Lecture Topic - Hydrology Introduction to Hydrology Reservoir Storage CE-321

1
Lecture Topic - HydrologyIntroduction to
HydrologyReservoir Storage CE-321

• Introduction to Environmental Engineering

2
(No Transcript)
3
(No Transcript)
4
HYDROGRAPH
5
(No Transcript)
6
(No Transcript)
7
Reservoir Storage
8

• Water Storage PROBLEMS in Alaska

9
Reservoir Storage
Water Storage - Reservoir

• Predicting the capacity of a reservoir
• Tabular Method
• Graphic Method
• Two examples

10
Reservoir Storage

• Tabular Method

Month Inflow (I) (MG/mi2/mo) OutFlow (O) (MG/mi2/mo) Cumulative Inflow (Graphical) (MG/mi2) Deficiency I O (MG/mi2) Cumulative Deficiency
Feb 31.0
Mar 54.0
Apr 90.0
May 10.0
Jun 7.0
Jul 8.0
Aug 2.0
Sep 28.0
Oct 42.0
Nov 108.0
Dec 98.0
Jan 22.0
Feb 50.0
11
Reservoir Storage

• Tabular Method

Month Inflow (I) (MG/mi2/mo) OutFlow (O) (MG/mi2/mo) Cumulative Inflow (Graphical) (MG/mi2) Deficiency I O (MG/mi2) Cumulative Deficiency (MG/mi2)
Feb 31.0 37.3
Mar 54.0 37.3
Apr 90.0 37.3
May 10.0 37.3
Jun 7.0 37.3
Jul 8.0 37.3
Aug 2.0 37.3
Sep 28.0 37.3
Oct 42.0 37.3
Nov 108.0 37.3
Dec 98.0 37.3
Jan 22.0 37.3
Feb 50.0 37.3
12
Reservoir Storage

• Tabular Method

Month Inflow (I) (MG/mi2/mo) OutFlow (O) (MG/mi2/mo) Cumulative Inflow (Graphical) (MG/mi2) Deficiency I O (MG/mi2) Cumulative Deficiency
Feb 31.0 37.3
Mar 54.0 37.3
Apr 90.0 37.3
May 10.0 37.3
Jun 7.0 37.3
Jul 8.0 37.3
Aug 2.0 37.3 202.0
Sep 28.0 37.3 230.0
Oct 42.0 37.3 272.0
Nov 108.0 37.3 380.0
Dec 98.0 37.3 478.0
Jan 22.0 37.3 500.0
Feb 50.0 37.3 550.0
13
Reservoir Storage

• Tabular Method

Month Inflow (I) (MG/mi2/mo) OutFlow (O) (MG/mi2/mo) Cumulative Inflow (Graphical) (MG/mi2) Deficiency I O (MG/mi2) Cumulative Deficiency
Feb 31.0 37.3
Mar 54.0 37.3
Apr 90.0 37.3
May 10.0 37.3
Jun 7.0 37.3
Jul 8.0 37.3
Aug 2.0 37.3 202.0 -35.3 -122.2
Sep 28.0 37.3 230.0 -9.3 -131.5
Oct 42.0 37.3 272.0 4.7 -126.8
Nov 108.0 37.3 380.0 70.7 -56.1
Dec 98.0 37.3 478.0 60.7 0.0
Jan 22.0 37.3 500.0 -15.3 -15.3
Feb 50.0 37.3 550.0 12.7 -2.6
14
Reservoir Storage

• Tabular Method

15
Month Inflow (I) (MG/mi2/mo) OutFlow (O) (MG/mi2/mo) Cumulative Inflow (Graphical) (MG/mi2) Deficiency I O (MG/mi2) Cumulative Deficiency
Feb 31.0 37.3 31.0 -6.3 -6.3
Mar 54.0 37.3 85.0 16.7 0.0
Apr 90.0 37.3 175.0 52.7 0.0
May 10.0 37.3 185.0 -27.3 -27.3
Jun 7.0 37.3 192.0 -30.3 -59.6
Jul 8.0 37.3 200.0 -29.3 -86.9
Aug 2.0 37.3 202.0 -35.3 -122.2
Sep 28.0 37.3 230.0 -9.3 -131.5
Oct 42.0 37.3 272.0 4.7 -126.8
Nov 108.0 37.3 380.0 70.7 -56.1
Dec 98.0 37.3 478.0 60.7 0.0
Jan 22.0 37.3 500.0 -15.3 -15.3
Feb 50.0 37.3 550.0 12.7 -2.6
16
Reservoir Storage

• To construct
• Plot Monthly Flow, Cumulative - Line OA
• Construct a Draft Line, used for comparison -
  Line OC

17
Reservoir Storage

• Tangents are constructed Parallel to OC
• When the slope of OA is less than that of the
  tangents the reservoir volume is decreasing
• When the slope is greater the volume is
  increasing
• The distance between adjacent tangents represents
  the volume added or withdrawn during the
  intervening period
• The largest withdrawal would indicate the
  capacity of the a reservoir needed to serve a
  community.

18
Reservoir Storage
19
Reservoir Storage
20
Reservoir Storage

• In both cases you look for data during a drought
  period

21
Class Problem
DRAFT 2.0 m3/s (flow to meet water demand) DRAFT 2.0 m3/s (flow to meet water demand) DRAFT 2.0 m3/s (flow to meet water demand) 28 day month 28 2419200 sec/28 day month
2 30 day month 30 2592000 sec/30 day month
31 day month 31 2678400 sec/31 day month
Month Inflow (I) (m3/s) Inflow (I) (m3/month) OutFlow (O) (Draft) (m3/month) Cumulative Inflow (m3) (Graphical) Deficiency I - O (m3) Cumulative Deficiency (m3)
Aug (31) 1.70
Sep 1.56
Oct (31) 1.56
Nov 2.04
Dec (31) 2.35
Jan (31) 2.89
Feb (28) 9.57
March (31) 17.70
April 16.40
May (31) 6.83
June 3.74
July (31) 1.60
Aug (31) 1.13
Sept 1.13
Oct (31) 1.42
Nov 1.98
Dec (31) 2.12
Jan (31) 1.78
Feb (28) 1.95
March (31) 7.25
April 24.70
May (31) 6.26
June 8.92
July (31) 3.57
Aug (31) 1.98
Sept 1.95
Oct (31) 3.09
Nov 3.94
Dec (31) 12.70
22
DRAFT 2.0 m3/s (flow to meet water demand) DRAFT 2.0 m3/s (flow to meet water demand) DRAFT 2.0 m3/s (flow to meet water demand) 28 day month 28 2419200 sec/28 day month
2 30 day month 30 2592000 sec/30 day month
31 day month 31 2678400 sec/31 day month
Month Inflow (I) (m3/s) Inflow (I) (m3/month) OutFlow (O) (Draft) (m3/month)
Aug (31) 1.70 4.55E06 5.36E06
Sep 1.56
Oct (31) 1.56
Nov 2.04
Dec (31) 2.35
Jan (31) 2.89
Feb (28) 9.57
March (31) 17.70
April 16.40
May (31) 6.83
June 3.74
July (31) 1.60
Aug (31) 1.13
Sept 1.13 2.93E06 5.18E06
Oct (31) 1.42 3.80E06 5.36E06
Nov 1.98 5.13E06 5.18E06
Dec (31) 2.12 5.68E06 5.36E06
Jan (31) 1.78 4.77E06 5.36E06
Feb (28) 1.95 4.72E06 4.84E06
March (31) 7.25 1.94E07 5.36E06
April 24.70 6.40E07 5.18E06
May (31) 6.26 1.68E07 5.36E06
June 8.92 2.31E07 5.18E06
July (31) 3.57 9.56E06 5.36E06
Aug (31) 1.98 5.30E06 5.36E06
Sept 1.95 5.05E06 5.18E06
Oct (31) 3.09 8.28E06 5.36E06
Nov 3.94 1.02E07 5.18E06
Dec (31) 12.70 3.40E07 5.36E06

23
Month Inflow (I) (m3/s) Inflow (I) (m3/month) OutFlow (O) (Draft) (m3/month) Cumulative Inflow (m3) (Graphical) Deficiency I - O (m3) Cumulative Deficiency (m3)
Aug (31) 1.70 4.55E06 5.36E06 4.55E06
Sep 1.56
Oct (31) 1.56
Nov 2.04
Dec (31) 2.35
Jan (31) 2.89
Feb (28) 9.57
March (31) 17.70
April 16.40
May (31) 6.83
June 3.74
July (31) 1.60
Aug (31) 1.13
Sept 1.13 2.93E06 5.18E06 1.83E08
Oct (31) 1.42 3.80E06 5.36E06 1.87E08
Nov 1.98 5.13E06 5.18E06 1.92E08
Dec (31) 2.12 5.68E06 5.36E06 1.98E08
Jan (31) 1.78 4.77E06 5.36E06 2.03E08
Feb (28) 1.95 4.72E06 4.84E06 2.07E08
March (31) 7.25 1.94E07 5.36E06 2.27E08
April 24.70 6.40E07 5.18E06 2.91E08
May (31) 6.26 1.68E07 5.36E06 3.08E08
June 8.92 2.31E07 5.18E06 3.31E08
July (31) 3.57 9.56E06 5.36E06 3.40E08
Aug (31) 1.98 5.30E06 5.36E06 3.46E08
Sept 1.95 5.05E06 5.18E06 3.51E08
Oct (31) 3.09 8.28E06 5.36E06 3.59E08
Nov 3.94 1.02E07 5.18E06 3.69E08
Dec (31) 12.70 3.40E07 5.36E06 4.03E08
24
Month Inflow (I) (m3/s) Inflow (I) (m3/month) OutFlow (O) (Draft) (m3/month) Cumulative Inflow (m3) (Graphical) Deficiency I - O (m3) Cumulative Deficiency (m3)
Aug (31) 1.70 4.55E06 5.36E06 4.55E06 -803520.00
Sep 1.56
Oct (31) 1.56
Nov 2.04
Dec (31) 2.35
Jan (31) 2.89
Feb (28) 9.57
March (31) 17.70
April 16.40
May (31) 6.83
June 3.74
July (31) 1.60
Aug (31) 1.13
Sept 1.13 2.93E06 5.18E06 1.83E08 -2255040.00
Oct (31) 1.42 3.80E06 5.36E06 1.87E08 -1553472.00
Nov 1.98 5.13E06 5.18E06 1.92E08 -51840.00
Dec (31) 2.12 5.68E06 5.36E06 1.98E08 321408.00
Jan (31) 1.78 4.77E06 5.36E06 2.03E08 -589248.00
Feb (28) 1.95 4.72E06 4.84E06 2.07E08 -120960.00
March (31) 7.25 1.94E07 5.36E06 2.27E08 14061600.00
April 24.70 6.40E07 5.18E06 2.91E08 58838400.00
May (31) 6.26 1.68E07 5.36E06 3.08E08 11409984.00
June 8.92 2.31E07 5.18E06 3.31E08 17936640.00
July (31) 3.57 9.56E06 5.36E06 3.40E08 4205088.00
Aug (31) 1.98 5.30E06 5.36E06 3.46E08 -53568.00
Sept 1.95 5.05E06 5.18E06 3.51E08 -129600.00
Oct (31) 3.09 8.28E06 5.36E06 3.59E08 2919456.00
Nov 3.94 1.02E07 5.18E06 3.69E08 5028480.00
Dec (31) 12.70 3.40E07 5.36E06 4.03E08 28658880.00
25
Month Inflow (I) (m3/s) Inflow (I) (m3/month) OutFlow (O) (Draft) (m3/month) Cumulative Inflow (m3) (Graphical) Deficiency I - O (m3) Cumulative Deficiency (m3)
Aug (31) 1.70 4.55E06 5.36E06 4.55E06 -803520.00 -803520.00
Sep 1.56
Oct (31) 1.56
Nov 2.04
Dec (31) 2.35
Jan (31) 2.89
Feb (28) 9.57
March (31) 17.70
April 16.40
May (31) 6.83
June 3.74
July (31) 1.60
Aug (31) 1.13
Sept 1.13 2.93E06 5.18E06 1.83E08 -2255040.00 -5656608.00
Oct (31) 1.42 3.80E06 5.36E06 1.87E08 -1553472.00 -7210080.00
Nov 1.98 5.13E06 5.18E06 1.92E08 -51840.00 -7261920.00
Dec (31) 2.12 5.68E06 5.36E06 1.98E08 321408.00 -6940512.00
Jan (31) 1.78 4.77E06 5.36E06 2.03E08 -589248.00 -7529760.00
Feb (28) 1.95 4.72E06 4.84E06 2.07E08 -120960.00 -7.65E06
March (31) 7.25 1.94E07 5.36E06 2.27E08 14061600.00 0.00
April 24.70 6.40E07 5.18E06 2.91E08 58838400.00 0.00
May (31) 6.26 1.68E07 5.36E06 3.08E08 11409984.00 0.00
June 8.92 2.31E07 5.18E06 3.31E08 17936640.00 0.00
July (31) 3.57 9.56E06 5.36E06 3.40E08 4205088.00 0.00
Aug (31) 1.98 5.30E06 5.36E06 3.46E08 -53568.00 -53568.00
Sept 1.95 5.05E06 5.18E06 3.51E08 -129600.00 -183168.00
Oct (31) 3.09 8.28E06 5.36E06 3.59E08 2919456.00 0.00
Nov 3.94 1.02E07 5.18E06 3.69E08 5028480.00 0.00
Dec (31) 12.70 3.40E07 5.36E06 4.03E08 28658880.00 0.00
