Chapter 8 Articulations and Movement

1
Chapter 8Articulations and Movement
2
Articulations or Joints

• Articulation or Joint
• Place where two bones come together
• Freely moveable to limited to no apparent
  movement
• Structure correlated with movement

3
Classes of Joints

• Structural Based on major connective tissue type
  that binds bones
• Fibrous
• Cartilaginous
• Synovial
• Functional Based on degree of motion
• Synarthrosis Nonmoveable
• Amphiarthrosis Slightly moveable
• Diarthrosis Freely moveable

4
Fibrous Joints

• Characteristics
• United by fibrous connective tissue
• Have no joint cavity
• Move little or none
• Types
• Sutures
• Syndesmoses
• Gomphoses

5
Syndesmoses

• Bones farther apart than suture and joined by
  ligaments (holds bone to bone)
• Some movement may occur

6
Gomphoses

• Specialized joints
• Pegs that fit into sockets
• Inflammations
• Gingivitis
• Periodontal disease

7
Cartilaginous Joints

• Unite two bones by means of cartilage
• Types
• Synchondroses
• Joined by hyaline
• Little or no movement
• Symphyses
• Fibrocartilage uniting two bones

8
Concept Check

• What is articulation?
• -point of contact b/n two bones
• What type of joint is gomphoses? symphyses?
• -Fibrous Joint in jaw (holds teeth) Fibrous
  Joint
• What is the difference b/n synarthrosis,
  amphiarthrosis, diarthorsis?
• -non-moveable slightly moveable, and freely
  moveable

9
Synovial Joints

• Allow considerable movement
• Most joints that unite bone of appendicular
  skeleton
• Complex
• Articular cartilage and disks
• Joint cavity and capsule
• Synovial membrane and fluid
• Ligments and menisci
• Bursae
• Pockets of synovial fluid reduces friction
• Bursitis

10
Types of Synovial Joints

• Plane or gliding
• Saddle
• Hinge
• Pivot
• Ball-and-socket
• Ellipsoid
• See Table 8.2 pg. 247

11
Types of Synovial Joints

• Uniaxial-movement _at_ 1 axis 1 plane
• Biaxial- 2 perpendicular axis 2 perpendicular
  planes
• Multiaxial- 3 or more axes 3 or more planes

12
Plane and Pivot Joints

• Plane or Gliding Joints
• Monoaxial/Slight Movement
• Example
• Articular processes between vertebrae
  (intervertebral)
• Sacroiliac
• Pivot Joints
• Monoaxial/Rotation
• Example
• Articulation between dens of axis and atlas
• Radius w/ ulna

13
Saddle and Hinge Joints

• Saddle Joints
• Biaxial/Slight Movement
• Example Thumb
• Hinge Joints
• Monoaxial
• Example Elbow, Knee
• Multiaxial
• Example
• Ankle-One predominates

14
Ellipsoid and Ball-and-Socket Joints

• Ellipsoid
• Modified ball-and-socket
• Biaxial
• Example Atlantooccipital Joint
• Ball-and-Socket
• Multiaxial
• Examples Shoulder and Hip joints

15
Types of Movement

• Gliding
• Angular
• Flexion and Extension
• Hyperextension
• Plantar and Dorsiflexion
• Circular
• Rotation
• Pronation and Supination
• Circumduction

16
Flexion and Extension
Posterior/Dorsal
Anterior/Ventral
17
Dorsiflexion and Plantar Flexion
toes
heel
18
Abduction and Adduction
bring together
take away
19
Rotation and Pronation and Supination
face down
lying face up
20
Circumduction
Combination of flexion, extension, abduction,
adduction
21
Special Movements

• Unique to only one or two joints
• Types
• Elevation and Depression
• Protraction and Retraction
• Inversion and Eversion

22
Elevation and Depression
superior
inferior
23
Protraction and Retraction
anterior
posterior
24
Inversion and Eversion
medial
lateral
25
Concept Check

• How are joints classified?
• Structural Degree of movement
• What type of joint makes up most of the
  appendicular skeleton?
• Synovial Joints
• What components make up a synovial joint?
• Synovial membrane, joint cavity, joint capsule,
  articular cartilage, ligaments, tendons, menisci,
  bursae

26
Knee Joint

• Modified hinge joint
• Menisci Fibrocartilage articular disks
• Pad of cartilage b/n bone of a synovial joint
• Cup-shaped for stability cushion guide shock
  absorber
• Cruciate ligaments ACL and PCL
• Collateral ligaments Fibular and tibial

27
Parts of the Knee

• Bones Femur, Patella, Tibia, Fibula
• Muscles Quadriceps, Hamstrings
• Actions Flexion, Extension
• Ligaments
• Anterior Cruciate prevents forward movement of
  tibia (ACL)
• Posterior Cruciate prevents forward movement of
  femur (PCL)
• Lateral Collateral- (Fibula) LCL
• Medial Collateral- (Tibia) MCL
• Tendons Patellar Tendon (Tibia)
• Cartilage (Fibrous Articular Cartilage)
• Medial Meniscus- shock absorber
• Lateral Meniscus- shock absorber

28
Knee Injuries and Disorders

• Football injuries
• Bursitis
• Chondromalacia
• Softening of cartilage
• Hemarthrosis
• Blood accumulation w/n joint cavity
• Acute swollen knee
• Water on the knee
• Slower accumulation of fluid may be caused by
  bursitis

29
Other Knee Disorders

• Osgood Schlatter- patellar tendon pulls away from
  tibia causing fracture new bone growth
• Associated w/ younger athletes
• Unhappy Triad ?- MCL, ACL, Medial Meniscus
• Caused by posterior, lateral blow or hit
• Dislocated Patella- medial forced w/ slightly
  flexed knee
• Patella flips over
• Bucket Handle Tear- meniscus tears piece fills
  in cavity

30
Knee Repair

• Arthroscopy- using tools camera to see inside
  of joint
• Ligament of cartilage repair, doesnt need full
  open exposure to repair
• Arthroplasty- knee replacement
• Diseased or damaged joint

31
Sprains/Strains

• Sprain- ligaments
• Strain- muscle tendons
• 1st Degree- stretch
• 2nd Degree- stretch partial tear
• 3rd Degree- complete tear

32
Joint Disorders

• Arthritis
• Osteoarthritis Wear and tear
• Rheumatoid Caused by transient infection or
  autoimmune disease
• Joint infections
• Lyme disease Bacterial infection Tick vector
• Gout
• Metabolic disorders of unknown cause (idiopathic
  arising spontaneously - cause unknown)

33
Effects of Aging on Joints

• Tissue repair slows
• Production of synovial fluid declines
• Ligaments and tendons become less flexible
• Decrease in ROM (Range of Motion) ?

34
Concept Check

• What is the function of menisci?
• Cup shaped to help with stability, cushion,
  guide the knee
• What is the difference b/n a ligament a tendon?
• Ligaments connect bone to bone Tendons connect
  muscle to bone
• What is the difference b/n arthroplasty
  arthroscopy?
• Arthroscopy using tools/camera to see inside the
  joint Arthoplasty knee replacement
