Workbook 7 Standard I/O and Pipes

1
Workbook 7Standard I/O and Pipes
Pace Center for Business and Technology
2
Standard I/O and Pipes

• Key Concepts
• Terminal based programs tend to read information
  from one source, and write information to one
  destination.
• The source programs read from is referred to as
  Standard In (stdin), and is usually connected to
  a terminal's keyboard.
• The destination programs write to is referred to
  as Standard Out (stdout), and is usually
  connected to a terminal's display.
• When using the bash shell, stdout can be
  redirected using gt or gtgt, and stdin can be
  redirected using lt.

3
Three types of programs

• How you can redirect where input is read from and
  where output goes. The output of one command can
  be used as the input for another command,
  allowing simple commands to be used together to
  perform more complicated tasks.
• Three types of programs
• In Linux (and Unix), programs can generally be
  grouped into the following three designs.
• Graphical Programs
• Graphical programs are designed to run in the X
  graphical environment. They expect the user to be
  using a mouse, and use common graphical
  components, such as popup menus and buttons, for
  user input. The mozilla web browser is an example
  of a graphical program.
• Screen Programs
• Screen based programs expect to use a text
  console. They make use of the entire display, and
  handle text placement and screen redraws in
  sophisticated ways. They do not require a mouse,
  and are appropriate for terminals and virtual
  consoles. The vi and nano text editors, and links
  web browser, are examples of screen based
  programs.
• Terminal Programs
• Terminal programs collect input and display
  output in a stream, seldom if ever redrawing the
  screen, as if writing directly to a printer that
  does not allow the cursor to move back up the
  page. Because of their simplicity, terminal based
  programs are often called simply commands. ls,
  grep, and useradd are examples of terminal based
  programs.
• This chapter focuses on the latter type of
  program. Do not let the simplicity of the way
  these commands receive input and output fool you.
  You will find that many of these commands are
  very sophisticated, and allow you to use the
  command line interface in powerful ways.

4
Standard in (stdin) and Standard out (stdout)

• Terminal based programs generally read
  information as stream from a single source, such
  as a terminal's keyboard. Likewise, they
  generally write information as a steam to a
  single destination, such as a display. In Linux
  (and Unix), the input stream is referred to as
  Standard In (usually abbreviated stdin), and the
  output stream is referred to as Standard Out
  (usually abbreviated stdout).
• Usually, stdin and stdout are connected to the
  terminal that runs the command. Sometimes, in
  order to automate commonly repeated commands, or
  in order to record the output of a command for
  later inclusion in a report or email, people find
  it convenient to redirect stdin from or stdout
  into files.

5
Redirecting stdout

• Writing Output to a File
• When a terminal based program generates output,
  it generally writes that output to its stdout
  stream, without knowing what is connected to the
  receiving end of that stream. Usually, the stdout
  stream is connected to the terminal that started
  the process, so the output is written to the
  terminal's display. The bash shell uses gt to
  redirect a process's stdout stream to a file.
• For example, suppose the machine elvis is using
  becomes very sluggish and non-responsive. In
  order to diagnose the problem, elvis would like
  to examine the currently running processes.
  Because the machine is so sluggish, however, he
  wants to collect the information now, but analyze
  it later. He can redirect the output of the ps
  aux command into the file sluggish.txt, and come
  back to examine the file when the machine is more
  responsive.

6
Redirecting stdout

• Notice that no output is displayed to the
  terminal. The ps command writes to stdout, as it
  always does, but stdout is redirected by the bash
  shell to the file sluggish.txt. The user elvis
  can examine the file later, at a more convenient
  time.

7
Appending Output to a File

• If the file sluggish.txt already existed, its
  original contents would be lost. This is often
  referred to as clobbering a file. To append a
  command's output to a file, rather than
  clobbering it, bash uses gtgt.
• Suppose that elvis wanted to record a timestamp
  of when the sluggish behavior was happening, as
  well as a list of currently running processes. He
  could first create (or clobber) the file with the
  output of the date command, using gt, and then
  append to it the output of the ps aux command
  using gtgt.

8
Redirecting stdin

• Just as bash uses gt to coax commands into
  delivering their output somewhere other than the
  display, bash uses lt to cause them to read input
  from somewhere other than the keyboard. The user
  elvis is still trying to figure out why his
  machine was acting sluggish. He talked to his
  local system administrator, who thought that
  looking at the list of currently running
  processes sounded like a good idea, and asked
  elvis to mail him a copy.
• Using the terminal based mail command, elvis
  first writes an email message to the
  administrator "manually", from the keyboard. The
  mail command expects a recipient as an argument,
  and the subject line can be specified with the -s
  command line switch. The email body is then
  entered from the keyboard. The end of the message
  text is signaled by a lone period on a line.

9
Redirecting stdin

• For his follow-up message, elvis can easily mail
  the output of the ps command he recorded in the
  file sluggish.txt. He just redirects the mail
  command's stdin stream to be read from the file.
• The system administrator will receive an email
  from elvis, with "ps output" as it's subject
  line, and the contents of the file sluggish.txt
  as its body.
• In the first case, the mail process's stdin was
  connected to the terminal, and the message body
  was provided by the keyboard. In the second case,
  bash arranged for the mail process's stdin to be
  connected to the file sluggish.txt, and the
  message body was provided by its contents. The
  mail command doesn't change its basic behavior
  It reads the body of the email message from
  stdin. 8

10
Under the Hood Open Files and File Descriptors

• Open Files and File Descriptors
• To fully appreciate how processes manage Standard
  In, Standard Out, and files, we must introduce
  the concept of a file descriptor. In order to
  read information from or write information to a
  file, a process must open the file. Linux (and
  Unix) processes keep track of the files they
  currently have open by assigning each an integer.
  The integer is called a file descriptor.
• The Linux kernel provides an easy way to examine
  the open files and file descriptors of a
  currently running process, using the /proc file
  system. Every process has an associated
  subdirectory under /proc, named after its PID
  (process ID). The process's subdirectory in turn
  has a subdirectory called fd (for file
  descritptor). Within the /proc/pid/fd
  subdirectory, a symbolic links exists for every
  file the process has open. The name of the
  symbolic link is the open file's integer file
  descriptor, and the symbolic link resolves to the
  open file itself.
• In the following, elvis cats the file
  /usr/share/hwdata/oui.txt, and then almost
  immediately suspends the program with a CTRLZ.

11
Under the Hood Open Files and File Descriptors

• Using the ps command to look up the process's
  PID, elvis next examines the process's
  /proc/pid/fd directory.
• Not surprisingly, the cat process has the file
  /usr/share/hwdata/oui.txt open (it must be able
  to read the file to display its contents).
  Perhaps a little surprising, it is not the only,
  or even the first, file that the process has
  open. The cat command has three open files before
  it, or, more exactly, the same file open three
  times /dev/tty1.

12
Under the Hood Open Files and File Descriptors

• As a Linux (and Unix) convention, every process
  inherits three open files upon startup. The
  first, file descriptor 0, is Standard In. The
  second, file descriptor 1, is Standard Out, and
  the third, file descriptor 2, is Standard Error
  (to be discussed in the next Lesson). What open
  files did the cat command inherit from the bash
  shell that started it? The device node /dev/tty1
  for all three.
• Recall that /dev/tty1 is the device node which
  connects to the console serial driver within the
  kernel. Whatever elvis types can be read from
  this file, and whatever is written to this file
  is displayed on elvis's terminal. What happens if
  the cat process reads from stdin? It reads input
  from elvis's keyboard. What happens if it writes
  to stdout? Whatever is written is displayed on
  elvis's terminal.

13
Redirection

• In the next example, elvis cat's the
  /usr/share/hwdata/oui.txt file, but this time
  redirects stdout to the file /tmp/foo. Again,
  elvis suspends the command in mid-stride with the
  CTRLZ control sequence.
• Using the same technique as above, elvis examines
  the files opened by the cat command, and the file
  descriptors associated with them.

14
What happens when elvis redirects both Standard
Out and Standard In?

• What happens when elvis redirects both Standard
  Out and Standard In?

15
What happens when elvis redirects both Standard
Out and Standard In?

• When the cat command is called without arguments
  (i.e., without any filenames of files to
  display), it displays Standard In instead. Rather
  than opening a specified file (using file
  descriptor 3, as above), the cat command reads
  from stdin instead.
• What is the effective difference between the
  following three commands?
• There is none. In order to appreciate the real
  benefit of designing commands to read from
  Standard In in lieu of named files, we must wait
  until pipes are introduced in a subsequent
  Lesson.

16
ExamplesChapter 1.  Standard In and Standard Out

• Automating Graph Generation with gnuplot
• About 20 minutes
• http//csis.pace.edu/adelgado/rha-030/scripts/work
  book-07/chapter-1/Gnuplot-lab.htm

17
Chapter 2.  Standard Error

• Key Concepts
• Unix programs commonly report error conditions to
  a destination called Standard Error (stderr).
• Usually, stderr is connected to a terminal's
  display, and error messages are found intermixed
  with standard output.
• When using the bash shell, the stderr stream can
  be redirected to a file using 2gt.
• When using bash, the stderr stream can be
  combined with stdout stream using 2gt1 or gt

18
Standard Error (stderr)

• We have discussed the standard input and output
  streams, stdin and stdout, and how to use gt and lt
  in the bash command line to redirect them. We are
  now ready to confuse matters a little by
  introducing a second output stream, commonly used
  for reporting error conditions, called Standard
  Error (often abbreviated stderr).

19
Standard Error (stderr)

• In the following sequence, elvis is using the
  head -1 command to generate a list of the first
  lines of all the files in the /etc/rc.d
  directory.

20
Standard Error (stderr)

• The head command, when fed multiple file names as
  arguments, conveniently decorates the name of the
  file, followed by the first specified number of
  lines (in this case, one). When the head command
  encounters a directory, however, it merely
  complains. Next, elvis runs the same command,
  redirecting stdout to the file rcsummary.out.
• Most of the output is obediently redirected to
  the file rcsummary.out, but the directory
  complaints are still displayed. Although not
  obvious at the outset, the head command is really
  sending output to two independent streams. Normal
  output is written to Standard Out, but error
  message are written to a separate stream called
  Standard Error (often abbreviated stderr).
  Usually, both streams are connected to the
  terminal, and so the two are difficult to
  distinguish. By redirecting stdout, however, the
  information written to stderr is obvious.

21
Redirecting stderr

• Just as bash uses gt to redirect stdout, bash uses
  2gt to redirect stderr. For example, elvis repeats
  the head command from above, but instead of
  redirecting stdout to rcsummary.out, he redirects
  stderr to the file rcsummary.err.

22
Redirecting stderr

• The output is the complement to the previous
  example. We now see the normal output displayed
  to the screen, but no error messages. Where did
  the error messages go? It shouldn't be hard to
  guess.
• In the following example, both gt and 2gt are used
  to redirect stdout and stderr independently.
• In this case, the standard output can be found in
  the file rcsummary.out, error messages can be
  found in rcsummary.err, and nothing is left over
  to be displayed to the screen.

23
Combining stdout and stderr Old School

• Often, someone would like to redirect the
  combined stdout and stderr streams to a single
  file. As a first attempt, elvis tries the
  following command.
• Upon examining the file rcsummary.both, however,
  elvis doesn't find what he expects.

24
Combining stdout and stderr Old School

• The bash shell opened the file rcsummary.both
  twice, but treated each open file independently.
  When stdout and stderr both wrote to the file,
  they clobbered each other's information. What is
  needed instead is some way to tell bash to
  effectively combine stderr and stdout into a
  single stream, and then redirect that stream to a
  single file. As you would expect, there is such a
  way.
• Although awkward, the last token 2gt1 should be
  thought of as saying "take stderr, and send it
  wherever stdout is currently going". Now
  rcsummary.both contains the expected output.

25
Combining stdout and stderr New School

• Using 2gt1 to combine stdout and stderr was
  introduced in the original Unix shell, the Bourne
  shell (sh). Because bash is designed to be
  backwards compatible with sh, it supports the
  syntax as well. The syntax, however, is
  inconvenient. Besides being difficult to write,
  the order of the redirections is important. Using
  "gtout.txt 2gt1" and "2gt1 gtout.txt" does not have
  the same effect!
• In order to simplify things, bash uses gt to
  combine both stdin and stdout, as in the
  following example.
• Summary
• The following table summarizes the syntax used by
  the bash shell for redirecting stdin, stdout, and
  stderr learned in this and the previous lesson.

26
ExamplesChapter 2.  Standard Error

• Using /dev/null to filter out stderr
• The user elvis is has recently learned that,
  besides the /home/elvis and /tmp directories he's
  familiar with, he may also own files in the /var
  directory. These files are usually spooling files
  for received but not yet viewed email, print jobs
  waiting to be sent to the printer, etc.
• Curious, he uses the find command to find all
  files within the /var directory that he owns.

27
ExamplesChapter 2.  Standard Error

• Although the find command appropriately reported
  the /var/spool/mail/elvis file, the output is
  difficult to find among all of the "Permission
  denied" error messages being reported from
  various subdirectories of /var. In order to help
  separate the wheat from the chaff, elvis
  redirects stderr to some file in the /tmp
  directory.
• While this works, elvis is left with a file
  called /tmp/foo that he really didn't want. In
  situations like this, when a user wants to
  discard a stream of information, experienced Unix
  users usually redirect output to a pseudo device
  called /dev/null.
• As the following long listing shows, /dev/null is
  a character device node, like those used for
  conventional device drivers.
• When a user writes to /dev/null, the information
  is merely discarded by the kernel. When a user
  reads from /dev/null, they encounter an immediate
  end of file. Notice that /dev/null is one of the
  few files in Red Hat Enterprise Linux that has
  world writable permissions by default.

28
QuestionsChapter 2.  Standard Error

• 1 and 2

29
Chapter 3.  PipesPart Workbook 7.  Standard I/O
and Pipes

• Key Concepts
• The stdout stream from one process can be
  connected to the stdin stream of another process,
  using what Unix calls a "pipe".
• Many commands in Unix are designed to operate as
  a filter, reading input from stdin and sending
  output to stdout.
• bash uses "" to create a pipe between two
  commands.

30
Pipes

• Pipes
• In the previous Lessons, we have seen that a
  process's output can be redirected to somewhere
  other than the terminal display, or that a
  process can be asked to read input from some
  location other than the terminal keyboard. One of
  the most common, and most powerful, forms of
  redirection is a combination of the two, where
  the output (Standard Out) of one command is
  "piped" directly into the input (Standard In) of
  another command, forming what Linux (and Unix)
  refers to as a pipe.
• When two commands are joined by a pipe, the
  stdout stream of the first process is tied
  directly to the stdin sequence of the second
  process, so that multiple processes can be
  combined in a sequence. In order to create a pipe
  using bash, the two commands are joined with a
  vertical bar . (On most keyboards, this
  character is found on the same key as the
  backslash, above the RETURN key.) All processes
  that are joined in a pipe are referred to as a
  process group.

31
Pipes

• As an example, consider prince, who is trying to
  find the largest files underneath the /etc
  directory. He begins by composing a find command
  that will list all file with a size greater than
  100Kbytes.
• Observing that the find command seems to list the
  files in no particular order, prince decides he
  would like the files to be listed alphabetically.
  He could redirect the output to a file, and then
  sort the file. Instead, he takes advantage of the
  fact that the sort command, when invoked without
  arguments, looks to Standard In for the data to
  sort. He pipes the output of his find command
  into sort.
• The files are now listed in alphabetical order.

32
Filtering output using grep

• The traditional Unix grep command is commonly
  used in pipes to reduce data to only the
  "interesting" parts. The grep command will be
  discussed in detail in a later Workbook. Here, we
  introduce grep in its simplest form.
• The grep command is used to search for and
  extract lines which contain a specified string of
  text. For example, in the following, prince
  prints all lines that contain the text "root"
  from the /etc/passwd file.
• The first argument to the grep command is the
  string of text to be searched for, and any
  remaining arguments are files to be searched for
  the text. If the grep command is called with only
  one argument (a string to be searched for, but no
  files to search), it looks to Standard In as its
  source of data on which to operate.

33
Filtering output using grep

• In the following, prince has so many files in his
  home directory that he is having trouble keeping
  track of them. He's trying to find a directory
  called templates that he created a few months
  ago. He uses the locate command to help him find
  it.
• Unfortunately for prince, there are many files
  which contain the text templates in their name on
  the system, and prince becomes overwhelmed with
  lines and lines of output. In order to reduce the
  information to more relevant files, prince next
  takes stdout from the locate command, and creates
  a pipe to stdin of the grep command, "grepping"
  for the word "prince".
• Because the grep command is not given a file to
  search, it looks to stdin, where it finds the
  stdout stream of the locate command. Filtering
  the stream, grep only duplicates to its stdout
  lines that matched the specified text, "prince".
  The rest were discarded. The user prince easily
  finds his directory under /proj, as well as
  another directory created by the application
  quanta.

34
Pipes and stderr

• In the next example, prince is curious to see
  where he shows up in the system's configuration
  files, and "greps" for his name in the /etc
  directory.

35
Pipes and stderr

• Again, prince is overwhelmed by the amount of
  output from this command. He tries the same
  trick, "grepping" it down for all lines that
  contain the word "passwd".
• While stdout from the first grep command was
  appropriately filtered, stderr is unaffected, and
  still gets displayed to the screen. How would
  prince go about suppressing stderr as well?
• Commands as filters
• The concept of a pipe extends naturally, so that
  multiple commands can be used together, each
  reading information from stdin, somehow modifying
  or filtering the information, and passing the
  result to stdout. In a subsequent Workbook, you
  will find that there are many standard Linux (and
  Unix) commands that are designed for this
  purpose, including some that you are already
  familiar with grep, head, tail, cut, sort, sed,
  and awk, to name a few.

36
Pipes

• Listing Processes by Name
• Often, one would like to list information about
  processes which are running a specific command.
  While ps aux tables a lot of information about
  currently running processes, the number of
  processes running on the machine can make the
  output overwhelming. The grep command can help
  simplify the output.
• In the following, prince would like to list
  information about the processes which are
  implementing his web server, the httpd command.
  He lists all processes, but then reduces the
  output to only those lines which contain the text
  httpd.

37
Examples

• Listing Processes by Name
• Often, one would like to list information about
  processes which are running a specific command.
  While ps aux tables a lot of information about
  currently running processes, the number of
  processes running on the machine can make the
  output overwhelming. The grep command can help
  simplify the output.
• In the following, prince would like to list
  information about the processes which are
  implementing his web server, the httpd command.
  He lists all processes, but then reduces the
  output to only those lines which contain the text
  httpd.

38
QuestionsChapter 3.  Pipes

• 1 and 2
