Lambert Schomaker

1
KI2 - 2

• Lambert Schomaker

Kunstmatige Intelligentie / RuG
2
Outline
Date 1st hour 2nd hour
6 nov Planning, NR 11-13 (LS) idem
13 nov Knowledge-based symbolic methods (LS) 19.6, 21 Example geometric modeling matching (MB)
20 nov Statistical symbolic methods 1 (LS) 17 Example spam filter
27 nov Statistical symbolic methods 2 (LS) Example autoclass
4 dec Heterogeneous-information integration Example writer identification, sat. images
11 dec Grammar induction Articles
18 dec Misc. topics Misc. applications
jan (exam)
3
Knowledge-based symbolic methods

• Assumption the Turing / Von Neumann
• computer is a universal computation engine
• therefore it can be used at all levels of
• information processing
• provided an appropriate algorithm can
• be designed
• which operates on appropriate
• representations

4
Knowledge-based symbolic methods

• provided an appropriate algorithm
• can be designed
• which operates on appropriate
• representations

5
Knowledge-based symbolic methods

• provided an appropriate algorithm
• can be designed
• mechanisms recursion, hierarchic procedures
• search algorithms
• parsers
• matching algorithms
• string manipulation
• .
• .
• numerical computing
• signal processing
• image processing
• statistical processing

6
Knowledge-based symbolic methods

• which operates on appropriate
• representations
• stacks
• linear strings and arrays
• matrices
• linked lists
• trees

7
Knowledge-based symbolic methods

• which operates on appropriate
• representations
• stacks
• linear strings and arrays
• matrices
• linked lists
• trees
• is indeed succesful in many information
• processing problems

8
Example double spiral problem
in inner or outer spiral?
9
Example double spiral problem
in inner or outer spiral?
? difficult for, e.g., neural nets
10
Example double spiral problem
in inner or outer spiral? Answer outside
? difficult for, e.g., neural nets
11
Example double spiral problem

• in inner or
• outer spiral?
• How?
• flood fill algorithm?
• other?

12
Example double spiral problem

• in inner or
• outer spiral?
• Find the right
• representation!
• ? odd/even count
• is not sensitive
• to shape variations
• of the spiral
• a general solution

count edges
Outside
13
Example double spiral problem
in inner or outer spiral?
Outside
14
Culture

• If it doesnt work, you didnt think hard enough
• You have to know what you do
• You have to prove that why it works
• Even neural networks work on top of the
• Turing/von Neumann engine (it will always
  win)
• If youre smart, you can often avoid
  NP-completeness
• Use of probabilities is a sign of weakness

15
Strong points

• Scalability is often possible
• Convenience little context dependence, no
  training
• Reusability
• Transformability (compilation)
• Algorithmic refinement once it is known
• how to do a trick (e.g., graphics cards and
• DSPs in mobile phones ugly code but
• highly efficient)

16
Challenges

• Knowledge dependence is expensive
• not a problem in IT application design
• a challenge to AI
• Uncertainty
• Noise
• Brittleness

17
Solutions

• More and more representational weight
• (UML, Semantic Web, XML solves everything)
• Symbolic learning mechanisms
• induction version spaces
• grammar inference
• decision tree learning
• rewriting formalisms
• Active hypothesis testing (what if, assume X)

18
Example

• In Reading Systems (optical character
  recognition), only a small part of the algorithm
  concerns problems of image processing and
  character classification
• Most of the code is concerned with the structure
• of the text image
• where are the blobs?
• are these blobs text, photo or graphics?
• how to segment into meaningful chunks
  characters, words?
• what is the logical organization (reading order)
  in the physical organization of pixels?
• ? Knowledge-based approaches are a necessity!

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Name of conference
Programme committee
Brief description of conference
Submission details
23
Example of layout analysis

• Knowing the type of a text block strongly reduces
  the number of possible interpretations
• Example address block
• Address
• name of person
• street, number
• postal code, city

24
pos tze gel
Amsterdam 7/7/2003
Express delivery
prof dr. L.R.B. Schomaker Grote Appelstraat
23 9712 TS Groningen Nederland
25
address
prof dr. L.R.B. Schomaker Grote Appelstraat
23 9712 TS Groningen Nederland
26
address
prof dr. L.R.B. Schomaker Grote Appelstraat
23 9712 TS Groningen Nederland
person name
street
codescity
country
27
address
prof dr. L.R.B. Schomaker Grote Appelstraat
23 9712 TS Groningen Nederland
titles initials surname
street street ,,, digits
4 digits 2 upper case city name
country name
28
Content
Layout
ltaddressgt ltpersongt lttitlegtlt/titlegt
ltinitials or first namegt lt/initials
or first namegt ltsurnamegtlt/surnamegt
lt/persongt lthomegt ltstreet
namegtlt/street namegt ltnumbergt lt/numbergt
lt/homegt ltcitygt ltpostal codegt
ltfour digitsgtlt/four digitsgt
ltwhite spacegtlt/white spacegt
lttwo upper-case lettersgt . lt/postal
codegt lt/citygt ltcountrygt
lt/countrygt lt/addressgt
(address (title is-left-of initials
is-left-of surname) is-above (street name
is-left-of number) is-above (city) is-above
(country))
etc.
prof dr. L.R.B. Schomaker Grote Appelstraat
23 9712 TS Groningen Nederland
etc.
29
Content
Layout
ltaddressgt ltpersongt lttitlegtlt/titlegt
ltinitials or first namegt lt/initials
or first namegt ltsurnamegtlt/surnamegt
lt/persongt lthomegt ltstreet
namegtlt/street namegt ltnumbergt lt/numbergt
lt/homegt ltcitygt ltpostal codegt
ltfour digitsgtlt/four digitsgt
ltwhite spacegtlt/white spacegt
lttwo upper-case lettersgt . lt/postal
codegt lt/citygt ltcountrygt
lt/countrygt lt/addressgt
(address (title is-left-of initials
is-left-of surname) is-above (street name
is-left-of number) is-above (city) is-above
(country))
etc.
HELPS TEXT SEGMENTATION
prof dr. L.R.B. Schomaker Grote Appelstraat
23 9712 TS Groningen Nederland
etc.
HELPS TEXT CLASSIFICATION
30
(No Transcript)
