Mapping for Surveillance and Outbreak Investigation

1
Mapping for Surveillance and Outbreak
Investigation
2
Mapping for Surveillance and Outbreak
Investigation

• This issue of FOCUS was adapted from the
  following online training on the NCCPHP Training
  Web Site (http//nccphp.sph.unc.edu/training/)
• Infectious disease surveillance and outbreak
  investigation using GIS (2004)
• Dionne Law, PhD, Spatial Epidemiology Research
  Associate
• Department of Epidemiology, University of North
  Carolina at Chapel Hill

3
Goals

• Describe ways maps can be used in field
  epidemiology
• Describe how geographic information systems (GIS)
  can display and analyze spatial data
• Provide examples of surveillance and outbreak
  investigation activities that relied on GIS
• Describe the use of global positioning systems
  (GPS) to increase GIS capabilities

4
Mapping for Surveillance and Outbreak
Investigation

• Maps are commonly used in epidemiology to present
  complicated information succinctly and clearly
• This issue discusses
• How maps can be used in field epidemiology
• Commonly used computer software programs that can
  capture and analyze data and integrate them into
  a spatial display

5
Maps

• Earliest documented epidemiologic study relied on
  mapping
• Dr. John Snows investigation of cholera
  outbreak, London, 1854
• Used maps and statistical data to trace source of
  outbreak to public water pump on Broad Street

6
Maps

• Most noted example of maps to convey complicated
  statistical information comes from outside public
  health (1)
• 1869 map of French armys march to and retreat
  from Moscow
• Displays multivariate data (army size, direction,
  geographic location, temperature, and time)

7
Maps

• Line widths show size of French army on advance
  to Moscow (tan) and retreat (black)
• Chart below lines plots temperature

8
Maps

• Map created during disease surveillance and
  response activities around avian influenza, rural
  Indonesia, 2005 (2)
• Created using participatory mapping
• Shows the sequence of events during outbreak of
  highly pathogenic H5N1 avian influenza in poultry
  in a small village

9
Maps

• Initially spread from House 1 to House 5 also in
  second village (6) and broiler farm (top right)

Photo credit Dr Gavin Macgregor-Skinner/USAID
10
Maps

• Subsequent investigation revealed that residents
  of House 1 and households in second village
  worked at broiler farm
• Probably introduced H5N1 virus into communities
  by carrying it home on shoes and clothing

11
Geographic Information Systems

• Geographic information system (GIS) a computer
  program designed to store, manipulate, analyze,
  and display data in a geographic context
• GIS capabilities are ideal for use in infectious
  disease surveillance and control, outbreak
  investigation and response

12
Geographic Information Systems

• GIS can help
• Optimize data collection and management
• Strengthen data analysis
• Strengthen outbreak infrastructure and support
• Map epidemic dynamics in near real-time
• Quickly plan and target response
• Rapidly communicate information
• Monitor changes in disease over time
• Plan, monitor intervention/eradication programs
• Aid emergency preparedness

13
GIS Example West Nile Virus

• GIS displays information in map layers

• Example West Nile virus
• Street network
• Buildings enclosures for sentinel species
  (chicken coops, horse stalls), offices,
  dwellings
• Population at risk
• Maps of land cover, digital elevation,
  precipitation, temperature, water features,
  veterinarians/physicians

14
GIS Example West Nile Virus

• After data is entered into GIS tool, you can
• Maintain surveillance of case-patient locations
  and progression of disease for early outbreak
  detection
• Identify areas ideal for mosquito breeding and
  apply preventive measures
• Predict which populations are vulnerable to
  infection based on proximity to breeding grounds
• Simulate how an epidemic could evolve given
  introduction of infected mosquitoes/birds at
  various locations
• Determine where to target interventions,
  strengthen healthcare resources

15
Surveillance and GIS Example Public Health
Mapping Programme

• Developed in 1993 by WHO and UNICEF to eradicate
  Guinea worm disease
• GIS used to
• Visualize disease foci
• Monitor newly infected or re-infected villages,
• Identify populations at risk
• Target cost-effective interventions
• Monitor eradication efforts

16
Surveillance and GIS Example Public Health
Mapping Programme

• Technology developed to control one disease can
  enhance control of others
• Since Guinea worm project, GIS and mapping
  expanded to meet data needs for
• Onchocerciasis (river blindness)
• Blinding trachoma
• African trypanosomiasis (sleeping sickness)
• Lymphatic filariasis (elephantiasis)
• Poliomyelitis
• Malaria

17
Surveillance and GIS Example HealthMapper

• Elimination of lymphatic filariasis possible
  through
• Mass drug administration to those at risk
• Promotion of intensive hygiene on affected body
  parts
• Populations at risk, size, location not
  identified
• HealthMapper enabled countries to estimate
  prevalence of disease at district level, identify
  precise areas to target for mass drug
  administration
• Also tool for standardizing surveillance,
  monitoring indicators in different countries and
  regions (3)

18
Surveillance and GIS Example Roll Back Malaria
Partnership

• Global partnership to enable effective,
  sustainable action against malaria
• WHO strategy includes prompt treatment with
  effective drugs, vector-control methods,
  preventive treatment in pregnancy, emergency and
  epidemic preparedness and response
• Developed GIS to
• Strengthen surveillance at local level for early
  detection, response to epidemics
• Complement existing national/international health
  monitoring systems
• Integrate information on community interventions,
  control interventions, private and public health
  providers, partner intervention areas,
  resources
• Be accessible at different levels

19
Surveillance and GIS Example US West Nile Virus
Surveillance

• CDC developed national surveillance plan for WNV
  to monitor spread of infection, provide
  national/regional information, identify regional
  distribution and incidence of other arbovirus
  diseases
• GIS used to enhance federal surveillance system,
  communicate results to the public

20
Surveillance and GIS Example US West Nile Virus
Surveillance

• CDC, US Geological Survey mapped mosquito, wild
  bird, horse, human populations
• Tracked in sentinel species (chickens)

2007 U.S. Geologic Survey
21
Surveillance and GIS Example US West Nile Virus
Surveillance

• Pennsylvania developed network to combat WNV
• Covers all 67 counties
• Includes trapping mosquitoes, collecting dead
  birds, monitoring horses, people, chickens
• WNV Tracking System spatially-driven
  surveillance program for following, responding to
  spread of WNV
• Collects information on presence of virus,
  identifies mosquito-breeding areas, helps target
  control efforts
• Alerts decision makers of new data via e-mail
• Generates, posts detailed maps on secure Web site
• Data for public release published on WNV
  Surveillance Program Web site (www.westnile.state.
  pa.us/)

22
Outbreak Investigation and GIS

• GIS used to
• Strengthen data collection, management, and
  analysis
• Develop early warning systems
• Plan and monitor response programs
• Communicate large volumes of complex information
  in simple, effective way to decision makers and
  public

23
Outbreak Investigation and GIS Example
Shigellosis

• Fort Bragg, North Carolina, 1997 (4)
• 59 cases of Shigella sonnei reported among
  military health beneficiaries
• Significant number of cases were children
• Preliminary investigation did not reveal
  associations with daycare or common location
• Outbreak persisted despite education about hand
  washing and hygiene

24
Outbreak Investigation and GIS Example
Shigellosis

• Imported addresses of all confirmed cases into
  GIS and mapped onto Fort Bragg housing areas
• Revealed cluster of infections on several streets
  in one particular neighborhood

25
Outbreak Investigation and GIS Example
Shigellosis

• Interviews with case families, neighbors revealed
  presence of small communal wading pools in
  several yards that were frequented by affected
  children
• Once pools were removed and home-based
  information campaigns were initiated, spread of
  illness was halted

26
Outbreak Investigation and GIS Example STIs

• GIS also used to map sexually transmitted
  infections
• Used in Baltimore to map distribution of syphilis
  before, during, after outbreak (5)
• Data suggested that disease spread outward from 2
  central cores of infection

27
Outbreak Investigation and GIS Example STIs

• Used to map distribution of 4 sexually
  transmitted infections (chlamydia, gonorrhea,
  syphilis, and HIV infection) in Wake County, NC
  (6)
• Found clearly defined spatially heterogeneous
  areas of infection for different diseases

28
Global Positioning Systems

• Global positioning systems (GPS) add function to
  GIS, increase capabilities
• A critical tool for precise identification of
  research subjects, locations, distances to
  related geographic features
• Allow users to locate positions on electronic map
  using satellite technology

29
Global Positioning Systems Example Atrazine
Exposure

• RTI International employed GPS-enabled handheld
  technology in a National Cancer Institute study
  to determine relationship between exposure to
  atrazine and distance from fields where used (7)
• Required field trips to verify locations of
  households in study area near corn fields in
  Illinois
• Used HP iPAQ Pocket PC with GPS receiver and
  ESRI's ArcPad software (GIS software for mapping
  that allows capture, display, analysis of
  geographic information on handheld devices)

30
Global Positioning Systems Example Atrazine
Exposure

• Candidate household addresses geocoded to street
  database, loaded onto ArcPad with aerial
  photographs, street centerline database

• Staff used GPS, street names to find approximate
  location of households
• Modified original address-matched location (green
  dots) to actual location (red dots) based on GPS
  and rooftops on aerial map
• If households not seen on map, GPS coordinate on
  street captured

31
Global Positioning Systems Example Atrazine
Exposure

• Measured household's distance from corn field
  where atrazine used
• Concentrations of atrazine in household, in
  biological samples from occupants correlated with
  distance from atrazine source
• Using ArcPad/GPS instead of paper maps
• Allowed quick navigation from household to
  household
• Made repositioning of household locations more
  accurate
• Would have been almost impossible to do under
  studys time constraints without this technology
• Precisely measured household locations and
  precise distances from households to corn fields
  provided higher precision during data
  analysis

32
Global Positioning Systems

• Approach could be applied to infectious disease
  surveillance and outbreak investigation and
  response
• To measure distance to exposure (e.g., water
  source with cryptosporidium or farm with hoof and
  mouth disease)
• Outbreak investigation and response are
  time-limited activities must be done quickly to
  have greatest effect
• GIS and GPS can greatly speed field work

33
Summary

• Spread of disease especially infectious disease
  is unavoidably spatial
• Infection moves from individual to individual
  following network of contacts within population
  through local or global transmission
• GIS capacity to capture geospatial information
  ideally suited for infectious disease
  surveillance and control highly relevant to meet
  demands of outbreak investigation and response
• Next issue will show how GIS used to conduct
  rapid needs assessments

34
Additional Resources for GIS Mapping

• World Health Organization Public Health Mapping
  Programme
• http//www.who.int/health_mapping/en/
• WHO HealthMapper
• http//www.who.int/health_mapping/tools/
  healthmapper/en/index.html
• Roll Back Malaria Partnership
• http//www.rbm.who.int/

35
Further Readings

• Melnick, Alan L. Introduction to geographic
  information systems in public health.
  Gaithersburg, Md Aspen Publishers 2002.
• Cromley, Ellen K. GIS and public health. New
  York Guilford Press 2002.
• Moore DA, Carpenter TE. Spatial Analytical
  Methods and Geographic Information Systems Use
  in Health Research and Epidemiology.
  Epidemiologic Reviews. 199921(2)143-160.

36
References

1. Tufte ER, The Visual Display of Quantative
   Information. 2nd ed. Cheshire, CT Graphics
   Press, LLC 1983176.
2. Macgregor-Skinner G. Avian influenza H5N1
   Getting our ducks in a row. Presentation at 5th
   Annual One Medicine Symposium December 12-13,
   2007 Durham, NC.
3. Brooker S, Beasley M, Ndinaromtan M, et al. Use
   of remote sensing and a geographical information
   system in a national helminth control programme
   in Chad. Bulletin of the World Health
   Organization. 200280783-789.
4. McKee KT, Shields TM, Jenkins PR, Zenilman JM,
   Glass GE. Application of a geographic information
   system to the tracking and control of an outbreak
   of shigellosis. Clin Infect Dis. 200031728-733.

37
References

1. Gesink Law DC, Bernstein KT, Serre ML, et al.
   Modeling a syphilis outbreak through space and
   time using the Bayesian maximum entropy approach.
   Ann Epidemiol. 200616797-804.
2. Law DCG, Serre ML, Christakos G, Leone PA, Miller
   WC. Spatial analysis and mapping of sexually
   transmitted diseases to optimise intervention and
   prevention strategies. Sex Transm Infect.
   200480294-299.
3. ArcPadMobile GIS software for field mapping
   applications. ESRI Web site. http//www.esri.com/s
   oftware/arcgis/arcpad/. Accessed April 23, 2008.
4. Holmes EE. Basic epidemiological concepts in a
   spatial context. In Tilman D, Kareiva P, eds.
   Spatial Ecology The Role of Space in Population
   Dynamics and Interspecific Interactions.
   Princeton, NJ Princeton University Press
   1997111-136.
