The secret life of typecheckers

1
The secret life of typecheckers
2
Introduction

• This presentation is modeled on a paper by Luca
  Cardelli (Bell Labs, 1985)
• A general view of type-checking will be presented
  from the perspective of the programming language
  designer
• We will explore type systems past, present and
  future

3
A little history

• Type systems have been around longer than
  computers
• In the 1920s David Hilbert started a program to
  formalize mathematics as strings of symbols
  manipulated by logic/grammar rules
• Idea was to be able to mechanically prove
  things
• Bertrand Russell understood the problems with
  self-reference and approached Hilberts challenge
  by assigning entities to types
• Entities of each type are built up from entities
  of the preceding type
• In 1931 Kurt Gödel proved that consistent systems
  of any complexity are incomplete, ending
  Hilberts program
• Application to programming languages
• Computing involves representing and manipulating
  entities as strings of symbols
• Problems of representation and self-reference
  crop up in numerous ways
• We want to mechanically prove things about
  programs
• Types support this

4
What are types, really?

• Types come into play whenever we have a universe
  of diverse things with a similar representation
• Bits in a computers memory
• XML strings
• DNA
• If you consider these things in the absence of a
  type system, you have an untyped universe
• This means there is really only one type (the
  memory word, the DNA base pair, etc.)

5
Operations in untyped universes

• Any such universe has various operations that can
  be performed
• Adding and subtracting (bit strings)
• Rendering HTML (XML)
• Transcription/translation (DNA)
• But these operations are only valid on subsets of
  the untyped universe
• Some XML strings represent HTML documents and
  some dont
• Some DNA sequences represent valid genes and some
  dont
• What happens if you blow it?
• Tumbolia, the land of dead hiccups and
  extinguished lightbulbs(Douglas Hofstadter)
• The major purpose of a type system is to avoid
  embarrassing questions about representations, and
  to forbid situations where these questions might
  come up (Cardelli)

6
Type-checking and programming languages

• Type-checking avoids these embarrassing questions
• Assigns types to constants, operators, variables,
  and functions
• Checks that every operation is performed on
  inputs of the correct type
• Accepts programs that can be proven to have no
  type errors
• Type-checker reads program code and says ok
  ornot ok and heres why
• By comparison
• An interpreter reads program code and executes
  the instructions
• A compiler reads program code and translates it
  into a different representation of the same
  program

7
Type systems in programming languages

• The term type system refers to the range of types
  that can be assigned to variables and values
• Base types int, float, double, etc.
• User-defined types (e.g. classes, parameterized
  types, etc.)
• Type systems are somewhat arbitrary, and inspired
  largely by the typical instruction sets of modern
  computers
• You can create different type systems for the
  same language that are more or less expressive
• Inexpressive type systems are frustrating they
  either accept too many erroneous programs, or
  forbid too many correct ones
• Expressive type systems are more precise,
  rejecting as many erroneous programs as possible
  and accepting a greater percentage of correct ones

8
Expressiveness and abstract data types

• Imagine a type system that supports only the
  types int and object
• Now youre compiling this function
• int foo (object o)
• return o.bar()
• Does the type system say yes or no?
• If yes, were overly permissive the
  type-checker doesnt know whether the bar
  method is really available
• If no, were overly restrictive
• The type system needs to be more expressive
  needs to include separate types for each class,
  etc.
• Expressiveness means having a rich language of
  types enabling the type-checker to determine with
  the greatest possible precision whether it should
  accept programs or not

9
Inexpressive type systems
Typesafeprograms
Programs withtype errors
Rejects too manytypesafe programs
Accepts too many unsafe programs
10
Expressive type systems
Typesafeprograms
Programs withtype errors
Does not accept any unsafe programs, and does
accept most typesafe programs
11
Polymorphism and type inference

• Polymorphism gives type-checkers an even bigger
  headache
• Requires a major increase in expressiveness
• What is the type of a generic List class?
• What is the type of a generic Sort function?
• Type checking is simplified by having programmers
  annotate programs with type information
• However this gets painful as the type system
  becomes expressive
• Solution is type inference let the computer
  figure out all the types
• The goal of type-checking researchMaximize the
  expressiveness of type systems while minimizing
  the need for programmers to annotate programs
  with complex type information

12
Examples

• The best way to explore the subtleties of type
  systems is to work through examples
• Lets try a few

13
Subtyping

• class Base
• class Derived public Base
• void main(char args)
• Base b new Derived ()
• Derived d b
• Is this typesafe?
• Should it be accepted by the compiler?
• If you add a dynamic cast (i.e. add further
  annotations to help the compiler), will the
  compiler add a runtime check? Should it?

14
Apples and oranges

• // from one header file
• struct Apple
• int x
• void appleProcessingService (Apple a)
• // from another header file
• struct Orange
• int x
• // source file
• void main(char args)
• appleProcessingService (new Apple())
• appleProcessingService (new Orange ())

15
How about this one?

• // from header file, US edition of software
• struct Apple
• int x
• void appleProcessingService (Apple a)
• // from header file, French edition of software
• struct Pomme
• int x
• // source file
• void main(char args)
• appleProcessingService (new Apple())
• appleProcessingService (new Pomme())

16
Math expressions

• void main (char args)
• int x 123
• int y 234
• int z x / y
• Is this typesafe? Should it be accepted by the
  compiler?

17
Wouldnt it be cool if

• We had a rational datatype?
• void main (char args)
• int w 123
• int x 234
• rational y w / x
• rational z w 0.5
• Any problems here?

18
What kind of error is this?

• void main (char args)
• int x 1
• int y 0
• int z x / y
• Could type systems help us here?

19
What if we introduced

• A nonzero datatype?
• Say the compiler requires the divisor to be of
  type nonzero
• void main (char args)
• int x 1
• nonzero y 0
• int z x / y
• Good idea? Or not?

20
Fibonacci strikes back

• Is this typesafe? Could a type-checker prove it?
• nonzero fib (int x)
• if (x lt 2)
• return 1
• else
• return fib(x-1) fib(x-2)
• How about this?
• int inputAndParseNumberFromUser ()
• void main (char args)
• nonzero x inputAndParseNumberFromUser ()
• Options?

21
User-constructed types

• Data abstraction implies the ability for
  programmers to create new types
• How do we express the type of variable foo in
  this example?
• struct
• int x
• float y
• foo
• Type theorists usually write the type something
  like this
• (int, float)
• The type of an array of integers would be
• int
• An array of arrays of integers would be
• int
• The type of a function with an int argument
  returning a float would be
• int ? float

22
User-constructed types

• The operators (), , and ? are type constructors
• They take types as arguments and define new types
• Once you have type constructors, your type system
  can contain as many types as you like
• Type-checker has to cope with all of this,
  providing a syntax for programmers to write all
  these types If necessary

23
Polymorphism

• When introducing polymorphic constructs into the
  language, type constructors are not enough
• Type of the Length function for arrays of
  integers
• int ? int
• Type of the Length function for arrays of
  anything
• forall (T) T ? int
• Introducing polymorphic types into a type system
  is analogous to introducing functions into a
  programming language
• The above type could also be written
• forall (U) U ? int
• U is a type variable and forall provides type
  abstraction
• Use of forall is called universal
  quantification because any type can be plugged in
  to U
• Polymorphic types can be specialized
• type V forall (U) U ? int
• type W Vltstringgt

24
Why have type notation?

• Why do we feel the need to write out these
  complicated types?
• If youre writing a function, you only need to
  write the types of the return value and
  arguments, not the function itself
• Two reasons
• If youre programming with higher order functions
  (which well be doing more of in the future) its
  helpful to write these types
• These functions do have types, regardless of
  whether were writing them out it would be nice
  to have a standard notation

25
Bounded quantification

• Bounded quantification is the idea that that only
  some types can be plugged in to U
• For example, if you had a Length function which
  could only be used on arrays of different kinds
  of numbers, you could write
• type T forall (U U lt number) U ? int
• U is constrained to be a number (or subtype
  thereof)
• But what if you do this?
• type V Tltstringgt
• Is that a type mismatch?

26
Types and kinds

• In the spirit of Russell, computer scientists
  generally like to keep these levels separate.
• Higher-level types which ensure correctness of
  types are called kinds
• This level of checking is referred to as kind
  checking
• There are countless papers floating around with
  titles like
• Is type a type?and A new programming
  language with type type
• They are exploring the question of whether a type
  system can operate on itself, or whether levels
  should be kept separate.

27
C bounded quantification question

• template lttypename Tgt
• class Copier
• T myStruct
• public
• void copy () myStruct.x myStruct.y
• struct IntPair int x, y
• struct FloatPair float x, y
• struct BogusPair float x char y
• void main(char args)
• CopierltIntPairgt cip
• cip.copy()
• CopierltFloatPairgt cfp
• cfp.copy()

28
Existential quantification

• The type of a function that takes an array of T
  and returns an integer, for some single type T
• exists(T) T ? int
• At this point we have implicitly defined a type T
• We know nothing about type T, except that
• A function of the above type could take a list of
  them and return an int
• T is intuitively a little like a class
• It is a type, and we dont know anything about
  how it works, but we know a way in which we can
  use it
• Universal and bounded quantification provide the
  theoretical basis for parameterized types
• Existential quantification provides the
  theoretical basis for information hiding

29
Type inference

• As type systems become more complicated, it
  becomes more burdensome for programmers to write
  out types
• Would you write expressions like this?
• forall (U U lt number) U ? int
  myFunction ()
• No you would just avoid higher order functions
• The solution is type inference

30
Type inference

• Allows programmers to omit type declarations and
  have the compiler infer them
• Promises all of the expressiveness of dynamic
  languages, but with static type safety
• Research in this area has come a long way but
  there are still valid, type-safe programs which
  type inference engines cannot handle
• Rudimentary type inference (local variables) is
  coming in .NET 3.0
• Given that type theory experts like Simon
  Peyton-Jones are at Microsoft we can expect to
  see this area of .NET evolve rapidly

31
Ideas for the future

• Continue improving type system expressiveness and
  type inference engines
• How about having the type-checker interact with
  the programmer? e.g.
• Can I assume this will always be an odd number?
• Can I assume that no instances of this class are
  constructed outside of this source tree?
• How about monitoring running programs to generate
  better type annotations for use in future
  compilations?
• How about a graphical interface for creating and
  manipulating type information

32
Conclusion

• Type-checking is not a simple, tidy field
• Its a matter of tradeoffs and judgment
• More expressiveness means that programming
  languages can become more powerful and
  polymorphic without compromising type safety
• However more expressiveness more pain for
  programmers
• Working with higher-order functions is great, but
  not if you have to type 10 lines of type
  declarations for each line of code
• Type inference is a promising solution
• Holy grail is to provide all the power of dynamic
  languages like Lisp, Python, and Ruby with the
  type safety of C and no need to write a single
  type declaration

33
The dreaded monad question

• Parameterized interface (two type parameters)
• Any monad type mlta,bgt must support methods
• gtgt (bind) mltagt ? (a ? mltbgt) ? mltbgt
• gtgt (sequence) mltagt ? mltbgt ? mltbgt
• return a ? mltagt
• fail String ? mltagt
• A kind of type framework that can represent
  sequencing,non-determinism, and other concepts
• Sequencing
• writeFile testFile.txt Hello File gtgt putStr
  Hello World
• The parameterized type Nullable also turns out to
  be a monad
