Runtime Data Flow Scheduling of Matrix Computations

1
Runtime Data Flow Scheduling of Matrix
Computations

• Ernie Chan

2
Motivation

• Solving Linear Systems
• Solve for x
• A x b
• Factorize A O(n3)
• P A L U
• Forward and Backward substitution O(n2)
• L y P b
• U x y

3
Goals

• Programmability
• Use tools provided by FLAME
• Parallelism
• Directed acyclic graph (DAG) scheduling

4
Outline

• LU Factorization with Partial Pivoting
• Algorithm-by-Blocks
• SuperMatrix Runtime System
• Performance
• Conclusion
• P A L U

5
LU Factorization with Partial Pivoting

• Formal Linear Algebra Method Environment (FLAME)
• High-level abstractions for expressing linear
  algebra algorithms
• Application programming interfaces (APIs) for
  seamlessly implementing algorithms in code
• Library of commonly used linear algebra
  operations in libflame

6
(No Transcript)
7
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 1

A12
A11
A21
A22
8
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 1

LUpiv
A12
A22
9
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 1

PIV
A11
A21
10
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 1

TRSM
A11
A21
A22
11
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 1

A12
A11
A21
GEMM
12
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 2

A00
A01
A02
A10
A11
A12
A20
A21
A22
13
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 2

A00
A01
A02
A10
LUpiv
A12
A20
A22
14
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 2

A00
A01
A02
PIV
A11
PIV
A21
15
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 2

A00
A01
A02
A10
A11
TRSM
A20
A21
A22
16
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 2

A00
A01
A02
A10
A11
A12
A20
A21
GEMM
17
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 3

A00
A01
A10
A11
18
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 3

A00
A01
A10
LUpiv
19
LU Factorization with Partial Pivoting

• Blocked Algorithm
• Iteration 3

A00
A01
PIV
A11
20
Outline

• LU Factorization with Partial Pivoting
• Algorithm-by-Blocks
• SuperMatrix Runtime System
• Performance
• Conclusion
• P A L U

21
Algorithm-by-Blocks

• FLASH
• Storage-by-blocks

22

• FLA_Part_2x2( A, ATL, ATR,
• ABL, ABR, 0, 0, FLA_TL
  )
• FLA_Part_2x1( p, pT,
• pB, 0, FLA_TOP
  )
• while ( FLA_Obj_length( ATL ) lt FLA_Obj_length( A
  ) )
• FLA_Repart_2x2_to_3x3( ATL, // ATR,
  A00, // A01, A02,
• / / /
  /
•
  A10, // A11, A12,
• ABL, // ABR,
  A20, // A21, A22, 1, 1, FLA_BR )
• FLA_Repart_2x1_to_3x1( pT, p0,
• / / /
  /
• p1,
• pB, p2,
  1, FLA_BOTTOM )
• /---------------------------------------------
  ---------/
• FLA_Merge_2x1( A11,
• A21, AB1 )
• FLASH_LU_piv( AB1 , p1 )

23
Algorithm-by-Blocks

• LU Factorization with Partial Pivoting
• Iteration 1

PIV1 TRSM3
LUpiv0
PIV2 TRSM4
PIV1 GEMM5
PIV2 GEMM7
LUpiv0
PIV1 GEMM6
LUpiv0
PIV2 GEMM8
24
Algorithm-by-Blocks

• LU Factorization with Partial Pivoting
• Iteration 2

LUpiv9
PIV11 TRSM12
PIV10
LUpiv9
PIV10
PIV11 GEMM13
25
Algorithm-by-Blocks

• LU Factorization with Partial Pivoting
• Iteration 3

PIV16
PIV15
LUpiv14
26
LUpiv0
PIV1
PIV2
TRSM4
TRSM3
GEMM5
GEMM8
GEMM6
GEMM7
LUpiv9
PIV11
PIV10
TRSM12
GEMM13
LUpiv14
PIV16
PIV15
27
Outline

• LU Factorization with Partial Pivoting
• Algorithm-by-Blocks
• SuperMatrix Runtime System
• Performance
• Conclusion
• P A L U

28
SuperMatrix Runtime System

• Separation of Concerns
• Analyzer
• Decomposes subproblems into component tasks
• Store tasks in global task queue sequentially
• Internally calculates all dependencies between
  tasks, which form a directed acyclic graph (DAG),
  only using input and output parameters for each
  task
• Dispatcher
• Spawn threads
• Schedule and dispatch tasks to threads in parallel

29
SuperMatrix Runtime System

• Dispatcher Single Queue
• Set of all ready and available tasks
• FIFO, priority

PE1

PE0
PEp-1
30
LUpiv0
PIV1
PIV2
TRSM4
TRSM3
GEMM5
GEMM8
GEMM6
GEMM7
LUpiv9
PIV11
PIV10
TRSM12
GEMM13
LUpiv14
PIV16
PIV15
31
SuperMatrix Runtime System

• Lookahead
• Schedule GEMM5 and GEMM6 tasks first so LUpiv9
  can be computed ahead in parallel with GEMM7
  and GEMM8
• Implemented directly within the code which
  increases the complexity and detracts from
  programmability
• High-Performance LINPACK

32
SuperMatrix Runtime System

• Scheduling
• Sorting tasks by height of each task in DAG
  mimics lookahead
• Multiple queues
• Data affinity
• Work stealing
• Macroblocks
• Tasks overwriting more than one block at a time

33
Outline

• LU Factorization with Partial Pivoting
• Algorithm-by-Blocks
• SuperMatrix Runtime System
• Performance
• Conclusion
• P A L U

34
Performance

• Implementations
• SuperMatrix serial BLAS
• Partial and incremental pivoting
• LAPACK dgetrf multithreaded BLAS
• Multithreaded dgetrf
• Multithreaded dgemm
• Double-precision real floating-point arithmetic
• Tuned block size per problem size

35
Performance

• Target Architecture Linux
• 4 socket 2.3 GHz AMD Opteron Quad-Core
• ranger.tacc.utexas.edu
• 3936 SMP nodes
• 16 cores per node
• 2 MB shared L3 cache per socket
• OpenMP
• Intel compiler 10.1
• BLAS
• GotoBLAS2 1.00

36
Performance
37
Performance
38
Performance

• Target Architecture Windows
• 4 socket 2.4 GHz Intel Xeon E7330 Quad-Core
• Windows Server 2008 R2 Enterprise
• 16 core UMA machine
• Two 3 MB shared L2 cache per socket
• OpenMP
• Microsoft Visual C 2010
• BLAS
• Intel MKL 10.2

39
Performance
40
Performance

• Results
• SuperMatrix is competitive with GotoBLAS and MKL
• Incremental pivoting ramps up in performance
  faster but partial pivoting provides better
  asymptotic performance
• Linux and Windows platforms attain similar
  performance curves

41
Performance

• Target Architecture Windows Linux
• 4 socket 2.66 GHz Intel Dunnington 24 cores
• Windows Server 2008 R2 Enterprise
• Red Hat 4.1.2-46
• 16 MB shared L3 cache per socket
• OpenMP
• Intel compiler 11.1
• BLAS
• Intel MKL 11.1, 10.2

42
Performance
43
Performance
44
Performance
45
Performance
46
Performance
47
Performance
48
Performance
49
Performance
50
Performance
51
Performance
52
Outline

• LU Factorization with Partial Pivoting
• Algorithm-by-Blocks
• SuperMatrix Runtime System
• Performance
• Conclusion
• P A L U

53
Conclusion

• Separation of Concerns
• Programmability
• Allows us to experiment with different scheduling
  algorithms

54
Acknowledgements

• Andrew Chapman, Robert van de Geijn
• I thank the other members of the FLAME team for
  their support
• Funding
• Microsoft
• NSF grants
• CCF0540926
• CCF0702714

55
Conclusion

• More Information
• http//www.cs.utexas.edu/flame
• Questions?
• echan_at_cs.utexas.edu
