Molecule as Computation

1
Molecule as Computation
Ehud Shapiro Weizmann Institute of Science Joint
work with Aviv Regev and Bill Silverman In
collaboration with Corrado Priami, Naama Barkai
and Luca Cardelli
2
The talk has three parts

1. Briefly introduce molecular biology
2. Computer-based consolidation of molecular biology
3. Our work on helping this happen

3
Part IBrief Introduction to Molecular Biology
4
Pentium II E. Coli
5
Pentium II E. Coli

• 1 million macromolecules
• 1 million bytes of static genetic memory
• 1 million amino-acids per second

• 3 million transistors
• 1/4 million bytes of memory
• 80 million operations per second

Comparison courtesy of Eric Winfree
6
Pentium II E. Coli
7
Pentium II E. Coli
1 micron
8
Pentium II E. Coli
1 micron
1 micron
9
Inside E. Coli
10
Inside E. Coli
(1Mbyte)
11
Ribosomes in operation

• Ribosomes translate RNA to Proteins
• RNA Polymerase transcribes DNA to RNA

12
Ribosomes in operation
( protein)
Computationally A stateless string transducer
from the RNA alphabet of nucleic acids to the
Protein alphabet of amino acids
13
Ribosome operation
14
Ribosome operation
15
Ribosome operation
16
Ribosome operation
17
Seqeunces and String Transducers

• Ribosomes translate RNA to Proteins
• RNA Polymerase transcribes DNA to RNA

18
Molecular Biology in One Slide

• Sequence Sequence of DNA and Proteins

19
(No Transcript)
20
(No Transcript)
21
Molecule as Computation
Ehud Shapiro Weizmann Institute of Science Joint
work with Aviv Regev and Bill Silverman In
collaboration with Corrado Priami, Naama Barkai
and Luca Cardelli
22
The talk has three parts

1. Briefly introduce molecular biology
2. Computer-based consolidation of molecular biology
3. Our work on helping this happen

23
Part IBrief Introduction to Molecular Biology
24
Pentium II E. Coli
25
Pentium II E. Coli

• 1 million macromolecules
• 1 million bytes of static genetic memory
• 1 million amino-acids per second

• 3 million transistors
• 1/4 million bytes of memory
• 80 million operations per second

Comparison courtesy of Eric Winfree
26
What about The Rest of biology the function,
activityand interaction of molecular systems in
cells?
?
27
Part III An Abstraction for Molecular Systems
28
The New Biology

• The cell as an information processing device
• Cellular information processing and passing are
  carried out by networks of interacting molecules
• Ultimate understanding of the cell requires an
  information processing model
• Which?

29

• We have no real algebra for describing
  regulatory circuits across different systems...
• - T. F. Smith (TIG 14291-293, 1998)
• The data are accumulating and the computers are
  humming, what we are lacking are the words, the
  grammar and the syntax of a new language
• - D. Bray (TIBS 22325-326, 1997)

30
Our Proposal Molecule as Computational Process
A system of interacting molecular entities is
described and modelled by a system of interacting
computational entities.
Cellular Abstractions Cells as Computation,
to appear in Nature, September 26th, 2002
31
Composition of two processes is a process,
therefore

• Molecular ensembles as processes
• Molecular networks as processes
• Cells as processes (virtual cell)
• Multi-cellular organisms as processes
• Collections of organisms as processes

32
Towards Molecule as Process

1. Use the p-calculus process algebra as molecule
   description language

33
The p-calculus (Milner, Walker and Parrow 1989)

• A program specifies a network of interacting
  processes
• Processes are defined by their potential
  communication activities
• Communication occurs on complementary channels,
  identified by names
• Message content Channel name

34
p-calculus key constructs
Parallel A B
Choice A B
Communication X ! M or X ? Y
Recursion, with state change P - P
35
Molecules as Processes
Molecule Process
Interaction capability Channel
Interaction Communication
Modification State change
36
Na Cl lt? Na Cl-

• Na Na Na Cl Cl Cl
• Na e ! , Na_plus .
• Na_plus e ? , Na .
• Cl e ? , Cl_minus .
• Cl_minus e ! , Cl .

Processes, guarded communication, alternation
between two states.
37
The RTK-MAPK pathway

• 16 molecular species
• 24 domains 15 sub-domains
• Four cellular compartments
• Binding, dimerization, phosphorylation,
  de-phosphorylation, conformational changes,
  translocation
• 100 literature articles
• 250 lines of code

38
Molecular systems with p-calculus

• Can express, qualitatively, the behavior of many
  complex molecular systems
• Cannot express quantitative aspects

39
Towards Molecule as Process

1. Use the p-calculus process algebra as molecule
   description language
2. Provide a biochemistry-oriented stochastic
   extension (with Corrado Priami)

40
Stochastic p-Calculus (Priami, 1995, Regev,
Priami, Shapiro, Silverman 2000)

• Every channel x attached with a base rate r
• A global (external) clock is maintained
• The clock is advanced and a communication is
  selected according to a race condition
• Rate calculation and race condition adapted for
  chemical reactions
• Rate(AB ? C) BaseRate AB
• A number of As willing to communicate with
  Bs.
• B number of Bs willing to communicate with
  As.

41
BioSPI implementation p-calculus Gillespies
algorithm

• Gillespie (1977) Accurate stochastic simulation
  of chemical reactions
• The BioSPI system
• Compiles (full) p-calculus
• Runtime incorporates Gillespies algorithm

42
Na Cl lt? Na Cl-

• global(e1(100),e2(10)).
• Na e1 ! , Na_plus .
• Na_plus e2 ? , Na .
• Cl e1 ? , Cl_minus .
• Cl_minus e2 ! , Cl .

43
Programming Experience with Stochastic Pi
Calculus

• Taught semesterial M.Sc. Course (available
  online) with lots of examples, exercises and
  final projects
• Textbook examples from chemistry, organic
  chemistry, enzymatic reactions, metabolic
  pathways, signal-transduction pathways

44
Circadian Clocks
J. Dunlap, Science (1998) 280 1548-9
45
The circadian clock machinery (Barkai and
Leibler, Nature 2000)
Differential rates Very fast, fast and slow
46
The machinery in p-calculus A molecules
A_GENE PROMOTED_A BASAL_APROMOTED_A pA ?
e.ACTIVATED_TRANSCRIPTION_A(e)BASAL_A bA ?
.( A_GENE A_RNA)ACTIVATED_TRANSCRIPTION_A
t1 . (ACTIVATED_TRANSCRIPTION_A A_RNA) e ?
. A_GENE
A_Gene
RNA_A TRANSLATION_A DEGRADATION_mATRANSLATIO
N_A utrA ? . (A_RNA A_PROTEIN)DEGRADATION
_mA degmA ? . 0
A_RNA
A_PROTEIN (new e1,e2,e3)
PROMOTION_A-R BINDING_R DEGRADATION_APROMOTIO
N_A-R pA!e2.e2!. A_PROTEIN
pR!e3.e3!. A_PRTOEINBINDING_R rbs !
e1 . BOUND_A_PRTOEIN BOUND_A_PROTEIN e1 ?
.A_PROTEIN degpA ? .e1 !.0DEGRADATION_A
degpA ? .0
A_protein
47
The machinery in p-calculus R molecules
R_GENE PROMOTED_R BASAL_RPROMOTED_R pR ?
e.ACTIVATED_TRANSCRIPTION_R(e)BASAL_R bR ?
.( R_GENE R_RNA)ACTIVATED_TRANSCRIPTION_R
t2 . (ACTIVATED_TRANSCRIPTION_R R_RNA) e ?
. R_GENE
R_Gene
RNA_R TRANSLATION_R DEGRADATION_mRTRANSLATIO
N_R utrR ? . (R_RNA R_PROTEIN)DEGRADATION
_mR degmR ? . 0
R_RNA
R_PROTEIN BINDING_A DEGRADATION_RBINDING_R
rbs ? e . BOUND_R_PRTOEIN
BOUND_R_PROTEIN e1 ? . A_PROTEIN degpR
? .e1 !.0DEGRADATION_R degpR ? .0
R_protein
48
BioSPI simulation
A
R
Robust to random perturbations
49
The A hysteresis module
A
A
ON
Fast
Fast
OFF
R
R

• The entire population of A molecules (gene, RNA,
  and protein) behaves as one bi-stable module

50
Hysteresis module
ON_H-MODULE(CA) CAltT1 . OFF_H-MODULE(CA)
CAgtT1 . (rbs ! e1 . ON_DECREASE
e1 ! . ON_H_MODULE pR ! e2 . (e2 !
.0 ON_H_MODULE) t1 . ON_INCREASE) ON_INCRE
ASE CA . ON_H-MODULEON_DECREASE CA--
. ON_H-MODULE
ON
OFF_H-MODULE(CA) CAgtT2 . ON_H-MODULE(CA)
CAltT2 . (rbs ! e1 . OFF_DECREASE
e1 ! . OFF_H_MODULE t2 .
OFF_INCREASE ) OFF_INCREASE CA .
OFF_H-MODULEOFF_DECREASE CA-- . OFF_H-MODULE
OFF
51
Modular cell biology

• Build two representations in the p-calculus
• Implementation (how?) molecular level
• Specification (what?) functional module level

52
The circadian specification
53
BioSPI simulation
Module, R protein and R RNA
R (module vs. molecules)
54
Modular cell biology

• Build two representations in the p-calculus
• Implementation (how?) molecular level
• Specification (what?) functional module level
• Ascribing a function to a biomolecular system
  equivalence between specification and
  implementation

55
Limitation of stochastic p- calculus Lack of
location information

• Membranes Cells and cellular compartments,
  inside and outside
• Molecular proximity The identity of complexes
  and single molecules
• Limited solution programming tricks

56
Towards Molecule as Process

1. Use the p-calculus process algebra as molecule
   description language
2. Provide a biochemistry-oriented stochastic
   extension (with Corrado Priami)
3. Provide an Ambient Calculus extension (with Luca
   Cardelli)

57
Mobile compartments
Compartment Compartment mobility Process mobility
Cells Cell movement Trans-membranal molecules (receptors, channels, transporters) Molecule entry and exit
Organelles and vesicles Merging, budding, bursting Trans-membranal molecules (receptors, channels, transporters) Molecule entry and exit
Multi-molecular complexes Form and break Bind and unbind to molecular scaffolds
58
The ambient calculus (Cardelli and Gordon)

• An ambient is a bounded place where computation
  happens

Ambient
Processes
59
The ambient calculus (Cardelli and Gordon)

• The ambients boundary restricts process
  interactions across it

Ambient
Processes
60
The ambient calculus (Cardelli and Gordon)

• Processes can move in and out of ambients

Ambient
Processes
61
Compartments as ambients
62
Synchronized ambient movement
enter/accept exit/expel merge/merge-
63
Molecules and complexes
enter/accept exit/expel merge/merge-
64
Vesicle merging
Vesicle
Cell
Cell
65
Single substrate reactionsEnzyme and substrate
as ambients
Enzyme
enter
exit
S
X
P
exit
enter
66
Bi-substrate reactions Inter-ambient
communication
Enzyme
enter
exit
S1
X
P1
exit
enter
s2s
enter
exit
S2
Y
P2
exit
enter
67
Example Multi-cellular system (hypothalamic body
weight control system)
68
2
69
Conclusions

• The most advanced tools for computer process
  description seem to be also the best tools for
  the description of biomolecular systems
• This intellectual economy validates the
  decades-long study of concurrency in computer
  science
• An essential foundation for the forthcoming
  Virtual Cell Project
