Presentation Dagin Marine Technology

1
(No Transcript)
2
DAGIN Marine Technology
WWW.DAGIN.NL

• Group of 5 Dutch companies, very experienced in
  the shipbuilding industry.
• Design and production of advanced goods,
  valuable for many types of ships.
• Synergy and cooperation to the advantage of our
  customers.

3
DAGIN Marine Technology
WWW.DAGIN.NL
The associated companies

• 1. Börger
• 2. Benes Machinefabriek
• 3. Eekels Elektrotechniek
• 4. Gebr. De Haan
• 5. SMST Rodenstaal

4
DAGIN Marine Technology
WWW.DAGIN.NL

• In 2008
• gt600 employees
• Turnover gt100 mill. Euro

5
DAGIN Marine Technology
Reference list (Partial)

• Owner Yard
• Arklow Shipping, Ireland Barkmeijer Stroobos
• Wijnne Barends, Netherlands Niestern Sander
• Hartmann, Germany Schlömer Leer
• Seatrade, The Netherlands Van Diepen
• Amasus Shipping, The Netherlands Damen Shipyards
• Many owners in Netherlands and abroad Peters
  Kampen
• Spanish Navy IZAR Spain
• Dutch Navy De Schelde
• Feederlines, Germany Damen Shipyards
• Carisbrooke Shipping Damen Shipyards
• Arpeni, Indonesia Volharding Shipyards
• Royal Boskalis Westminster , Netherlands Merwede
• Bockstiegel, Germany Jiong Dong Shipyard, China
• UK Navy Kvaerner Govan
• Rensen Shipbrokers Hong Ha, Vietnam
• Several owners via Conoship, Netherlands Chowgule,
  India
• Partenreedereien, Germany Bahrati, India

6
boot
7
Börger
WWW.MF-BORGER.NL

• Börger manufactures a wide range of standard
• and tailor-made products
• -Ladders, Stairs, Platforms
• -Gangways
• -Hatches and Louvers
• -Watertight doors
• -Oiltanks
• -Bollards
• -Masts
• -Housings
• And many more products

8
Börger
WWW.MF-BORGER.NL

• Deliveries to many types of vessels
• Well known for exact delivery times
• High quality
• Strong in supplying complete packages
• Steel, stainless steel, aluminium
• Competitive prices

9
Engine Room Floors
10
Hatches
Doors
Stairs and Ladders
11
Benes Machinefabriek
WWW.BENESGROEP.NL

• Internationally renowned for the design
• and production of manoeuvring modules with
• many types of rudders like
• (Semi-)Spade Rudders
• Balanced rudders
• Flaprudders (High Lift)
• Fish-Tail Rudders
• and many more

12
Benes Machinefabriek
WWW.BENESGROEP.NL

• Complete ruddersections with
• rudderstock, trunk, fairwater,
• machined for all types of rudder-actuator.
• Sternrollers, winches and all kinds of
• other general constructionwork.

13
Benes Machinefabriek
WWW.BENESGROEP.NL

• Strong in designing the best steering
• solutions for your vessel
• More than 85 years experience
• Thousands of rudders and sections
• Other steel constructions
• Many satisfied customers all around the world

14
FLAPRUDDERS
MV BEATRIX with Benes rudder
15
Production of flaprudder make Barke
Classic Balance Rudder
Flaprudder
Sterntube
16

Fishtail rudder
Flaprudder
Machining
Trunk, Fairwater
Machining shaft
17
Eekels
WWW.eekels.com

• a history of more than 100 years of experience in
  the field of installation work.
• - Installations in the range of inland navi
  gation till highly specialised sea ships.
• - Consultancy, design, maintenance, service,
  inspection

18
Eekels
www.eekels.com

• Eekels Elektrotechniek BV designs and produces
  Eekels made
• Switchboards
• control- and signalling panels
• motor control centers (MCC)
• control desks and alarm installations
• according to customers specifications or Eekels
  standard profile

19
Eekels
www.eekels.com

• alarm systems equipment (Eekels)
• automation (Eekels)
• ballast pump (Eekels)
• bilge pump (Eekels)
• bow thruster control unit (Eekels)
• control systems (Eekels)
• converters (Eekels)
• engineering (Eekels)
• frequency converter (Eekels)
• power management (Eekels)
• repair services (Eekels)
• ship's telegraphs (Eekels)
• switchboard (Eekels)
• telegraph, emergency (Eekels


20
Cabinet
Frequency converters
21
MV ALTENA
22
Gebr. De Haan
WWW.DEHAANHVAC.NL

• De Haan is well known in many countries for
• their expertise in the field of HVAC.
• De Haan can supply the engineering and
• assembly kits of the complete HVAC and sanitary
• systems on board of ships and mega-yachts

23
Gebr. De Haan
WWW.DEHAANHVAC.NL

• De Haan exports to various countries in
• Europe and Asia.
• - Engineering ( AutoCad / Nupass Cadmatic )
• Supply of complete systems
• Supply of components and units
• Support during installation
• Commissioning
• Turn-key projects by De Haan

24
Self contained AC-unit
Hydrofore
AC-unit in engine room
25
Sanitary Equipment
Mist Eliminator
26
Commissioning
Workshop
References
27
SMST Rodenstaal
WWW.SMST.NL

• Well known manufacturer and designer of all kinds
• and types of ships hatches, like
• Hydraulic Folding
• Single pull
• Pontoon
• StackPack
• Tweendeck hatches
• Grain Bulkheads

28
SMST Rodenstaal
WWW.SMST.NL

• SMST Rodenstaal can design and engineer all types
  of
• hatches for your ship.
• The choice is for the customer to decide where to
• produce the hatches
• At the yard
• At another steel construction company
• At SMST Rodenstaal

29
SMST Rodenstaal
WWW.SMST.NL

• When SMST Rodenstaal supplies design and
• engineering they also deliver the necessary
  parts
• cleats, rubber, cylinders etc.
• We also deliver the gantry crane when pontoon
• hatches will be chosen.

30
Special design hatches
Folding Hatches with close up of cylinders
31
Folding Hatches
Hatch cover crane
Hatch cover crane
Three ships in the Eemshaven with RODENSTAAL
Hatches
32
SMST Rodenstaal
WWW.SMST.NL

• SMST Rodenstaal is also well known supplier of
• Navy hangar doors
• Navy hull and stern doors
• Navy fly deck hatches
• Equipment for Jack-ups, Drillships
  Semi-submersible Rigs
• Pipelay equipment
• Exploration and production equipment

33
Offshore products
34
Navy equipment
35
Member of Holland Marine Equipment

• Holland Marine Equipment (HME) represents the
  interests of the Dutch suppliers of marine
  technology and services. Core activities are
  networking, projectmanagement, member events, and
  government contacts. The member companies are
  active in the fields of maritime engineering
  contracting, fabrication of installations and
  components, the supply of maritime services and
  ship repair. New members are carefully screened
  on their reputation in the marine sector before
  they may enter the association.
• For more information about Holland Marine
  Equipment please visit www.hme.nl
• We are proud to be one of the members of HME.
  Please take a look at our HME-certificate at the
  next page

36
(No Transcript)
37
Dagin Marine Technology

• CONTACT ADDRESS AND PERSON
• Dagin Marine Technology
• Mr. H. Th. Pronk
• Paterswoldseweg 810
• 9728 BM Groningen
• The Netherlands
• Tel. [phone]
• Fax [phone]
• Email harrypronk_at_dagin.nl
• Website www.dagin.nl (click on Marine
  Technology)
