Skeletal Muscles

1
Skeletal Muscles
2
Anatomy and innervation of skeletal muscle tissue

• Connective tissue components
• Fascia (bandage) sheet or band of fibrous C.T.
  under the skin or around organs
• Superficial fascia (subcutaneous fascia)
• Areolar C.T. and adipose tissue
• Stores water and fat
• Reduces heat loss (insulates)
• Protects against trauma
• Framework for nerves and blood vessels

3

• Deep fascia
• Dense irregular C.T. holds muscles together and
  separates them into groups
• 3 layers
• Epimysium surrounds the whole muscle
• Perimysium separates muscle into bundles of
  muscle fibers fascicles
• Endomysium covers individual fibers

4
(No Transcript)
5
(No Transcript)
6

• These three layers come together to form cords of
  dense, regular connective tissue called tendons.
  Tendons attach muscle to the periosteum of bones.
• When the connective tissues form a broad, flat
  layer, the tendon is called an aponeurosis.

7
(No Transcript)
8
(No Transcript)
9
Microscopic Anatomy

• Muscle cells are called muscle fibers or
  myofibers
• Plasma membrane sarcolemma
• Cytoplasm sarcoplasm
• Myoblasts fuse to form one myofiber several
  nuclei
• Myofibrils run lengthwise

10
Myofibrils are made of filaments

• Thin filaments primarily actin
• Thick filament myosin
• Elastic filaments
• Sarcomeres are the basic, functional units of
  striated muscle fibers.

11
(No Transcript)
12
(No Transcript)
13
Thick filaments

• Made of about 200 molecules of myosin
• Each myosin molecule has two heads
• Each head has an actin binding site and an ATP
  binding site
• The ATP site splits ATP and transfers energy to
  myosin head which remains charged (cocked)
  until contraction.

14
(No Transcript)
15
(No Transcript)
16
Thin Filaments

• Actin molecules form a helix
• Each actin molecule has a myosin binding site
• Other proteins
• Tropomyosin long, filamentous protein, it wraps
  around the actin and covers the myosin binding
  sites
• Troponin a smaller molecule bound to
  tropomyosin, it has calcium binding sites.

17
(No Transcript)
18
Sarcoplasmic reticulum

• Specialized smooth E. R.
• Tubes fuse to form cisternae
• In a relaxed muscle, S.R. stores Ca (Ca
  active transport pumps)
• When stimulated, Ca leaves through Ca release
  channels.

19
Transverse tubules (T-tubules)

• Infoldings of sarcolemma that penetrate into
  muscle fiber at right angles to filaments. They
  are filled with extracellular fluid.
• T-tubules and the cisternae on either side form a
  triad.

20
(No Transcript)
21
Blood and nerve supply

• Muscle contraction uses a lot of ATP
• To generate ATP, muscles need oxygen
• Each muscle fiber is in close contact with one or
  more capillaries
• Motor neurons originate in brain and spinal
  cord cause muscle contraction

22
Motor unit

• A Motor Unit is made of one motor neuron and all
  the muscle fibers it innervates.
• These cells all contract together.
• A single motor unit can have 2 2,000 muscle
  fibers.
• Precise movements are controlled by small motor
  units, and large movements by large motor units.

23
(No Transcript)
24
Neuromuscular Junction (NMJ)

• Nerves communicate with muscles and other organs
  at structures called synapses.
• Synaptic cleft gap between neuron and
  sarcolemma
• Axon releases a chemical called a
  neurotransmitter Acetylcholine (Ach)
• Axon branches into axon terminals.
• At the end of each axon terminal is a swelling
  called the synaptic end bulb.

25
(No Transcript)
26
(No Transcript)
27

• The region across the synaptic cleft from the
  synaptic end bulb is called the motor end plate.
• The sarcolemma of the motor end plate is folded
  and contains many receptors for ACh .
• When a nerve impulse reaches the synaptic end
  bulbs, it causes synaptic vesicles to fuse with
  the membrane and release ACh by exocytosis.

28
(No Transcript)
29
(No Transcript)
30

• Acetylcholine diffuses across the synaptic cleft,
  and binds with receptors on the motor end plate.
• This binding causes the receptor to change shape,
  and opens Na channels in the membrane.
• When enough Na channels are opened, an
  electrical current is generated and is carried
  along the sarcolemma. This is called a muscle
  impulse or muscle action potential. This
  electrical activity can be recorded in an
  electromyogram.

31
Sliding Filament Mechanism

• When a nerve impulse reaches an axon terminal,
  the synaptic vesicles release
• acetylcholine (ACh)
• ACh crosses the synaptic cleft and binds with
• receptors on the motor end plate.
• This binding opens channels that allow
• sodium to rush in, beginning a muscle action
  potential in the sarcolemma.

32

• The action potential or impulse travels down the
  sarcolemma and into the T-tubules, causing the
  sarcoplasmic reticulum to release Ca into the
  sarcoplasm.
• The Ca binds to the troponin, which changes
  shape, pulling the tropomyosin away from the
  myosin binding sites on the actin.
• The activated myosin attaches to the actin,
  forming actin/myosin crossbridges.
• The myosin head moves toward the center of the
  sarcomere, pulling the actin filaments past the
  myosin. This is called a power stroke.

33

• When the myosin heads turn, they release ADP, and
  ATP binds to the heads.
• When ATP binds, it causes the myosin to release
  the actin.
• ATP is split, and the myosin heads again bind to
  the actin, but further down the filament.
• The myosin again pulls the actin.
• This action is repeated many times.
• The Z lines (discs) get closer together as the
  actin and myosin filaments slide past each other,
  and the muscle fiber shortens.

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
Relaxation

• ACh is broken down by an enzyme called
  acetylcholinesterase.
• Action potentials are no longer generated, so the
  Ca release channels in the S.R. close.
• Ca active transport pumps take Ca out of the
  sarcoplasm and into the S.R. where it binds to a
  protein called calsequestrin.

39

• As the Ca levels in the sarcoplasm fall,
  troponin releases tropomyosin, which falls back
  and covers the myosin binding sites on the actin.
• The thin filaments slip back into their relaxed
  positions.

40
Rigor mortis

• After death, muscle cells begin autolysis, and
  Ca leaks out of the S.R.
• This causes muscles to begin to contract.
• Since the body is dead, no more ATP is produced.
• Without the ATP to recharge the myosin heads,
  they remain linked to the actin, and neither
  relax nor contract any further.
• After about 24 - 72 hours it disappears as the
  tissues begin to disintegrate.

41
Origin and Insertions

• Origin the attachment of a muscle to the less
  movable part (torso, etc.)
• Insertion the attachment of a muscle to the
  more movable part

42
(No Transcript)
43
Interactions of muscles

• Prime mover the muscle primarily responsible
  for a movement
• Synergist stabilizes or assists prime mover
• Antagonist opposes action of prime mover and
  must relax for prime mover to contract completely
