Single-Chip Multiprocessor

1
Single-Chip Multiprocessor

• Nirmal Andrews

2
Case for single chip multiprocessors

• Advances in the field of integrated chip
  processing.
• - Gate density (More transistors per
  chip)
• - Cost of wires
• Many studies done in Stanford University during
  late 90s and proved CMP (single-chip
  multiprocessor) is better than competing
  technology .

3
Parallelism

• Parallelism becomes a necessity for improving
  performance.
• Parallelism made possible using dynamic
  scheduling, multiple instruction issue,
  speculative execution, non-blocking caches etc.,
  (late 90s)
• Parallelism classifications
• Instruction level
• Loop level
• Thread level - Future trend
• Process level - Future trend

4
Loop level parallelism

• To increase amount of parallelism exploit
  parallelism among iterations of a loop.
• ILP that results from data independent loop
  iterations is LLP.
• No circular dependencies. This could be avoided
  too using loop unrolling (beyond the scope of
  this lecture).

5
LLP (Loop Level Parallelism)

• 15 ILP extracted from a basic block in an
  integer programs 7 instructions.
• for (i1 ilt100 i i1)
•   ai ai bi         //s1
  bi1 ci di     //s2
• s1 depends on s2. So to extract LLP rearrange
• a1 a1 b1 for (i1 ilt99 i
  i1)
•   bi1 ci di   ai1
  ai1 bi1 b101 c100 d100

• No dependencies.

6
Competing technology - Superscalar

• Executing multiple instruction in the same clock
  cycle.
• Dynamic scheduling
• Single processor
• Redundant functional units on processor
• Mixture between a scalar and vector processor

7
Competing technology - Superscalar
8
Wide issue superscalar
9
Fetch Phase

• 3 phase Fetch, Issue, Execution
• Bottlenecks Issue and Execution phase.
• Fetch phase Provide large and accurate window of
  decoded instructions - 3 issues instruction
  misalignment, cache miss, mispredicted branch.
• - misprediction reduced to under 5 using
  branch predictor designed by McFarling.
• - instruction misalignement reduced to under
  3 by dividing cache into banks (Conte).
• - Roesnblum et al. shows that the 60 of
  latency by cache miss can be hidden.
• S. McFarling, Combining branch
  predictors, WRL Technical Note TN-36, Digital
  Equipment Corporation, 1993.
• M. Rosenblum, E. Bugnion, S. Herrod, E.
  Witchel, and A. Gupta, The impact of
  architectural trends on operating system
  performance, Proceedings of 15th ACM
• symposium on Operating Systems Principles,
  Colorado,December, 1995.

10
Issue phase

• Issue phase Register renaming.
• 2 techniques for register renaming
• - Use a table to map architectural
  registers and physical registers. Ports
  required operands per instruction Instruction
  window size
• - Use reorder buffer. Comparators required
  to find which physical register should provide
  data to which packet of instruction. Large number
  of comparators required.
• In HP PA 8000 20 of die space occupied by
  comparators.
• Quadratic increase in instruction queue register
  with increase in issue width.
• Queue register uses broadcast to connect to
  registers which increases the wires used
  increased delay and cost

11
Execute phase

• Execution phase also has similar issues.
• Increase in issue width causes increase in
  renamed registers leading to quadratic increase
  in register file complexity.
• Increase in execution unit causes quadratic
  increase in the complexity of bypass logic.
• Bottleneck Interconnect delay between
  execution units.

12
Architecture - Superscalar
13
Competing technologies Simultaneous Multi
Threading

• Simultaneous Multi threading architecture is
  similar to that of the superscalar.
• SMT processors support wide superscalar
  processors with hardware, to execute instructions
  from multiple thread concurrently.
• Provides latency tolerance.
• Reduces to conventional wide-issue superscalar
  when no multiple threads possible.

14
Competing technologies - Simultaneous Multi
Threading

• SMT (Simultaneous Multi-threading)

15
Centralized architecture

• Disadvantages of centralized architectures such
  as SMT and Superscalars are
• - Area increases quadratically with cores
  complexity.
• - Increase in cycle time interconnect
  delays. Delay with wires dominate delay of
  critical path of CPU. Possible to make simpler
  clusters, but results in deeper pipeline and
  increase in branch misprediction penalty.
• - Design verification cost high, due to
  complexity and single processor
• - Large demand on memory system.

16
Single Chip multiprocessor

• Motivation for a decentralized architecture due
  to the disadvantages of competing technologies.
• Simple individual processors and high clock rate.
• Low interconnect latency
• Exploits thread level and processor level
  parallelism.

17
Single chip Multiprocessor architecture
18
Performance comparison

• Example 8 core Cell processor in the PS3 and the
  3 core Xenon processor in the Xbox 360)
• Performance chart
• Run for different benchmark programs.

19
Summary (CMP)

• CMP (Chip level multiprocessor) provides superior
  performance with simpler hardware.
• No parallelism Superscalar performance is 30
  better than CMP
• Fine grained thread-level parallelism
  Superscalar is 10 better in performance
• Coarse grained thread-level parallelism CMP
  is 50-100 better than superscalar.
• Disadvantage Slow when no multithreading, equal
  development of software required.

20
Reference

• K Olukotun, BA Nayfeh, L Hammond, K Wilson, K,
  The case for a single-chip multiprocessor,ACM
  SIGPLAN Notices, 1996.
• L Hammond, BA Nayfeh, K Olukotun, A Single-Chip
  Multiprocessor, IEEE, Sept 1997.
• Wikipedia, Superscalar, April 2008.
  http//en.wikipedia.org/wiki/Superscalar.
• Wikipedia, Multi-core, April 2008.
  http//en.wikipedia.org/wiki/Multi-core_computing.
