From DNA to Proteins

1
From DNA to Proteins

• Chapter 15

2
Functions of DNA

• Heredity passing on traits from parents to
  offspring
• Replication
• Coding for our traits by containing the
  information to make proteins
• Protein Synthesis
• Transcription
• Translation

3
Genes

• Genes are units of DNA that code to make a single
  polypeptide (protein)
• Found within specific location on the chromosomes
  (loci)
• Humans have gt30,000 genes
• How do we make a protein from the information in
  a gene?

4
Steps of Protein synthesis

• Same two steps produce all proteins
• Transcription
• DNA (Gene) is transcribed to form messenger RNA
  (mRNA)
• Occurs in the nucleus
• 2) Translation
• mRNA is translated to form polypeptide chains,
  which fold to form proteins
• Occurs in ribosomes which are in the cytoplasm

5
Transcription and Translation
6
RNA vs. DNA
DNA RNA
Number of strands Two One
Nucleotides A T G C A U G C
Sugar Deoxyribose Ribose
Location Nucleus only Nucleus and Cytoplasm
7
Three Classes of RNAs

• Messenger RNA (mRNA)
• Carries protein-building instruction
• Ribosomal RNA (rRNA)
• Major component of ribosomes
• Transfer RNA (tRNA)
• Delivers amino acids to ribosomes

8
A Nucleotide Subunit of RNA
uracil (base)
phosphate group
sugar (ribose)
Figure 14.2Page 228
9
Transcription

• DNA ? RNA
• Occurs in the nucleus
• Requires the enzyme RNA Polymerase
• Consists of 3 steps
• Initiation
• Elongation
• Termination

10
RNA Polymerases

• No primers needed to start complementary copy
• RNA is made in the 5? 3 direction
• DNA template strand is 3? 5

11
Steps of Transcription Initiation

• RNA Polymerase binds to Promoter
• Promoter A base sequence in the DNA that signals
  the start of a gene
• DNA is unwound
• i.e. hydrogen bonds are broken

12
Transcription Initiation
13
Steps of Transctription Elongation

• RNA ploymerase adds complementary RNA nucleotides
  to one strand of DNA Template strand
• Forms Pre-mRNA

14
Transcription Elongation
15
Steps of Transcription Termination

• When mRNA synthesis is complete, RNA Polymerase
  falls off of DNA, RNA is released from DNA, and
  DNA rewinds

16
Transcription Termination
17
Transcription vs. DNA Replication

• Like DNA replication
• Nucleotides added in 5 to 3 direction
• Unlike DNA replication
• Only small stretch is template
• RNA polymerase catalyzes nucleotide addition
• Product is a single strand of RNA

18
Production of mRNAs in Eukaryotes

• Eukaryotic protein-coding genes are transcribed
  into precursor-mRNAs that are modified in the
  nucleus
• Introns are removed during pre-mRNA processing to
  produce the translatable mRNA
• Introns contribute to protein variability

19
Messenger RNA

• Prokaryotes
• Coding region flanked by 5 and 3 untranslated
  regions
• Eukaryotes
• Coding region flanked by 5 and 3 untranslated
  regions (as in prokaryotes)
• Additional noncoding elements

20
Eukaryotic Pre-mRNA

• Precursor-mRNA (pre-mRNA)
• Must be processed in nucleus to produce
  translatable mRNA
• 5 cap
• Reversed guanine-containing nucleotide
• Site where ribosome attaches to mRNA
• Poly(A) tail
• 50 to 250 adenine nucleotides added to 3 end
• Protects mRNA from RNA-digesting enzymes

21
Eukaryotic Pre-mRNA

• Introns
• Non-protein-coding sequences in the pre-mRNA
• Must be removed before translation
• Exons
• Amino acid coding sequences in pre-mRNA
• Joined together sequentially in final mRNA

22
RNA Processing
23
mRNA Splicing

• Introns in pre-mRNAs removed
• Spliceosome
• Pre-mRNA
• Small ribonucleoprotein particles (snRNP)
• Small nuclear RNA (snRNA) several proteins
• Bind to introns
• Loop introns out of the pre-mRNA,
• Clip the intron at each exon boundary
• Join adjacent exons together

24
mRNA Splicing
25
Why are Introns Present?

• Alternative splicing
• Different versions of mRNA can be produced
• Exon shuffling
• Generates new proteins

26
Alternative Splicing

• Exons joined in different combinations to produce
  different mRNAs from the same gene
• Different mRNA versions translated into different
  proteins with different functions
• More information can be stored in the DNA

27
Alternative mRNA Splicing

• a-tropomyosin in smooth and striated muscle

28
The next step Translation

• Translating from nucleic acid (DNA/RNA)
  language (nucleotides) to protein language
  (amino acids)
• Occurs in the ribosome within the cytoplasm
• Requires tRNA transfer RNA
• How does the mRNA (and DNA) code for proteins?
• The Genetic Code

29
Genetic Code

• Information
• 4 nucleotide bases in DNA or RNA sequences
• DNA A,T,G,C RNA A,U,G,C
• 20 different amino acids in polypeptides
• Code
• One-letter words only 4 combinations
• Two-letter words only 16 combinations
• Three-letter words 64 combinations

30
Genetic Code

• DNA
• Three-letter code triplet
• RNA
• Three-letter code codon

31
Genetic Code
32
Features of the Genetic Code

• Sense codons
• 61 codons specify amino acids
• Most amino acids specified by several codons
  (degeneracy or redundancy)
• Ex CCU, CCC, CCA, CCG all specify proline
• Start codon or initiator codon
• First amino acid recognized during translation
• Specifies amino acid methionine

33
Features of the Genetic Code

• Stop codons or termination codons
• End of a polypeptide-encoding mRNA sequence
• UAA, UAG, UGA
• Commaless
• Nucleic acid codes are sequential
• No commas or spaces between codons
• Start codon AUG establishes the reading frame

34
The Genetic Code
35
Genetic Code is Universal

• Same codons specify the same amino acids in all
  living organisms and viruses
• Only a few minor exceptions
• Genetic code was established very early in the
  evolution of life and has remained unchanged

36
Translation Overview
37
Translation

• Purpose
• To translate from nucleic acid language to
  protein language
• RNA?protein
• What is needed for translation?
• mRNA transcript (processed)
• tRNAs
• Ribosomes

38
tRNAs

• Transfer RNAs (tRNA)
• Bring specific amino acids to ribosome
• Cloverleaf shape
• Bottom end of tRNA contains anticodon sequence
  that pairs with codon in mRNAs

39
tRNA Structure
40
Ribosomes

• Made of ribosomal RNA (rRNA) and proteins
• Two subunits large and small

41
Translation Stages

• Initiation
• Ribosome assembled with mRNA molecule and
  initiator methionine-tRNA
• Elongation
• Amino acids linked to tRNAs added one at a time
  to growing polypeptide chain
• Termination
• New polypeptide released from ribosome
• Ribosomal subunits separate from mRNA

42
Initiation

• Initiator tRNA (Met-tRNA) binds to small subunit

43
Initiation

• Complex binds to 5 cap of mRNA, scans along mRNA
  to find AUG start codon

44
Initiation

• Large ribosomal subunit binds to complete
  initiation

45
Elongation

• tRNA matching the next codon enters A site
  carrying its amino acid
• A peptide bond forms between the first and second
  amino acids, which breaks the bond between the
  first amino acid and its tRNA
• Ribosome moves along mRNA to next codon
• Empty tRNA moves from P site to E site, then
  released
• Newly formed peptidyl-tRNA moves from A site to P
  site
• A site empty again

46
Elongation
47
Termination

• Begins when A site reaches stop codon
• Release factor (RF) or termination factor binds
  to A site
• Polypeptide chain released from P site
• Remaining parts of complex separated

48
Termination
49
What Happens to the New Polypeptides?

• Some just enter the cytoplasm
• Many enter the endoplasmic reticulum and move
  through the cytomembrane system where they are
  modified

50
Gene ExpressionSummary
Transcription
mRNA
rRNA
tRNA
Mature mRNA transcripts
ribosomal subunits
mature tRNA
Translation
51
Gene Mutations

• Changes in genetic material
• Base-pair mutations change DNA triplet
• Results in change in mRNA codon
• May lead to changes in the amino acid sequence of
  the encoded polypeptide

52
Gene Mutation Types

• Missense mutation
• Nonsense mutation
• Silent mutation
• Frameshift mutation

53
Missense Mutation

• Changes one sense codon to one that specifies a
  different amino acid

54
Sickle-Cell Anemia

• Caused by a single missense mutation

55
Nonsense Mutation

• Changes a sense codon to a stop codon

56
Silent Mutation

• Changes one sense codon to another sense codon
  that specifies the same amino acid

57
Frameshift Mutation

• Base-pair insertion or deletion alters the
  reading frame after the point of the mutation

58
Mutation Rates

• Each gene has a characteristic mutation rate
• Average rate for eukaryotes is between 10-4 and
  10-6 per gene per generation
• Only mutations that arise in germ cells can be
  passed on to next generation

59
Mutagens

• Ionizing radiation (X rays)
• Nonionizing radiation (UV)
• Natural and synthetic chemicals
