Chapter 6: Cell Structures

1
Chapter 6 Cell Structures Their Functions
2
6.1 Cell Study Technology

• All living things are made of cells!
• (Remember its one of our characteristics of
  life)
• A living thing can be made of one cell or
  trillions of them.

3
6.1 Cell Study Technology

• Examples of multicellular organisms animals,
  plants, fungi
• Examples of unicellular organisms algae,
  bacteria, yeast

4
6.1 Cell Study Technology

• THE CELL THEORY
• 1. Cells, or products made by cells, are the
  units of structure function in organisms.
• (All living things are made up of cells)
• 2. All cells come from preexisting cells.
• (Cells can only come from other cells.)

5
6.1 Cell Study Technology

• Technological Advances
• Improved microscopes dictated the progress of
  cell study. As microscopes got more advanced,
  scientists could study more complex aspects of
  the cell.

6
6.1 Cell Study Technology

• Technological Advances
• Electron microscopes reveal the tiniest cell
  parts with tremendous magnification HOWEVER, you
  can only examine non-living cells

Picture of a hair using an electron microscope
7
6.1 Cell Study Technology

• Cell Size
• Cells vary greatly in size, but on average they
  are 10 20 µm (micrometers 10-6m)

8
6.2 Two Basic Types of Cells

• All living things fall into one of two categories
  of cells
• 1. Prokaryotes (simple cells)
• Example Any bacteria (E. Coli, Salmonella,
  Streptococcus, etc.)
• Found everywhere
• Size/Structure very small, unicellular, have NO
  membrane-bound organelles so that means NO
  NUCLEUS

9
6.2 Two Basic Types of Cells

• All living things fall into one of two categories
  of cells
• 2. Eukaryotes
• More complex than prokaryotes
• Examples Animals, Plants, Fungi
• Have many parts that each have their own function
  advantageous
• Biggest difference presence of NUCLEUS other
  membrane-bound parts
• Nucleus membrane-bound structure that contains
  DNA

10
6.3 Prokaryotic Cell Structure
11
6.3 Prokaryotic Cell Structure

• Nucleoid the nuclear region of a prokayrotic
  cell, in which the chromosome is attached to the
  plasma membrane

12
6.3 Prokaryotic Cell Structure

• Plasmid Circular DNA molecules found in
  prokaryotic cells that contain a few genes that
  help the bacteria survive under specific
  conditions.

13
6.3 Prokaryotic Cell Structure

• Bacterial cells typically come in 3 shapes
• 1. Bacilli rod shaped

14
6.3 Prokaryotic Cell Structure

• 2. Coccus spherical

15
6.3 Prokaryotic Cell Structure

• 3. Spirillum corkscrew shaped

16
6.3 Prokaryotic Cell Structure

• Many prokaryotic cells have flagella.
• Flagella long, whiplike extensions made of
  protein that rotate like propellers, allowing
  cells to swim through water or other fluids

17
6.4 Eukaryotic Cell Structure

• Organelles small functional cell parts each
  have their own structure function
• Compartmentalization makes eukaryotic cells more
  efficient b/c processes can be separated which
  allows for division of labor.

18
6.4 Eukaryotic Cell Structure

• Cell Wall
• A rigid structure that surrounds plant fungal
  cells (NOT ANIMAL CELLS) used for support
  protection
• One of the biggest differences between plant
  animal cells.

19
6.4 Eukaryotic Cell Structure

• Centriole
• Tubular structures in animal, algae, some
  fungal cells (NOT IN PLANTS) that play a role in
  cell division/reproduction
• Another difference between plant animal
  cells)

20
6.4 Eukaryotic Cell Structure

• Chloroplast
• Double-membrane organelle in plant cells (NOT IN
  ANIMAL CELLS) in which photosynthesis occurs
• Another major difference between animal
  plant cells

21
6.4 Eukaryotic Cell Structure

• Cilia
• Short flagella surrounding the cell that are used
  for movement of the cell or moving material along
  a cell/tissue

22
6.4 Eukaryotic Cell Structure

• Cytoplasm (Cytosol)
• The gel-like substance that fills the cell in
  which the organelles are bathed

23
6.4 Eukaryotic Cell Structure

• Cytoskeleton
• Fine protein fibers that help shape the cell
  organize the cytoplasm can help move eukaryotic
  cells can hold organelles in place or move them
  around

24
6.4 Eukaryotic Cell Structure

• Endoplasmic Reticulum (ER)
• A system of membranes that form tubes channels
  used to transport proteins other substances

25
6.4 Eukaryotic Cell Structure

• Flagella
• Found in some eukaryotic cells found within the
  plasma membrane used for motion

26
6.4 Eukaryotic Cell Structure

• Golgi Apparatus
• A series of membranous sacs that packages
  materials in vesicles for movement around the
  cell or export out of the cell

27
6.4 Eukaryotic Cell Structure

• Lysosome
• Special vesicle in animal cells (NOT IN PLANT
  CELLS) that contains enzymes to break down food
  digest food

28
6.4 Eukaryotic Cell Structure

• Mitochondrion
• A double-membraned organelle which is the major
  site of ATP synthesis power plant of cell

29
6.4 Eukaryotic Cell Structure

• Nucleolus
• An area within the nucleus where RNA is
  synthesized

30
6.4 Eukaryotic Cell Structure

• Nucleus
• Organelle surrounded by a nuclear membrane
  considered the genetic control center b/c it
  contains chromosomes (strands of DNA)
• Major difference of prokaryotes vs.
  eukaryotes

31
6.4 Eukaryotic Cell Structure

• Plasma Membrane
• (Cell Membrane)
• Surrounds all types of cells (prokaryotic
  eukaryotic) is responsible for letting
  substances into out of the cell
• -Not a source of protection.

32
6.4 Eukaryotic Cell Structure

• Ribosomes
• Small bodies of RNA that catalyze the synthesis
  of proteins can be found floating in cytoplasm
  or attached to the ER

33
6.4 Eukaryotic Cell Structure

• Vacuole
• Vesicles in a cell that store water food (among
  some other substances)
• Make up a huge percentage of volume of plants
  cells (give plants their rigidity) They are
  present in animal cells also, but they are much
  smaller in size.

34
(No Transcript)
35
6.5 Cooperation among Cells

• Division of unicellular organisms
• When single-celled organisms divide, some remain
  in a cluster (NOT A MULTI-CELLULAR ORGANISM).
• Each cell could break away and live
  individually

36
6.5 Cooperation among Cells

• Colonies groups of unicellular organisms living
  together ex Volvox

37
6.5 Cooperation among Cells

• Colonies
• Advantage act together do things more
  efficiently than a single cell
• For example Volvox (type of alga) tend to form
  colonies If in a colony, all the cells can use
  their flagella in a certain way to move the whole
  group vs. moving flagella independently moving
  randomly

38
6.6 Division of Labor

• Problem of large, multicellular organisms
• Need to transport materials across a large
  surface area (inner cells very far away from
  environment)

39
6.6 Division of Labor

• Solution to problem Increase your internal
  surface area (by organizing cells into blood
  vessels, lungs, leaves, intestines, etc.) that
  can help transport materials

40
6.6 Division of Labor

• Requirement Need to have many specialized cell
  types
• Examples
• Gland cell makes chemicals
• Nerve cell conducts electric signals
• Muscle cell specialized for movement

41
6.6 Division of Labor

• Cells of larger organisms are more distinctive in
  appearance

Red blood cells
Nerve Cell
42
6.6 Division of Labor

• Tissue group of cells with same function
• ex epidermal (skin) cells of hydra
• cells lining our stomachs

43
6.6 Division of Labor

• Organ group of tissues working together
• Ex lungs, heart, eye, fruits, leaves, stomach

44
6.6 Division of Labor

• System group of organs working together
• Ex Circulatory system includes the heart,
  vessels, etc (all organs)

45
6.7 Systems

• Why do we need systems?
• In larger organisms, many cells are buried too
  far inside the organism so they cant exchange
  materials with the environment

46
6.7 Systems

• Example of system in animals
• The circulatory system in animals delivers
  nutrients and oxygen and takes away wastes from
  cells all over the body.

47
6.7 Systems

• Example of system in plants
• Water food are transported around in a plants
  vascular system (a series of vessels found inside
  the plant)

48
Levels of Structure in Biosphere pg 180

• Biospherepart of Earth that has life
• Ecosystem Chesapeake Bay
• Community all organisms in Chesapeake Bay
• Population all striped bass in Chesapeake Bay
• Organism a striped bass

Organelles
