Using Electromyography-Based Controls to Direct a LEGO Mindstorm Unit

1
Using Electromyography-Based Controls to Direct a
LEGO Mindstorm Unit

• Preston Steele
• James Brooks
• Nicholas Gomes

2
PIC
-timing interface -A/D converter -filtering -EMG
algorithm -RS232 serial port
Amplifier
EMG
Bluetooth adapter
NXT
-switch motors on/off -adjust motor speed
3
Signal processing

• Regardless of samples

• Sample dependent

• 60 hz notch filter
• Bandpass ()

• Fourier
• Range of bandpass

4
PIC18F4525

• 8 bit microcontroller
• Develop timer
• Analog to digital conversion
• Signal filtering
• Special EMG algorithm
• Bluetooth communication

5
NXT

• 4 input, 3 output
• 32 bit microprocessor
• Phone app
• Sensors
• Light, touch, ultrasonic,
• Own software
• Icon based drag and drop

6
LEGO Mindstorm
7
References

• Inman, Verne, J.B. Sanders, and Leroy Abbott.
  "Observations of the Function of the Shoulder
  Joint." Clinical Orthopaedics Related Research
  330 (1996) 3-12. Print.
• Lobo-Pratt, Joan, Arvid Keemink, Arno Steinen,
  Alfred Schouten, Peter Veltink, and Bart
  Koopmann. "Evaluation of EMG, Force and Joystick
  as Control Interfaces for Active Arm Supports."
  Journal of NeuroEngineering and Rehabilitation
  11.68 (2014). Print.
• E. Lum, C. Perez, Y . Sun. On detecting and
  Adaptive Timing for Electromyogram based control
  signals. Proceedings 38th Northeast
  Bioengineering Conference, Philadelphia, PA,
  pp.43-44, March 16-18, 2012.
• B. McCarthy, K. Stevens, C. King, E. Chabot, Y.
  Sun. Graded Muscle Contractions Determined by
  Temporal Recruitment. Proceedings, 39th
  Northeast Bioengineering Conference, Syracuse,
  NY, pp. 267-277, 2013.
• Microchip. PIC18F2525/2620/4525/4620 Data Sheet.
  San Jose, 2008. Print.
• BeagleBone. BeagleBone Black System Reference
  Manual. Dallas, 2013. Print.
