Memory and Cognition

1
Memory and Cognition

• PSY 324
• Topic 2 Cognition and the Brain
• Dr. Ellen Campana
• Arizona State University

2
A Brain

• Gray White Matter
• Solid tissue
• Made up of neurons
• Golgi showed by staining slices with dye

3
Neurons

• Similarities with other cells of the body
• Have a nucleus containing DNA
• Surrounded by a cell membrane
• Contain mitochondria and other organelles
• Do basic cell stuff (protein synthesis, energy
  production)
• Unique characteristics
• Do not reproduce
• Structure, function, chemicals (details to come)

4
Structure of a Neuron
5
Structure of a Neuron
6
Varieties of neurons

• Function transmit information to other cells
• Sensory / Afferent neurons info TOWARD CNS
• Motor / Efferent neurons info AWAY from CNS
• Interneurons info to other neurons in the CNS

7
Info Transmission Simple Story

• Neurons are transducers convert environmental
  energy to electrical energy (starting with
  receptors)
• Energy is propagated from the dendrites into the
  cell body.
• Energy is propagated to the end of the axon. When
  it goes above a threshold, it triggers the
  release of neurotransmitters into the synapse
• The neurotransmitters in the synapse trigger the
  same process (or a different one) in the next cell

8
Synapses
9
Info Transmission Deeper Story

• Background concepts from physics
• Matter composed of molecules (always moving)
• Molecules can have /- charge
• Like charges repel, opposite charges attract

-
-

-
10
Info Transmission Deeper Story

• Each neuron has a resting potential, the voltage
  difference across the cell membrane, caused by
  the chemicals inside/outside the cell when the
  cell is not firing

11
Info Transmission Deeper Story

• Axon lined with ion channels (sodium channels,
  potassium channels) that open and close during an
  action potential to propagate the signal
• Depolarization phase Sodium (Na) Channels
• Repolarization phase Potassium (K) Channels

12
Depolarization Phase
13
Depolarization Repolarization
14
Info Transmission Deeper Story

• Action potential moves down the axon, as gates
  open and close in sequence

15
Synapses

• Action Potential reaches the end of the axon,
  triggering release of neurotransmitters

• Excitatory neurotransmitters increase firing rate
  in next neuron
• Inhibitory neurotransmitters decrease firing rate
  in next neuron
• NOTE Other neurotransmitters do other things
  (less well understood, less relevant to
  cognition, especially to models we will talk
  about)

16
Method Single-Cell Recording

• It is possible to record activity of a single
  cell
• Tiny wires (called microelectrodes) stuck into
  axon, attached to oscilloscope for data display
• Time is a factor
• De/Repolarization cycle 1/1000 S or 1 ms
• Activities of cognition take at least 100ms at
  that resolution action potentials show up as
  spikes
• Often most useful to talk about firing rate

17
Method Single-Cell Recording

• Pictures of spikes
• http//viperlib.york.ac.uk/ , keyword single cell
  recording
• Video clip from Hubel Weisel (they got the 1981
  Nobel Prize in physiology and medicine for this
  work)
• http//viperlib.york.ac.uk/ , keyword single-cell
  recording

18
History of Single-Cell Recording

• Participants in experiments
• 1880s People injured by accident with exposed
  brains, also patients with epilepsy
• 1950s Fully anesthetized animals (cats,
  squirrels, monkeys, apes)
• 1980s Awake, active monkeys and apes
• Invasive, destructive procedure
• Data there is a cell in the animal that
  increases firing under conditions

19
Value of Single-Cell Recording

• By itself, the data doesnt tell us much
• Can find cells that do almost anything
• The value of single-cell recording for
  understanding human cognition depends on
• Functional organization of the brain
• Consistencies of organization within species
• Meaningful mapping from animal models to
  organization of human brain
• Fortunately, much evidence that these exist

20
Clarification from last time

• Question came up about diffusion and connection
  to neuron behavior

21
Clarification from last time

• Background concepts from physics
• Matter composed of molecules (always moving)
• Molecules can have /- charge
• Like charges repel, opposite charges attract

-
-

-
22
Clarification from last time

• Background concepts from physics
• Matter composed of molecules (always moving)
• Molecules can have /- charge
• Like charges repel, opposite charges attract
• Cell membrane maintains an imbalance
• At rest, negative inside and positive outside
  (pumps maintain)
• Ion channels open / close quickly
• Particles rush in / out (like a hole in a boat)
• Sodium and Potassium are , but other chemicals
  create the negativity inside the axon at rest
• Focus on Sodium and Potassium because of the gates

23
Clarification from last time
Axon Cell membrane (imbalance) Diffusion and
charge drive the process cells rush
in/out There are mechanical pumps but they just
restore resting potential at the end
24
Clarification from last time

• Things to note
• All action potentials are the same size, in terms
  of voltage (all-or-nothing principle)
• Most useful to think of them as on / off, or to
  think about firing rates (spikes per second)

These are from a specific study. Neuron A
responds when the stimulus is ON. Neuron B
responds when the stimulus is OFF. Neuron C
responds to changes in the stimulus.
25
Why study neurons?

• Everything we see, hear, do, smell, remember,
  taste, touch, pay attention to, and think about
  is represented physiologically by neurons firing
• All sensations, perceptions and thoughts are
  neural activation
• All of our actions arise from neural signals
• Study of cognition is about both physiological
  and functional models
• Increasingly uses brain imaging and neuroscience
  methods (later today)

26
Brain Organization

• Hierarchical Structure
• Smallest unit Neuron
• Neurons form Circuits (many levels)
• Convergence, Inhibition, Excitation
• Related circuits contribute to localized function
• Brain areas for different functions
• Hemispheric specialization

27
Neurons as part of circuits

• Neural processing occurs when neurons synapse
  together to form a neural circuit
• Convergence
• Interaction of excitation and inhibition

28
Neurons as part of circuits

• Neural processing occurs when neurons synapse
  together to form a neural circuit
• Convergence
• Interaction of excitation and inhibition

29
Hubel Weisel

• Single-cell recording of feature detectors
• Simple neurons (from the video last time)
• Orientation (thickness, location of line)
• Complex neurons
• Orientation, direction of motion
• End-stopped
• Length, direction of motion

30
Feature Detectors

• Lines (shapes and orientations)
• Directed Motion
• Complex Stimuli
• Geometrical figures
• Common objects in the environment (houses,
  man-made objects, birds)
• Faces
• Depend on selectivity neurons firing at some
  times and not at others

31
Neural Codes in Daily Life

• Consider the case of recognizing the face of a
  specific person how could that happen?
• Hypothesis 1 specificity tuning a particular
  neuron could selectively fire when you see that
  person

32
Specificity Coding

• Difficulties with Specificity Coding Hypothesis
• Too many different faces, concepts, etc. to have
  a neuron for each one
• Depends on experience would have to learn each
  face (because neurons dont reproduce)
• Neurons selective for faces are active for many
  different faces
• Related idea Grandmother cell (coined by
  Lettvin)
• Cell responds to image of a grandmother, general
  concept of grandmothers, your own grandmother
• Some evidence that these might exist in
  Hippocampus associated with memory storage, not
  vision
• For recognition (and many other types of
  cognition), specificity coding is not enough

33
Neural Codes in Daily Life

• Hypothesis 2 Distibuted Coding code for a
  specific face is distributed across a set of
  neurons

34
Distributed Coding

• Advantages
• Efficient -- firing of fewer neurons can
  represent many more different stimuli
• Similar items can have similar neural codes
• Helps with learning
• Graceful degradation -- if one or two neurons do
  not fire, it is still possible to recognize a
  face

35
Reconciling types of coding

• Evidence for Specificity Coding
• Feature detectors
• Concept cells in hippocampus (memory area)
• Argument for Distributed Coding in recognition
• Clear theoretical advantages in recognition
• Will see a lot of evidence later
• Both are happening in the brain in different
  areas at the same time (parallel processing)
• Pattern across ( interaction btwn)
  areascognition

36
The Whole Brain

• Localization of function - Different parts of the
  brain serve different functions
• Many, many ways to divide the brain
• Like an onion, many layers
• Like a fractal, the closer you look the more
  complex it seems
• Descriptions may seem contradictory and/or
  overlapping because of this

37
Cerebral Cortex

• Most important for Cognition

38
Cerebral Cortex

• Temporal Lobe
• Language
• Memory
• Hearing
• Perceiving forms
• Occipital Lobe
• Visual information (early processing) feature
  detectors

39
Cerebral Cortex

• Parietal Lobe
• Touch
• Vision
• Attention
• Frontal Lobe
• Proportionately larger in humans than in other
  species
• Language
• Thought
• Memory
• Motor functioning

40
Subcortical Structures
41
Subcortical Structures

• Hippocampus
• Forming memories
• Amygdala
• Emotions, emotional memories
• Thalamus
• Processing sensory information (vision, hearing,
  touch)

42
Hemispheres

• Brain separated into sides (hemispheres)
• Corpus Collosum connects them

• Structurally and functionally very similar
• Lateralization specific functions occurring in
  one hemisphere or the other

Note Sperry studied split-brain patients, who
had had their corpus collosum severed as a
treatment for epilepsy. He shared Hubel
Weisels Nobel Prize for this work.
43
Lateralization

• Vision of left part of the world lateralized to
  the right side (opposite also true)
• Motor Control of left side of body lateralized to
  the right side (opposite also true)
• Touch on left side of body lateralized to the
  right side (opposite also true)

44
Lateralization

• Are there right-brained and left-brained
  people?
• Analytical/Logical processing (syntax of
  language) usually on the left side (not always)
• Analogy and Broad Thinking usually on the right
  side (not always)
• Everyone has (and uses) both
• Patients who have had a hemispherectomy
• Other side usually takes over missing
  functionality
• Coglab Brain Assymetry

45
Localized Function

• Parietal Lobe
• Sensory Homunculus (near the front, somatosensory
  cortex)
• Motor Homunculus (near the back, motor cortex)

46
Sensory Homunculus
Each side of the brain has a copy, which
processes touch from the other side
47
Localized Function

• Parietal Lobe
• Sensory Homunculus (near the front, somatosensory
  cortex)
• Motor Homunculus (near the back, motor cortex)
• Temporal Lobe
• Wernickes Area metaphor, meaning in language
• Brocas Area logical structure of language
• Fusiform Face Area (FFA) specialized for faces
  (or is it things were experts at recognizing???)

48
Researching Localized Function

• Neuropsychology comparing patients with
  localized brain damage
• Single dissociation single patient has some
  things impaired, other things not impaired

49
Single Dissociation Phineas Gage

• Construction accident 1848
• Harlow (doctor) wrote a lot about his condition

• Gage lived, could talk, act, and do all normal
  activities, but suffered impairment of emotional,
  social, and personal traits
• Evidence for some separation of language and
  social traits, etc.

50
Researching Localized Function

• Neuropsychology comparing patients with
  localized brain damage
• Single dissociation single patient has some
  things impaired, other things not impaired
• Alice Short-Term Memory OK, Long-Term Memory
  impaired (like in Memento)
• Double dissociation -- two (or more) patients
  show opposite single impairments
• Bert Long-Term Memory OK, Short-Term Memory
  impaired

51
Double Dissociation
Short-term memory Long-term memory
Alice (temporal lobe damage) OK Impaired
Bert (frontal lobe damage Impaired OK
52
Double Dissociation
Naming Living Things Naming Nonliving Things
Group 1 (damage to area 1) OK Impaired
Group 2 (damage to area 2) Impaired OK
53
What can we conclude?

• Double dissociation
• Two functions involve different mechanisms
• Two functions involve different brain areas
• Mechanisms are independent
• Single dissociation
• Two functions involve different mechanisms
• Two functions involve different brain areas
• Mechanisms may not be independent

54
Limitations of Neuropsychology

• At least for human processing, brain damage comes
  about from natural means (accident, etc.)
• Members of groups rarely have exactly the same
  damage (location or extent)
• No record of processing or brain organization
  before the damage
• Difficult to assess all possible types of
  functional impairment
• Damage may cause reorganization (plasticity)

55
Imaging Methods

• EEG- Electrodes on outside of head continuously
  measure electrical activity
• PET- Radioactive dye injected, accumulates in
  different regions over time and can be read by a
  scanner. Essentially measures metabolism of
  neurons
• fMRI- Brief magnetic pulses used to give a
  snapshot of ratio of oxygenated to deoxygenated
  blood (metabolism)
• TMS- New measure. Magnetic field can disable
  specific portions of the brain for a short time,
  simulating damage.
• Temporal resolution Detail with respect to time
• Spatial Resolution Detail with respect to
  physiology

56
Image from an fMRI scan
Image from a PET scan
57
Imaging Methods
Spatial Resolution Temporal Resolution
EEG Poor Good
PET Excellent Poor
fMRI Good Good
TMS Good Good
58
Subtraction Technique
Visual Stimulus (light flashing)
Visual Stimulus (light flashing)

• Used for fMRI studies
• Method similar to Donders study
• Compared two situations that included different
  cognitive processes
• Data blood glucose level
• Relative measure

Perception of the light
Perception of the light
DECISION
Response
Response
59
Subtraction Technique

• Activation in control condition is subtracted
  from experimental condition to get activity due
  to stimulation in the experimental condition

60
Effects of experience

• Experience-dependant plasticity
• Developmental environment can affect neuron
  specialization
• Kittens raised in environment with only vertical
  lines had more of their brain devoted to
  recognizing vertical lines in adulthood (and none
  devoted to horizontal)
• Learning happens through changes in connections
  and relationships between neurons, even in
  adulthood
• Greebles study (back to the FFA)

61
Greebles

• Recall discussion of localization of function
• Fusiform Face Area (FFA) was an area in the
  Temporal lobe devoted to recognizing faces or
  was it things were experts at recognizing???
• Kanwisher has demonstrated, using fMRI, that the
  area does selectively respond to faces
• Gauthier and colleagues showed fMRI evidence for
  experience-based plasticity in this area
  (Greebles study)

62
Greebles Study

• Step 1 measure brain activity in FFA when
  viewing Greebles
• Step 2 train people to recognize individual
  Greebles and families of Greebles
• Step 3 measure brain activity in FFA when
  viewing Greebles
• Analysis compare activity in FFA before and
  after training

63
Greebles Study

• Conclusions
• Plasticity of FFA
• FFA selects for things were experts about
• Faces are things were experts about
