Title: MALE REPRODUCTIVE SYSTEM


1
MALE REPRODUCTIVE SYSTEM
2
OBJECTIVES
  • By the end of the lecture, the student should be
    able to
  • List the different components of the male
    reproductive system.
  • Describe the anatomy of the primary the
    secondary sex organs regarding (location,
    function, structure, blood supply lymph
    drainage).
  • Describe the anatomy of the male external genital
    organs.

3
Components Of Male Reproductive System
  • I- Primary Sex Organ
  • Testis.
  • II- Reproductive Tract
  • Epididymis.
  • Vas Deferens.
  • Spermatic cord.
  • III- Accessory Sex Glands
  • Seminal vesicles.
  • Prostate gland.
  • Bulbourethral glands.
  • IV- External Genitalia
  • Penis

4
Scrotum
  • An out pouching of loose skin superficial
    fascia.
  • The Left scrotum is slightly lower than the
    right.
  • Functions
  • Houses Protects the testis
  • Regulates testicular temperature (no superficial
    fat )
  • It has thin skin with sparse hairs and sweat
    glands.
  • The Dartos muscle lies within the superficial
    fascia replaces Scarpas fascia.

T
L
5
Testes
sc
  • Paired almond-shape gonads that suspended in the
    scrotum by the spermatic cord.
  • Its volume is about 20-25 ml.
  • 4 - 5 cm long
  • Weigh (10.5 14 g.).
  • Functions
  • Spermatogenesis.
  • Hormone production
  • (Androgens--testosterone)
  • Testis or Testicle (singular), Testes (plural).

Epididymis
T
6
Coverings Of The Testis
  • Tunica Vaginalis
  • Peritoneal covering, formed of parietal and
    visceral layers.
  • It surrounds testis epididymis.
  • It allows free movement of testis within the
    scrotum.
  • Tunica albugenia
  • It is a whitish fibrous capsule.

TV
7
Internal Structure of The Testis
  • Fibrous septae extend from the capsule, divide
    the testis into a (200-300) -average 250-
    lobules.
  • Each lobule contains, (1-3) seminiferous
    tubules.
  • Seminiferous Tubules (60 cm coiled tubule).
  • They are the site of the spermatogenesis.
  • They form the bulk of testicular tissue.
  • Interstitial cells of Leydig secret Testosterone.
  • Rete testis
  • A network of tubules.
  • It is the site of merging of the Seminiferous
    tubules.

RT
8
Blood Supply of Testis
  • Testicular artery
  • It arises from the abdominal aorta at the level
    of L 3.
  • Venous drainage
  • (Pampiniform plexus of veins.
  • About dozen of veins which forms a network in
    the spermatic cord.
  • They become larger, converge as it approached the
    inguinal canal to form the Testicular vein.
  • Right Vein drains into IVC.
  • Left Vein drains into left renal vein.

Testicular Artery
9
Testicular Lymphatics Follow arteries,
veins End in Lumbar (par aortic) nodes.
Scrotum, Penis and Prepuce Terminate in
Superficial inguinal nodes
10
Indication Evaluation of testicular pain in
case of (Testicular Torsion). Technique
Examiner strokes or pinches the skin in the
upper medial thigh. It causes cremasteric muscle
contraction Observe, rise of the Testicle on
same side (normal) Interpretation Normal It
is present with Epididymitis Absent(
cremasteric reflex) (no Testicle rise) Is
Suggestive of Testicular Torsion. Also absent in
50 of boys under age 30 months. Do not use this
test under age of 30 months. Efficacy. Test
Sensitivity for Testicular Torsion 99 Assumes
age over 30 months Nerve involved Genitofemoral
(GFN), ( L 1, 2) Sensory femoral branch of
(GFN) Ilioinguinal n. Motor Genital branch of
(GFN).
Cremasteric reflex
11
Epididymis
  • A Single coiled tubule
  • 6 Meters long.
  • Located on the superior and posterior margins of
    the testis.
  • It is divided into 3 parts
  • Head, Body and Tail.
  • The Head receives (rete testis) efferent ductules
    from the testis.
  • The Tail is continuous with Vas Deferens.
  • Functions
  • 1. Secretes/absorbs the nourishing fluid.
  • 2. Recycles damaged spermatozoa.
  • 3. Stores spermatozoa Up to 2 weeks to allow for
    maturation.

H
V D
B
T
12
Vas Deferens
  • A muscular tube 45 cm long.
  • Carries sperms from the epididymis to pelvic
    cavity.
  • Passes through the inguinal canal.
  • It crosses the ureter.
  • Its terminal part is dilated to form the Ampulla
    of the vas
  • It joins the duct of the seminal vesicle to form
    ejaculatory duct which opens in the prostatic
    urethra.

13
Accessory Glands
  • Seminal vesicle.
  • Bulbourethral or Coopers glands.
  • Prostate.
  • Functions
  • 1. Secretion of seminal fluid.
  • 2. Nourishing, activation of sperms.
  • 3. Protection of sperms.

14
Seminal Vesicles
VD
BASE OF THE URINARY BLADDER
  • Paired elongated glands.
  • Located posterior inferior to the urinary
    bladder
  • Secrete (60 of Semen)

SV
Prostate
15
Ejaculatory Ducts
  • Formed by the union of the lower end of the vas
    deferens and the duct of the seminal vesicle.
  • Its length is about 2.5cm.
  • The 2 ejaculatory ducts open into the prostatic
    urethra on both sides of the seminal colliculus.
  • They drain the seminal fluid into the prostatic
    urethra.

16
Prostate Gland
  • The Largest male accessory gland.
  • It is a fibromuscular glandular tissue.
  • Walnut sized.
  • Located at the neck of bladder.
  • Traversed by the prostatic urethra.
  • Secretes (20-30 of semen)
  • Shape Conical, It has
  • Base (Superior)
  • Attached to neck of urinary bladder
  • Apex (Inferior), rests on the Urogenital
    diaphragm.
  • Four Surfaces Anterior, posterior and 2 lateral
    (Right Left).
  • It secretes enzymes which has the following
    functions
  • Aid in activating sperm motility
  • Mucus degradation
  • Neutralize female reproductive tract (Alkaline
    fluid )

P
U
P
17
Capsule
  • Internally, it has a dense fibrous capsule
    (prostatic capsule), which is surrounded from
    outside by a fibrous prostatic sheath.
  • The later is continuous with the puboprostatic
    part of the levator ani muscle. (levator
    prostate).
  • In between the prostatic capsule and the
    prostatic facial sheath lies the prostatic venous
    plexus.

18
Relations
UB
  • Anterior
  • Symphysis pubis (SP).
  • Superior
  • Neck of the bladder.
  • Posterior
  • Rectum (important for PR examination)
  • Inferior
  • Urogenital diaphragm, (UGD).
  • Lateral Medial margins of levator ani muscles
    (levator prostate).

R
SP
D
UB
SP
UG
R
UGD
19
Lobes
  • Anatomically
  • It is divided into 5 lobes according to their
    relation to the urethra
  • Anterior (isthmus)
  • Lies anterior to the urethra,
  • It is fibromuscular.
  • Posterior
  • Posterior to the urethra and inferior to the
    ejaculatory ducts.
  • Two lateral
  • On each side of the urethra.
  • Middle (median)
  • Between the urethra and ejaculatory ducts
    closely related to neck of urinary bladder.
  • Usually it projects into lumen of the bladder
    distorting the internal urethral sphincter, after
    the age of 40 years.
  • The median lateral lobes are rich in glandular
    tissue.

20
  • Urologists Sonographers, divide the prostate
    into central (internal) peripheral zones.
  • The central zone is represented by the middle
    lobe.
  • Within each lobe are four lobules, which are
    defined by the ducts and connective tissue

21
Blood Supply Lymph Drainage
  • Arterial Supply
  • Inferior vesical artery from IIA.
  • Prostatic venous plexus
  • Lies between the prostatic fibrous capsule and
    the prostatic sheath.
  • It drains into the internal iliac veins.
  • It is continuous superiorly with the vesical
    venous plexus and posteriorly to the internal
    vertebral venous plexus. Importance?
  • Lymph drainage
  • Internal iliac lymph nodes.

22
Hypertrophy of the Prostate
  • Benign
  • Common after middle age.
  • An enlarged prostate projects into the urinary
    bladder and distorts the prostatic urethra.
  • The middle lobe often enlarges and obstructs the
    internal urethral orifice, this leads to
    nocturia, dysuria and urgency.
  • Malignant
  • It is common after the age of 55
  • The malignant prostate is felt hard irregular
    in Per rectal examination (PR) .
  • The malignant cells metastasize first to internal
    iliac sacral lymph nodes (lymphatic spread)
  • Later to distant nodes , bone brain through
    (IVVP) -venous spread.
  • It can cause obstruction to urine flow because of
    its close relationship to the prostatic urethra.

23
Prostatic Urethra
  • Structures seen on its posterior wall
  • Urethral crest
  • A longitudinal elevated ridge.
  • Prostatic sinus
  • A groove on each side of the crest.
  • The prostatic gland opens into the sinuses.
  • Seminal colliculus a rounded eminence that opens
    into the prostatic utricle.
  • Prostatic utricle
  • A depression on the summit of the urethral crest.
  • The ejaculatory ducts open on the sides of the
    utricle.

24
Bulbourethral or Coopers Gland
  • Small paired glands
  • Located at the base of the penis.
  • Secrete alkaline mucus for
  • Neutralization of urinary acids
  • Lubrication

25
Penis
  • A Copulatory Excretory organ.
  • Excretory
  • Penile urethra transmits urine sperm.
  • Copulatory
  • Has (3) cylindrical masses of erectile tissue
  • Two Corpora Cavernosa
  • One Corpus Spongiosum

CS
CC
26
Corpora Cavernosa
  • Two superior (right left) masses of
  • (Primary erectile tissue).
  • They Provide the majority of rigidity length of
    penis.
  • Their posterior expansions, forms the 2 Crurae
    (anchor tissue) against pelvic bone

27
Corpus Spongiosum
  • The single inferior mass
  • (Secondary erectile tissue)
  • It is traversed by the penile urethra.
  • Its Anterior expansion forms the Glans penis.
  • Its posterior expansion forms the bulb of the
    penis.
  • Prepuce or foreskin
  • Fold of skin covering glans penis (before
    circumcision)

28
THANK YOU GOOD LUCK
