Weekly Group Meeting 20080710 Title: Programmable Baseband Processors (Chapters 5)

1
Weekly Group Meeting20080710Title
Programmable Baseband Processors (Chapters 5)

• By
• Assad Saleem

2
Radio System Overview

• A typical wireless communication system

3
Digital Baseband Processor

• Transmitter performs
• Channel coding
• Modulation
• Symbol shaping
• sReceiver performs
• Filtering, synchronization, Gain control
• Demodulation, channel estimation, and
  compensation
• Forward error correction

4
Baseband Processing Challenges

• Multipath propogation (Fading)
• Data transported trough air gets effected by the
  surrounding environment
• Multiple propagation paths
• Delayed multi-path signal components add at the
  receiver
• Some freq.s add constructively, other
  destructively
• Thus destroying the original signal
• Causing inter-symbol interference

5
Baseband Processing Challenges

• Timing and Frequency Offset
• Different reference oscillators in the
  transmitter and receiver
• Causing slight discrepancy between the
  transmitter and receiver
• Carrier frequency
• Sample rate
• Uncorrected, limits the useful data rate of a
  system

6
Baseband Processing Challenges

• Mobility
• Fast fading rapid changes of the channel
• Doppler-spread further increases the frequency
  offset

7
Baseband Processing Challenges

• Noise and Burst Interference
• Signal degradation
• Bit errors
• FEC techniques are utilized to increase the
  reliability of the wireless link
• Popular FEC codes and algorithms are the Viterbi
  algorithm used for the Convolutional codes, Turbo
  codes, Reed-Solomon codes
• Interleaving is used to even out bit error and
  burst interference or frequency selective fading

8
Baseband Processing Challenges

• Dynamic Range
• Fading and other surrounding equipment increase
  dynamic range
• A dynamic range of 60-100 dB is not uncommon
• Not practical to design systems with such large
  dynamic range
• Instead AGC circuit are used

9
Baseband Processing Challenges

• Processing Latency
• Baseband processing strict hard real-time
  procedure
• Heavy peak work load for the processor during
  computationally demanding tasks, such as
• Channel decoding
• Channel estimation
• Gain control calculations
• Hardware must be able to handle peak work load
• Even though it occurs less than 1 percent of the
  time

10
Programmable Baseband Processors

• Traditionally fixed function hardware have been
  used, since baseband processing is
  computationally very heavy
• Two disadvantages of fixed function hardware
• Low flexibility
• Short product lifetime
• Whereas programmable solutions need only software
  update

11
Programmable Baseband Processors

• Multimode systems
• A high end cellular telephone will support a
  number of standards such as
• GSM/GPRS, EDGE, UMTS, WLAN, WiMAX, UWB,
  Blutetooth, GPS, DVB-H
• One way is to integrate many separate baseband
  processing modules
• Its drawbacks
• Large silicon area
• Lack of hardware reuse

12
Programmable Baseband Processors

• Dynamic MIPS allocation
• Redistribute the resources dynamically
• Focus on either mobility management or high data
  rate
• During severe fading, we run advanced channel
  tracking and compensation algorithms for reliable
  communication
• In good channels, more resources can be allocated
  to symbol processing for high throughput

13
Programmable Baseband Processors
14
Programmable Baseband Processors

• Hardware multiplexing through programmability
• Most wireless communication schemes use
  multiplexing which can be divided into three
  classes
• OFDM, CDMA, single carrier modulation
• By carefully selecting the functional blocks the
  hardware reuse between different standards can be
  achieved

15
Programmable BasebandProcessors

• Hardware multiplexing on
• LeoCore DSPs

16
Spectrum of an OFDM (orthogonal frequency
division multiplexing) communication system
16 National Instruments, Orthogonal Frequency
Division Multiplexing available at www.ni.com,
2004.
17
Cyclic Prefix Insertion
16 National Instruments, Orthogonal Frequency
Division Multiplexing available at www.ni.com,
2004.
18
OFDM symbol time structure showing insertion of
Cyclic Prefix
4 WiMAX Forum, Mobile WiMAX Part 1  A
Technical Overview and Performance Evaluation,
2006.
19
OFDMProcessing Flow
20
Job overview

• FFT Computation complexity for different
  communication standards

21
Hardware Considerations for Programmable OFDM
Processing

• Flexibility
• Multiple FFT sizes must be supported for
  different standards
• As a bonus, other transforms such as cosine and
  Walsh transforms can also be supported
• Hardware Reuse
• In many cases, it results into a smaller total
  silicon area than a corresponding fixed function
  solution

22
Hardware Considerations for Programmable OFDM
Processing
23
Code Division Multiple Access (CDMA)

• Concurrent transmission in the same spectrum
  using orthogonal spreading codes
• In a CDMA transmitter
• A binary data is mapped onto complex valued
  symbols which are then multiplicated (spread)
  with a code from a set of orthogonal set of codes
• Length of the code is called the spreading factor

24
Code Division Multiple Access (CDMA)

• In a CDMA Receiver
• Data is recovered by calculating a dot product
  (de-spread) between the received data and the
  assigned code
• Dot product will be zero for all other codes
  since the spreading codes are selected from a set
  of orthogonal codes except the assigned code.
• WCDMA
• Can scale the bandwidth of a user by assigning
  multiple spreading codes to that user

25
Job Overview

• Signal processing in WCDMA and HSDPA can be
  divided into
• Chip-rate processing
• Symbol-rate processing
• Chip is one complex element of the spreading code
• Synchronization, channel estimation, channel
  equalization are performed in chip-rate
• Additional channel equalization is performed in
  symbol-rate

26
Job Overview

• Synchronization
• Responsible of finding the start of the data
  frame and identifying the base station parameters
• This is done by correlating the received data
  with 256 chips long synchronization code
• The chip rate of WCDMA/HSDPA is 3.84 MChips/s
• Main operation in the step is complex
  multiplication and accumulation (complex dot
  product)

27
Job Overview

• Channel Equalization
• Two step procedure in WCDMA
• Strongest multi-path components are identified
  (using the data from the synchronizer)
• Components are aligned in time and added
  constructively (using max. ratio combining). This
  is known as a Rake receiver.
• In HSDPA, (which uses up to 16 QAM), additional
  equalization is necessary
• The resulting complex-valued symbols (after
  de-spread) is equalized by a second linear
  equalizer
• It uses training symbols inserted in the middle
  of the data slot (mid-amble)

28
Job Overview
29
Hardware considerations for a WCDMA Processor

• All chip and symbol related operations are
  performed on complex valued data (true for OFDM
  also)
• programmable baseband processor needs to do
  complex efficient computing
• Fairly short symbols with high data rate
• Min loop overhead
• Which means wider execution units for processing
  efficiency
• In WCDMA, HSDPA, and other CDMA systems
• Complex spreading codes have constant envelop
• Therefore, de-spread operation can be performed
  in the complex ALU instead of entirely in a
  complex MAC unit.
• Addressing support for Rake-addressing
• Implemented as function level accelerators in
  memory blocks

30
Multi-standard Processor Design

• A processor architecture suitable for OFDM, CDMA,
  and single carrier based standard is as follows
• Requirements for such a processor
• Efficient instruction set suited for baseband
  processing. Use of both natively complex
  computing and integer computing.
• Efficient hardware reuse through instruction
  level acceleration.
• Wide execution units to increase processing
  parallelism.
• High memory bandwidth to support parallel
  execution.
• Low overhead in processing
• Balance between configurable accelerators and
  execution units.

31
Complex Computing

• Very large part of processing (FFTs,
  frequency/timing offset estimation,
  synchronization, and channel estimation) employ
  convolution based functions.
• Such operations can be performed efficiently in
  DSPs using CMAC unit, optimized memory, bus
  architecture, and addressing modes.
• In baseband processing all operations are
  complex-valued
• Therefore, complex computing should be supported
  throughout the architecture

32
Complex Computing
33
LeoCore Processor Architecture

• Two main parts
• Natively complex part which operates on vectors
  of complex numbers
• Natively integer part which operates on integers
  and single bits

34
LeoCore Processor Architecture

• Two main parts purpose
• Complex part is used to extract soft data symbols
  that can be de-mapped into bits
• Integer part is used for FEC and bit manipulation

35
LeoCore Processor Architecture

• Execution units
• To do complex tasks in an efficient manner
• DSP controller core, multi-lane complex MAC, ALU
  SIMD data-paths
• Execution units range from a CMAC units capable
  of executing a radix-4 FFT butterflies in one
  clock cycle, to complex ALUs used by CDMA based
  standards

36
LeoCore Processor Architecture

• Memory subsystems
• Memory is connected through on-chip network
• The on-chip network allows any memory to be
  connected to any execution unit
• Amount of memory needed is small but the required
  memory bandwidth is very large (several hundred M
  sample/s)
• Whereas each sample consists of two parts (real
  and imaginary)

37
LeoCore Processor Architecture

• It uses vector instructions
• E.g., a single instruction that triggers a
  complete vector operation such as a complex 128
  sample dot-product
• This means that the execution unit must be able
  to process large data chunks without any
  intervention from the processor core
• Which in turn means execution unit and memory
  subsystem to have
• Automatic address generation
• Efficient load/store subsystems
• Therefore, the base architecture utilizes
  de-centralized memories, memory addressing
  together with vector execution units

38
LeoCore Processor Architecture

• HW Acceleration
• Accelerators are also attached to the network
• To improve efficiency function level accelerators
  could be used
• Function level accelerator is a configurable
  piece of hardware which performs a specific task
  without support from the processor core.
• How to decide which functions to accelerate?
  Consider following
• MIPS cost, Reuse, Circuit area (considerable
  reduction of clock frequency and power)

39
LeoCore Processor Architecture

• Typical Accelerators
• Front-end acceleration (filtering/decimation)
• Re-sampling
• Rotor (an NCO and a complex multiplier)
• Packet Detector
• Shaping filter
• Forward Error Correction (FEC)

40
Conclusion

• Multi-standard baseband processing can be
  implemented in a programmable hardware
• Its main features should be
• Support for complex valued computing
• Instruction level acceleration of FFT,
  convolution and similar kernel functions
• Small total memory but with optimized
  architecture meeting
• High bandwidth and real-time requirements
• Function level accelerators for channel coding,
  and general tasks close to ADC/DAC interface

41
Reference

1. M. Ismail, D. Gonzalez Radion Design in
   Nanometer Technologies 2006 Springer

42
Thank You.
