Title: Comparison of Risk Assessment for Radioactive and Chemical Contaminants
1Comparison of Risk Assessment for Radioactive and
Chemical Contaminants
- Similarities, Differences and Scope for
Comparison - BRMF/SAFESPUR Workshop,
- 30 September 2008
- Dr James Wilson, Quintessa, Ltd.
2Structure of this Presentation
- Exposure and Response
- Pathways, mechanisms and responses
- Comparison of criteria for the protection of
human health for radionuclides and
non-radioactive contaminants in soil - Comparison of exposure assessment tools for
radiological and non-radiological soil
contamination - An example of rad vs non-rad contamination
assessment
3Exposure Pathways
- Similarities
- Low concentrations
- Intake (ingestion, inhalation)
- Differences
- Irradiation at distance
- Hypersensitisation
4Exposure-Response Radionuclides
- Most evidence from A-bombs
- Same mechanism for all radionuclides
- Direct ionisation or free radicals
- Depends on intensity, duration, organs
- Deterministic threshold
- Stochastic non-threshold
- Important uncertainties remain
- Progression from damage to cancer
- Response at low dose rates
- Extrapolation from animals
5Exposure-ResponseChemicals
- Observations are key (animal experiments, human
epidemiology, occupational exposures) - Threshold and non-threshold effects
- Uncertainties include
- Extrapolation from animal experiments
- Exposure route extrapolation and bio-availability
- Inter and intra-species variability
6Dose Criteria Radionuclides
- Recommendations of ICRP
- Dose proportional to absorbed energy
- Weightings type of radiation, organ
- Risk proportional to dose (lt thresholds)
- Standards and Criteria (IAEA, Euratom)
- Risks and thresholds
- Can be compared with natural background
- Independent of particular radionuclides
- UK legislation reflects ICRP recommendations
7 Radiation Dose Criteria for Contaminated Land
- HPA (2006) Annual dose approaching 10 mSv
justifies intervention (considers ICRP
recommendations) - HPA health criteria for determination 3 mSv
yr-1 (to protect from non-threshold effects,
lifetime cancer risk of 1/100) - - or annual equivalent dose to lens of eye gt 15
mSv or annual equivalent dose to skin gt 50 mSv - Dose criteria apply to incremental dose from
contamination (i.e. total dose background),
average UK background dose is 2.2 mSv yr-1
therefore additional dose of 3 mSv yr-1 is
increase between 2 and 3 times UK annual average.
8Health Criteria Values for Chemicals- threshold
effects
- Defra/Environment Agency CLR Toxicological
reports - Assess international and other national guidance
(e.g. WHO) - HCV Tolerable Daily Soil Intake (TDSI)
- TDI (from all sources) identified from NOAELs (or
LOAELs) often from animal experiments -
multiplied by uncertainty factor(s) e.g. 10 for
interspecies and 10 for intra-species variation - Mean Daily Intake (MDI) set by considering other
(non-soil) routes of exposure - TDSI TDI - MDI
- Old approach If MDI gt 80 TDI, then TDSI 20
TDI. - New approach If MDI lt 50 TDI, then TDSI
TDI-MDI - If MDI TDI, TDSI 50 TDI
9Setting a LOAEL from animal data
10Health Criteria Values for Chemicals- non
threshold effects
- HCV Index Dose (ID)
- ID is daily intake that represents a very low to
negligible risk to human health (i.e. set to be
protective) - Provision that all exposures (inc. soil) should
be ALARP, therefore intakes from sources other
than soil not included - In UK not directly based on a fixed level of risk
(issue of animal to human extrapolation for
quantitative risk assessment) - Excess lifetime cancer risks generally 1/10 000
to 1/ 100 000 depending on substance and
exposure route - Possible future use of Benchmark Dose (BMD) data?
11(No Transcript)
12Soil Assessment Criteria Chemicals
- Soil Guideline Values / Site Specific Assessment
Criteria - SGVs are concentrations of contaminant in soil
such that Health Criteria Values should not be
exceeded (based on CLEA exposure model
assumptions) - Generic non-statutory guidance
- Difficulties reported by Local Authorities in use
of SGVs for determination under Part IIA of the
EPA (1990), and uncertainty in how great HCV has
to be exceeded to represent significant
possibility of significant harm - triggered Way Forward consultation (Defra)
13Non-threshold riskChemical vs. Radiation
- Chemicals
- Index Dose not set at specific risk - excess
lifetime cancer risks generally range from 1/10
000 to 1 000 000
(ID oral for As 1/1000) - UK Expert Medical Committee (CoC) does not
endorse quantitative cancer risk models based on
high-dose animal data - Non-soil intakes not considered (ALARP principle
assumed to have been applied to all sources of
exposure) - Radiation
- UK effective dose criteria set at 3 mSv yr-1
(lifetime fatal cancer risk of 1/100) - Background doses were considered in setting
effective dose
14CLEA Approach
- CLEA UK (now in redevelopment) and RCLEA
- Tiered approach
- Contaminant-specific guideline values
- Produces soil concentrations SGVs/RSGVs, or Site
Specific Assessment Criteria (SSACs) - Generic land-use scenarios residential both with
and without plant uptake, allotments,
commerical/industrial - Critical receptors
15(No Transcript)
16Differences between CLEA UK and RCLEA
- CLEA SGVs are contaminant specific, RCLEA allows
additive effective dose to be calculated - CLEA UK had 18 age groups, RCLEA has 3 (infant,
adult, child) - RCLEA has 2 additional exposure pathways (1)
whole body external irradiation from
contamination at a distance (2) irradiation of
skin from direct contact with contaminated
material - Adsorption through skin not applicable in RCLEA
(tritium exposure should be considered
separately) - RCLEA has only 1 soil type due to uncertainties
in solidliquid Kd values - Volatilisation is excluded from RCLEA
considered insignificant for historic
contamination
17Similarities, Differences
- Exposure-response
- Threshold and non-threshold effects
- Intake pathways/other pathways
- Dependence on contaminant
- Standards
- Epidemiological/toxicological studies
- Protection from threshold effects
- Dependence on contaminant/pathway
- Regulatory approach to non-threshold risks
- Assessments
- Exposure pathways and groups
18Common Basis for Comparison?
- Only intended to be an illustration
- Hypothetical site
- Radionuclides assessed using RCLEA
- Non-radionuclides assessed using CLEA UK (beta)
19Rads vs Non-rads Example
- Substances include H-3, Co-60, Sr-90, Ra-226,
As, Cd. - Ingestion, inhalation, ext. irradiation, dermal
- SSAC values for residential land use (with plant
uptake and female infant receptor
20Example SSAC Values
21Example risk comparison
- Arsenic oral intake is 2.6 times oral Index Dose
(ID oral 0.3 µg/kgbw/day
lifetime risk of developing skin cancer 1/1000,
assuming 1 mortality rate of those who develop
skin cancer, risk of death 1/10 000) - Cadium oral intake is 3.1 times TDSI
- (TDSI 0.77 µg/kg bw/day set to protect
against kidney damage, based on studies of
proteinuria in humans) - Total effective radiation dose is 1.2 times
criteria dose (3 mSv yr-1 lifetime fatal
cancer risk of 1/100)
22Conclusions
- Comparisons of risk can be made
- Differences in risk assessment approaches are
significant (especially with regard to
availability of toxicological data and regulatory
approaches for using cancer risk models)
23References
- Defra/Environment Agency. (2002) Contaminants in
soil collation of toxicological data and intake
values for humans (CLR 9). - HPA (2006) Dose criteria for the designation of
radioactively contaminated land. Report RCE-2. - Defra/Environment Agency. (2002) The Contaminated
Land Exposure Assessment (CLEA) model technical
basis and algorithms (CLR 10). - Defra (2005) CLAN briefing note 2/05 Soil
Guideline Values and the Determination of Land as
Contaminated Land under Part IIA. - Defra (2007) The radioactively contaminated land
exposure assessment methodology - technical
report (CLR 14)
