MPR-Aware Performance Improvement for Inter-Domain Routing in MANETs

1
MPR-Aware Performance Improvement for
Inter-Domain Routing in MANETs
You Lu, Yenan Lin, Biao Zhou, Mario Gerla UCLA
2
Outline

• Introduction Previous Work
• New features
• Dynamic TDMA
• MPR-aware Slot Allocation for OLSR
• MPR-aware Gateway selection
• Simulation Results
• Throughput increased efficiency
• Reduced Control Overhead
• Conclusions

3
Previous Work

• Inter-Domain Routing for MANETs
• Group Mobility
• One Cluster head per Group
• Cluster heads periodically advertise member list
• Advertisements propagate via dissemination

A
LISTA
B
LISTB
4
Previous Work

• TDMA domain is the bottleneck
• Inefficient slot usage
• Three categories of TDMA
• Static TDMA
• Cluster TDMA
• Dynamic TDMA

5
Our Approach DTDMA
Slot Allocation for Node 1 contention area
6
DTDMA with OLSR MPR

• DTDMA performance much better than STDMA
• Same slot reused in different contention areas
• However
• Can we further improve performance?
• Yes, if OLSR is used in the TDMA domain
• Key idea assign multiple slots to popular
  nodes, such as Multipoint Relay Nodes (MPR)

7
OLSR Multi Point Relays
8
New Feature multiple slots for MPRs

• MPR-aware slot allocation
• MPR nodes get more slots than regular nodes
• Motivation MPRs form the backbone
• They are the nodes that do most store and
  forwarding
• MPRS MPR Selector, the node that selects that
  MPR
• The more Selectors, the more popular the MPR


9
DTDMA MPR Selectors
MPRS
MPRS
MPR
MPRS
MPRS
Selectors for MPR in node 3
10
More on MPR

• MPR- aware Gateway selection
• - Can further improve performance by selecting
  as Gateway a popular MPR Node
• - Assign candidate Gateways the WEIGHT

11
Performance Evaluation

• Simulator Qualnet 5.0.2
• Data traffic CBR, pkt size 512 byte
• Geographic area 2000m 2000m
• Mobility model RPGM
• In each domain the Reference Point moves
  randomly. All nodes in the domain move around the
  RP
• intra-group speed 0-5m/s
• pause time is 10 seconds
• MAC protocols CSMA TDMA
• Routing protocols AODV OLSR
• Metrics
• Average Receiver Throughput Normalized Control
  Overhead

12
Average Delivered Throughput
The larger the density, the larger the frame for
the Contention set gt the lower the throughput
13
Normalized Control Overhead
14
Conclusion

• Dynamic TDMA OLSR
• MPR-aware Slot Allocation
• MPR-aware Gateway Selection
• We get
• Throughput improvement
• Reduced Control Overhead

15
Thanks

• Q A
