Chapter 6 Landslides

1
Chapter 6 Landslides Related Phenomena
2
Learning Objectives

• Gain a basic understanding of slope stability and
  mechanisms of slope failure
• Understand the role of driving and resisting
  forces affecting slope stability
• Understand factors that affect slope processes
• Topography
• Climate
• Vegetation
• Water
• Time
• (Gravity)
• (rock type)
• Understand how human use of land affect
  landslides slopes
• Familiarization with identification, prevention,
  warning, correction of landslides
• Appreciation for processes related to land
  subsidence (Part B)

3
Terms Definitions

• Landslide
• Rapid downslope movement of rock/soil as a
  coherent mass
• Comprehensive term for any type of downslope
  movement of rock/soil
• Related terms
• Slope failure
• Mass wasting

4
(No Transcript)
5
Slope Processes

• Slopes
• Common landform
• Appearance as stable/static features
• Typically dynamic, evolving systems
• Downslope movement of material
• Interaction with other systems
• Rivers, stream valleys, floodplains
• Soil formation
• Eolian (wind)
• Volcanoes

6
Slope Elements

• Convex slope/crest
• Associated with creep
• Free-face (steep/vertical)
• Associated with rockfalls
• Debris slope
• Angle of repose ? 30o-35o
• Concave slope or wash slope
• Produced by processes associated with running
  water

7
(No Transcript)
8
Types/Patterns of Downslope Movement
9
Patterns of Downslope Movement
10
Classification of Downslope Movements
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Debris Flow
15
(No Transcript)
16
Slope Stability

• Relationship between driving resisting forces
• Driving forces (DF)
• Weight of rock, soil
• Weight of superimposed material
• Vegetation
• Fill
• Buildings
• Resisting forces (RF)
• Shear-strength of slope material acting along
  potential slip planes
• Cohesion
• Internal friction
• Ratio RF/DF Factor of Safety (FS)
• gt1.0 stable
• lt1.0 unstable
• Subject to changed conditions (see example fig.
  6.4)

17
Causes of Landslides

• Real Causes
• Driving Forces gt Resisting Forces
• Primary Forces
• Gravity (downward force downslope component)
• Resistance shear strength
• Factors and Causes
• Landslides occur when forces along potential
  rupture surfaces exceed the forces resisting
  movement (i.e., cohesion, frictional)

18
Functional Relationships
Relationships between driving force (weight)
resistance force (R)
Resisting force (R) is proportional to shear
strength of material (S) Where shear strength or
resistance (S) S C (sn -u) tan f

• The main driving force is the downslope component
  of the weight (force) of the material above the
  potential slip plane W sin q where
• W
• Weight of material (above plane)
• angle of the plane
• (from horizontal)

The factors in S are u fluid pressure (pore
water pressure) tan f coefficient of internal
friction f angle of internal friction
(frict. resist.) sn normal stress (i.e., normal
to surface or plane of discontinuity C
cohesion of material -----------------------------
------------ C and f depend on material type C,
f, and u vary with water content
19
Factors/Controls

• Gravity/Amount of material (above a slip plane)
• Weight (force) downslope component of the weight
  of the slope materials above the slip plane
• Downward
• Normal to surface or plane of discontinuity (sn)
• Angle of repose (slope angle)
• Parallel to surface or plane of discontinuity
• Rock/Material Type
• Structure (layering, foliation, etc.)
• Water
• Others?

20
(No Transcript)
21
(No Transcript)
22
Some Implications, Relationships

• The steeper the angle of inclination from
  horizontal, the larger the shear stress
• Decreases in S ? less strength, i.e., less force
  is required to cause a rupture
• C and q have different values for
• different types of soil or rock materials
• dry materials vs. wet materials
• Angles of frictional resistence (q) of dry rock
  materials vary from q gt40o for some igneous
  rocks, to q 10o-20o for clay.
• For materials like soil and clay-rich rocks, q
  can be smaller by a factor of 2 for saturated
  conditions

23
Factors Resulting in Decreased Slope Stability

• Increased pore pressure (affects sn) e.g.,
  Storms, fluctuating groundwater
• Increased water content (reduces C, q)
• Steepening of slopes (affects sn)
• Loading of slopes (affects sn)
• Earthquake shaking (reduces C, q)
• Removal of material from the base of slopes
  (Directly reduces S)
• Rivers, waves, man
• Changes in vegetation
• Change in chemical composition of pore water

24
Role of Slope Topography

• Slope angle (slope) correlated with
• Driving force (e.g., gt15 slope)
• Correlation w/ geography
• Extent of landslide activity
• Steep slopes
• Rockfalls, debris avalanches
• Soil slips turn into mudflows (saturated slopes)
• Moderate slopes
• Earthflows/mudflows, debris flow

25
Roles of Rock/Soil Type

• Patterns of movement
• Rotational slides (slumps)
• occur along curved surfaces
• Produces topographic benches (see fig.)
• Commonly occur in weak rock types (e.g., shale)
• Translational slides
• Planar
• Occur along inclined slip planes within a slope
  (6.2)
• Fractures in all rock types
• Bedding planes in rock slopes
• Clay partings
• Foliation planes (metamorphic rocks)
• Soil Slips
• Type of translation slide
• Slip plane above bedrock, below soil
• Colluvium

26
Slope Material Strength

• Influences magnitude frequency of slides
• Creep, earthflows, slumps, soil slip
• Common on slope of
• Shale
• Weak pyroclastic (volcanic) material
• Less common on slopes of more resistant rock
• Well-cemented sandstone
• Limestone
• granite

27
Role of Water

• Almost always involved with slope failure
• Soil water/moisture
• Cohesion (unsaturated vs. saturated effects)
• Chemical weathering effects on slope strength
• Soil shear strength ? 1/(pore water pressure)
• pore water pressure ? water saturation
• Rise in water table (incl. perched) ? reduced
  shear strength
• Unsupported bank storage
• Liquifaction (of clay-rich sediments that loose
  shear strength)

28
(No Transcript)
29
Role of Climate Vegetation

• Controls nature/extent of ppt., moisture content
• Vegetation effects (dependent on plant type)
• Enhances infiltration/retards erosion
• Enhanced cohesion
• Adds weight to slope
• Transpiration reduces soil moisture

30
Climatic Effects

• Semiarid regions or regions with resistant rocks
• Steep slope profiles (free-faces) (6.1a)
• Soil at crest wash slope (not free face)
• Subhumid regions or areas of soft rocks
• Gentler slope profiles (6.1b)
• Soil
• thick at top bottom parts of slope
• Thin in steeper middle portions

31
Role of Time

• Forces on slopes change w/ time
• Moisture content
• Water table
• Weathering (reduced cohesion)

32
Causes Prevention
33
(No Transcript)
34
Human Use and Landslides

• Timber harvesting
• Urbanization
• (Irrigation)

35
Minimizing Landslide Hazards

• Identification of potential landslides
• Prevention of Landslides
• Drainage controls
• Grading
• Slope supports
• Warning systems
• Landslide correction

36
(No Transcript)
37
(No Transcript)
38
Mitigation/Prevention

• Slope Drainage
• Slope Reduction
• Engineering Methods/Structures
• Grading of slopes
• (see figures)

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Features Recognition of Landslides
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
Examples, Case Studies
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
Others(Subsidence-In Part B)

• Snow Avalanche
• Subsidence
• Sinkholes
• Salt deposits
• Coal mining

57
Causes of Landslides

• Real Causes
• Driving Forces gt Resisting Forces
• Immediate causes (triggers)
• Earthquake shocks
• Vibrations
• Sudden increase in water
• External Causes
• Slope loading
• Steepening
• Earthquake shocks
• Internal Causes Causes that reduce shear
  strength
