Meiosis (Chapter 13)

1
Meiosis (Chapter 13)
2
Mitosis

• Two identical daughter cells
• Interphase
• Cell growth, preparing for cell division
• Prophase, Metaphase, Anaphase, Telophase
• Cytokinesis

3
Fig. 12-4
0.5 µm
Chromosomes
DNA molecules
Chromo- some arm
Chromosome duplication (including DNA synthesis)
Centromere
Sister chromatids
Separation of sister chromatids
Centromere
Sister chromatids
4
Why meiosis?

• Produces haploid cells.
• Genetic diversity
• Evolution

5
Eukaryotes

• Haploid(n)
• Single set of chromosomes (23 in humans)
• Diploid(2n)
• Twice the haploid number or two sets (46)
• Homologous chromosomes
• 2 chromosomes that match up
• One from the mother one from the father
• Homologs
• One of the pair of chromosomes

6
Human chromosomes

• 23 pairs
• 22 autosomes
• 1 sex chromosome pair
• XX female
• All eggs are X
• XY male
• Sperm are either X or Y
• Chromosomes are divided into 7 groups
• Based on size, shape and appearance

7
Fig. 13-3b
5 µm
Pair of homologous replicated chromosomes
Centromere
Sister chromatids
Metaphase chromosome
8
Karyotype

• Display of the chromosomes

9
(No Transcript)
10
(No Transcript)
11
Downs Syndrome
12
Turners syndrome
13
Meiosis

• 2 successive rounds of cell division
• No replication of DNA between rounds
• Meiosis I
• Half the number of chromosomes
• Meiosis II
• 4 haploid cells

14
Meiosis

• Each round of division has a
• Prophase
• Metaphase
• Anaphase
• Telophase

15
(No Transcript)
16
Interphase
Pair of homologous chromosomes in diploid parent
cell
Chromosomes duplicate
Pair of duplicated homologous chromosomes
Sister chromatids
Diploid cell with duplicated chromosomes
Meiosis I
Homologous chromosomes separate
Haploid cells with duplicated chromosomes
Meiosis II
Sister chromatids separate
Haploid cells with unduplicated chromosomes
17
Meiosis I
Homologous chromosomes separate
Haploid cells with duplicated chromosomes
Meiosis II
Sister chromatids separate
Haploid cells with unduplicated chromosomes
18
Meiosis

• Synapsis
• Homologous chromosomes
• Closely associated
• Synaptonemal complex
• Homologous chromosomes are paired
• Protein complex between them
• Occurs in prophase I

19
Meiosis

• Crossing-over
• Homologues exchange chromosomal information
• Genetic recombination
• Chromosomes from one parent carry info from both
• Chiasma cross (pluralChiasmata)
• Site where crossing-over happens

20
Pair of homologous chromosomes
DNA breaks
DNA breaks
Crossover
Crossover
Paternal sister chromatids
Centromere
Cohesins
Maternal sister chromatids
Chiasmata
Synaptonemal complex forming
21
Cross-over

• Between non-sister chromatids
• Stabilized by sister chromatids

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Prophase I

• DNA coils tighter
• DNA already duplicated
• Sister chromatids joined at centromeres

27
Prophase I

• Sister chromatid cohesion
• Sister chromatids closely associate
• Homologous chromosomes line up next to each other
• Crossing over happens
• Non-sister chromatids

28
Prophase I

• Crossing over ends
• 4 chromatids (2 homologs) stay close due to
• 1.Sister chromatid cohesion
• 2.Chiasmata where crossover occurs

29
Metaphase I

• Homologous pairs align beside each other
• Metaphase plate (center)
• Chiasmata holds homologous chromosomes together
• Maternal homologue orients towards one pole
• Paternal homologue orients towards other pole

30
Metaphase I
31
Fig. 13-8b
Prophase I
Metaphase I
Centrosome (with centriole pair)
Centromere (with kinetochore)
Sister chromatids
Chiasmata
Spindle
Metaphase plate
Homologous chromosomes
Fragments of nuclear envelope
Microtubule attached to kinetochore
32
Anaphase I

• 90 meiosis is spent in Prophase Metaphase
• Spindle fibers begin to shorten
• Pull apart homologous chromosomes
• Go to separate poles
• Sister chromatids remain together
• Mitosis-sister chromatids separate

33
Anaphase I

• Each pole has a complete haploid set of
  chromosomes
• Each pole has one member of the homologous pair
• Either a maternal or paternal homologue

34
Anaphase I
35
Telophase I

• Homologues cluster at the poles
• Nuclear membrane reforms
• Each daughter cell contains half the of
  chromosomes
• Sister chromatids
• Different due to crossover

36
Telophase I

• Cytokinesis may occur
• Second division occurs after variable length

37
Meiosis I
38
Prophase II

• Nuclear membrane breaks down
• New spindles form

39
Metaphase II

• Spindle fibers bind to both sides of the
  centromere

40
Anaphase II

• Spindle fibers contract
• Sister chromatid cohesion is released
• Splits the sister chromatids
• Move to opposite poles

41
Telophase II

• Nuclear envelope reforms
• 4 haploid cells

42
Meiosis II
43
Meiosis
44
(No Transcript)
45
(No Transcript)
46
Sexual reproduction

• Gametes
• Egg sperm
• Half the number of chromosomes
• Zygote
• Egg and sperm combine
• Fertilization or syngamy
• Fusion of gametes to form a new cell

47
Sexual reproduction

• Life cycles alternate
• Diploid haploid chromosome numbers
• Alternates between meiosis fertilization
• Offspring inherit chromosomes from both parents
• Variations occur producing 3 types of sexual life
  cycles

48
1. Animals

• Majority of time as diploids
• Haploids do not under go mitosis
• Germ-line cells
• Cells that will under go meiosis
• Produce gametes

49
(No Transcript)
50
2. Fungi and some algae

• Spend majority of time as haploid
• Zygote undergoes meiosis
• Then mitosis

51
3. Plants

• Alternate between multicellular haploid
• Multicellular diploid phase

52
Evolution

• Asexual reproduction
• Inherit chromosomes from one parent
• Identical to parent
• Protists reproduce asexually
• Plants reproduce asexually

53
Sexual reproduction

• Generates genetic diversity
• Evolutionary adaptation depends on a populations
  genetic variation

54
Genetic diversity

• 1. Independent assortment
• 2. Crossover
• 3. Random fertilization

55
Independent assortment

• Genes on different chromosomes
• Orient independently
• Homologous pairs line up as a matter of chance

56
Independent assortment
57
Crossover

• Recombinant chromosomes
• Carry information from 2 different parents

58
Random fertilization
59
