Real-time Traffic monitoring and containment

1
Real-time Traffic monitoring and containment
A. L. Narasimha Reddy Dept. of Electrical
Engineering Texas A M University reddy_at_ee.tamu.
edu http//ee.tamu.edu/reddy/
2
Acknowledgements

• Deying Tong, Smitha, Phani Achanta
• Seong Soo Kim

3
Outline

• Introduction Motivation
• DOS attacks
• Partial state routers
• DDOS attacks, worms
• Aggregate Packet header data as signals
• Signal/image based anomaly/attack detectors

4
Introduction

• UDP-based multimedia traffic increasing
• UDP does not have congestion control
• Applications can be selfish
• If everyone is selfish, network can break down
• Controlling selfish flows desired
• Identify Resource hogs and control them

5
Impact of UDP -- Unfairness

• When UDP and TCP compete, UDP wins by pushing TCP
  into congestion FloydFall 99

6
Unfairness - FIFO
7
Unfairness - WRR
8
Loss of goodput -FIFO

• Packets dropped later in network

9
Loss of goodput -WRR
10
UDP -- Summary

• Individual flows need to respond to congestion
• When end-hosts dont respond to congestion
• Need to identify and contain such flows
• Need network mechanisms for such control

11
Introduction (contd)

• Many Network attacks
• Exploit Application, Protocol, Network
  architecture vulnerabilities
• Denial of Service attacks
• Consume all resources
• Leave no resources for legitimate users

12
TCP SYN Flooding (contd)

• The attack occurs by the attacker initiating a
  TCP connection to the server with a SYN. (using a
  legitimate or spoofed source address)
• The server replies with a SYN-ACK
• The client then doesnt send back a ACK, causing
  the server to allocate memory for the pending
  connection and wait.
• (If the client spoofed the initial source
  address, it will never receive the SYN-ACK)

13
TCP SYN Flooding Results

• The half-open connections buffer on the victim
  server will eventually fill
• The system will be unable to accept any new
  incoming connections until the buffer is emptied
  out.
• There is a timeout associated with a pending
  connection, so the half-open connections will
  eventually expire.
• The attacking system can continue sending
  connection requesting new connections faster than
  the victim system can expire the pending
  connections.

14
TCP Three-Way Handshake
Client connecting to a TCP port
Client initiates request
Connection is now half-open
Client connection Established
Server connection Established
15
SYN Flood Illustrated
Client SYN Flood
Client spoofs request
half-open
half-open
I have ACKed these connections, but I have not
received an ACK back!
half-open
Queue filled
Queue filled
Queue filled
16
Smurf Example
1. Attacker sends ICMP packet with spoofed source
IP Victim?10.1.2.255
2. Attacker sends ICMP packet with spoofed source
IP Victim?192.168.1.255
3. Victim is flooded with ICMP echo responses
4. Victim hangs?
17
Distributed Denial of Service Attacks (DDOS)

• Attacker logs into Master and signals slaves to
  launch an attack on a specific target address
  (victim).
• Slaves then respond by initiating TCP, UDP, ICMP
  or Smurf attack on victim.

18
Network Attacks -- Summary

• Many vulnerabilities exist in Networks
• Malicious traffic increasing
• For fun and profit
• Need mechansims to identify and control malicious
  traffic
• DOS and DDOS
• DOS, resource hog problem similar
• DDOS requires new approach

19
Real-time traffic monitoring

• Attacks motivate us to monitor network traffic
• Potential anomaly/attack detectors
• Potentially contain/throttle them as they happen
• Line speeds are increasing
• Need simple, effective mechanisms
• Attacks constantly changing
• CodeRed yesterday, MyDoom today, what next

20
Motivation

• Most current monitoring/policing tools are
  tailored to known attacks
• Look for packets with port number 1434 (CodeRed)
• Contain Kaaza traffic to 20 of the link
• Become ineffective when traffic patterns or
  attacks change
• New threats are constantly emerging

21
Motivation

• Can we design generic (and generalized)
  mechanisms for attack detection and containment?
• Can we make them simple enough to implement them
  at line speeds?

22
Introduction

• Why look for Kaaza packets
• They consume resources
• Consume resources more than we want
• Not much different from DOS flood
• Consumes resources to stage attacks
• Why not monitor resource usage?
• Do not want to rely on attack specific info

23
Attacks

• DOS attacks
• Few sources resource hogs
• DDOS attacks, worms
• Many sources
• Individual flows look normal
• Look at the aggregate picture

24
DOS attacks Network Flows

• Too many flows to monitor each flow
• Maintain a fixed amount of state/memory
• State not enough to monitor all flows (Partial
  state)
• Manage the state to monitor high-bandwidth flows
• How?
• Sample packets
• High-BW flows more likely to be selected
• Use a cache and employ LRU type policy
• Traffic driven
• Cache retains frequently arriving flows

25
Partial State Approach

• Similar to how caches are employed in computer
  memory systems
• Exploit locality
• Employ an engineering solution in an
  architecture-transparent fashion

26
Identifying resource hogs

• Lots of web flows
• Tend to corrupt the cache quickly
• Apply probabilistic admission into cache
• Flow has to arrive often to be included in cache
• Most web flows not admitted
• Works well in identifying high-BW flows
• Can apply resource management techniques to
  contain cached/identified flows

27
LRU with probabilistic admission

• Employ a modified LRU
• On a miss, flow admitted with probability p
• When p is small, keeps smaller flows out
• High-BW flows more likely admitted
• Allows high-BW flows to be retained in cache
• Nonresponsive flows more likely to stay in cache

28
Traffic Driven State Management

• Monitor top 100 flows at any time
• Dont know the identity of these flows
• Dont know how much BW these may consume

29
Policy Driven State Management

• An ISP could decide to monitor flows above 1Mbps
• Will need state gt link capacity/1 Mbps
• Could monitor flows consuming more than 1 of
  link capacity
• For security reasons
• At most 100 flows with 1 BW consumption

30
Partial State Trace-driven evaluation
31
Partial State Trace-driven Evaluation
32
UDP Cache Occupancy
33
TCP Cache Occupancy
34
Resource Management
35
Preferential Dropping
1
drop prob
maxp
minth
maxth
Queue length
drop prob for high bandwidth flows
drop prob for other flows
36
Multiple possibilities

• SACRED Monitor flows above certain rate (policy
  driven), differential RED, (iwqos99)
• LRU-RED Traffic driven state management,
  differential RED (Globecom01)
• Approximately fair BW distribution
• LRU-FQ Traffic driven state management, fair
  queuing (ICC 04)
• Contain DOS attacks
• Provide shorter delays for short-term flows

37
SACRED

• Sampling And Caching RED
• Maintain flow rate as state for cached flows
• If flow rate gt threshold, drop at higher rate
• Drop rate keeps increasing if flow stays above
  threshold
• Tends to punish nonresponsive flows, high-BW
  flows
• If flow rate lt threshold, remove from cache
• Make room for another flow

38
SACRED results -10 state
39
SACRED cache associativity
40
SACRED --Additive
41
SACRED TCP only
42
LRU-FQ Resource Management
43
LRU-FQ flow chart enqueue event
Is Flow in Cache?
Does Cache Have space?
Packet Arrival
No
Admit flow with Probability p
No
Yes
Yes
Is Flow Admitted?
Record flow details Initialize count to 0
Yes
Increment count Move flow to top of cache
No
Is count gt threshold
No
Yes
Enqueue in Normal Queue
Enqueue in Partial state Queue
44
Linux IP Packet Forwarding
Local packet Deliver to upper layers
UPPER LAYERS
Route to destination Update Packet
Error checking Verify Destination
IP LAYER
Packet Enqueued
Scheduler invokes Bottom half
Design space
Scheduler runs Device driver
LINK LAYER
Request Scheduler To invoke bottom half
Device Prepares packet
Packet Departure
Packet Arrival
Check Store Packet Enqueue pkt
45
Linux Kernel traffic control

• Filters are used to distinguish between different
  classes of flows.
• Each class of flows can be further categorized
  into sub-classes using filters.
• Queuing disciplines control how the packets are
  enqueued and dequeued

46
LRU-FQ Implementation

• LRU component of the scheme is implemented as a
  filter.
• All parameters threshold, probability and cache
  size are passed as parameters to the filter
• Fair Queuing employed as a queuing discipline.
• Scheduling based on queues weight.
• Start-time Fair Queuing

47
Experimental Setup
48
Long-Term flow differentiation
Normal TCP fraction 0.07
Probability 1/25 Cache size 11 threshold
125
49
Long-term flow differentiation
Probability 1/25 Cache size 11 threshold
125
50
Protecting Web Mice
51
Protecting Web mice
Experimental Setup
52
Protecting Web Mice

Bandwidth Results
Normal Router
LRU-FQ Router
53
Protecting Web Mice
Timing Results
Normal Router
LRU-FQ Router
54
Summary of Partial-State

• Sampling and Caching allows simple identification
  of resource hogs
• Provides a good control of DOS attacks with
  limited number of flows
• Provides fairer distribution of link BW
• Partial state packet handling cost -not an issue
  at 100Mbps/1Gbps.
• 1Gbps implemented on Intel Network processor

55
Applications of Partial State

• More intelligent control of network traffic
• Accounting and measurement of high bandwidth
  flows
• Denial of Service (DOS) attack prevention
• Tracing of high bandwidth flows
• QOS routing

56
Aggregated packet analysis
57
Approach
Anomaly Detection (Thresholding)
Signal Generation Data Filtering (Address
correlation)
Statistical or Signal Analysis (Wavelets or DCT)
Detection Signal
Network Traffic
58
Signal Generation

• Traffic volume (bytes or packets)
• Analyzed before
• May not be a great signal when links are always
  congested (typical campus access links)
• Lot more information in packet headers
• Source address
• Destination address
• Protocol number
• Port numbers

59
Signal Generation

• Per packet cost is important driver
• Update a counter for each packet header field
• Too much memory to put in SRAM
• Break the field into multiple 8-bit fields
• 32-bit address into four 8-bit fields
• 1024 locations instead of 232 locations
• In general, 256 (k/8) instead of 2k
• k/8 counter updates instead of 1

60
Signal Generation

• What kind of signals can we generate with
  addresses, port numbers and protocol numbers?

61
Addresses are correlated

• Most of us have habits
• Access same web sites
• Large web sites get significant part of traffic
• Google.com, hp.com, yahoo.com
• Large downloads correlate over time
• ftp, video
• On an aggregate, addresses are correlated

62
Address Correlation attacks?

• Address correlation changes when traffic patterns
  change abruptly
• Denial of service attacks
• Flash crowds
• Worms
• Results in differences in correlation
• High --single attack victim
• Low lots of addresses --worm

63
Address correlation signals

• Address correlation
• Simplified Address correlation

64
Address Correlation Signals
65
Address Correlation Signals
66
Signal Analysis

• Capture information over a sampling period
• Of the order of a few seconds to minutes
• Analyze each sample to detect anomalies
• Compare with historical norms
• Post-mortem/Real-time analysis
• May use different amounts of data analysis
• Detailed information of past few samples
• Less detailed information of older samples

67
Signal Analysis

• Address correlation as a time series signal
• Employ known techniques to analyze time series
  signals
• Wavelets one powerful technique
• Allows analysis in both time and frequency domain
• Per-sample analysis has more flexibility
• Not in forwarding path

68
Does this work?
69
Analysis of address signal
70
Image based analysis

• Treat the traffic data as images
• Apply image processing based analysis
• Treat each sample as a frame in a video
• Video compression techniques lead to data
  reduction
• Scene change analysis leads to anomaly detection
• Motion prediction leads to attack prediction

71
Signal Generation
72
Two dimensional images

• Horizontal/vertical lines indicate anomalies
• Infected machine contacting multiple destinations
  (worm propagation)
• Multiple source machines targeting a destination
  (DDOS)

73
DCT analysis of addresses
74
Semi-random attacks
75
Random attacks
76
Complex attacks
77
Better than volume analysis
78
Evaluation

• True Positive Rate
• False Alarm Rate or False Positive Rate
• True Negative Rate
• False Negative Rate
• LR true positive rate/ false positive rate
• NLR false negative rate/true ve rate
• Ideally, LR infinity, NLR 0

79
Comparison of Scalar signals
80
Protocol Composition

• During attack, attack protocol volume will be
  higher
• Observation of changes can lead to detection

81
Protocol Composition
82
Address based signals
83
Port Number Domain
84
Thresholds vs. Detection
85
Motion prediction
86
End host attacks

• Common solution to several kinds of attacks?
• Do something simple in the network layer
• State maintenance and policing
• Our Key Idea Per Resource regulation
• Hierarchical regulation (per resource, per flow)
  also possible
• Move regulation away from server into the network
  (eg. At firewall)

87
QOS Regulation to control network attacks
88
End host QOS regulation

• Limit consumption of each resource
• At bastion Host
• Limit resource consumption to a traffic class so
  that other classes keep getting service

89
End host protection

• Have a uniform picture of resources at the
  network layer
• We do this at the QOS Regulator
• Resource Aggregates (resource principals)
• Memory, Protocol State Buffers, mbuf / sk_buff
  Clusters, Network Bandwidth, CPU Cycles...
• Charge incoming traffic to one or more of these
  resource aggregates

90
End host protection (contd)

• What does Rate Control achieve?
• UDP food regulation
• ICMP flood regulation
• Interrupt / packet processing regulation
• What about TCP SYN? CGI attack?
• Consume Fixed number of resources
• What does Window Control achieve?
• Regulates fixed number of resources
• Need to keep track of resource usage
• TCP SYN data structures, CGI processes, Memory
• Sometimes action required to reset system state
  and free resources

91
Experimental results
92
Results SYN attacks
93
Advantages

• Not looking for specific known attacks
• Generic mechanism
• Works in real-time
• Latencies of a few samples
• Simple enough to be implemented inline

94
Prototypes

• Linux-PC boxes
• On Intel Network processors
• Can push to Gbps packet forwarding rates
• Forwarding throughput not impacted
• Sampling rates of a few ms possible

95
Related Work

• Resource usage monitoring
• Estan Verghese Bloom filters
• Kodialam Lakshman Run detection
• Mahajan et al RED-PD
• Duffield (AT T) Sampling
• Others

96
Related Work Worms

• Payload monitoring
• Singh, Savage Verghese, Tang Chen
• Look for matches against constant length payloads
• Sampling, Rabin Signatures
• Prototype implementation
• Detects worms within 5-30 seconds
• Effective with polymorphic worms

97
Related Work -- Worms

• Look for TCP Reset signals
• Weaver Paxson
• Random host scan at a specific ports
• Not all hosts open attack port
• Attacking worm will get many Resets
• Too many Resets gt Attacker
• Effective for TCP based attacks
• Can detect/contain in real-time

98
Related Work -- Worms

• Quick spreading worms use randomly generated
  addresses
• Normal users use names, DNS
• Worms dont have DNS activity
• Lots of accesses without DNS requests gt Worms
• Many detectors within a campus
• Local DNS servers

99
Related Work -- Worms

• Address honeypots
• Arbor networks, Paxson, CrowCroft
• Configure machines to accept packets for
  unassigned addresses
• Only worms will contact these machines
• Capture payloads to analyze
• Quickly propagate signatures

100
Related Work -- Worms

• IP Traceback Savage et al
• Address spoofing makes origin of attacks
  difficult to detect
• Tracing, if universal, will limit attacks
• Fear of detection
• Post-attack detection
• Not helpful in mitigating or detection
• Most attack machines are innocent participants

101
Related Work host based

• Limit the number of new connections of individual
  hosts
• TwyCross Williamson (HP)
• Reduces the speed at which a worm can spread
• Can be used to detect worms
• Monitor application execution sequences
• Profiling based indication of anomalous behavior
  gt Detect and sandbox worms

102
Conclusion

• Real-time resource accounting is feasible
• Real-time traffic monitoring is feasible
• Simple enough to be implemented inline
• Can rely on many tools from signal/image
  processing area
• More robust offline analysis possible
• Concise for logging and playback

103
Thank you !!For more information,http//ee.ta
mu.edu/reddyreddy_at_ee.tamu.edu

104
LRU-RED Results
105
RTT Bias -TCP flows
106
Impact of Cache size

• Effect of varying cache size
• to study impact of cache size on performance of
  the scheme
• probability 1/55, threshold 125
• number of TCP flows20
• equal weights for both queues.

107
Results Cache size
108
Normal Workloads

• Performance under normal workloads
• working of scheme when non-responsive loads are
  absent or use their fair share of bandwidth
• cache size 9, threshold 125
• probability 1/55

109
Results Normal workload
110
Normal Mixed workload
111
Interrupt processing overhead for
server(incoming UDP traffic 100Mbps)
Received UDP Goodput (Kpkts/sec) -gt
QoS Rate Limit on Regulator -gt
