Title: Non-Experimental designs: Developmental designs
1Non-Experimental designs Developmental designs
Small-N designs
- Psych 231 Research Methods in Psychology
2Announcements
- Journal Summary 2 due this week
- Bring your group project data to labs this week
- Decide how to analyze it
- What test
- Organize the data
- Somebody from each group is encouraged to visit
an office hour next week to finish the group
project data analysis
3Developmental designs
- Used to study changes in behavior that occur as a
function of age changes
- Three major types
- Cross-sectional
- Age is subject variable treated as a
between-subjects variable - Longitudinal
- Cohort-sequential
4Developmental designs
- Follow the same individual or group over time
- Age is treated as a within-subjects variable
- Rather than comparing groups, the same
individuals are compared to themselves at
different times - Repeated measurements over extended period of
time - Changes in dependent variable reflect changes due
to aging process - Changes in performance are compared on an
individual basis and overall
5Developmental designs
- Advantages
- Can see developmental changes clearly
- Avoid some cohort effects (participants are all
from same generation, so changes are more likely
to be due to aging) - Can measure differences within individuals
6Developmental designs
- Disadvantages
- Can be very time-consuming
- Can have cross-generational effects
- Conclusions based on members of one generation
may not apply to other generations - Numerous threats to internal validity
- Attrition/mortality
- History
- Practice effects
- Improved performance over multiple tests may be
due to practice taking the test - Cannot determine causality
7Developmental designs
- Measure groups of participants as they age
- Example measure a group of 5 year olds, then the
same group 5 years later, as well as another
group of 5 year olds - Age is both between and within subjects variable
- Combines elements of cross-sectional and
longitudinal designs - Addresses some of the concerns raised by other
designs - For example, allows to evaluate the contribution
of generation effects
8Developmental designs
- Advantages
- Can measure generation effect
- Less time-consuming than longitudinal
- Disadvantages
- Still time-consuming
- Still cannot make causal claims
9Small N designs
- What are they?
- Review Chapter 13
- One or a few participants
- Data are not analyzed statistically rather rely
on visual interpretation of the data - Basic method
- Observations begin in the absence of treatment
(BASELINE) - Look for stable level
- Then treatment is implemented
- Changes in frequency, magnitude, or intensity of
behavior are recorded
10Statistics
- Why do we use them?
- Descriptive statistics
- Used to describe, simplify, organize data sets
- Inferential statistics
- Used to test claims about the population, based
on data gathered from samples - Takes sampling error into account, are the
results above and beyond what youd expect by
random chance
11Distributions
- Recall that a variable is a characteristic that
can take different values. - The distribution of a variable is a summary of
all the different values of a variable - both type (each value) and token (each instance)
How much do you like psy231? 1 - 2 - 3 - 4 -
5 Hate it Love it
5 values (1, 2, 3, 4, 5)
7 tokens (1,1,2,3,4,5,5)
12Distribution
- Example Distribution of scores on an exam
- A frequency histogram
Frequency
13Distributions
- A picture of the distribution is usually helpful
- Gives a good sense of the properties of the
distribution - Many different ways to display distribution
- Graphs
- Continuous variable
- histogram, line graph (frequency polygons)
- Categorical variable
- pie chart, bar chart
- Table
- Frequency distribution table
- Stem and leaf plot
14Graphs for continuous variables
15Graphs for categorical variables
16Frequency distribution table
17Distribution
- Properties of a distribution
- Shape
- Symmetric v. asymmetric (skew)
- Unimodal v. multimodal
- Center
- Where most of the data in the distribution are
- Mean, Median, Mode
- Spread (variability)
- How similar/dissimilar are the scores in the
distribution? - Standard deviation (variance), Range
18Shape
Positive Skew
Negative Skew
19Shape
- Multimodal
- Bimodal examples
20Center
- There are three main measures of center
- Mean (M) the arithmetic average
- Add up all of the scores and divide by the total
number - Most used measure of center
- Median (Mdn) the middle score in terms of
location - The score that cuts off the top 50 of the from
the bottom 50 - Good for skewed distributions (e.g. net worth)
- Mode the most frequent score
- Good for nominal scales (e.g. eye color)
- A must for multi-modal distributions
21The Mean
- The most commonly used measure of center
- The arithmetic average
- Computing the mean
- The formula for the population mean is (a
parameter)
- The formula for the sample mean is (a
statistic)
22The Mean
- The most commonly used measure of center
- The arithmetic average
- Computing the mean
Our population
2, 4, 6, 8
23Spread (Variability)
- How similar are the scores?
- Range the maximum value - minimum value
- Only takes two scores from the distribution into
account - Influenced by extreme values (outliers)
- Standard deviation (SD) (essentially) the
average amount that the scores in the
distribution deviate from the mean - Takes all of the scores into account
- Also influenced by extreme values (but not as
much as the range) - Variance standard deviation squared
24Variability
- High variability
- The scores are fairly dissimilar
- Low variability
- The scores are fairly similar
25Standard deviation
- The standard deviation is the most popular and
most important measure of variability. - In essence, the standard deviation measures how
far off all of the individuals in the
distribution are from a standard, where that
standard is the mean of the distribution.
Essentially, the average of the deviations.
26Computing standard deviation (population)
- Step 1 To get a measure of the deviation we need
to subtract the population mean from every
individual in our distribution.
Our population
2, 4, 6, 8
X - ? deviation scores
2 - 5 -3
27Computing standard deviation (population)
- Step 1 To get a measure of the deviation we need
to subtract the population mean from every
individual in our distribution.
Our population
2, 4, 6, 8
X - ? deviation scores
2 - 5 -3
4 - 5 -1
28Computing standard deviation (population)
- Step 1 To get a measure of the deviation we need
to subtract the population mean from every
individual in our distribution.
Our population
2, 4, 6, 8
X - ? deviation scores
2 - 5 -3
6 - 5 1
4 - 5 -1
29Computing standard deviation (population)
- Step 1 To get a measure of the deviation we need
to subtract the population mean from every
individual in our distribution.
Our population
2, 4, 6, 8
X - ? deviation scores
2 - 5 -3
6 - 5 1
Notice that if you add up all of the deviations
they must equal 0.
4 - 5 -1
8 - 5 3
30Computing standard deviation (population)
- Step 2 So what we have to do is get rid of the
negative signs. We do this by squaring the
deviations and then taking the square root of the
sum of the squared deviations (SS).
SS ? (X - ?)2
(-3)2
(-1)2
(1)2
(3)2
9 1 1 9 20
31Computing standard deviation (population)
- Step 3 Now we have the sum of squares (SS), but
to get the Variance which is simply the average
of the squared deviations - we want the population variance not just the SS,
because the SS depends on the number of
individuals in the population, so we want the
mean - So to get the mean, we need to divide by the
number of individuals in the population.
variance ?2 SS/N
32Computing standard deviation (population)
- Step 4 However the population variance isnt
exactly what we want, we want the standard
deviation from the mean of the population. To
get this we need to take the square root of the
population variance.
33Computing standard deviation (population)
- To review
- Step 1 compute deviation scores
- Step 2 compute the SS
- either by using definitional formula or the
computational formula - Step 3 determine the variance
- take the average of the squared deviations
- divide the SS by the N
- Step 4 determine the standard deviation
- take the square root of the variance
