Sliding Windows

1
Sliding Windows Silver Bullet or Evolutionary
Deadend?

• Alyosha Efros, Bastian Leibe, Krystian
  Mikolajczyk
• Sicily Workshop, Syracusa, 23.09.2006

2
What is a Sliding Window Approach?

• Search over space and scale
• Detection as subwindow classification problem
• In the absence of a more intelligent strategy,
  any global image classification approach can be
  converted into a localization approach by using a
  sliding-window search.

3
Task Object Localization in Still Images

• What options do we have to choose from?
• Sliding window approaches
• Classification problem
• PapageorgiouPoggio,00, SchneidermanKanade,0
  0, ViolaJones,01, Mikolajczyk et al.,04,
  Torralba et al.,04, DalalTriggs,05,
  WuNevatia,05, Laptev,06,
• Feature-transform based approaches
• Part-based generative models, typically with a
  star topology
• Fergus et al.,03, LeibeSchiele,04,
  Fei-Fei et al.,04, FelszenszwalbHuttenlocher,
  05, WinnCriminisi,06, Opelt et al.,06,
  Mikolajczyk et al.,06,
• Massively parallel NN architectures
• e.g. convolutional NNs
• LeCun et al.,98, Osadchy et al.,04, Garcia
  et al.,??,
• Smart segmentation based approaches
• Localization based on robustified bottom-up
  segmentation
• TodorovicAhuja,06, RothOmmer,06

4
Sliding-Window Approaches

• Pros
• Can draw from vast stock of ML methods.
• Independence assumption between subwindows.
• Makes classification easier.
• Process can be parallelized.
• Simple technique, can be tried out very easily.
• No translation/scale invariance required in
  model.
• There are methods to do it very fast.
• Cascades with AdaBoost/SVMs
• Good detection performance on many benchmark
  datasets.
• e.g. face detection, VOC challenges
• Direct control over search range (e.g. on ground
  plane).

5
Sliding-Window Approaches

• Cons
• Can draw from vast stock of ML methodsas long
  as they can be evaluated in a few ms.
• Need to evaluate many subwindows (100000s).
• ? Needs very fast accurate classification
• ? Many training examples required, often limited
  to low training resolution.
• ? Can only deal with relatively small occlusions.
• Still need to fuse resulting detections
• ? Hard/suboptimal from binary classification
  output
• Classification task often ill-defined
• How to label half a car?
• Difficult to deal with changing aspect ratios

6
Duality to Feature-Based Approaches

• How to find maxima in the Hough space
  efficiently?
• Maxima search coarse-to-fine sliding window
  stage!
• Main differences
• All features evaluated upfront (instead of in
  cascade).
• Generative model instead of discriminative
  classifier.
• Maxima search already performs detection fusion.

7
So What is Left to Oppose?

1. Feature-based vs. Window-based?
2. (Almost) exclusive use of discriminative methods
3. Low training resolutions
4. How to deal with changing aspect ratios?

8
1. Feature-based vs. Window-based

• May be mainly an implementation trade-off
• Few, localized features ? feature-based
  evaluation better
• Many, dense features ? window-based evaluation
  better
• Noticed already by e.g. Schneiderman,04
• The trade-offs may change as your method develops

9
2. Exclusive Use of Discriminative Methods
Leibe Schiele,04
10
Generative Models for Sliding Windows

• Continuous confidence scores
• Smoother maxima in hypothesis space
• Coarser sampling possible

11
Generative Models for Sliding Windows

• Continuous confidence scores
• Smoother maxima in hypothesis space
• Coarser sampling possible
• Backprojection capability
• Determine a hypothesiss support in the image
• Resolve overlapping cases

12
Generative Models for Sliding Windows

• Continuous confidence scores
• Smoother maxima in hypothesis space
• Coarser sampling possible
• Backprojection capability
• Determine a hypothesiss support in the image
• Resolve overlapping cases
• Easier to deal with partial occlusion
• Part-based models
• Reasoning about missing parts

13
Sliding Windows for Generative Models

• Apply cascade idea to generative models
• Discriminative training
• Evaluate most promising features first

14
Sliding Windows for Generative Models

• Apply cascade idea to generative models
• Discriminative training
• Evaluate most promising features first
• Direct control over search range
• Only need to evaluate positions in search
  corridor
• Only need to consider subset of features
• Easier to adapt to different geometry(e.g.
  curved ground surface)
• ? Should combine discriminative and generative
  elements!

Search corridor
15
3. Low Training Resolutions

• Many current s-w detectors operate on tiny images
• ViolaJones 24?24 pixels
• Torralba et al. 32?32 pixels
• DalalTriggs 64?96 pixels (notable exception)
• Main reasons
• Training efficiency (exhaustive feature selection
  in AdaBoost)
• Evaluation speed
• Want to recognize objects at small scales
• But
• Limited information content available at those
  resolutions
• Not enough support to compensate for occlusions!

16
4. Changing Aspect Ratios

• Sliding window requires fixed window size
• Basis for learning efficient cascade classifier
• How to deal with changing aspect ratios?
• Fixed window size
• ? Wastes training dimensions
• Adapted window size
• ? Difficult to share features
• Squashed views DalalTriggs
• ? Need to squash test image, too

17

• What is wrong with sliding window? Search
  complexity?

18

• Is there anything that cannot be done with
  sliding window?

19
Sliding-Window Approaches

• Pros
• Can draw from vast stock of ML methods.
• Simple technique, can be tried out very easily.
• There are methods to do it very fast.
• Good detection performance on many benchmark
  datasets.
• Direct control over search range (e.g. on ground
  plane).
• Cons
• Need to evaluate many subwindows (100000s).
• ? Needs very fast accurate classification ?
  cascades, AdaBoost
• ? Many training examples, often limited to low
  training resolution.
• ? Can only deal with relatively small occlusions.
• Still need to fuse resulting detections
• ? Hard/suboptimal from binary classification
  output
• Difficult to deal with changing aspect ratios

20
So What is Left to Oppose?

• Feature-based vs. Window-based?
• Mainly implementation trade-off
• (Almost) exclusive use of discriminative methods
• Why not apply generative methods instead, or
  combinations?
• ? Smoother maxima in sampled 3D space.
• ? Ability to backproject responses (top-down
  segmentation).
• ? Easier to deal with partial occlusions.
• Low training resolutions
• Only limited information content
• How to deal with changing aspect ratios?
• E.g. front side views of cars?
• Fixed/adaptive window size?
• How to share features between those?
