Performing Tasks in Asynchronous Environments

• Dariusz Kowalski
• University of Connecticut Warsaw University
• joint work with
• Alex Shvartsman
• University of Connecticut MIT

2
Do-All problem (DHW et al.)

• DA(p,t) problem abstracts the basic problem of
  cooperation in a distributed setting
• p processors must perform t tasks, andat least
  one processor must know about it
  Dwork Halpern Waarts
  92/98
• Tasks are
• known to every processor
• similar - each takes similar number of local
  steps
• independent - may be performed in any order
• idempotent - may be performed concurrently

3
Do-All synchronous model with crashes

• Model processors are synchronous, may fail by
  crashes
• Solutions problem well understood, results close
  to optimal
• Shared-memory model -- communication by
  read/write
• Kanellakis, P.C., Shvartsman, A.A.
• Fault-tolerant parallel computation. Kluwer
  Academic Publishers (1997)
• Message-passing model -- communication by
  exchanging messages
• Dwork, C., Halpern, J., Waarts, O.
• Performing work efficiently in the presence of
  faults.
• SIAM Journal on Computing, 27 (1998)
• De Prisco, R., Mayer, A., Yung, M.
• Time-optimal message-efficient work performance
  in the presence of faults. Proc. of 13th
  PODC, (1994)
• Chlebus, B., De Prisco, R., Shvartsman, A.A.
• Performing tasks on synchronous restartable
  message- passing processors. Distributed
  Computing, 14 (2001)

4
Do-All asynchronous models

• Models
• Shared-memory model -- communication by
  read/write -- widely studied, but solutions far
  from optimal
• Kanellakis, P.C., Shvartsman, A.A.
  Fault-tolerant parallel computation. Kluwer
  Academic Publishers (1997)
• Anderson, R.J., Woll, H. Algorithms for the
  certified Write-All problem. SIAM Journal on
  Computing, 26 (1997)
• Kedem, Z., Palem, K., Raghunathan, A., Spirakis,
  P. Combining tentative and definite executions
  for very fast dependable parallel computing.
  Proc. of 23rd STOC, (1991)
• Message-passing model -- communication by
  exchanging messages -- no interesting solutions
  until recently

5
Shared-Memory vs. Message-Passing

• Shared-Memory (atomic registers)
• processors communicate by read/write in
  shared-memory
• atomicity - guarantees that read outputs the last
  written value
• one read/write operation per local clock cycle
• information propagates and information is
  persistent
• Hence cooperation is always possible, although
  delayedHere processor scheduling is the major
  challenge
• Message-Passing
• processors communicate by exchanging messages
• duration of a local step may be unbounded
• message delays may be unbounded
• information may not propagate -- send/recv depend
  on delay

6
Message-delay-sensitive approach

• Even if messages delay are bounded by d
  (d-adversary),cooperation may be difficult
• Observation
• If d ?(t) then work must be ?(t p)
• This means that cooperation is difficult, and
  addressing scheduling alone is not enough - -
  algorithm design and analysis must be d-sensitive
• Message-delay-sensitive approach
• C. Dwork, N. Lynch and L. Stockmeyer. Consensus
  in the presence of partial synchrony. J. of the
  ACM, 35 (1988)

7
Measures of efficiency

• Termination time the first time when all tasks
  are done and at least one processors knows about
  it
• Used only to define work and message complexity
• Not interesting on its own if all processors but
  one are delayed then trivially time is ?(t)
• Work measures the sum, over all processors, of
  the number of local steps taken until termination
  time
• Message complexity (message-passing model)
  measures number of all point-to-point messages
  sent until termination time

8
Structure of the presentation

• Part 1 Shared-memory model
• Model and bibliography
• Improving AW algorithm in shared-memory by better
  scheduling processors (task load-balancing)

• Part 2 Message-passing model.
• Model asynchrony, message delay, and modeling
  issues
• Delay-sensitive lower bounds for Do-All
• Progress-tree Do-All algorithms
• Simulating shared-memory and Anderson-Woll (AW)
• Asynch. message-passing progress-tree algorithm
• Permutation Do-All algorithms

9
Shared-Memory - model and goal

• We consider the following model
• p asynchronous processors with PID in 0,,p-1
• processors communicate by read/write in
  shared-memory
• atomicity - read outputs the last written value
• one read/write operation per local clock cycle
• Write-All write 1s into t locations of given
  array

Goal improve scheduling of cooperating
asynchronous processors leading to better
load-balancing wrt tasks
10
Write-All Selected Bibliography

• Introducing Write-All problem
• Kanellakis, P.C., Shvartsman, A.A. Efficient
  parallel algorithms can be made robust. PODC
  (1989), Distributed Computing (1992)
• AW algorithm with work O(t p? )
• Anderson, R.J., Woll, H. Algorithms for the
  certified Write-All problem. SIAM Journal on
  Computing, 26 (1997)
• Randomized algorithm with work ?(t plog p)
• Martel, C., Subramonian, R. On the complexity of
  Certified Write-All algorithms. J. Algorithms 16
  (1994)
• First work-optimal deterministic algorithm for
  t ?(p4log p)
• Malewicz, G. A work-optimal deterministic
  algorithm for the asynchronous Certified
  Write-All problem. PODC (2003)

11
Progress tree algorithms BKRS, AW

• Shared memory
• p processors, t tasks (p t)
• q permutations of q
• q-ary progress tree of depth logq p
• nodes are binary completion bits

• Permutations establish the order in which
  the children are visited
• p processors traverse the tree and use
  q-ary expansion of their PID to choose
  permutations
• Anderson Woll

1 2 3 q
1 2 3 q
1 2 3 q
12
Algorithm AWT Anderson Woll

• Progress tree data structure is stored in shared
  memory
• p, t 9 , q 3
• ? list of 3 schedules from S3
• T ternary tree of 9 leaves (progress
  tree), values 0-1
• PID(j) j-th digit of ternary-representation
  of PID

1
2
3
?0 PID 0,3,6
?1 PID 1,4,7
0
?2 PID 2,5,8
7213
1
2
3
7213
4
5
8
7
9
10
12
11
6
13
Contention of permutations

• Sn - group of all permutations on set n,
• with composition ? and identity ?n
• ?, ? - permutations in Sn
• ? - set of q permutations from Sn
• i is lrm (left-to-right maximum) in ? if ?(i) gt
  maxjlti ?(j)
• LRM(? ) - number of lrm in ? Knuth
• Cont(?,? ) ?? ?? LRM(? -1 ? ?)
• Contention of ? Cont(? ) max? Cont(?,? )
  AW
• Theorem AW For any n gt 0 there exists set ?
  of n permutations from Sn with Cont(? ) ? 3nHn
  ?(n log n).
• Knuth Knuth, D.E. The art of computer
  programming Vol. 3 (third edition).
  Addison-Wesley Pub Co. (1998)

10
3
5
2
4
6
1
9
7
8
11
14
Procedure Oblivious Do

• n - number of jobs and units
• ? - list of n schedules from Sn
• Procedure Oblivious
• Forall processors PID 0 to n-1
• for i 1 to n do
• perform Job(? PID(i))
• Execution of Job(? PID(i)) by processor PID is
  primary, if job ? PID(i) has not been previously
  performed
• Lemma AW In algorithm Oblivious with n units,
  n jobs, and using the list? of n permutations
  from Sn, the number of primary job executions is
  at most Cont(? ).

15
AWT(q) - new progress tree traversal algorithm

• Instead of using q permutations on set q, we
  use q permutations on set n, where n q2 log
  q
• p 6 , t 16 , q 2, n 4
• ? list of 2 schedules from S4
• T 4-ary tree of 16 leaves (progress
  tree), values 0-1
• PID(j) j-th digit of ternary-representation
  of PID

?0 PID even
?1 PID odd
0
51014
1
2
3
4
51014
5
6
9
8
10
11
13
12
7
14
15
16
17
18
19
20
16
Main result

• Set n q2 log q and let ? be list of q
  schedules from Sn
• Define Cont(?, ?) max? ? ? Cont(?,? )
• Lemma For sufficiently large q and any set ? of
  at most exp(q2 log2 q) permutations on set q2
  log q, there is a list of q schedules ? from Sn
  such that
• Cont(?, ?) ? q2 log q 6q log q
• Take q log p and ? from above Lemma
• Theorem For every ? gt 0, sufficiently large p
  and t ?(p2?), algorithm AWT(q) performs
  work O(t).

17
Message-Passing - model and goals

• We consider the following model
• p asynchronous processors with PID in 0,,p-1
• processors communicate by message passing
• in one local step each processor can send a
  message to any subset of processors
• messages incur delays between send and receive
• processing of all received messages can be done
  during one local step
• Goal understand the impact of message delay on
  efficiency of algorithmic solutions for Do-All

18
Lower bound - randomized algorithms

• Theorem Any randomized algorithm solving DA with
  t tasks using p asynchronous message-passing
  processors performs expected work
• ?(tp?d?logd1 t)
• against any d-adversary.
• Proof (sketch)
• Adversary partitions computation into stages,
  each containingd time units, and constructs
  delay pattern stage after stage
• ? delays all messages in stage to be received at
  the end of stage
• ? delays linear number of processors (which want
  to perform more than (1-1/(3d)) fraction of
  undone tasks) during stage
• selection is on-line, with high probability has
  good properties

19
Simulating shared-memory algorithms

• Write-All algorithm AWT
• Anderson, R.J., Woll, H. Algorithms for the
  certified Write-All problem. SIAM Journal on
  Computing, 26 (1997)
• Quorum systems Atomic memory services
• Attiya, H., Bar-Noy, A., Dolev, D. Sharing
  memory robust-ly in message passing systems. J.
  of the ACM, 42 (1996)
• Lynch, N., Shvartsman, A. RAMBO A
  Reconfigurable Atomic Memory Service. Proc. of
  16th DISC, (2002)
• Emulating asynchronous shared-memory algorithms
• Momenzadeh, M. Emulating shared-memory Do-All in
  asynchronous message passing systems. Masters
  Thesis, CSE, University of Conn, (2003)

20
Atomic memory is not required

• We use q-ary progress trees as the main data
  structure that is written and read -- note
  that atomicity is not required
• If the following two writes occur (the entire
  tree is written), then a subsequent read may
  obtain a third value that was never written
• Property of monotone progress
• 1 at a tree node i indicates that all tasks
  attached to the leaves in the sub-tree rooted in
  i have been performed
• If 1 is written at a node i in the progress tree
  of a processor, it remains 1 forever

0
0
0
write
write
read
1
0
0
1
1
1
21
Algorithm DAq - traverse progress tree

• Instead of using shared memory, processors
  broadcast their progress trees as soon as local
  progress is recorded
• p, t 9 , q 3
• ? list of 3 schedules from S3
• T ternary tree of 9 leaves (progress
  tree), values 0-1
• PID(j) j-th digit of ternary-representation
  of PID

1
2
3
?0 PID 0,3,6
?1 PID 1,4,7
0
?2 PID 2,5,8
7213
1
2
3
7213
4
5
8
7
9
10
12
11
6
22
Algorithm DAq - case p ? t
23
Procedure DOWORK
24
Algorithm DAq - analysis

• Modification of algorithm DAq for p lt t
• We partition the t tasks into p jobs of size t
  /p and let the algorithm DAq work with these
  jobs.
• It takes a processor O(t /p) work (instead of
  constant) to process such a job (job unit).
• In each step, a processor broadcasts at most one
  message to p-1 other processors, we obtain
• Theorem 4 For any constant ? gt 0 there is a
  constant q such that the algorithm DAq has work
• W(p,t,d) O(t?p? p?d??t /d? ? )
• and message complexity
• O(p ? W(p,t,d))
• against any d-adversary (do(t)).

25
Permutation algorithms - case p ? t

• Algorithms proceed in a loop
• select the next task using ORDERSELECT rule
• perform selected task
• send messages, receive messages, and update state
• ORDERSELECT rules
• PARAN1 initially processor PID permutes tasks
  randomly
• PID selects first task remaining on
  his schedule
• PARAN2 no initial order
• PID selects task from remaining sets
  randomly
• PADET initially processor PID chooses
  schedule ?PID in ?
• PID selects first task remaining on
  schedule ?PID
• ? - list of p schedules from St

26
d-Contention of permutations

• We introduce the notion of d-Contention
• i is d-lrm in ? if j lt i ?(i) lt ?(j) lt d
• d 2
• LRMd(?) - number of d-lrm in ?
• Contd(?,? ) ?? ?? LRMd(? -1 ? ?)
• d-Contention of ? Contd(? ) max? Contd(?,?
  )
• Theorem For sufficiently large p and n, there
  is a list ? of p permutations from Sn such that,
  for every integer d gt1,
• Contd(? ) ? n log n 5pd ln(en/d).
• Moreover, random ? is good with high
  probability.

10
3
5
2
4
6
1
9
7
8
11
27
d-Contention and work

• Lemma For algorithms PADET and PARAN1, the
  respective worst case work and expected work is
  at most
• Contd(? )
• against any d-adversary.
• Example
• p 2, t 11, d 2

Order of tasks to perform 1,2,3,4,5,6,7,8,9,10,1
1
1
3
2
5
7
4
9
8
6
11
10
1
3
2
5
7
9
11
10
2
4
6
8
10
11
9
7
5
3
1
2
4
6
8
10
11
28
Permutation algorithms - results

• Theorem Randomized algorithms PARAN1 and PARAN2
  perform expected work
• O(t?log p p?d?log(t /d))
• and have expected communication
• O(t?p?log p p2?d?log(t /d))
• against any d-adversary (do(t)).
• Corollary There exists a deterministic list of
  schedules ? such that algorithm PADET performs
  work
• O(t?log p p?mint,d?log(2t /d))
• and has communication
• O(t?p?log p p2?mint,d?log(2t /d))
• when p ? t.

29
Conclusions and open problems

• Work-optimal Write-All algorithm for t ?(p2?)
• First message-delay-sensitive analysis of the
  Do-All problem for asynchronous processors in
  message-passing model
• lower bounds for deterministic and randomized
  algorithms
• deterministic and randomized algorithms with
  subquadratic(in p and t ) work for any message
  delay d as long as do(t)
• Among the interesting open questions are
• is there work-optimal scheduling for t ?(p log
  p)
• for algorithm PADET how to construct list ? of
  permutations efficiently
• closing the gap between the upper and the lower
  bounds
• investigate algorithms that simultaneously
  control work and message complexity
