Statistical Debugging: A Tutorial

1
Statistical Debugging A Tutorial

• Steven C.H. Hoi

Acknowledgement Some slides in this tutorial
were borrowed from Chao Liu at UIUC.
2
Motivations

• Software is full of bugs
• Windows 2000 had about 63,000 known bugs at its
  time of release, 2 bugs per 1000 lines
• A study by the National Institute of Standards
  and Technology showed that software faults cost
  the U.S.economy about 59.5 billion
  annuallyhttp//www.nist.gov/director/prog-ofc/rep
  ort02-3.pdf
• Testing and debugging are laborious and expensive
• 50 of my company employees are testers, and the
  rest spends 50 of their time testing!
• --Bill Gates, in 1995

3
Expedite Debugging

• Manual debugging
• Trace the executions step-by-step.
• Verify observations against expectations
• Automated debugging
• Collect runtime behaviors as the program
  executes.
• Identify bug-relevant points by contrasting the
  correct and incorrect executions
• Best efforts so far bug localization

4
An Example
void subline(char lin, char pat, char sub)
int i, lastm, m lastm -1 i 0
while((lini ! ENDSTR)) m amatch(lin, i,
pat, 0) if (m gt 0) putsub(lin, i, m,
sub) lastm m if ((m -1)
(m i)) fputc(lini, stdout) i
i 1 else i m
void subline(char lin, char pat, char
sub) int i, lastm, m lastm -1
i 0 while((lini ! ENDSTR)) m
amatch(lin, i, pat, 0) if ((m gt 0) (lastm
! m) ) putsub(lin, i, m, sub) lastm
m if ((m -1) (m i))
fputc(lini, stdout) i i 1 else
i m

• Symptoms
• 563 lines of C code
• 130 out of 5542 test cases fail to give correct
  outputs
• No crashes
• Conventional debugging
• Few hints
• Step-by-step tracing
• Better method
• Pinpoint the buggy line

5
Review of Recent Work

• SOBER Algorithm
• Cause Transition Algorithm
• Statistical Debugging Liblit05
• Statistical Debugging Simultaneous
  Identification of Multiple Bugs

6
SOBER Statistical Model-based Bug Localization

• Program Predicates
• Predicate Rankings
• Experimental Results

7
Program Predicates

• A predicate is a proposition about any program
  properties
• e.g., idx lt BUFSIZE, a b c, foo() gt 0
• Each can be evaluated multiple times during one
  execution
• Every evaluation gives either true or false
• Therefore, a predicate is simply a boolean random
  variable, which encodes program executions from a
  particular aspect.

8
Evaluation Bias of Predicate P

• Evaluation bias
• Defn the probability of being evaluated as true
  within one execution
• Maximum likelihood estimation Number of true
  evaluations over the total number of evaluations
  in one run
• Each run gives one observation of evaluation bias
  for predicate P
• Suppose we have n correct and m incorrect
  executions, for any predicate P, we end up with
• An observation sequence for correct runs
• S_p (X_1, X_2, , X_n)
• An observation sequence for incorrect runs
• S_f (X_1, X_2, , X_m)
• Can we infer whether P is suspicious based on S_p
  and S_f?

9
Underlying Populations

• Imagine the underlying distribution of evaluation
  bias for correct and incorrect executions are
  and
• S_p and S_f can be viewed as a random sample from
  the underlying populations respectively
• One major heuristic is
• The larger the divergence between and
  , the more relevant the predicate P is to
  the bug

10
Major Challenges

• No knowledge of the closed forms of both
  distributions
• Usually, we do not have sufficient incorrect
  executions to estimate
  reliably.

11
SOBERs Approach
12
Algorithm Outputs

• A ranked list of program predicates w.r.t. the
  bug relevance score s(P)
• Higher-ranked predicates are regarded more
  relevant to the bug
• Whats the use?
• Top-ranked predicates suggest the possible buggy
  regions
• Several predicates may point to the same region

13
Cause Transition (CT)

• Locating Causes of Program Failures, Cleve et
  al., published in ICSE05, May 15, 2005
• A variant of delta debugging Z02
• Previous state-of-the-art performance holder on
  Siemens suite
• Cons it relies on memory abnormality, hence its
  performance is restricted.

14
Statistical Debugging Liblit05

• Scalable Statistical bug isolation, Liblit et
  al., published in PLDI05, June 12, 2005
• Main idea rank predicates according to their
  correlation with program crashes

15
Statistical Debugging Liblit05

• Context (P) Pr(Crash P observed)
• Failure (P) Pr(Crash P observed as true)
• The probability difference
• Increase (P) Failure (P) Context (P)
• Limitation Ignores evaluation patterns of
  predicates within each execution

16
Experiment Results

• Localization quality metric
• Software bug benchmark
• Quantitative metric
• Related works
• Cause Transition (CT), CZ05
• Statistical Debugging, LN05
• Performance comparisons

17
Bug Benchmark

• Bug benchmark
• Dreaming benchmark
• Large number of known bugs on large-scale
  programs with adequate test suite
• Siemens Program Suite
• 130 variants of 7 subject programs, each of
  100-600 LOC
• 130 known bugs in total
• mainly logic (or semantic) bugs
• Advantages
• Known bugs, thus judgments are objective
• Large number of bugs, thus comparative study is
  statistically significant.
• Disadvantages
• Small-scaled subject programs
• State-of-the-art performance, so far claimed in
  literature,
• Cause-transition approach, CZ05

18
Localization Quality Metric RR03
19
1st Example
1
10
2
6
3
5
4
7
9
8
T-score 70
20
2nd Example
1
10
2
6
3
5
7
4
9
8
T-score 20
21
Localized bugs w.r.t. Examined Code
22
Cumulative Effects w.r.t. Code Examination
23
Top-k Selection

• Regardless of specific selection of k, both
  Liblit05 and SOBER are better than CT, the
  current state-of-the-art holder
• From k2 to 10, SOBER is better than Liblit05
  consistently

24
Conclusion and Discussion

• A tutorial on statistical debugging
• Discussion on Future Work
• Better Statistical Models
• Identification of Multiple Bugs
• Robust to Sampling
