Electronic structure in atoms

1
Electronic structure in atoms

• AH Chemistry, Unit 1(a)

2
(No Transcript)
3

• Bohrs theory cannot explain spectra for atoms
  more complex than hydrogen, which show sub-lines.
• In 1926 Erwin Schrodinger devised a theory to
  describe more complicated atoms quantum
  mechanics.
• This classifies regions of atoms into SHELLS,
  SUB-SHELLS and ORBITALS.

4
Quantum numbers

• Each electron in an atom is described by 4
  different quantum numbers
• n, l, ml, ms
• The first three (n, l and ml) describe an atomic
  orbital where an electron is found
• 3 numbers because three dimensions
• A fourth quantum number describes the spin of an
  electron

5
Quantum Numbers 1 and 2
SHELLS

• 1. PRINCIPAL QUANTUM NUMBER (n) one on
  which energy of an electron principally depends
  orbitals with same n are in same shell also
  determines size of an orbital values 1, 2, 3,

6
Quantum Numbers 1 and 2
SUB-SHELLS
2. ANGULAR MOMENTUM QUANTUM NUMBER (l) energy of
an atom also depends to a small extent on l
distinguishes orbitals of same n by giving them
different shapes any integer value from 0 to
n-1 orbitals of same n but different l are in
different sub-shells
s p d f g
0 1 2 3
4 Example 2p indicates shell 2 (energy),
sub-level p (shape)
7
(No Transcript)
8
(No Transcript)
9

• Werner Heisenberg stated in 1927 that it is
  impossible to know with precision both the
  position and the momentum of an electron.
• The observer affects the observed.
• Only noticeable on the sub-atomic scale (e.g. an
  electron, not a baseball, nor dust).
• It is not possible to define a point in space
  where an electron will be found.
• However, we can obtain the probability of finding
  an electron at a certain point.

10
An area where there is a greater than 90 chance
of finding an electron atomic orbital
11
Quantum Number 3
ORBITALS

• 3. MAGNETIC QUANTUM NUMBER (ml)
  distinguishes orbitals in same shell and subshell
  (i.e. energy and shape) by giving them a
  different orientation in space values -l to l

12
s orbitals
13
p orbitals
14
d orbitals
15
(No Transcript)
16
SHELL
SUB-SHELL
ORBITAL
17
Pauli Exclusion Principle

• No two electrons in any one atom can have the
  same four quantum numbers
• An orbital can hold at most two electrons, and
  then only if the two electrons in that orbital
  have opposite spins

18
Quantum number 4

• 4. SPIN QUANTUM NUMBER (ms) each orbital can
  hold 2 electrons, and each has a different
  direction of spin, -½ and ½

19
(No Transcript)
20
Hunds Rule

• Electrons fill orbitals singly and with parallel
  spins before pairing occurs.

21
(No Transcript)
22
Electronic configurations

• Orbital notation

Spectroscopic notation
Outer electrons, control chemical properties
23
Practise

• Write electronic configurations (obital-box and
  spectroscopic) for
• Helium
• Beryllium
• Oxygen
• Aluminium
• Calcium
• Bromine

24
Aufbau principle

• The Aufbau principle is a building up principle,
  which helps you to write electronic
  configurations
• When electrons are placed in orbitals, the
  energy levels are filled up in order of
  increasing energy

25
Filling orbitals
1s, 2s, 2p, 3s, 3p, 4s, 3d, 4p, 5s, 4d, 5p, 6s,
4f, 5d, 6p, 7s, 5f
26
Energy depends on n and l Different orbitals in
the same sub-shell have the same energy Orbitals
with the same energy are called
degenerate, There is interaction among different
sub-shells in higher energy levels, which lowers
their energy and explains the order of filling.
27
(No Transcript)
