Title: Address Autoconfiguration


1
Address Autoconfiguration
  • Feng Zou
  • SW2
  • ZyXEL Communications Corp.
  • 04/11/2006

2
Outline
  • Why We Need Address Autoconfiguration?
  • IPv6 Address Structure Review
  • How to Autoconfiguration?
  • Autoconfiguration Process
  • Autoconfigured Address States
  • Types of Autoconfiguration
  • QA

3
Why We Need Address Autoconfiguration?
  • The size of an address in IPv6 is 128 bits
  • Each interface have multiple IPv6 addresses
  • Its difficult to configure those IP addresses
    manually

MAC 00-B0-D0-23-47-33 FE802B0D0FFFE234733
(link-local address) FEC0F2822B0D0FFFE2347
33 (site-local address) 3FFE2900D005F2822B0D0
FFFE234733 (global address) FF021FF23
4733 (solicited-node address)
Host A
4
IPv6 Address Structure Review
  • Link-local address
  • FE80 XXXXXXXXXXXXXXXX
  • (Fixed Prefix) (Interface ID)

5
IPv6 Address Structure Review
  • Site-local address
  • FEC0 SSSS XXXXXXXXXXXXXXXX
  • (Fixed) (Subnet ID)
  • Prefix
    (Interface ID)

6
IPv6 Address Structure Review
  • Aggregatable global address
  • Prefix Interface ID

7
IPv6 Address Structure Review
  • Solicited-node address
  • FF021FF XXXXXX
  • (Fixed Prefix) (last 24 bits of Interface ID)

64 bits
64 bits
Interface ID
Unicast prefix
104 bits
24 bits
FF02
1FF
0000
XXXXXX
8
(No Transcript)
9
How to Autoconfigure Address
  • IPv6 address Prefix Interface ID
  • Interface ID is converted from MAC
  • Link-local address
  • Prefix FE80 is fixed
  • Can be determined even without a router and a
    DHCPv6 server
  • Site-local address ,aggregatable global address
  • Prefix can be determined by Prefix Information
    options in Router Advertisement message
  • Other configuration parameters
  • Other configuration parameters include hop limit,
    reachable time, retransmission timer, MTU
  • Can be determined by Router Advertisement message

10
Autoconfiguration Process
  • For IPv6 node
  • 1. Derive tentative link-local address based on
    FE80/64 and a EUI-64-derived Interface ID.
  • 2. Using Duplicate Address Detection to verify
    the uniqueness of the tentative link-local
    address.
  • 3. If a Neighbor Advertisement message is
    received, address auto-configuration stops.
    Manual configure or assign a new Interface ID
    (must do Duplicate Address Detection either) to
    this interface.
  • 4. If NO Neighbor Advertisement message is
    received, the tentative link-local address is
    valid and the link-layer multicast address of the
    corresponding solicited-node address is
    registered.

11
Autoconfiguration Process
  • For IPv6 host
  • 1. The host sends a Router Solicitation message.
  • 2. If NO Router Advertisement messages are
    received, the host uses a stateful address
    auto-configuration protocol to obtain addresses
    and other configuration parameters.
  • 3. If a Router Advertisement message is received,
    the host sets configuration parameters (hop
    limit, reachable time, retransmission timer,
    MTU).

12
Autoconfiguration Process
  • 4. For each Prefix Information option present
  • If the On-Link flag is set to 1, the prefix is
    added to the prefix list.
  • If the Autonomous flag is set to 1, the prefix
    and an appropriate Interface ID are used to
    derive a tentative address.
  • Use duplicate address detection to verify the
    uniqueness of the tentative address.
  • If the tentative address is in use, dont use the
    address to initialize the interface.
  • If the tentative address is not in use, the
    address is initialized. If needed, registers the
    new link-layer multicast address of the
    corresponding solicited-node address.
  • 5. If the Managed Address Configuration flag is
    set to 1, a stateful address auto-configuration
    protocol is used to obtain additional addresses.
  • 6. If the Other Stateful Configuration flag is
    set to 1, a stateful address auto-configuration
    protocol is used to obtain additional
    configuration parameters.

13
(No Transcript)
14
(No Transcript)
15
  • Ethernet Header
  • Destination MAC is 33-33-FF-23-47-33
  • IPv6 Header
  • Source Address is
  • Destination Address is FF021FF234733
  • Hop limit is 1
  • Multicast Listener Report Header
  • Multicast Address is FF021FF234733

? Send Multicast Listener Report
Multicast Listener Report
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
16
  • Ethernet Header
  • Destination MAC is 33-33-00-00-00-02
  • IPv6 Header
  • Source Address is
  • Destination Address is FF022
  • Hop limit is 255
  • Router Solicitation Header

? Send Router Solicitation
Router Solicitation
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
17
  • Ethernet Header
  • Destination MAC is 33-33-FF-23-47-33
  • IPv6 Header
  • Source Address is
  • Destination Address is FF021FF234733
  • Hop limit is 255
  • Neighbor Solicitation Header
  • Target Address is FE802B0D0FFFE234733

? Send Neighbor Solicitation
Neighbor Solicitation
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
18
  • Ethernet Header
  • Destination MAC is 33-33-00-00-00-01
  • IPv6 Header
  • Source Address is FE80210FFFFFED658C0
  • Destination Address is FF021
  • Hop limit is 255
  • Router Advertisement Header
  • Current Hop Limit 64
  • Router Lifetime 1800
  • Source Link-Layer Address is 00-10-FF-D6-58-C0
  • Prefix Information is for FEC000F282
  • Valid Lifetime 2592000
  • Preferred Lifetime 604800
  • Prefix Information is for 3FFE2900D005F282

Router Advertisement
? Send Router Advertisement
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
19
  • Ethernet Header
  • Destination MAC is 33-33-FF-23-47-33
  • IPv6 Header
  • Source Address is
  • Destination Address is FF021FF234733
  • Hop limit is 255
  • Neighbor Solicitation Header
  • Target Address is FEC0F2822B0D0FFFE234733

? Send Neighbor Solicitation
Neighbor Solicitation
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
20
  • Ethernet Header
  • Destination MAC is 33-33-FF-23-47-33
  • IPv6 Header
  • Source Address is
  • Destination Address is FF021FF234733
  • Hop limit is 255
  • Neighbor Solicitation Header
  • Target Address is 3FFE2900D005F2822B0D0FFFE2
    34733

? Send Neighbor Solicitation
Neighbor Solicitation
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
21
? NO Neighbor Advertisement message received
MAC 0010FFD658C0 IP FE80210FFFFFED658C0 FE
C000F282210FFFFFED658C0 3FFE2900D005F28
2210FFFFFED658C0
Router
Host B
22
Autoconfigured Address States
  • Tentative
  • The address is in the process of being verified
    as unique
  • Valid
  • An address from which unicast traffic can be sent
    and received
  • Preferred state
  • An address for which uniqueness has been
    verified, unrestricted use
  • Deprecated state
  • An address that is still valid, but is
    discouraged for new communication
  • Invalid
  • An address for which a node can no longer send or
    receive unicast traffic

23
Autoconfigured Address States
24
Types of Autoconfiguration
  • Stateless
  • Receipt of Router Advertisement messages with one
    or more Prefix Information options
  • Stateful
  • Use of a stateful address configuration protocol
    such as DHCPv6
  • Both
  • Receipt of Router Advertisement messages and
    stateful configuration protocol
  • For all types, a link-local address is always
    configured automatically.

25
  • Q A
