Servlets: Building Your First Servlet

1
ServletsBuilding Your First Servlet

• Ethan Cerami
• New York University

2
Road Map

• Generic Template for Creating Servlets
• Servlet 2.2 API
• Hello World Examples
• Outputting Text, HTML, and the current time.
• Compiling your own Servlets
• Instructions for installing/compiling servlets on
  I5
• Packaging Servlets
• HTML Utilities

3
Generic Servlet Template
4
Servlet Template

• First, lets take a look at a generic servlet
  template.
• The code does not actually do anything, but all
  your future servlets will follow this general
  structure.
• The most important pieces are noted in yellow.

5
import java.io. import javax.servlet. import
javax.servlet.http. public class
ServletTemplate extends HttpServlet public
void doGet(HttpServletRequest request,
HttpServletResponse response)
throws ServletException, IOException
// Use "request" to read incoming HTTP headers
// (e.g. cookies) and HTML form data (e.g. data
the user // entered and submitted).
// Use "response" to specify the HTTP response
status // code and headers (e.g. the content
type, cookies). PrintWriter out
response.getWriter() // Use "out" to send
content to browser
6
Generic Template

• Import the Servlet API
• import javax.servlet.
• import javax.servlet.http.
• To create servlets, you must remember to always
  use these two import statements.

7
Generic Template

• All your servlets must extend HTTPServlet.
• HTTPServlet represents the base class for
  creating Servlets within the Servlet API.
• The Full Servlet API is available at
• http//www.java.sun.com/products/servlet/2.2/javad
  oc/index.html
• Once you have extended HTTPServlet, you must
  override one or both
• doGet() to capture HTTP Get Requests
• doPost() to capture HTTP Post Requests

8
doGet and doPost

• The doGet() and doPost() methods each take two
  parameters
• HTTPServletRequest encapsulates all information
  regarding the browser request.
• Form data, client host name, HTTP request
  headers.
• HTTPServletResponse encapsulate all information
  regarding the servlet response.
• HTTP Return status, outgoing cookies, HTML
  response.
• If you want the same servlet to handle both GET
  and POST, you can have doGet call doPost or vice
  versa.

9
Getting an OutputStream

• The HTTPResponse object has a getWriter() method.
• This method returns a java.io.PrintWriter object
  for writing data out to the Web Browser.
• PrintWriter out response.getWriter()

10
Hello World!
11
Hello World!

• We are finally ready to see our first real
  servlet.
• This servlet outputs Hello World! as plain
  text, not HTML.
• Note All examples are available on the web
  site.
• Lets take a look at the code, and then see the
  servlet in action.

12
import java.io. import javax.servlet. import
javax.servlet.http. public class HelloWorld
extends HttpServlet public void
doGet(HttpServletRequest request,
HttpServletResponse response) throws
ServletException, IOException PrintWriter
out response.getWriter()
out.println("Hello World")
13
Output Stream

• Once you have an OutputStream object, you just
  call the println() method to output to the
  browser.
• Anything you print will display directly within
  the web browser.
• As we will now see, you can also output any HTML
  tags.

14
Generating HTML

• To generate HTML, you need to add two steps
• Tell the browser that you are sending back HTML.
• Modify the println() statements to return valid
  HTML.

15
HelloWWW.java
import java.io. import javax.servlet. import
javax.servlet.http. public class HelloWWW
extends HttpServlet public void
doGet(HttpServletRequest request,
HttpServletResponse response) throws
ServletException, IOException
response.setContentType("text/html") PrintWrite
r out response.getWriter() out.println("ltHTMLgt
\n" "ltHEADgtltTITLEgtHello
WWWlt/TITLEgtlt/HEADgt\n"
"ltBODYgt\n" "ltH1gtHello
WWWlt/H1gt\n" "lt/BODYgtlt/HTMLgt")

16
Generating HTML

• To return HTML, you must set the content MIME
  type to text/html
• response.setContentType("text/html")
• Remember that you must set the content type
  before you output any content.
• Once you have set the MIME type, you can return
  any HTML document you want.

17
Time Servlet

• Lets try one more simple servlet
• Using the java.util.Date object, you can obtain
  the current time.
• Lets create a simple Servlet that outputs the
  current time.

18
import java.io. import java.util. import
javax.servlet. import javax.servlet.http. pub
lic class TimeServlet extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse response) throws
ServletException, IOException
response.setContentType("text/html") Date
now new Date() PrintWriter out
response.getWriter() out.println("ltHTMLgt\n"
"ltHEADgtltTITLEgtHello
WWWlt/TITLEgtlt/HEADgt\n"
"ltBODYgt\n" "ltH1gtHello
WWWlt/H1gt\n" "ltH2gtTime is now
"now"lt/H2gt" "lt/BODYgtlt/HTMLgt")

19
Installing / Compiling Servlets
20
Basic Setup

• I5 now has the Jakarta-Tomcat Servlet Engine
  installed.
• Tomcat is an open source servlet engine.
• Supports both Servlets and JSPs.
• Maintained by the same group that develops the
  Apache Web Server.

21
Tomcat Set-up
Send request to port 9712
Web Browser
Tomcat Servlet Engine
Hello World Servlet
22
Getting Started

• Lets take a look at todays handout.
• Handout is also available online at
• http//ecerami.com/applied_fall_2001/handouts/i5_s
  ervlets.php4
• Change to handout
• CLASSPATH"/usr/local/jakarta-tomcat-3.2.3/lib/ser
  vlet.jar."

Add . to Classpath!
23
Packaging Servlets
24
What is a Package?

• Package Group of related classes.
• For example
• package coreservlets
• In real web sites, multiple programmers may be
  creating multiple servlets.
• By dividing your code base into packages, it
  helps to modularize the code.
• A very common practice in the real world, and
  used throughout our textbook.

25
Creating Packages

• To create your own package, you need to follow
  three steps
• Move your .java files to a subdirectory that
  matches your package name.
• For example, the text book uses the package name
  coreservlets.
• You therefore need to create a coreservlets
  directory within /public_html/tomcat/WEB-INF/clas
  ses and place your code here.

26
Creating Packages

• Insert a package statement in the first line of
  your class file
• For example package coreservlets
• Compile your Java code like this
• type servlets
• type javac coreservlets/HelloWWW2.java

27
package coreservlets import java.io. import
javax.servlet. import javax.servlet.http. pub
lic class HelloWWW2 extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse response)
throws ServletException, IOException
response.setContentType("text/html")
PrintWriter out response.getWriter()
out.println("ltHTMLgt\n"
"ltHEADgtltTITLEgtHello WWWlt/TITLEgtlt/HEADgt\n"
"ltBODYgt\n" "ltH1gtHello
WWWlt/H1gt\n" "ltH2gtThis is a
servlet within a package.lt/H2gt"
"lt/BODYgtlt/HTMLgt")
28
Invoking a Packaged Servlet

• To invoke a packaged servlet, you need to specify
  the package name and the servlet name
• http//host/servlet/packageName.servletName
• For example, to access the HelloWWW2 servlet on
  ecerami.com
• http//ecerami.com/servlet/coreservlets.HelloWWW2
• To access the servlet on I5
• http//i5.nyu.edu9712/eqc3844/servlet/coreservlet
  s.HelloWWW2

29
HTML Utilities
30
Servlet Utilities

• Author of our text book has created a class
  called ServletUtilities.
• This class contains some simple HTML utilities
  that you can use.
• As we read further in the book, the author adds
  more utilities to this class.
• Lets first examine the ServletUtilities class,
  and then examine how to use it.

31
ServletUtilities.java

• For now, let us examine just one method
  headWithTitle().
• This method outputs
• HTML DOCTYPE, used to specify which version of
  HTML we are using.
• The title of the page via the HTML ltTITLEgt tag.

32
package coreservlets import javax.servlet. impo
rt javax.servlet.http. / Some simple time
savers. Note that most are static
methods. / public class ServletUtilities
public static final String DOCTYPE
"lt!DOCTYPE HTML PUBLIC \"-//W3C//DTD HTML 4.0 "
"Transitional//EN\"gt" public static
String headWithTitle(String title)
return(DOCTYPE "\n" "ltHTMLgt\n"
"ltHEADgtltTITLEgt" title
"lt/TITLEgtlt/HEADgt\n") ...
33
Using Servlet Utilities

• To use the Servlet Utilities class, you just need
  to call the headWithTitle() method
• ServletUtilities.headWithTitle("Hello WWW")
• If you are placing your servlet in a different
  package, you also need to import coreservlets

34
package coreservlets import java.io. import
javax.servlet. import javax.servlet.http. pub
lic class HelloWWW3 extends HttpServlet
public void doGet(HttpServletRequest request,
HttpServletResponse response) throws
ServletException, IOException
response.setContentType("text/html")
PrintWriter out response.getWriter()
out.println(ServletUtilities.headWithTitle("Hello
WWW") "ltBODYgt\n"
"ltH1gtHello WWWlt/H1gt\n"
"lt/BODYgtlt/HTMLgt")
35
Compiling

• To compile this servlet
• Download ServletUtilities.java and copy to your
  coreservlets directory.
• Download HelloWorldWWW3.java and copy to your
  coreservlets directory.
• Type
• javac coreservlets/HelloWWW3.java
• Then, open browser and go to
• http//i5.nyu.edu9712/NET-ID/servlet/coreservle
  ts.HelloWWW3
