E-learning

1
E-learning

• Basic Knowledge

2
Hand tools market positioning
Aerospace level It is higher than industrial
level to request products quality with the strict
way.
Industrial level It is higher than professional
level to request higher product quality.
Professional level Its the basic level of
professional hand tools.
DIY level Its for general use.
3
Market place
Market segmentation Major sales channel
DIY level 1. Normal user 2. General family
Professional level 1. Automobile repair factories 2. The maintenance of general machines and equipments 3. The maintenance of agricultural machines
Industrial level 1. Manufacture and assembling line for vehicles 2. Mining industries 3. The petroleum industries 4. The public projects 5. Other industries
Aerospace level 1. Aircraft manufacturing industries 2. Aerospace industries
4
The difference between Hexagonal and 12 angular

• The difference between Hexagonal and 12 angular
  points on the socket
• 1. Timing
• The hexagonal is traditional shape, but the 12
  angular is later than Hexagonal .
• 2.Function
• The angle of 12 angular are the double angles of
  hexagonal. When you used the wrench to put into
  screw, the hexagonal wrench needs 60 angle, but
  12 angular wrench needs 30 angle. (As figure)
• 3.Size
• The functions and size of the 12 points type is
  the same with the 6 points type and its inner
  part is serrate. It can be fitted with the
  screws head or bolts more closely, its shape
  looks like plum blossom, so it also known as plum
  blossom type.

The red frame is hexagonal and the black frame
is 12 angular.
5
What is the function of the wrenchs angle? 0
,15 ,45 , 75

• To choose various angle wrenches is mainly based
  on using places or the depth of the screws in the
  machines.
• Description
• If the users used the tool non-smoothly, it might
  be caused the space limited or machines location
  problem. In order to use the tools conveniently,
  we design various angle wrenches when we produced
  them.

6
The 0 or 15 of Wrench is suitable for
disassembling the screws without depth.
If there is a little depth for its screws, the
user cant use with 15 wrench.
The user may need to choose its angle of wrench
according to hows depth of its screws.
7
What is the difference of the teeth application
for ratchet ?

• Due to the different number of teeth, the main
  difference is the angle of rotation. The circle
  is 360 degrees. When the numbers of teeth is
  bigger, each tooth is assigned to the smaller
  angle. (As figure)
• For example,
• When the head of ratchet is 72 teeth, the angle
  of each tooth is 5. In other hand, when the head
  of ratchet is 24 teeth, the angle of each tooth
  will be 15.

8
Advantages and disadvantages

• The users set ratchet into screw or socket when
  they used it.
• They usually turn the body of ratchet to use it.
• If the angle of teeth is smaller, then you can
  use less force on turning its angle. When repair
  technician fixed the car in a narrow place, he
  cant use bigger turning angle.
• However, the advantage of ratchet head has less
  teeth
• The structure of driver and pawl contradict each
  other. (As Figure)
• The teeth are lesser, so the structure is more
  stronger.

9
The types of Bit/Bit socket

• The using ends divide into 8 type
• PHILLIPS
• SLOTTED
• POZIDRIV
• HEXAGON
• TORX
• TORX
• -TAMPER RESISTANT

RIBE BIT Socket TORX-TAMPER Internal XZN
SQUARE
10
The ratchet of Quick-release

• The ratchet has two using functions that divide
  into PUSH and NO PUSH.( As figure)

11
The sockets add the friction with handle and
ratchet when setting sockets doesnt shake, so
they process bead groove in the square hole. The
bead groove of sockets gets stuck the bead of
connector. The PUSH and NO PUSH buttons of
ratchet are designed for the bead groove.
12
PUSH function

• The ratchet has direction button which controls
  the clockwise and counterclockwise and circle
  button which uses to set or disassemble sockets.
  These are two functions
• 1. The steel ball will sink when you press the
  circle button, so it can reduce the resistance to
  set the socket.

• 2. The socket cant be taken off if you dont
  press the circle button, so it can prevent the
  socket falling and causing an accident.

(Picture 1) The steel ball will sink when you
press the circle button.
13
(Picture 2) It is convenient to set the socket.
The socket cant set into the ratchet when you
dont press the button.
(Picture 3) When you dont press the button, you
cant take off socket from the ratchet. (When
working on the high altitude, it can prevent from
socket dropping and causing danger.)
14
The specification of screws for screwdriver
bits
15
The specification of the screwdrivers PHILLIPS
/ POZIDRIV head
16
The specification of the screwdrivers - SLOTTED
head
17
The specification of the screwdrivers Star
Socket
The specification of the screwdrivers-TORX head
18
The specification of the screwdrivers- Hex driver
The specification of the screwdrivers- Nutspinner
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
The simple description of tools classification

• According to its power sourcing , there are two
  different kind of tools.

Driving force Products category Difference Difference Difference
Driving force Products category Torque Speed Price
Human force Hand Tools Small Slow Cheap
Mechanical force Pneumatic Tools Big Quick A little expensive
Mechanical force Electrical Tools Middle Quick Expensive
Mechanical force Hydraulic Tools More big Slow Expensive
24
The description of the hand tools
Wrenches category Pictures Purpose Using place
Open End Wrenches(1900) 75 Offset Ring Wrenches(1970)Combination Wrenches (1060) It is used to lock/unlock the Hex Screws and nuts in the industrial machines, motorcycles, and automobiles. It is used to lock/unlock the Hex Screws and nuts in the factories, garage, and motorcycles stores. The 45 and 75 Offset Ring Wrenches are used in the place where has the gas between high and low.
Ball Hex Key(1130) It is used to lock/unlock the Hexagon Screws in the industrial machines, motorcycles, and automobiles. It is used to lock/unlock the Hex Socket Screws in the factories, garage, and motorcycles stores.
Adjustable Wrenches (3611-10P) It is used to lock/unlock the Hex Screws or nuts in the industrial machines, motorcycles, and automobiles. The using side can be adjusted. It is used to lock/unlock the Hex Screws or nuts in the factories, garage, and motorcycles stores. The using side can be adjusted.
25
Wrenches category Pictures Purpose Using place
Star L-wrench(1143) It is used to lock/unlock the screws in the industrial machines, motorcycles, and automobiles. It is used to lock/unlock screws in the factories and automobiles / motorcycles repair factories
Angled Socket Wrenches (1081) It is used to lock/unlock the nuts in the machines. It is used in the factories and automobiles / motorcycles repair factories
Speed Wrenches (373Xseries) It is used to lock/unlock quickly the screws and nuts in the industrial machines, motorcycles, and automobiles. It is used in the factories and automobiles / motorcycles repair factories
Flare Nut wrenches(1930US) It is used to lock/unlock the screws or nuts of oil pipes in the industrial machines, motorcycles, and automobiles. It is used in the factories and automobiles / motorcycles repair factories
Wrench (1941) It is used to adjust the tension of the bead wire. It is used to adjust the tension of the bead wire in the bicycles stores.
26
Wrenches category Pictures Purpose Using place
Universal joints The universal joint which is also known as universal coupling. Its used to add the difference using angle and space. Factories and Automobiles / Motorcycles repair factories
Spark Plug Socket The Spark Plug Socket is used to lock/unlock the spark plug. Automobiles / Motorcycles repair factories
Star Socket It is used to lock/unlock the star screws on the motorcycles and automobiles. Automobiles / Motorcycles repair factories
T-type Universal Socket Wrench It is used to lock/unlock the screws in the all angle of workplace. Factories and Automobiles / Motorcycles repair factories
Standard/Deep Socket It is used to lock/unlock the Hex Screws or 12 points screws. Factories and Automobiles / Motorcycles repair factories
27
Screwdriver with BIT Pictures Purpose Using place
Standard Screwdriver (PHILLIPS/SLOTTED head) It is used to lock/unlock the screws. Its used in the industry and machine maintenance.
Insulated Screwdriver It is used to lock/unlock the screws in the using electrical site or electric shock site. It is used to lock/unlock the screws in the using electrical site or electric shock site.
