Title: NoC


1
(No Transcript)
2
NoC
  • General concepts
  • Andreas Ehliar - Per Karlström

3
Outline
  • Background
  • Some Implementations
  • Design Issues / Tools
  • Example Application
  • Conclusions

4
Current situation
  • Many transistors
  • Hard to design
  • IP cores
  • Solve design issue
  • Comunication problem
  • BUS TDM
  • Can't handle many nodes

5
Current Situation
6
Current Situation
IP
IP
IP
IP
IP
7
NOC implementations
  • SoCBUS
  • xPipes
  • Pleiades
  • Eclipse
  • (FPGA)

8
SoCBUS
  • Arbitrary topology
  • Packet Connected Circuit (PCC)
  • No need for buffers
  • Payload transfer latency 1cc
  • Mesochronous
  • No asynchronuous bridging
  • Only retiming
  • Timing per link

9
SoCBUS
10
?Pipes
  • Multi-GHz
  • Heterogeneous
  • Packet-switched
  • Parameterizable components
  • Compileable
  • Wormhole switching
  • Street sign routing
  • Error detection
  • Pipelined links

11
?Pipes
12
Pleiades
  • Platform
  • Instantiation Maia processor
  • Hetrogenous FUs
  • ALU
  • Memories
  • FPGAs
  • MACs
  • etc
  • GALS
  • Two level network

13
Pleiades
14
Eclipse
  • Embedded chip level integrated parallel
    supercomputer
  • 2D sparse mesh
  • High bandwidth
  • MTAC processors
  • Multi Threaded Architecture with Chaining
  • Thread Level Parallelism

15
Eclipse
16
FPGA
  • Field Programmable Gate Array
  • Archetype of future NoC
  • Fine grained NoC
  • Homogenous blocks
  • Heterogeneous links

17
FPGA
18
Different NoC
  • Homogenous
  • In function
  • Simplify design and floorplan
  • Heterogeneous
  • In function
  • Better functionality and silicon usage

19
Homogenous NoC
FU
FU
FU
FU
FU
20
Heterogeneous NoC
FU
FU
FU
MUL
DSP
FU
FU
ALU
21
Heterogeneous NoC
DSP
FU
FU
MUL
FU
FU
ALU
22
Quality of Service
  • Guaranteed latency
  • Guaranteed bandwidth
  • Correctness

23
Design Issues
  • Physical layer
  • low swing
  • Differential signaling
  • Pseudo differential signaling
  • Clocks (GALS, Mesochronous)

24
Design Issues - Signaling
V
t
25
Design Issues - Clocking
MEM
ALU
FPGA
DSP
26
Design Issues - Architecture
27
Design Issues - Architecture
28
Design Issues
  • Data-link
  • Error detection/correction
  • Media access control

29
Design Issues- Errors
Cost
Error detection
Error correction
Ne/Np
30
Design Issues
  • Network layer
  • Architecture
  • Hierarchy
  • Switching scheme
  • Packed switched
  • Circuit switched

31
Design Issues
  • Transport layer
  • Connection-oriented/-less
  • Flow control
  • Packet segmentation / reassembly
  • Reordering

32
Design Issues - Flow Control
33
Design Issues - Power Control
  • Application Layer
  • Power management
  • Node/Network centric
  • Power aware API

34
Design Issues - Effect of Design
Silicon
Transistor
Gate
RTL
Architecture
Algorithm
35
Design Issues - Power Control
36
(No Transcript)
37
Design Issues - Long Wires
  • Solving the global interconnect mess
  • Delay
  • Bit errors
  • Repeaters
  • Clock domains
  • Create one optimized solution that can be reused

38
Design Issues - Long Wires
  • Add flip flops to increase clock frequency
  • What about ACKs?

NoC Router
NoC Router
39
Design Issues - Long Wires
  • Add flip flops to increase clock frequency
  • What about ACKs?

NoC Router
NoC Router
What about bit errors?
40
Design Issues - Long Wires
  • Bit errors on long wires will not be avoidable in
    the future
  • Use error correcting codes
  • Disadvantage More wires
  • Use parity bits to discover errors
  • Resend damaged packets
  • No longer possible to guarantee real-time
    performance

41
Design Issues - Long Wires
  • Possibility to create heavily optimized solution
  • Low voltage signaling
  • Advanced symbol encoding/decoding
  • Wave pipelining

42
Design Issues - Long Wires
  • High performance interconnect through wave
    pipelining
  • Need very careful analysis

NoC Router
NoC Router
NoC Router
NoC Router
43
Design Issues - Long Wires
  • Wave pipelining performance
  • 3.45 Ghz signaling on one bit line in 0.25 um
  • More energy efficient than regular pipeline
  • Faster than regular pipeline
  • Disadvantage
  • Much harder to test/verify

44
System design
  • Typical tools
  • Simulator
  • Network generator

45
System design
  • What I would want
  • Graphical frontend to design NoC
  • C and RTL models of the finished NoC
  • C API to create C level models of the NoC
  • Mix C and RTL models in RTL simulator
  • And of course...

46
System design
IP cores
47
Example Core Router
  • SoCBUS Simulation
  • Study of 16 port core router on a chip
  • 16 x 10 Gigabit Ethernet Ports
  • Prove feasibility of using SoCBUS

48
Example Core Router
IPP
FT
PB
CPU
MU
OPP
49
Example Core Router
  • IPP (Input Packet Processor)
  • Receive packet from network
  • Validate Packet/Filter packet
  • Send lookup request to forwarding table
  • Send packet to Packet Buffer
  • FT (Forwarding Table)
  • Get IP address from IPP
  • Perform Lookup and send the output port to the
    packet buffer
  • OPP (Output Packet Processor)
  • Send packet to Network

50
Example Core Router
  • PB (Packet Buffer)
  • Responsible for packet buffering
  • Buffers packets until output port information is
    received from the forwarding table
  • MU (Multicast Unit)
  • Handle multicast packets
  • CPU

51
Example Core Router
  • Data flow for a single packet

Forwarding Table
Output Packet Processor
Packet Buffer
Input Packet Processor
52
Example Core Router
  • Assumptions
  • Each link can transfer 64 bits each clock cycle
  • SoCBUS can be clocked at 1.2 Ghz
  • Packet buffers are large enough

53
Example Core Router
  • Results for Internet Mix packet sizes

54
Example Core Router
  • Results for minimum size packets

55
Example Core Router
  • Network utilization

56
Example Core Router
  • Bottleneck in forwarding table access
  • Current version of SoCBUS creates a virtual
    circuit for each request
  • Proposal Extend SoCBUS
  • Reliable delivery of small (64 bit or less)
    packets without setting up a virtual circuit

57
Example Core Router
  • Conclusion on this application example
  • Initial concept seems to work in simulation
  • Current work
  • Master thesis to test concept in an FPGA

58
Our Reflections
  • Many papers use routers for each connection core
  • Not every IP core has to have a NoC Uplink
  • Probably better to use local shared buses with a
    common NoC Uplink
  • On the Internet, terminals are not connected
    directly to routers
  • Hard to design a network if the traffic is unknown

59
Our Reflections
  • Research on how to improve NoCs can often be used
    to improve non-NoC based designs
  • Communication over long distances
  • Improved crossbars
  • It will be hard to guarantee real-time
    performance on NoCs

60
Conclusions
  • NoC seems to be a reasonable tradeoff
  • Similar to how standard cells make it easier to
    design chips
  • No industry usage (yet?)
  • As yet, no killer application has been
    demonstrated
  • Next level of abstraction
  • IP centric design

61
Questions/Discussion
  • Will future chips have communication patterns
    favoring NoCs?

62
References
  • Networks on chips a new SoC paradigm Benini, L.
    De Micheli, G. Computer , Volume 35 , Issue 1
    , Jan. 2002 Pages70 - 78
  • Powering networks on chips Benini, L. De
    Micheli, G. System Synthesis, 2001. Proceedings.
    The 14th International Symposium on, 30 Sept.-3
    Oct. 2001 Pages33 38
  • Addressing the system-on-a-chip interconnect woes
    through communication-based design Sgroi, M.
    Sheets, M. Mihal, A. Keutzer, K. Malik, S.
    Rabaey, J. Sangiovanni-Vincentelli, A. Design
    Automation Conference, 2001. Proceedings , 18-22
    June 2001 Pages667 - 672
  • On-chip networks a scalable, communication-centri
    c embedded system design paradigm Henkel, J.
    Wolf, W. Chakradhar, S. VLSI Design, 2004.
    Proceedings. 17th International Conference on ,
    2004 Pages845 - 851
  • Design of a Core Router using the SoCBUS On-chip
    Network Jimmy Svensson LiTH-ISY-EX-04/3562-SE
    LiTH

63
References
  • A scalable high-performance computing solution
    for networks on chips Forsell, M. Micro, IEEE ,
    Volume 22 , Issue 5 , Sept.-Oct. 2002 Pages46
    - 55
  • Xpipes a network-on-chip architecture for
    gigascale systems-on-chip Bertozzi, D. Benini,
    L. Circuits and Systems Magazine, IEEE , Volume
    4 , Issue 2 , 2004 Pages18 - 31
  • xpipesCompiler a tool for instantiating
    application specific networks on chip Jalabert,
    A. Murali, S. Benini, L. De Micheli, G.
    Design, Automation and Test in Europe Conference
    and Exhibition, 2004. Proceedings , Volume 2 ,
    16-20 Feb. 2004 Pages884 - 889 Vol.2
  • A wave-pipelined on-chip interconnect structure
    for networks-on-chips Jiang Xu Wayne, W. High
    Performance Interconnects, 2003. Proceedings.
    11th Symposium on, Vol., Iss., 20-22 Aug. 2003
    Pages 10- 14
  • An on-chip network architecture for hard real
    time system Daniel Wiklund LiU-TEK-LIC-200269
    LIU
