EZ Positioning with SINAMICS S120 Testing Application

1
EZ Positioning with SINAMICS S120Testing
Application
2
Verify Control Word One

• Use VAR table in S7 Manager with Starter
  Diagnostics
• Open the VAR Table Online
• Open Starter Online
• Right Click on False of Bit 0.0 and force to 1.
• VAR Table included is addressed to DB120 if your
  test is for different DB you will need to edit
  VAR table

3
Verify Control Word One

• Open Control Logic in Starter and Observe Bit 0
• Toggle Bit O ON / OFF with VAR Table
• Off2, OFF3, and Enable are set Initially to 1 in
  the DB
• Initial Value can be changed by user
• OFF2 is Coast to Stop
• OFF3 is Quick Ramp Down Stop
• Enable is Pulse Enable to Drive

4
Notes on Control Word One

• Sequence order for Bits during Operation
• Bit 10 is High for PLC Control
• Off2, OFF3, and Enable are set to 1
• OFF1 (Bit 0) Transitions to 1 and remains high
• Control Word 1 is needed for Operation

5
Jogging Axis

• Use the VAR Table to Jog the axis
• Control Word 1 Bit 0 must be ON for Operation
• Set Bit 4.0 (Jog1) to True
• Override must be Changed to set Value (E.g. 4000
  Hex)
• Initial DB value for Accel and Decel is 4000 Hex
• Use Bit 62.1 for Jog 2

6
Verify Jogging of Axis

• Open Jog Folder to View Jogging
• All Motion Functions will be under Basis
  Positioner Folder

7
Verify Jogging of Axis

• Check Both Analog and Digital Setpoints
• Check Digital Setpoints and Checkback with Radio
  Buttons
• Check Analog Setpoints to see Override Velocity
  value
• Open Diagnostics Folder for more information
• Incremental Jogging can be set with a bit in the
  Instance DB

8
Jogging Setpoints

• Click on Configure Jog Setpoints
• Adjust setpoints if needed

9
Homing Axis for Absolute Value Encoders

• Homing for Incremental Encoders on next Slide
• Jog the Axis to the Desired Home Position
• Turn off JOG and ON bits in the VAR chart
• Open the Homing Folder (Basis Positioner /
  Homing)
• Click on the Homing Graphic for Active and
  Passive 1
• Choose Active Homing 2
• Perform Absolute Value Calibration

1
2
3
10
Incremental Encoder Homing Note Exercise uses
absolute encoder

• Select a Digital Input for Proximity Signal
• Select a Digital Input for External Zero Mark

11
Incremental Encoder Homing

• Test digital Input from Switch Box
• Verify the Operation of the Digital Input for
  Zero Mark

12
Homing Axis for Incremental Encoders

• Start Drive with DB Bit 0.0
• Start Referencing with DB bit 4.1
• Positive Direction for Homing is DB Bit 65.3 0
• Force Drive External Zero Marker in Previous
  Screen
• Drive Should stop and have Homing Position Set

13
Setup Mode Direct Setpoint Spec. / MDI

• Use VAR Table to Run drive is Setup Mode
• Sequence for Setup Mode
• Set Control Word 1 in Operation (OFF1)
• Bit 10.1 MDI_Setup Bit 1
• Choose a Direction Fwd or Backward (10.3 or 10.4)
• Bit 10.7 Intermediate_Stop 1
• Bit 10.0 MDI_Start 1
• Bit 10.5 Edge_Trigger 1 (Positive transition)

14
Setup Mode Direct Setpoint Spec. / MDI

• Use Direct Setpoint Specification / MDI Folder in
  Starter
• Check the Analog and Digital Signals during Setup
  / MDI

• Configure MDI Positioning Velocity
• Open Configure MDI Fixed Setpoints

15
MDI Positioning - Relative

• Use VAR Table to Run drive is Relative
  Positioning
• Sequence for Relative Positioning
• Set Control Word 1 in Operation (OFF1)
• Bit 10.1 MDI_Setup Bit 0
• Bit 10.2 Position_Type 0 (Relative)
• Bit 10.7 Intermediate_Stop 1
• Bit 10.0 MDI_Start 1
• MDI Velocity Override Desired Override
• MDI Position DB Double Word 6 Desired Position
  Move (Relative)
• Bit 10.5 Edge_Trigger 1 (Positive transition)

16
MDI Positioning Relative

• Use Direct Setpoint Specification / MDI Folder in
  Starter
• Check the Analog and Digital Signals during Setup
  / MDI

• Note Positive Edge Required for Relative
  Positioning

17
MDI Positioning Absolute

• Use VAR Table to Run drive is Absolute
  Positioning
• Sequence for Absolute Positioning
• Set Control Word 1 in Operation (OFF1)
• Bit 10.1 MDI_Setup Bit 0
• Bit 10.2 Position_Type 1 (Absolute)
• Bit 10.7 Intermediate_Stop 1
• Bit 10.0 MDI_Start 1
• MDI Velocity Override DB Word 2 Desired
  Override
• MDI Position DB Double Word 6 Desired Position
• Bit 10.5 Edge_Trigger or 10.6 Constant_Trigger
  can be Used
• Note Axis will move if new position given and
  Constant Trigger used

18
MDI Positioning Absolute

• Use Direct Setpoint Specification / MDI Folder in
  Starter
• Check the Analog and Digital Signals during Setup
  / MDI

• Note Edge Type Trigger or Continuous can be used
  for Absolute Positioning

19
Traversing Block

• Set Up Traversing Block in Starter
• Open Traversing Blocks Editor under Traversing
  Blocks Folder
• See Next page for Block Editor

20
Traversing Block

• Set Up Traversing Block in Starter
• Edit a few Blocks for Testing See Example Below
• Blocks can be continuous or Single Block
  Execution
• Note the Advance Field for type of Execution
• In Job Field - Value of Wait or Go To (Block )
  Possible

21
Traversing Blocks

• Use VAR Table to Run Traversing Blocks
• Sequence for Traversing
• Set Control Word 1 in Operation (OFF1)
• Bit 10.0 MDI_Start 0
• Bit 10.7 Intermediate Stop 1
• Bit 64.7 Traverse Start
• DB Word 66 Traversing Bit to Start (E.g. Block
  1)

22
FB 120 Diagnostics

• Diagnostics Mentioned in the VAR Table
• These Bits and Words can be used in PLC Logic

23
FB 120 Block View
