Biomechanics of BKA

1
Biomechanics of BKA

• Renee Kitto
• Port Macquarie Base Hospital

2
Contents

• Normal gait
• Prerequisites of Normal Gait
• Gait characteristics of BKA
• Other causes of gait abnormalities

3
Normal gait

• Analysing pathological gait, compare to normal
• Identifying gait deviation, you can work towards
  normal gait
• Normal gait is the most energy efficient

4
Stance Phase

• Begins at heel strike on one leg and ends at toe
  off on the same leg
• Initial contact (heel Strike)
• Loading response (0-10)
• Mid-stance (10-30)
• Terminal stance (push off) (30-50)
• Pre swing (toe off) (50-60)

5
Swing Phase

• Begins where stance ends and is the period
  between toe off on one leg and heel strike on the
  same leg
• Initial swing (60-73)
• Mid-swing (73-87)
• Terminal-swing (87-100)

6
Prerequisites of normal gait

• Stability in Stance
• Clearance in swing
• Pre-position of the foot in terminal swing
• Adequate step length
• Energy conservation

7
Gait characteristics

• BKA gait is asymmetrical

8
Gait Characteristics

• Temporal and distance factors
• Stance phase shorter on prosthetic side
• Step length of the prosthetic side longer and
  faster
• Self selected walking velocity is lower
• Decreased Cadence
• Average stride length is shorter

9
Gait Characteristics

• Joint Angles
• Decreased knee flexion (prosthetic side) during
  early stance
• Decreased knee flexion (prosthetic side) during
  late stance
• Larger relative knee angle range on the
  prosthetic side compared to the unaffected side
• Greater than normal positions of maximum hip
  flexion (prosthetic side)
• Increased knee flexion (unaffected side) during
  early stance

10
Gait Characteristics

• Joint moments
• Unaffected side
• Higher hip extensor moment during stance
• Higher hip flexor moment during early swing
• Higher knee extension moment during stance
• Prosthetic side
• Ankle D/F moment longer in duration and larger in
  amplitude during early stance

11
Gait Characteristics

• Joint Power
• Heel Contact (unaffected side)
• Increased hip extensor activity (unaffected side)
• Heel Contact (prosthetic side)
• Increased hip abductor activity (unaffected side)
• Increased knee extensor activity (unaffected
  side)
• Increased hip extensor muscle bursts on both
  sides

12
Gait Characteristics

• Joint Power
• Midstance
• Increased hip abductor activity (prosthetic side)
• Push-off
• Increased hip flexor power generation (prosthetic
  side)

13
Other causes of gait abnormalities
Prosthesis Patients capability and general
condition Shape, length and size of the residual
limb Discomfort Inadequate or incorrect
re-education Psychological, social or economic
reasons
14
References

• Bateni, H et al (2002) Kinematic and Kinetic
  Variations of Below-Knee Amputee Gait. Journal of
  Prosthetics and Orthotics, 14, 2-10.
• Engstrom, B, Van de Ven, C (1999) Therapy for
  Amputees. London Churchill Livingstone.,
  115-136.
• Robinson, J et al (1977) Accelerographic,
  Temporal, and Distance Gait Factors in Below-Knee
  Amputees. Physical Therapy, 57, 898-904.

15
References

• Sadeghi, H et al (2001)Muscle Power Compensatory
  Mechanisims in Below- Knee Amputee Gait. American
  Journal of Physical Medicine and Rehabilitation,
  80, 25-32.
• Ruud, W et al (2004) Adaptions to Mass
  Perturbations in Transtibial Amputees Kinetic or
  Kinematic Invariance. Archives of Physical
  Medicine and Rehabilitation, 85, 2046-2052.
