (1200), B
  (1300), C (1400)

22
Applying to Examples

• Now consider the capacitated case. At root the
  possible delay sets are A, B and C
• Delaying A or B leads to immediate
  backtracking (the interval 1300 - 1330 is too
  short for a 1 hour class)
• Delaying C results in the correct schedule
  where A and B start at 1200 and C starts at 1300

23
Branching by Assigning generalized precedence
relationships

• (Brucker et al, 1998) suggest branching by making
  a decision at every node to assign either a
  concurrent or a disjunctive relationship between
  two free activities
• A leaf node in such a tree has all activities
  associated with some precedence relationship

• (Brucker et al, 1998) show that it is possible to
  tell whether or not a solution exists at such a
  leaf node, and if it does to find the active
  schedule
• Note that the branching factor is only 2
• This scheme was shown to be quite good by (Cesta
  et al, 2000)

24
Applying to Examples

• The unit-capacity example is not interesting
  since all activities must be in disjunction
• For the capacitated example the root node
  contains no precedence relationships

• By following the algorithm, the following leafs
  form ( means concurrent, - means disjunctive)
• A B, A C, B C
• A B, A C, B C
• A B, A C, B C
• A B, A C, B C
• A B, A C, B C
• A B, A C, B C
• A B, A C, B C
• A B, A C, B C

25
Applying to Examples

• The last 4 have no solution since A and B cannot
  possibly be in disjunction (because their core
  execution intervals overlap)
• The first one has no solution also since ABC
  exceed the resource capacity

• A B, A C, B - C is a solution B starts at
  1200, A starts at 1215 and C starts at 1300
• Similarly for A B, A - C, B C (A and B are
  reversed)
• A B, A - C, B - C is also a solution A and B
  both start at 1200 and C starts at 1300

26
Branching by Assigning or Delaying Start Times of
Activities

• (Dorndorf et al, 2000) present a branching scheme
  that picks a free activity at each node and
  either assigns it the earliest start time, or
  delays the start time by some amount
• Algorithm makes use of 4 consistency tests

• Precedence consistency test
• Resource consistency test
• Interval-based disjunctive consistency test
• Lag-based disjunctive consistency test
• These tests are applied at each node to further
  prune the search tree

27
Branching by Assigning or Delaying Start Times of
Activities

• Selection of an activity from a subset of free
  activities is done as follows
• Find all activities such that either its earliest
  start time matches its precedence and resource
  feasible start time or it must precede some other
  free activity
• Heuristically pick an activity from this subset

• Delaying of the selected activity
• Look at all activities which share a resource
  with the current activity such that their end
  times are after the current activitys start time
• If there is at least one such activity pick the
  minimal end time of this activity as the delay
• Otherwise delay by one

28
Branching by Assigning or Delaying Start Times of
Activities

• Note that again, the branching factor is only 2
• Unlike the two previous schemes, this scheme does
  not use lower bound on the makespan
• This scheme was shown to be quite good by (Cesta
  et al, 2000)

29
Applying to Examples

• Consider unit-capacity case. Assume that the
  heuristics selects A
• It will first try assigning it to the earliest
  start time
• This will result in pruning B to 1300, 1400)
  and, consequently C to 1400, 1600)

• The algorithm then backtracks and will eventually
  find the solution B, A, C (after selecting B
  first) and no solutions starting with C

30
Applying to Examples

• Now consider the general capacitated example
• The execution is very similar - selecting C as
  the first activity leads to backtracking and
  delaying C since it is impossible to have C start
  at 1200
• Selecting A or B will lead to the 3 solutions
  mentioned above

31
Conclusion

• Propagators the tradeoff between speed versus
  pruning power
• Branch-and-bound and usefulness of good initial
  bounds
• The three branch-and-bound algorithms
• Disadvantages of Constructive Search on large
  problem instances

32
References

• Baptiste Philippe, Claude Le Pape, Nuijten Wim.
  2003. Constraint-Based Scheduling Applying
  Constraint Programming to Scheduling Problems,
  Second Printing. Kluwer Academic Publishers.
• Brucker Peter, Knust Sigrid, Schoo Arno, Thiele
  Olaf. 1998. A branch and bound algorithm for
  the resource-constrained project scheduling
  problem. European Journal of Operations
  Research, 107 (1998) 272-288.

33
References

• Cesta Amedeo, Oddi Angelo, Smith F. Stephen.
  2000. Iterative Flattening A Scalable Method
  for Solving Multi-Capacity Scheduling Problems.
  American Association for Artificial Intelligence,
  2000, pp 742-747.
• Fest Andreas, Möhring Rolf H., Stork Frederik,
  Uetz Marc. 1998. Resource-Constrained Project
  Scheduling with Time Windwos A Branching Scheme
  Based on Dynamic Release Dates. Technical Report
  596, Technische Universit at Berlin.
• Dorndorf Ulrich, Pesch Erwin, Phan-Huy Toàn.
  2000. A Time-Oriented Branch-and-Bound Algorithm
  for Resource-Constrained Project Scheduling with
  Generalised Precedence Constraints. Management
  Science, Vol. 46, No. 10, October 2000, pp.
  1365-1384.
