Mobile video reminder to improve medicine compliance of Deaf patients

1
Mobile video reminder to improve medicine
compliance of Deaf patients

• Buhle Bongco
• Supervisor Prof Venter
• Co-Supervisor Prof Tucker

2
Content

1. Recap
2. Implementation
3. Progress
4. Challenges
5. Future work
6. Tools
7. Project Plan
8. Demo
9. QA

3
Recap

• The aim of the project is to help improve
  medicine compliance of Deaf people.
• This application serves as an add on feature on
  SignSupport where the pharmacist has the option
  to set a date and time for the patient to
  consumer their medication with the instructions.

4
Implementation
5
Progress

• Term3

• Term4

• Stand alone video reminder
• Used App Inventor.
• Unable to notify the deaf patient when its the
  right time and instruct at the same time

• Integrated the reminder onto Sign Support.
• Used Android.
• Notifies the deaf patient when it is the right
  time and it comes with a set of instructions to
  follow

6
Challenges

• Allow the pharmacist freedom to change and add
  more or other instructions.
• Getting the notification to still notify even
  when the phone is off.
• Aligning the application to run using the time
  and date of Google calendar.
• Google calendar does not allow for videos, only
  text and audio based.

7
Future Work

• Get the application aligned with Google calendar
• Get the application to notify even if it is off
• Getting the notification to also produce a
  flashing light
• Getting the notification to repeat again if the
  deaf patient did not open notification the first
  time around

8
Tools

• Eclipse Juno for developers
• Java Development Kit (JDK) and Java Runtime
  Environment (JRE)
• Android Developer Tools (ADT)
• Android Virtual Device (AVD)
• Android Real Device(ARD- Samsung S2 in my case)
• Android SDK

9
Project Plan Term 4
Week1 Week2 Week3 Week4 Week5 Week6
Usability testing
Performance testing
Acceptance test
Multi-user testing
Install/uninstall test
Alpha testing
Beta testing
10
Demo

• The pharmacist logs-in on SignSupport
• Checks the patient details if they are correct
• Dispenses medication and the instructions the
  patient should follow.
• The Pharmacist then sets the exact time and date
  the patient should take the medication.
• At the appropriate time the deaf user receives a
  notification with the instructions to follow

11

• Question
• Answers

12
Code

• public class DateAndTimeSelector extends
  Activity
• DatePicker pickerDate// This is the date picker
  used to select the date for our notification
• TimePicker pickerTime// This is the time picker
  used to select the time for our notification
• Button buttonSetAlarm// The set button once
  clicked sets the time and date so that a
  notification is called up
• TextView info// Variable for displaying pieces
  of information
• ImageButton next// Button for moving to the next
  page.
• final static int RQS_1 1
• / Called when the activity is first created.
  /
• _at_Override
• protected void onCreate(Bundle savedInstanceState)


13
Code Continued

• super.onCreate(savedInstanceState)
• setContentView(R.layout.activity_main)// this
  will pull the xml file named activity
• next (ImageButton)findViewById(R.id.imageButton1)
  //imageButton1 id is pulled and will be
  accessible when the next button is pressed.
• info (TextView)findViewById(R.id.info)//text
  is stored as id info and accessible through the
  name info
• pickerDate (DatePicker)findViewById(R.id.pickerd
  ate)// id pickerdate
• pickerTime (TimePicker)findViewById(R.id.pickert
  ime)// id pickertime
• / The button next is pressed it goes to a
  method that performs an action when pressed /
• next.setOnClickListener(new View.OnClickListener()


14
Code continued

• public void onClick(View v)
• //myVib.vibrate(100)
• goNext() // method goNext() is called
• )
• public class AlarmReceiver2 extends
  BroadcastReceiver
• private static final int MY_NOTIFICATION_ID2 2
• Notification myNotification2
• NotificationManager notificationManager2
• _at_Override

15
Code continued

• public void onReceive(Context context, Intent
  intent)
• Toast.makeText(context, "Alarm received!",
  Toast.LENGTH_LONG).show()
• Vibrator vibrator (Vibrator)
  context.getSystemService(Context.VIBRATOR_SERVICE)

• vibrator.vibrate(5000)
• Intent myIntent new Intent(context,
  RefresherViewInstructions.class)
• PendingIntent pendingIntent
  PendingIntent.getActivity(
• context,
• 0,
• myIntent,
• Intent.FLAG_ACTIVITY_NEW_TASK)
• myNotification2 new NotificationCompat.B
  uilder(context)
• .setContentTitle("Notification2!")
• .setContentText("Follow this instructions to take
  the correct medication")
• .setTicker("Notification!")
• .setWhen(System.currentTimeMillis())
• .setContentIntent(pendingIntent)
• .setDefaults(Notification.DEFAULT_SOUND)

16
Code continued

• notificationManager2
• (NotificationManager)context.getSystemService(
  Context.NOTIFICATION_SERVICE)
• notificationManager2.notify(MY_NOTIFICATION_ID
  2, myNotification2)

17
References

• https//github.com/benbahrenburg/benCoding.AlarmM
  anager
• http//www.appsrox.com/android/tutorials/remindme
  /3/8
• http//blog.blundell-apps.com/notification-for-a-
  user-chosen-time/
• http//stackoverflow.com/questions/3226495/androi
  d-exit-application-code
• http//stackoverflow.com/questions/6898770/androi
  d-multiple-alarms-w-pending-intents-how-to-determi
  ne-which-intent-is-b
• http//gitorious.org/0xdroid/packages_apps_alarmcl
  ock/source/185d17974729a98cf48a71ab9f16adaab9d1e1e
  0src/com/android/alarmclock/AlarmClock.java
• http//android-er.blogspot.com/2012/05/to-schedule
  -repeating-alarm-call.html
• www.cs.uwc.ac.za/mmotlhabi
