Title: Hydraulic Symbols Exercise


1
Hydraulic Symbols Exercise
2
Normally Closed 2/2 DCV
3
Normally Open 2/2 DCV
4
4/2 DCV
5
4/3 DCV
6
4/2 DCV Lever Spring
7
4/2 DCV Lever Detent
8
Unidirectional Fixed Displacement Pump
9
Unidirectional Variable Displacement Pump
10
Bi-directional Fixed Displacement Pump
11
Double Acting, Differential, Cushioned Linear
Actuator
12
Semi-Rotary Actuator
13
Pressure Gauge
14
OR Valve
15
AND valve
16
Pressure Relief Valve
17
Filter
18
Fixed Restrictor
19
Check Valve or Non Return Valve
20
Restrictor with Bypass
21
Hydraulic Tank
