Weak Values in Quantum Measurement Theory - Concepts and Applications -

1
Weak Values in Quantum Measurement Theory-
Concepts and Applications -
Master Thesis Presentation

• Yutaka Shikano
• 07M01099
• Department of Physics,
• Tokyo Institute of Technology

2
Outline

1. Aim
2. Conventional Quantum Measurement
3. Concepts of Weak Values
4. Quantum Operations for Weak Operators
5. Conclusions and Discussions

3
1. Aim
4
Motivations

• Measurement and state changes are highly
  non-trivial in quantum mechanics.
• In conventional quantum measurement theory, we
  have only obtained the probability distribution.
• Experimentalists obtain the probability
  distribution from the experimental data to show
  quantum phenomena.
• However, is the representation of the measurement
  outcome only the probability distribution?

5
Aim

• To construct the general framework of the weak
  values advocated by Aharonov and his
  collaborators, which are experimentally
  accessible by the shift of the probe wave
  function in weak measurement.
• To show the efficiency of our proposed framework.

6
2. Conventional Quantum Measurement
7
Quantum Measurement Theory
(M. Ozawa, J. Math. Phys. 25, 79 (1984))
Target system
Probe system
t 0
t ?t
time
8
Representation of Quantum Measurement
Probe observable associated with the measured
observable is
Target state to obtain the measurement outcome
m is
Kraus operator
Positive operator valued measure (POVM)
9
What information is obtained?
Experimentalists task
histogram
x
x
eigenvalues
Projective measurement (more generally speaking,
POVM measurement) only gives information of the
probability distribution.
10
3. Concepts of Weak Values

• Could we construct another representation of the
  measurement outcome?

11
Definition of Weak Values
Def Weak values of observable A
pre-selected state
post-selected state
In order to measure the weak value
Def Weak measurement is called if a coupling
constant with a probe interaction is very small
and a measurement back action is also very small.
(Y. Aharonov, D. Albert, and L. Vaidman, Phys.
Rev. Lett. 60, 1351 (1988))
12
In order to Measure Weak Values
Probe system the pointer operator (position of
the pointer) is q and its conjugate operator is p.
Target system
Observable A
Probe state after measurement
Probe state before measurement
13
Probe system the pointer operator (position of
the pointer) is q and its conjugate operator is p.
Target system
Observable A
Since the weak value of A is complex in general,
Initial probe variance for the momentum
Weak values are experimentally accessible by the
shifts of expectation values for the probe
observables.
(R. Jozsa, Phys. Rev. A 76, 044103 (2007))
14
Experimental Realization
(K. Resch, J. S. Lundeen and A. Steinberg, Phys.
Lett. A 324, 125 (2003))
Prepare the initial state
Post-selected state
0
0
1
-1
15
Creating superposition of initial state
Creating the post-selected state.
Weak Measurement
Measuring the polarization.
16
Weak Measurement by Slide Glass
(N. M. W. Ritchie, J. G. Story, and R. G. Hulet,
Phys. Rev. Lett. 66, 1107 (2003))

• Use transverse position of each photon as pointer
• Weak measurement can be performed by tilting a
  glass optical flat, where effective

Probe
CCD camera
17
Perform weak measurement on rail C.
Post-selection rail AB-C (negative shift)
Post-selection rail C (positive shift)
Post-selection rail A and B (No shift)
18
Experimental Realization
Prepare the initial state
Post-selected state
0
0
1
-1
19
4. Quantum Operations
for Weak Operators

• Could we construct the general framework
  analogous to the conventional quantum measurement?

20
CP map for Quantum Operations
Positive map
Arbitrary extension of Hilbert space
When
is positive map,
is called a completely positive map (CP map).
(M. Ozawa, J. Math. Phys. 25, 79 (1984))
21
Kraus Representation
Any quantum state change can be described as the
operation only on the target system via the Kraus
operator .
In the case of Weak Values???
22
Weak Operator
(YS and A. Hosoya, arXiv0812.4507)

• In order to define the quantum operations
  associated with the weak values,

Weak Operator
23
Properties of Weak Operator
Relationship to Weak Value
Analogous to the expectation value
24
Quantum Operations for Weak Operators

• Key points of Proof
• Polar decomposition for the weak operator
• Complete positivity of the quantum operation

• The properties of the quantum operation are
• Two Kraus operators
• Partial trace for the auxiliary Hilbert space
• Mixed states for the weak operator

25
Weak operator describes the entire history of the
state evolution.
environment
system
Post-selected state
Possible history
Pre-selected state
environment
26
Weak Measurement with Decoherence
Target system
Environment
Observable A
No noisy operations with impulsive weak
measurement
The shifts of the expectation values of the probe
are
27
5. Conclusions and Discussions
28
Conclusions

• We have introduced the weak values and reviewed
  the experimental realization in the optical
  system.
• In analogous to the quantum operation for density
  operator, we construct the quantum operation for
  the weak operator associated with the weak values.

Probability Distribution
Phase Information
29
Discussions

• To construct the (differential) geometrical
  structure for the weak operator. (lt--gt the Bloch
  sphere representation for the density operator.)
• To extend the concept of the observable. The weak
  values can be defined for non-self-adjoint
  operators (e.g., phase operator and time
  operator.).

Thank you for your attention!
