Lustre File System Evaluation at FNAL

1
Lustre File System Evaluation at FNAL
Stephen Wolbers for Alex Kulyavtsev, Matt
Crawford, Stu Fuess, Don Holmgren, Dmitry
Litvintsev, Alexander Moibenko, Stan Naymola,
Gene Oleynik,Timur Perelmutov, Don Petravick,
Vladimir Podstavkov, Ron Rechenmacher, Nirmal
Seenu, Jim Simone Fermilab

• CHEP'09, Prague
  March 23, 2009

2
Outline

• Goals of Storage Evaluation Project and
  Introduction
• General Criteria
• HPC Specific Criteria
• HSM Related Criteria
• HEP Specific Criteria
• Test Suite and Results
• Lustre at FNAL HPC Facilities Cosmology and LQCD
• Conclusions

3
Storage Evaluation

• Fermilab's Computing Division regularly
  investigates global/high-performance file systems
  which meet criteria in
• capacity, scalability and I/O performance
• data integrity, security and accessibility
• usability, maintainability, ability to
  troubleshoot isolate problems
• tape integration
• namespace and its performance
• Produced a list of weighted criteria a system
  would need to meet (HEP and HPC) FNAL CD DocDB
  2576
• http//cd-docdb.fnal.gov/cgi-bin/ShowDocument?doci
  d2576
• Set up test stands to get experience with file
  systems and to perform measurements where possible

4
Storage Evaluation

• Additional input for evaluation
• File system documentation
• Design and performance of existing installations
• Communications with vendor/organization staff
• Training
• The focus of this talk is our evaluation of
  Lustre
• Most effort so far concentrated on general
  functionality and HPC (Cosmological Computing
  Cluster and Lattice QCD)
• We are in process of evaluating Lustre for HEP
• Lustre Installations
• Preproduction and production systems on Cosmology
  Computation Cluster
• LQCD Cluster

5
Storage Evaluation Criteria

• Capacity of 5 PB scalable by adding storage units
• Aggregate I/O gt 5 GB/s today scalable by adding
  I/O units
• LLNL BlueGene/L has 200,000 clients processes
  access 2.5PB Lustre fs through 1024 IO nodes
  over 1Gbit Ethernet network at 35 GB/sec
• Disk subsystem should impose no limit on sizes of
  files. The typical file used in HEP today are 1GB
  to 50GB
• Legend for the criteria
• Means satisfies criteria
• Means either doesnt satisfy or partially
  satisfies criteria
• Not tested
• green - example exists
• purple coming soon
• red needs attention

5
6
Criteria Functionality

• Storage capacity and aggregate data IO bandwidth
  scale linearly by adding scalable storage units
• Storage runs on general purpose platform.
  Ethernet is primary access medium for capacity
  computing
• Easy to add, remove, replace scalable storage
  unit. Can work on mix of storage hardware. System
  scales up when units are replaced by ones with
  advanced technology.
• addition and replacement are fine
• removal still has issues

7
Criteria Namespace

• Provides hierarchical namespace mountable with
  POSIX access on apx. 2000 nodes (apx. 25,000
  nodes on RedStorm at SNL)
• Supports millions of online (and tape resident)
  files
• 74 million _at_ LLNL.
• Client processes can open at least 100 files, and
  tens of thousands files can be open for read in
  the system. We have not tested this requirement,
  but Lustres metadata server does not limit the
  number of open files
• Supports hundreds metadata ops/sec without
  affecting I/O
• The measured meta data rate is by factor 10-100
  better
• It must be possible to make a backup or dump of
  the namespace metadata without taking the
  system down
• We perform hourly LVM snapshots, but we really
  need the equivalent of transaction logging

8
Criteria Scaling Data Transfers and
Recovery

• Must support at least 600 WAN and 6000 LAN
  transfers simultaneously, with a mixture of
  writes and reads (perhaps 1 to 4 ratio). One set
  must not starve the other
• Must be able to control number of WAN and LAN
  transfers independently, and/or set limits for
  each transfer protocol
• Must be able to limit striping across storage
  units to contain the impact of a total disk
  failure to a small percentage of files
• Serving hot files to multiple clients may
  conflict with less striping
• We are interested in some future features
• file Migration for Space Rebalancing
• set of tools for Information Lifecycle Management

9
Criteria Data Integrity Security

• Support for Hashing or checksum algorithms.
• Adler32, CRC32 and more will be provided on
  Lustre v2.0. End-to-end data integrity will be
  provided by ZFS DMU
• System must scan itself or allow or allow
  scanning for the silent file corruption without
  undue impact on performance
• under investigation
• Security over the WAN is provided by WAN
  protocols such as GridFTP, SRM, etc.
• We require communication integrity rather than
  confidentiality
• Kerberos support will be available in Lustre v2.0

• ACLs, user/group quotas
• Space management (v2.x ? )

10
HPC Specific Criteria and Lustre

• Lustre on Computational Cosmology and LQCD
  clusters
• Large, transparently (without downtime)
  extensible, hierarchal file system accessible
  through standard Unix system calls
• Parallel file access
• File system visible to all executables, with
  possibility of parallel I/O
• Deadlock free for MPI jobs
• POSIX IO
• More stable than NFS (Computational Cosmology
  only)
• Ability to run on commodity hardware and Linux OS
  to reuse existing hardware

11
HSM-Related Criteria

• Integration of the file system sites HSM (e.g.,
  Enstore, CASTOR, HPSS) is required for use at
  large HEP installations
• The HSM shall provide transparent access to 10 to
  100 PB of data on tape (growing in time)
• Must be able to create file stubs in Lustre for
  millions of files already existing in HSM in a
  reasonable time
• Automatically migrates designated files to tape
• Transparent file restore on open()
• Pre-stage large file sets from HSM to disk.
  Enqueue many read requests (current CMS FNAL T1
  peak 30,000) with O(100) active transfers
• Evict files already archived when disk space is
  needed

12
Lustre HSM Feature

• Lustre does not yet have HSM feature. Some sites
  implement simple tape backup schemes
• HSM integration feature is under development by
  CEA and Sun
• HSM version v1.0
• Basic HSM in a future release of Lustre
  beta in fall 2009 ?
• Integration with HPSS (v1), others will follow
• Metadata scans to select files to store in HSM v1
• File store on close() on-write in HSM v2
• Integration work
• Work specific to the HSM is required for
  integration

13
HEP and general Criteria and Lustre

• GridFTP server from Globus Toolkit v4.0.7 worked
  out of the box
• BeStMan SRM gateway server is installed on LQCD
  cluster
• Storm SRM performance on top of Lustre is
  reported on this conference
• Open source, training and commercial support
  available
• Issues reported to Lustre-discuss list are
  quickly answered

14
Lustre Tests at Fermilab

• Developed test harness and test suite to evaluate
  systems against criteria
• Torture tests to emulate large loads for large
  data sets
• metadata stressor create millions of files
• Used standard tests against a Lustre filesystem
• data I/O IOZone, b_eff_io
• metadata I/O fileop/IOZone, metarates, mdtest
• Pilot test system was used to get experience and
  validate system stability
• Initial throughputs were limited by the disks
  used for Lustres data storage. Subsequent
  installations used high-performance disk arrays
  and achieved higher speeds.

15
Lustre Test System
Three to five client nodes Two data servers Each
node Dual CPU quad-core Xeon 16 GB mem Local
SATA disk 500 GB
16
Lustre Metadata Rates
Single client metadata rates measured with
fileop/IOZone benchmark
17
Lustre Metadata Rates
Aggregate metadata rate measured with metarates
benchmark for one to 128 multiple clients running
on 5 nodes 8 cores
18
Lustre on Computational Cosmology Cluster
125 Compute nodes
1Gb Ethernet Stackable Switch SMS 8848M
4 Lustre data Servers one shared with Metadata
Server 250 GB on LVM
Lustre DATA 2 SATABeasts 72 TB RAID6 2 12
LUNS 2 3 vol. 4 partitions
19
Lustre on FNAL LQCD clusters
IPoIB
IPoIB
Lustre Infiniband network 1 MetaData Server
4 file servers 72 TB data RAID6 two 4Gbit FC
per SATABeast
LCC Bldg.
750 GB RAID1
10 GigE
GCC Bldg.
20
Lustre Experience - HPC

• From our experience in production on
  Computational Cosmology Cluster (starting summer
  2008) and limited pre-production on LQCD JPsi
  cluster (December 2008) the Lustre File system
• Lustre doesnt suffer the MPI deadlocks of dCache
• direct access eliminates the staging of files
  to/from worker nodes that was needed with dCache
  (Posix IO)
• improved IO rates compared to NFS and eliminated
  periodic NFS server freezes
• reduced administration effort

21
Conclusions - HEP

• Lustre file system meets and exceeds our storage
  evaluation criteria in most areas, such as system
  capacity, scalability, IO performance,
  functionality, stability and high availability,
  accessibility, maintenance, and WAN access.
• Lustre has much faster metadata performance than
  our current storage system.
• At present Lustre can only be used for HEP
  applications not requiring large scale tape IO,
  such as LHC T2/T3 centers or scratch or volatile
  disk space at T1 centers.
• Lustre near term roadmap (about one year) for HSM
  in principle satisfies our HSM criteria. Some
  work will still be needed to integrate any
  existing tape system.

22

• Backup Slides

23
Lustre Jargon

• Client client node where user application runs.
  It talks to MetaData Server and data server (OSS)
• MDS MetaData Server - the node, one active per
  system
• MDT MetaData Target disk storage for
  metadata, connected to MDS
• OSS Object Store Server the node serving data
  files or file stripes
• OST Object Store Target disk storage for data
  files or file stripes, connected to OSS

24
What is Lustre?
Metadata Server
Lustre
Client Nodes (workers)
Data Storage
Data Servers
