Chapter 8 File Management

1
Chapter 8File Management
2
8.1 Introduction

• Data should be organized in some convenient and
  efficient manner. In particular, users should be
  able to
• Put data into files
• Find and use files that have previously been
  created

3
File System

• Set of OS Services that provides Files and
  Directories for user applications

4
8.2 Files

• A file is simply a sequence of bytes that have
  been stored in some device (storage) on the
  computer

5
Files

• Those bytes will contain whatever data we would
  like to store in the file such as
• A text file just containing characters that we
  are interested in
• A word processing document file that also
  contains data about how to format the text
• A database file that contains data organized in
  multiple tables.
• In general, the File Management system does not
  have any knowledge about how the data in a file
  is organized. That is the responsibility of the
  application programs that create and use the file.

6
Permanent (non-volatile) Storage Devices

• Disk Drives
• Flash Memory (Memory stick)
• CDs and DVDs
• Magnetic tape drives

7
8.2.1 File Attributes

• Name
• Symbolic (Human-readable) name of the file
• Type
• Executable file, print file, etc.
• Location
• Where file is on disk

8
File Attributes

• Size
• Protection
• Who can read, write file, etc.
• Time, date
• When file was created, modified, accessed

9
8.2.2 Folders

• An important attribute of folders is the Name
• Typically, a folder may contain Files and other
  Folders (commonly called sub-folders or
  sub-directories)
• This results in a Tree Structure of Folder and
  Files.

10
Folder/Directory Tree Structure
11
8.2.3 Pathnames

• The pathname of a file specifies the sequence of
  folders one must traverse to travel down the tree
  to the file.
• This pathname actually describes the absolute
  path of the file, which is the sequence of
  folders one must travel from the root of the tree
  to the desired file.
• A relative path describes the sequence of Folders
  one must traverse starting at some intermediate
  place on the absolute path.
• The Absolute path provides a unique
  identification for a file. Two different files
  can have the same filename as long as the
  resulting pathnames are unique.

12
File Links

• Allow a directory entry to point to a file (or
  entry) that is not directly below it in the tree
  structure
• Unix Symbolic Link
• Windows Shortcut

13
Link in Directory Tree Structure
14
8.3 Access Methods

• An access method describes the manner and
  mechanisms by which a process accesses the data
  in a file.
• There are two common access methods
• Sequential
• Random (or Direct)

15
File Operations

• When a process needs to use a file, there are a
  number of operations it can perform
• Open
• Close
• Read
• Write

16
Create File

• Allocate space for file
• Make entry for file in the Directory

17
8.3.1 Open File

• Make files accessible for read/write operations
• Locates files in the Directory
• Returns internal ID for the file
• Commonly called a Handle
• handle open(filename, parameters)

18
File Open
19
8.3.2 Close File

• Makes file no longer accessible from application
• Deletes the Handle created by Open

20
File Close
21
8.3.3 Read File

• System call specifies
• Handle from Open call
• Memory Location, length of information to be read
• Possibly, location in the file where data is to
  be read from
• read(file handle, buffer)
• read(file handle, buffer, length)

22
Read File

• Uses Handle to locate file on disk
• Uses files Read Pointer to determine the
  position in the file to read from
• Update files Read Pointer

23
8.3.4 Write File

• System call specifies
• Handle from Open call
• Location, length of information to be written
• Possibly, location in the file where data is to
  be written
• write(file handle,buffer,length)

24
Write File

• Use Handle to locate file on disk
• Use files Write pointer to determine the
  position in the file to write to
• Update files Write Pointer

25
Delete File

• Deletes entry for file in Directory
• De-allocates disk space used by the file

26
8.3.5 Sequential Access

• If the process has opened a file for sequential
  access, the File Management subsystem will keep
  track of the current file position for reading
  and writing.
• To carry this out, the system will maintain a
  file pointer that will be the position of the
  next read or write.

27
File Pointer

• The value of the file pointer will be initialized
  during Open to one of two possible values
• Normally, this value will be set to 0 to start
  the reading or writing at the beginning of the
  file.
• If the file is being opened to append data to the
  file, the File Position pointer will be set to
  the current size of the file.
• After each read or write, the File Position
  Pointer will be incremented by the amount of data
  that was read or written.

28
8.3.6 Streams, Pipes, and I/O Redirection

• A Stream is the flow of data bytes, one byte
  after another, into the process (for reading) and
  out of the process (for writing).
• This concept applies to Sequential Access and was
  originally invented for network I/O, but several
  modern programming environments (e.g. Java, C)
  have also incorporated it.

29
Standard I/O

• Standard Input
• Defaults to keyboard
• Standard Output
• Defaults to console

30
I/O Redirection

• Standard Input can come from a file
• app.exe lt def.txt
• Standard Output can go to a file
• App.exe gt def.txt
• Standard Output from one application can be
  Standard Input for another
• App1.exe app2.exe

Called a Pipe
31
A Pipe
32
Pipe

• A Pipe is a connection that is dynamically
  established between two processes.
• When a process reads data, the data will come
  from another process rather than a file. Thus, a
  pipe has a process at one end that is writing to
  the pipe and another process reading data at the
  other end of the pipe.
• It is often the situation that one process will
  produce output that another process needs for
  input.
• Rather than having the first process write to a
  file and the second process read that file, we
  can save time by having each process communicate
  via a pipe.

33
Pipe and Performance

• Using a pipe can improve system performance in
  two ways
• By not using a file, the applications save time
  by not using disk I/O.
• A pipe has the characteristic that the receiving
  process can read whatever data has already been
  written. Thus we do not need to wait until the
  first process has written all of the data before
  we start executing the second process. This
  creates a pipeline similar to an automobile
  assembly line to speed up overall performance.

34
8.4 Directory Functions

• Search for a file
• Create a file
• Delete a file
• List a directory
• Rename a file
• Traverse the file system

35
8.5 File Space Allocation

• Contiguous
• File is allocated contiguous disk space

36
File System Implementation

• A possible file system layout

A Master Boot Record (MBR) is a special type of
boot sector at the very beginning of partitioned
computer mass storage devices. The MBR holds the
information on how the logical partitions,
containing file systems, are organized on that
medium.
37
Implementing Files (1)

• (a) Contiguous allocation of disk space for 7
  files
• (b) State of the disk after files D and E have
  been removed

38
Contiguous Allocation

• Advantages
• Simple to implement
• Good disk I/O performance
• Disadvantages
• Need to know max file size ahead of time
• Probably will waste disk space
• Necessary space may not be available

39
Contiguous Allocation
Read/Write Disk Address Calculation
40
8.5.1 Cluster Allocation

• Cluster Allocation
• Disk space allocated in blocks
• Space allocated as needed

41
Cluster Allocation
42
Implementing Files (3)

• Linked list allocation using a file allocation
  table in RAM

43
Implementing Files (4)

• An example i-node

44
Cluster Allocation

• Advantages
• Tends not to waste disk space
• Disadvantages
• Additional overhead to keep track of clusters
• Can cause poor disk I/O performance
• May limit maximum size of File System

45
Cluster Performance

• Clusters tend to be scattered around the disk
• This is called External Fragmentation
• Can cause poor performance as disk arm needs to
  move a lot
• Requires De-fragmentation utility

46
Cluster Performance

• Large clusters can reduce External Fragmentation
• If lots of small files, then space will be wasted
  inside each cluster
• This is called Internal Fragmentation

47
Managing Cluster Allocation

• Linked
• Each cluster has a pointer to the next cluster
• Indexed
• Single table has pointers to each of the clusters

48
Linked Blocks
49
Index Block
50
8.6 Real-World Systems
51
8.6 Real-World Systems

• Microsoft FAT
• Microsoft NTFS
• Linux Ext2, Ext3
• Others

52
8.6.1 MS FAT System

• Fat16 (FAT file allocation table )
• MS-Dos, Windows 95
• Max 2GB space for a FileSystem
• Generally bad disk fragmentation
• Fat32
• Windows 98
• Supported by Windows 2000, XP, 2003

53
The MS-DOS File System (1)

• The MS-DOS directory entry

54
The Windows 98 File System (1)
Bytes

• The extended MOS-DOS directory entry used in
  Windows 98

55
Cluster Sizes of FAT16 and FAT32
Drive Size Default FAT16 Cluster Size Default FAT32 Cluster Size
260 MB511 MB 8 KB Not supported
512 MB1,023 MB 16 KB 4 KB
1,024 MB2 GB 32 KB 4 KB
2 GB8 GB Not supported 4 KB
8 GB16 GB Not supported 8 KB
16 GB32 GB Not supported 16 KB
gt 32 GB Not supported 32 KB
56
Windows FAT Table
57
8.6.2. Windows NTFS File System

• The NTFS file system (New Technology File System)
  is based on a structure called the "master file
  table" or MFT, which is able to hold detailed
  information on files. This system allows the use
  of long names, but, unlike the FAT32 system, it
  is case-sensitive, which means that is capable of
  distinguishing lower-case and upper-case letters.

• Available on Windows 2000, XP, 2003
• Maintains transaction log to recover after reboot
• Support for file protection
• Large (64 bit) cluster pointers
• Allows small clusters
• Avoids internal fragmentation

58
Windows NTFS File System
Master File Table containing records about the
files and directories of the partition. The first
record, called a descriptor, contains information
on the MFT (a copy of it is stored in the second
record). The third record contains the log file,
a file containing all actions performed on the
partition. The following records, making up what
is known as the core, reference each file and
directory of the partition in the form of objects
with assigned attributes.
59
File System Structure (1)

• The NTFS master file table

60
File System Structure (2)

• The attributes used in MFT records

61
File System Structure (3)

• An MFT record for a three-run, nine-block file

62
8.6.3 Linux Ext2 and Ext3 File System

• Ext2
• Ext2 stands for second extended file system.
• It was introduced in 1993. Developed by Rémy
  Card.
• Maximum individual file size can be from 16 GB to
  2 TB
• Ext3
• Ext3 stands for third extended file system.
• It was introduced in 2001. Developed by Stephen
  Tweedie.
• Starting from Linux Kernel 2.4.15 ext3 was
  available.
• Maximum individual file size can be from 16 GB to
  2 TB

63
UNIX File System (1)

• Disk layout in classical UNIX systems

64
UNIX File System (3)

• The relation between the file descriptor
  table, the open file description

65
UNIX File System (2)

• Directory entry fields.

Structure of the i-node
66
The Linux File System

• Layout of the Linux Ex2 file system.
