FPGA Defect Tolerance: Impact of Granularity

1
FPGA Defect Tolerance Impact of Granularity

• Anthony Yu Guy Lemieux
• December 14, 2005

2
Outline

• Introduction and motivation
• Previous works
• New architectures
• Coarse-grain redundancy (CGR)
• Fine-grain redundancy (FGR)
• Experimentation Results
• Conclusions

3
Introduction and Motivation

• Scaling introduces new types of defects
• Smaller feature sizes susceptible to smaller
  defects
• Expected results
• Defects per chip increases
• Chip yield declines
• FPGAs are mostly interconnect
• FPGAs must tolerate multiple interconnect defects
  to improve yield (and )

4
General Defect Tolerant Techniques

• Defect-tolerant techniques minimize impact (cost)
  of manufacturing defects
• FPGA defect-tolerance can be loosely categorized
  into three classes
• Software Redundancy use CAD tools to map around
  the defects
• Hardware Redundancy incorporate spare resources
  to assist in defect correction (eg. Spare
  row/column)
• Run-time Redundancy protection against
  transient faults such as SEUs (eg. TMR)

5
Previous work 1 Xilinx

• Xilinxs Defect-Tolerant Approach
• Customer (knowingly) purchases less that
  perfect parts
• Customer gives Xilinx configuration bitstream
• Xilinx tests FPGA devices against bitstream
• Sells FPGA parts that appear perfect
• Defects avoid the bitstream
• Limitation
• Chips work only with given bitstream no changes!

6
Previous work 2 Altera

• Alteras Defect-Tolerant Approach
• Customer purchases seemingly perfect parts
• Make defective resources inaccessible to user
• Coarse-grain architecture
• Spare row and column in array (like memories)
• Defective row/column must be bypassed
• Use the spare row/column instead
• Limitation
• Does not scale well (multiple defects)

7
Objective

• Problem
• FPGA yield is on decline because of aggressive
  technology scaling
• Proposed Solutions
• Defect-tolerance through redundancy
• Important Objectives
• Interconnect defects important (dominates area)
• Tolerate multiple defects (future trend)
• Preserve timing (no timing re-verification)
• Fast correction time (production use)
• Understand the factors that influence yield

8
Background
9
Island-style FPGA
10
Directional Switch Block
11
Directional Switch Block
12
Course-grain Redundancy (CGR)
13
Coarse-grain Redundancy (CGR)
14
Sowhats wrong with it?
15
Improving yield for CGR Adding Multiple Global
Spares

• Add multiple global spare to traditional CGR
• Global spares can be used to repair any defective
  row/column in the array
• Wire extensions are now longer

16
Yield Impact of Multiple Global Spares
17
Increasing AreaDelay Overhead
MORE SPARES ? MORE MUX OVERHEAD IN EVERY SWITCH
ELEMENT
NO SPARES
2 GLOBAL SPARES
4 GLOBAL SPARES MAY BE IMPRACTICAL !!!
1 GLOBAL SPARE
18
Improving yield for CGR Adding Multiple Local
Spares

• Divide FPGA into subdivisions
• Each subdivision has local spare(s)
• Distributes spares across chip
• Reduces mux area overhead(of Global scheme)
• Limitation
• Spare(s) can only repair defect within the
  subdivision

19
Yield Impact of Multiple Local Spares(not as
good as Global with same spares)
20
Fine-grain Redundancy (FGR)
21
Fine-grain Redundancy (FGR) Defect Avoidance by
Shifting
22
Defect-tolerant Switch Block
23
Switch Implementation Options

• Several detailed implementations are possible
• Trade off area / delay / yield(repairability)

24
Minimum Fault-free Radius (MFFR)
25
Experimentation Results

• Switch implementation
• Array size
• Wire length
• Area
• Summary

26
Switch Implementation
Assumes all bridging defects
27
Fixed Array Size (32x32) Global Sparing
28
Fixed Array Size (32x32) Local Sparing
29
Increasing Array Size
30
Yield for Varying Wire Length
31
Estimated Area overhead at equal yield (80)
CGR-G1 can only tolerate 1-2 defects
32
Limitations of Study Architectures

• Logic and power/ground shorts were not considered
• Assumed that all defects are randomly distributed
• Assumed that all defects can be corrected with a
  single row/column
• Switch area was not accounted for our yield model
• Area results for CGR are approximated

33
Conclusions

• CGR is effective for 1 or 2 defects
• FGR meets desired objectives
• Tolerates multiple randomly distributed defects
• Defect correction does not perturb timing
• Tolerates an increasing number of defects as
  array size increases
• Correction can be applied quickly

34
Thank you!

• anthonyy_at_ece.ubc.ca

35
Summary

• As the density of FPGAs increase, they becoming
  in susceptible to manufacturing defects
• Fault-redundant techniques alleviate this growing
  problem
• Depending on the desired level of protection, we
  can apply different techniques
• At low defect rates, the spare row and column
  approach has lower overhead than the fine-grain
  approach
• At large array sizes, the spare row and column
  approach requires more area overhead to tolerate
  the same number of defects as the fine-grain
  approach
