Sorting

• Dr. Bernard Chen Ph.D.
• University of Central Arkansas

2
Insertion Sort I

• The list is assumed to be broken into a sorted
  portion and an unsorted portion
• Keys will be inserted from the unsorted portion
  into the sorted portion.

Unsorted
Sorted
3
Insertion Sort II

• For each new key, search backward through sorted
  keys
• Move keys until proper position is found
• Place key in proper position

4
Insertion Sort Code
template ltclass Comparablegt void insertionSort(
vectorltComparablegt a ) for( int p 1 p
lt a.size( ) p ) Comparable tmp
a p int j for( j p j gt 0
tmp lt a j - 1 j-- ) a j a
j - 1 a j tmp
Fixed n-1 iterations
Worst case i-1 comparisons
Searching for the proper position for the new key
Move current key to right
Insert the new key to its proper position
5
Insertion Sort Analysis

• Worst Case Keys are in reverse order
• Do i-1 comparisons for each new key, where i runs
  from 2 to n.
• Total Comparisons 123 n-1

Comparison
6
Optimality Analysis I

• To discover an optimal algorithm we need to find
  an upper and lower asymptotic bound for a
  problem.
• An algorithm gives us an upper bound. The worst
  case for sorting cannot exceed ?(n2) because we
  have Insertion Sort that runs that fast.
• Lower bounds require mathematical arguments.

7
Other Assumptions

• The only operation used for sorting the list is
  swapping two keys.
• Only adjacent keys can be swapped.
• This is true for Insertion Sort and Bubble Sort.

8
Shell Sort

• With insertion sort, each time we insert an
  element, other elements get nudged one step
  closer to where they ought to be
• What if we could move elements a much longer
  distance each time?
• We could move each element
• A long distance
• A somewhat shorter distance
• A shorter distance still
• This approach is what makes shellsort so much
  faster than insertion sort

9
Sorting nonconsecutive subarrays
Here is an array to be sorted (numbers arent
important)

• Consider just the red locations
• Suppose we do an insertion sort on just these
  numbers, as if they were the only ones in the
  array?
• Now consider just the yellow locations
• We do an insertion sort on just these numbers
• Now do the same for each additional group of
  numbers
• The resultant array is sorted within groups, but
  not overall

10
Doing the 1-sort

• In the previous slide, we compared numbers that
  were spaced every 5 locations
• This is a 5-sort
• Ordinary insertion sort is just like this, only
  the numbers are spaced 1 apart
• We can think of this as a 1-sort
• Suppose, after doing the 5-sort, we do a 1-sort?
• In general, we would expect that each insertion
  would involve moving fewer numbers out of the way
• The array would end up completely sorted

11
Example of shell sort
original 81 94 11 96 12 35 17 95 28 58 41 75 15
5-sort 35 17 11 28 12 41 75 15 96 58 81 94 95
3-sort 28 12 11 35 15 41 58 17 94 75 81 96 95
1-sort 11 12 15 17 28 35 41 58 75 81 94 95 96
12
Diminishing gaps

• For a large array, we dont want to do a 5-sort
  we want to do an N-sort, where N depends on the
  size of the array
• N is called the gap size, or interval size

13
Diminishing gaps

• We may want to do several stages, reducing the
  gap size each time
• For example, on a 1000-element array, we may want
  to do a 364-sort, then a 121-sort, then a
  40-sort, then a 13-sort, then a 4-sort, then a
  1-sort
• Why these numbers?

14
Increment sequence

• No one knows the optimal sequence of diminishing
  gaps
• This sequence is attributed to Donald E. Knuth
• Start with h 1
• Repeatedly compute h 3h 1
• 1, 4, 13, 40, 121, 364, 1093
• This sequence seems to work very well

15
Increment sequence

• Another increment sequence mentioned in the
  textbook is based on the following formula
• start with h the half of the containers size
• hi floor (hi-1 / 2.2)
• It turns out that just cutting the array size in
  half each time does not work out as well

16
Analysis

• What is the real running time of shellsort?
• Nobody knows!
• Experiments suggest something like O(n3/2) or
  O(n7/6)
• Analysis isnt always easy!

17
Merge Sort

• If List has only one Element, do nothing
• Otherwise, Split List in Half
• Recursively Sort Both Lists
• Merge Sorted Lists

18
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

smallest
smallest
auxiliary array









A
19
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A









G
20
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A
G








H
21
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A
G
H







I
22
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A
G
H
I






L
23
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A
G
H
I
L





M
24
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A
G
H
I
L
M




O
25
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

auxiliary array
A
G
H
I
L
M
O



R
26
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

first halfexhausted
auxiliary array
A
G
H
I
L
M
O
R


S
27
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

first halfexhausted
auxiliary array
A
G
H
I
L
M
O
R
S

T
28
Merging

• Merge.
• Keep track of smallest element in each sorted
  half.
• Insert smallest of two elements into auxiliary
  array.
• Repeat until done.

first halfexhausted
second halfexhausted
auxiliary array
A
G
H
I
L
M
O
R
S
T
29
Merging numerical example
30
Binary Merge Sort

• Given a single file
• Split into two files

31
Binary Merge Sort

• Merge first one-element "subfile" of F1 with
  first one-element subfile of F2
• Gives a sorted two-element subfile of F
• Continue with rest of one-element subfiles

32
Binary Merge Sort

• Split again
• Merge again as before
• Each time, the size of the sorted subgroups
  doubles

33
Binary Merge Sort

• Last splitting gives two files each in order
• Last merging yields a single file, entirely in
  order

34
Quicksort

• Quicksort uses a divide-and-conquer strategy
• A recursive approach
• The original problem partitioned into simpler
  sub-problems,
• Each sub problem considered independently.
• Subdivision continues until sub problems obtained
  are simple enough to be solved directly

35
Quicksort

• Choose some element called a pivot
• Perform a sequence of exchanges so that
• All elements that are less than this pivot are to
  its left and
• All elements that are greater than the pivot are
  to its right.

36
Quicksort

• If the list has 0 or 1 elements,
• return. // the list is sorted
• Else do
• Pick an element in the list to use as the pivot.
•   Split the remaining elements into two disjoint
  groups
• SmallerThanPivot all elements lt pivot
• LargerThanPivot all elements gt pivot
•
•  Return the list rearranged as
• Quicksort(SmallerThanPivot),
• pivot,
• Quicksort(LargerThanPivot).

37
Quicksort

• Given to sort75, 70, 65, 84, 98, 78, 100, 93,
  55, 61, 81, 68
• Select, arbitrarily, the first element, 75, as
  pivot.
• Search from right for elements lt 75, stop at
  first element lt75
• And then search from left for elements gt 75,
  starting from pivot itself, stop at first element
  gt75
• Swap these two elements, and then repeat this
  process until Right and Left point at the same
  location

38
Quicksort Example

• 75, 70, 65, 68, 61, 55, 100, 93, 78, 98, 81, 84

• When done, swap with pivot
• This SPLIT operation placed pivot 75 so that all
  elements to the left were lt 75 and all elements
  to the right were gt75.
• View code for split() template
• 75 is now placed appropriately
• Need to sort sublists on either side of 75

39
Quicksort Example

• Need to sort (independently)
• 55, 70, 65, 68, 61 and 100, 93, 78, 98, 81,
  84
• Let pivot be 55, look from each end for values
  larger/smaller than 55, swap
• Same for 2nd list, pivot is 100
• Sort the resulting sublists in the same manner
  until sublist is trivial (size 0 or 1)
• View quicksort() recursive function

40
Quicksort Split

• int split (ElementType x, int first, int last)
• ElementType pivot xfirst
• int left first, right last
• While (left lt right)
• while (pivot lt xright)
• right--
• while (left lt right xleftltpivot)
• left
• if (left lt right)
• swap(xleft,xright)
• int pos right
• xfirst xpos
• xpos pivot
• return pos

41
Quicksort

• Note visual example ofa quicksort on an array

etc.
42
Quicksort Performance

• O(nlog2n) is the average case computing time
• If the pivot results in sublists of approximately
  the same size.
• O(n2) worst-case
• List already ordered, elements in reverse
• When Split() repetitively results, for example,
  in one empty sublist

43
Improvements to Quicksort

• Better method for selecting the pivot is the
  median-of-three rule,
• Select the median of the first, middle, and last
  elements in each sublist as the pivot.
• Often the list to be sorted is already partially
  ordered
• Median-of-three rule will select a pivot closer
  to the middle of the sublist than will the
  first-element rule.

44
Counting Sort

• Counting sort assumes that each of the n input
  elements is an integer in the range 0 to k
• When kO(n), the sort runs in O(n) time

45
Counting Sort

• Approach
• Sorts keys with values over range 0..k
• Count number of occurrences of each key
• Calculate of keys lt each key
• Place keys in sorted location using keys counted

46
(No Transcript)
47
Radix Sort

• Approach
• 1. Decompose key C into components C1, C2, Cd
• Component d is least significant, Each component
  has values over range 0..k

48
(No Transcript)
