An Action due to Thermal Inequilibrium

1
An Action due to Thermal Inequilibrium

• P M V Subbarao
• Professor
• Mechanical Engineering Department

Every member of earth wants it for A Refresh
.... A Natural Happening ..
2
A Wake-up Call to Earth
3
A Means of Generating Primary Wealth on Earth

• Development and ripening of vegetable substances
  demand the light and the heat of the Sun.
• The source of energy to the Organic Sphere.
• The energy of winds and water originate from the
  heat of the Sun.
• The winds arise from air currents due to the
  heating of the air by the Sun on Earth's surface.
• In order to fall, water must first be raised - by
  evaporation, which due to the heat of the Sun
  persists at the surface of the seas and Earth.
• Hence the heat of the Sun maintains all
  meteorological, climatic, geological and organic
  processes of Earth.

4
(No Transcript)
5
The Sun enlightens Every Life

• Kowsalya supraja Rama poorva sandhya
  pravarthatheUthishta narasardoola karthavyam
  daivamahnikam

6
A Natural Engineering Process for the Existence,
Growth and Performance.

• A True Design Reason behind Existence of Natural
  Systems..
• A Strong Design Modification for the Performance
  of Artificial Systems.

7
The Engineering Process Responsible for Evolution
8
The Geometry of Natural Products

• An orange is about double the diameter of a
  lemon, but could in principle hold eight times
  more juice in volume.
• Same goes for Elephants.
• Elephants are warm blooded tetrapods.
• Warm blooded animals desire to remain at an
  isothermal body temperature of 35 to 42 C
  (varies between animals).
• The body temperature is maintained at the desired
  value with a built-in thermo-regulatory
  mechanism.
• This mechanism either releases the excess heat
  produced in the metabolism or
• triggers the body to generate higher metabolic
  rate at times, when the body temperature falls
  below the desired value.

9
Why I Am Different ?
?
10
Geometry of An Elephent ?!?!?!

• A bigger warm blooded animal should in principle
  generate more metabolic heat energy simply
  because it has more volume hence more flesh and
  cells.
• This metabolic heat release has to be regulated
  if it is excess only through the heat transfer
  across the skin surface area.
• Firstly, in such a situation, having a fur coat
  of a hair structure is the least desired thing
  and hence Elephants are mostly bald.
• The hotter the climate in which they live, the
  balder they are.
• Secondly, Elephants have large ears which are
  packed with capillary structure through which
  sizable quantity of blood flows.
• The ear flaps of the elephant serve as an
  enormous convection fin - a flapping one at that
  - to enhance heat transfer from the elephant body
  to the environment.

11
Classification of Elephants
12
Mammoths, living in a cold tundra region, have
fur coats and small hairy ears.
13
An Exotic Artificial Device

• The basic invention is due to other sciences
• The final and reliable existence is due to Heat
  Transfer

14
The Pentium 4 Processor
15
Basic Location on A Mother Board
16
Heat Sinks for Pentium 4
17
Pentium 4 While Performing
18
Heat Sinks of Cooling of Electronics
19
Heat Sinks Guided Flow
20
Heat Sinks Guided Flow with Different Fin Shapes
21
Heat Sinks Curious Paired Video
Card-Motherboard Design
22
What is Heat Transfer?

• Thermal energy is related to the temperature of
  matter.
• For a given material and mass, the higher the
  temperature, the greater its thermal energy.
• Heat transfer is a study of the exchange of
  thermal energy through a body or between bodies
  which occurs when there is a temperature
  difference.
• When system and its surroundings are at different
  temperatures, thermal energy transfers from the
  one with higher temperature to the one with lower
  temperature.
• Thermal Energy always travels from hot to cold.
• This spontaneous act is called Heat Action or
  Heat Transfer.

23
Heat Transfer Between System Surroundings

• Heat transfer is typically given the symbol Q,
  and is expressed in joules (J) in SI units.
• The rate of heat transfer is measured in watts
  (W), equal to joules per second, and is denoted
  by q.
• The heat flux, or the rate of heat transfer per
  unit area, is measured in watts per area (W/m2),
  and uses q" for the symbol.

24
Heat Transfer What Happens to the System ?

• The thermal energy of the system may decrease or
  increase.
• However, temperature may or may not change
• What is the other property, which is directly
  affected by heat transfer?
• Specific Heat?
• Any couple like pressure and volume during work
  transfer?
• Not now .. May be later.

25
Modes of Heat Mass Transfer

• Conduction or Diffusion
• Radiation
• Convection

26
Thermal conduction through Earth's crust

• Two problems of Geophysics created a concern
  about heat conduction
• To what extent affects the heat of Earth's
  interior by conduction the temperature at the
  surface ?
• How far inward and in what manner propagate daily
  and seasonal temperature variations at Earth's
  surface?
• The answer through the theory of Kelvin to the
  first question is
• A stationary thermal state near Earth's surface,
  which maintains the heat of its interior, demands
  a uniform temperature gradient per metre inwards
  from the surface to the centre, provided all the
  different layers have the same thermal
  conductivity.
• Depending on their locations, temperature
  measurements in bore holes have yielded different
  results, on the average about 1ºC per 33m (medium
  geothermal depth gradient).
• An answer to the second question is best based on
  the observations of the Edinburgh Observatory
  (since 1837).

27
Conduction Heat Transfer

• Conduction is a significant mode of transfer when
  system and surroundings consist of solids or
  stationery fluids.
• When you touch a hot object, the heat you feel is
  transferred through your skin by conduction.
• Two mechanisms explain how heat is transferred by
  conduction lattice vibration and particle
  collision.
• Conduction through solids occurs by a combination
  of the two mechanisms heat is conducted through
  stationery fluids primarily by molecular
  collisions.

28
(No Transcript)
29
(No Transcript)
30
Fourier law of heat conduction
A Constitutive Relation

• The rate of heat transfer through the wall
  increases when
• The temperatures difference between the left and
  right surfaces increase,
• The wall surface area increases,
• The wall thickness reduces,
• The wall is changed from brick to aluminum.
• If we measure temperatures of the wall from left
  to right and plot the temperature variation with
  the wall thickness, we get

This is called as Fourier Law of Conduction
31
Thermal Image of Laptop Casing
32
Graphite Covering
33
Thermal Image of Laptop Casing with Graphite cover
34
Most General form of Fourier Law of Conduction
35
Radiative Mode of Heat Transfer

• Any body (gt absolute zero) emits radiation at
  various wavelengths.
• Transparent bodies radiate energy in spherical
  space.

• Non-transparent bodies radiate energy in
  hemi-spherical space.

• The radiation energy emitted by a body is
  distributed in space at various wavelengths.
• This complex phenomenon requires simplified laws
  for engineering use of radiation.

36
Planck Radiation Law

• The primary law governing blackbody radiation is
  the Planck Radiation Law.
• This law governs the intensity of radiation
  emitted by unit surface area of a blackbody as a
  function of wavelength for a fixed temperature.

• The Planck Law can be expressed through the
  following equation.

h 6.625 X 10-27 erg-sec (Planck Constant) K
1.38 X 10-16 erg/K (Boltzmann Constant) C
Speed of light in vacuum
37
Stefan-Boltzmann Law

• The maximum emissive power at a given temperature
  is the black body emissive power (Eb).
• Integrating Planks Law over all wavelengths gives
  Eb.

• Driving forces Heat transfer by radiation is
  driven by differences in emissive power
  (proportional to T4.

38
Radiation from a Thermodynamic System
The total energy emitted by a real system,
regardless of the wavelengths, is given by

• where esys is the emissivity of the system,
• Asys-surface is the surface area,
• Tsys is the temperature, and
• s is the Stefan-Boltzmann constant, equal to
  5.6710-8 W/m2K4.
• Emissivity is a material property, ranging from 0
  to 1, which measures how much energy a surface
  can emit with respect to an ideal emitter (e 1)
  at the same temperature
