[e-mail] August, 2002

1
ASAP 2.2 Update
Availability What is ASAP DOTs API OEM 2.x
Update EDL Directions
m.miller_at_hp.com
ITUG Summit 2002 2731 October San Jose,
California EM-08-HP

• m.miller_at_hp.comAugust, 2002

Presentation contains animation sequences that
are best viewed in slide show mode. A colon
character at the end of a slide bullet indicates
when to click the mouse button to advance
animation
2
ASAP 2.2Update
Availability What is ASAP DOTs API OEM 2.x
Update EDL Directions

• m.miller_at_hp.com

Presentation contains animation sequences that
are best viewed in slide show mode. A colon
character at the end of a slide bullet indicates
when to click the mouse button to advance
animation
3
Overview
Contents

• ASAP Resources
• Internet - http//NonStopAsap.Com
• Manuals - TIM Independent Products CD
• Training - Technical Update Training CD 30
• Presentation Provides Overview of
• Availability concepts
• What is ASAP?
• Release 2.0, 2.1, 2.2 update examples
• Before discussing ASAP
• Its important to understand, why monitor
  availability?
• Its because monitoring increases actual
  availability.
• To understand why, first discuss availability
  concepts.

4
Dependencies
Availability

• Scenario - Person needs Taxi
• Has No Cash... so needs ATM
• Assumes ATM will be Available
• Availability has many dependencies

Right Card.. Valid Pin.. Remember Pin.. No Line..
Atm Up.. Network Up.. Routers Up.. Server Up..
Application running.. Account valid.. Balance
OK.. Atm ?
5
Is a Relative Notion
Availability

• Scenario - Person in hurry - Has 2 minutes to
  catch Taxi
• If there is a long line, for example Q10
• Even though ATM is Operational
• For User at end of the line
• ATM is NOT Available

6
Service Level Objectives
Availability

• People define Availability according to their
  objectives.
• Formal notion is called - Service Level
  ObjectivesEasy to remember, if SLO not met...
  things slow down.
• ATM Service Level Objectives - Taxi fare
• Status Up
• Queue 0
• Cash 20

7
Varies with Usage
Availability

• User definition of Availability varies with
  usage.
• Definition of ATM Availability is different for
  20 Taxi fare versus 300 Air fare
• Goal ATM
• Status Up
• Queue 0
• Cash 20

8
Depends on Application
Availability

• Availability depends on how you intend to use
  object.
• People define Availability based on their own
  criteria.
• Goal Air Fare
• Status Up
• Queue 0
• Cash 300

• What if Air Fare were 800?
• Would ATM be available?
• Depends on Policy, not Hardware.

9
Review
Availability

• Availability
• Has many Dependencies
• Is a relative Notion
• Depends on Usage or Application
• Can be defined with Service Level Objectives
• To provide true High Availability Enterprise
• Cannot just Monitor Hardware Operating System
• But must also Monitor Availability of Application
  Domains
• External Monitoring inadequate Apps Hang, Loop,
  Deadlock
• External Monitoring cant know about internal
  domains values
• If Application Domain Service Levels are not
  monitored, its impossible to know when an
  enterprise becomes unavailable.

10
Availability Monitoring Infrastructure
WhatisASAP?

• An Availability Monitoring Infrastructure
• For NonStop Servers
• Engineered specifically for NonStop Server
  Architecture
• Provides NonStop Server Agents, Process-Pairs,
  Fault-Tolerant DB,and published API for
  applications.
• Automatically Restarts/Reconfigures when Cpus
  and/or Devices go up/down.

11
Not an Enterprise Management Framework
WhatASAP is NOT

• ASAP is not an enterprise management framework
  such as Unicenter, NetView, OpenView, ...
• ASAP is availability monitoring infrastructure
  for NSK
• Engineered specifically for NonStop servers
• Includes deep system and subsystem agents
• Includes massively-parallel shared-segment API
• Includes patented provider interface 6301557
• Provides wide-variety of public interfaces

12
Interfaces
ASAPInterfaces

• ASAP Public interfaces
• Tandem EMS Events
• SNMP Agent Traps
• Provider/Consumer API
• Plug-in 3rd party Entities
• Published Database
• Batch Query Interface
• Conversational Interface
• Graphical User Interface
• Web Viewpoint interface
• Optional EMF interfaces

02-09-17 114201 TANDEM.ASAP.V02 ASAP
ALERT Atm Chicago\Atm Status Cash 150 02-09-17
114201 TANDEM.ASAP.V02 ASAP ALERT File
Data.App.Cash RWEP nnnn 02-09-17 114202
TANDEM.ASAP.V02 ASAP ALERT Process App2
Status Down 02-09-17 114902 TANDEM.ASAP.V02
ASAP ALERT Funds\Transfer Status Lost
Trans 02-09-17 114902 TANDEM.ASAP.V02
ASAP ALERT Expand Lhny Status
Connecting 02-09-17 114902 TANDEM.ASAP.V02
ASAP ALERT Disk Data Full gt 95
13
How does ASAP work?
HowASAPWorks

• Monitors
• Status
• Performance

• Objectifies
• Information into Object-State DB

• Reports
• Results

• Analyzes
• Service Level Objectives
• Determines Availability

14
Monitoring
ASAPMonitoring

• ASAP Monitors both Status and Performance of
  System objects and Application domains
• Status refers to
• Qualitative Attributes, such as Up, Down,
  Warning...
• Performance refers to
• Quantitative Attributes, such as Busy, Queue,
  Rate, ...
• System Objects are
• Subsystems or components, such as File, Rdf,
  Spooler, Tmf,
• Application Domains are
• Abstract Domains of Service, such as
  Accounts\Payable, Funds, Sales, ...

15
Objectification
ASAPObjectification
ATM Cash 150

• ASAP Objectifies
• Status and performance information into
  normalized object-state data base
• Objectification provides basis
• For Analysis and Visualizationof whether objects
  meet their Service Level Objectives.

16
Analysis
ASAPAnalysis

• ASAP Analyzes Object
• Status and Performance
• Compares Service Objectives
• Determines Object Availability

ATM WARNING Cash 150
Analysis
Availability
Availability
ATM Cash 150
17
Reporting
ASAPReporting

• ASAP Reports Availability Info
• Many different ways...EMS, Traps, DB, CI, WebVpt
• Information is mapped onto a Uniform State Model
• Also includes Analysis GUI
• Tree
• Graph
• Grid Views
• Context sensitive
• Popup menus can be displayed on any object
• Analysis Includes
• Color synchronized
• Graph elements
• Grid elements
• State icons

TreeGraphGrid
18
State Propagation
ASAPStatePropagation

• ASAP Provides a uniform
• Browsing paradigm for access to monitored objects
• Tree View
• Allows object navigation
• Access to many objects
• Drives Graph/Grid views
• State Information
• Propagated upward in tree
• Provides guide to state of nodes, entities, and
  objects
• State info always visible even if tree is
  collapsedExample - Newyork

19
Availability Vectors
ASAPAvailabilityVectors

• Easy to assume ASAP just
• Graphs Data Colors Elements.
• Easy to Underestimate Content.
• Includes Analysis Engine.
• Determines Availability
• Based on user defined rules.
• Each PropertyAvailability Vector
• Allows Availability Graphs/Icons
• Result, Visual Display combines
• Alpha, Numeric, Status,
• Performance, SLOs all
• Together in uniform paradigm
• 3D, Color-Coded, Graphical display
• Human mind good at patterns...
• Faces, Buildings, Automobiles...

20
DOTs - Discrete Object Thresholds
ASAPService-Level Objectives

• ASAP DOTs Hierarchical Service-Level
  Objectives
• Rank Atm, Cash gt 1500
• Rank Atm Zeist, Cash gt 3000
• Rank Atm Zeist\North, Cash gt 4500
• Rank Cpu 7, Busy lt 60, Queue lt 3, Swaps lt 6
• Rank File Data.Master.Accounts, Full lt 80
• Rank File System.System.Userid RWEP oooo
• Dynamic Inclusion-Exclusion
• Monitor Cpu, ON
• Monitor Cpu 7, OFF
• Monitor Disk, ON
• Monitor Disk Data2, OFF
• Monitor Process App5, ON
• Monitor File System.System.Userid

21
Architectural Overview
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• Right side of diagram
• Represents Provider functions
• Including Smart Agents.

• Left side of diagram
• Represents Consumer Functions.
• Includes Agent/Analysis Features.

22
Smart Gathering Processes - SGPs
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• Smart Gathering Processes - SGPs
• Collect Status Performance info
• Store Stats in ASAP history data base

23
Service Level Objectives
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• SGPs also provide Service Level Objectives.
• SGPs inform you when SLOs are not met.
• Tell you what objects did not meet objectives.
• DB also provides history of failed objectives.

24
Application Program Interface - API
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• ASAP includes published API for application
  access.
• Allows Customer-Third Party access to
  infrastructure.
• Allows you to utilize all ASAP Client/Server
  functions.
• API is a shared-seg, high-performance,
  architecture.
• API calls include ASAP_Register, ASAP_Update.

25
Massively-Parallel Shared-Segment API
ASAP MPS2 Architecture

• ASAPs Massively-Parallel Shared-Segment API
  Architecture
• Allows deep application domain API integration
• Engineered for NonStop server MP architecture
• Ultra-fast, non-blocking, interface - Apps never
  wait
• Efficient stats collection, aggregation,
  objective alerts

26
ASAP Extension API
ASAPXAPI
Data_item - Defined by EDL Value - Defined
by application Math 0 - Add Value to
Data_itemMath 1 - Assign Value to
Data_itemMath 2 - Assign Text to Data_item
27
ASAP API Example TeleBanking Web Server
ASAPXAPI
28
ASAP API Example - BASE24 plugin
ASAPXAPI
29
ASAP API Example TCPIP plugin
ASAPXAPI
30
API Service Level Objectives
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• API also monitors Service Level Objectives for
  Apps
• Informs you when Application SLOs are not met.
• Tells what Apps did not meet objectives.
• DB also provides history of failed App
  objectives.

31
Data Base
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• ASAP DB contains normalized object info.
• DB history is automatically maintained.
• Includes Object, State, Performance, Service
  Objectives
• DB Schema published in TIM, and DDL is on CD.
• Allows Customer Third Party DB access.

32
ASAP Client
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• Asap Client provides analysis agent functions.

• Allows viewing of Availability, Performance, and
  SLOs.
• Uses standard Windows visualization paradigm.

33
Client as Analysis Tool
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPClient
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• Client displays analysis using Graph, Grid,
  Tree, Report Windows.
• Users can select their own sets of Entities,
  Objects, and Properties.
• Users can also specify their own sets of State
  Propagation Rules.
• All graphical objects automatically update in
  real-time.

34
Client as Object-State Provider Agent
ASAPArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
OIL
OEM
ASAPAgent
ASAPServer
X Adapter
Enterprise Management Framework
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
AlertsWindow
Y Adapter
Enterprise Management Framework
Y
? Adapter
Enterprise Management Framework
...

• ASAP can also act as an Object-State Provider.
• Utilizes the OEM Gateway to export Object-State
  information to EMFs.
• OEM also provides Alert Windows, with sorted
  highest-to-lowest state views.
• OEM acts as a multi-ported, bi-directional,
  Enterprise-Management Gateway

35
What is Open Enterprise Management gateway
WhatisOEM?

• OEM is not an enterprise management framework
  such as Unicenter, NetView, OpenView, ...
• OEM is an Object-State gateway to EMFs
• Reports Application domain Object-States
• Reports System Subsystem Object-States
• Optionally forwards object-state info to EMFs
• Uses patented OEM provider API 6301557
• OEM API published in TIM protects investment.
• Allows change from one Enterprise Management
  solution to another without changing apps or
  agents.

36
OEM Gateway to EMFs
OEMArchitecture
Workstation
Local Node
Remote Nodes
OIL Adapter


Enterprise Objects
Object Integration Layer
Open EnterpriseManagementGateway
ASAP Client
ASAP Server
ASAPServer
Cpu
OIL
Disk
OEM
ASAPAgent
Expand
ASAPServer
Process
X Adapter
Enterprise Objects
Enterprise Management Framework
ASAPExtension
Collector
X
ASAP Database App Cpu Disk Expand Process
Analysis Reports Graphs Grids Trees
...
AlertsWindow
...
API
Y Adapter
Enterprise Objects
Enterprise Management Framework
ASAP
...

Y
...
? Adapter
Enterprise Management Framework
...

• OEM Provides API to EMFs via Adapters
• Adapters handle Framework specific APIs
• Leverages Enterprise Framework Expertise
• Allows integration with different Frameworks

• Simplifies Client/Agent API Interface
• Minimizes impact on Applications
• Application-Agent Interface coded once
• Handles Client Object-State arbitration

37
ASAP OEM - Custom Adapter view
ASAPOEM

• Consumer Adapter Left
• OEM Provider - Right
• Adapter Consumes Object-State information..
• - Displays Updates
• - Calls Back on Query
• OEM Options Dialog- Allows adding Adapters

38
ASAP OEM - EMF Adapter view
ASAPOEM
39
ASAP OEM - Standard Alerts view
ASAPOEM
40
ASAP 2.x Update
ASAPStatus Update

• New features and fixes during last year
• Release 2.0 June 2001
• Discrete Object Thresholds Add service level
  objective monitoring
• 6 New System Entities All old entities
  reworked for DOTs EMS
• Entity Definition Language Provide extensible
  environment
• Custom Namespace, Icons, and Colors Addressed
  I18N
• Release 2.1 Nov 2001
• Availability Events EMS, Web ViewPoint,
  OpenView Traps
• EMS availability events - Extended to include
  object status
• 37 new features and minor bug fixes Extreme
  reliability
• Release 2.2 June 2002
• EDL compiler performance improved 403 -
  Ansi?Unicode
• Support for regional language locales -
  internationalization
• 12 New plug-in entities - total entities number
  in 100s

41
New Entities
ASAPStatus Update
Plug-ins
42
DOTs Feature Summary
ASAPStatus Update

• Provides uniform Service Level Objectives for all
  entity types
• Uniform Object-State model now applies to all
  object types
• All Objects Objectives can be changed on the
  fly
• Dynamic re/definition of Service Level Objectives

• Support instant, massive SLO reconfiguration
• Dynamic addition and/or removal of Objects
• Tokenized EMS events

43
Icons Colors
ASAP Status Update

• Release 1.0 - Fixed set of Icons Alert Colors
• Release 2.x - Allows User Defined Icons Colors
• Custom State Icons
• Custom Alert Colors
• Address Internationalization

44
EMS Events
ASAP Status Update

• DOTs - Service Level Objective - Availability
  Events
• EMS Events now Logged when DOTs SLO objectives
  are not met.
• Event Generation Options include
• INFO
• CRITICAL
• REPEAT
• DISPLAY
• Burst Suppression on EMS events
• Eliminates Event Avalanches
• Includes Burst Summary Reports

45
EDL Overview
ASAP Status Update

• ASAP R2 - Design Goals Realized...
• Provide extensible Entity Definitions
• Allow Customer Applications to define and add
  Entities.
• Allow Third Party EMF access to all Entity
  types.
• Provide entity-attribute Name-Space
• Allow DOTs to use entity-attribute Names, instead
  of metric ids.
• Allow users to customize entity-attribute Names
  (internationalization)
• Provide Version Independent code
• Support Mixed version code environments and
  entity definitions
• Eliminate maintenance (R2 Client runs with R1,
  R2, 2.1, 2.2... Servers)
• Eliminate code changes (can add Entities without
  code changes)
• Single ASAP thread support of K-series, S-series,
  and Itanium.

46
EDL
ASAP Status Update

• What is EDL ?
• A meta-data language file that defines how
  NonStop Server availability domains relate to
  ASAP features and functions.
• Developers use EDL
• To define how to monitor Subsystem Availability
• To define how to monitor Application Availability
• EDL is not something that ASAP users
• Need to see,
• Understand,
• Or even be aware of

47
Why Care about EDL?
ASAP Status Update

• EDL was designed to define availability
  properties
• However EDL resulted in many additional benefits
• Allows users to have different sets of customized
  ASAP settings.
• Allows entire environments to be archived for
  later reference.
• Observed behavior can be shared with other ASAP
  users.
• ASAP environments can be mailed to other people.
• Useful for Application and System reporting.
• Both Schema and Data can be stored in EDL files
• Allows an entire ASAP environment to be saved in
  an EDL file.
• Means you can completely snapshot or capture
  situations.
• Means you can snapshot your entire system/app
  configuration.
• EDL Files can be saved, mailed, reviewed, and
  displayed.

48
EDL 2.x Features
ASAP Status Update

• Externalizes Definition Customization of
• Entity Names
• Attribute Names
• Help Text
• Heading Text
• Availability Vectors
• Data Integrity Checks
• State Determination Rules
• Graph Normalization Values
• Data Formatting Alignment
• Command required to retrieve data
• and any other ASAP property that is related to
  Entity-Attribute definitions.

49
EDL Container Files
ASAP Status Update

• EDL File - Contains Entity Definition Language
• EDL File - provides Container for ASAP
  properties
• EDL File - allows ASAP properties to be
  Portable.
• Provides Portable encapsulation of ASAP
  Properties.
• Entities, attributes, and data can be moved
  around.
• You can save/share different ASAP environments.
• Client registers the .EDL extension with Windows.
• EDL also allows DATA to be included in an EDL
  File.
• Allows Data to be associated with
  Entity-Attribute definitions.
• Entities, Attributes, Data are encapsulated all
  together

50
ASAP EDL Interactive Development Environment
ASAP Status Update
51
EDL Features
ASAP Status Update

• EDL allows encapsulation of entire ASAP
  environment.
• EDL Provides a way to
• Have different sets of customized ASAP settings.
• Save your current environment for later
  reference.
• Mail your entire ASAP environment (with data) to
  others.
• Share observed behavior with other ASAP users.
• EDL also useful for
• Problem Reporting - Capture entire environment.
• Prototyping Entity, Attribute, Data
  definitions.
• Version Independence - due to encapsulation.
• Education Demo features of environment.
• QA/Testing - Reproducing test scenarios.

52
EDL Summary
ASAP Status Update

• EDL Defines how Application Entities and
  Attributes relate to ASAP features, functions,
  and infrastructure.
• Developers use EDL to define how to Monitor
  Availability
• EDL is not something that ASAP users
• Need to see,
• Understand,
• Or even be aware of

53
ASAP Futures
ASAP Futures

• ASAP
• Ongoing massively-parallel architectural
  enhancements to overall infrastructure
• Performance enhancements always a goal eg
  403 faster EDL compiler v2.2
• Monitor command enhancements, multiple objects,
  improved advisory messages
• Process hierarchical-logical-name-grouping of
  Processes and their Aggregates
• SGP placement, eg Disk, Expand, File, Process,
  Spooler, RDF, TMF, Tape
• SHOW command display flags rank-able state pair
  attributes
• Misc Discrete Objective Threshold (DOTs)
  enhancements
• ASAPX
• Larger and variable numbers of Data Items
• In-Memory Detail Record retrieval (cordwood)
• Java package for simplified access from Java
• Allow finer Data Item Aggregation Control in
  ASAPX
• Slot re-use of same domain for temp process names
  (X, Y, Z)

54
ASAP - OpenView Futures
ASAP Futures

• OpenView will become another strategic interface
  for ASAP
• ASAP OEM architecture will continue to be
  supported
• OVO Survey available at http//NonStopAsap.com
• Requesting input to help define OVO
  alternatives.
• ASAP integration research for OVO underway
• Actively Seeking Interested EAP Sites
• Please Fill Out ASAP - OVO Survey

55
Availability Summary
ASAP Summary

• Definition of Availability is subjective. It
  depends on how you intend to use object.
• Studies indicate if you monitor
  AvailabilityActual object Availability is
  increased...
• If Application Service Levels are not monitored,
  you will not know when Applications become
  unavailable.
• ASAP provides both Availability monitoring, and
  Service-Level Objectives monitoring.

56
ASAP 2.x Release Summary
ASAP Summary

• ASAP 2.x - Uniformly Extend Features to overall
  ASAP infrastructure
• Allow concurrent Customer/Third party access -
  Multi-Entity Apps
• Add Subsystem Monitoring - File, Process, RDF,
  Spooler, TMF, ...
• Add Service-Level-Objectives For both new old
  entities
• Add Service-Level Events - Satisfying EMS
  Requirements
• Add Custom Namespace, Icons, Colors -
  Internationalization
• Add Object State Change Views Allows
  reaching-back in time
• Permit External Entity definitions - Entity
  Definition Language
• Shift Focus from that of system monitoring
  Point-Product to a Fault-Tolerant Availability
  Monitoring Infrastructure for NonStop Server
  Subsystems and Applications.
