Title: Design Of Water Distribution Network Of Misilyah Village Using EPANET


1
Design Of Water Distribution Network Of Misilyah
Village Using EPANET
Prepared by Fatima Hirzallah Heba Abu Jaber
2
The importance of water distribution network
  • To facilitate the process of providing consumers
    with clean water.
  • Provide quantity that suit their needs and
    control the quality of this water because the
    presence of this network ensure unpolluted water
    and access to consumers with best quality.

3
Objectives
  • Design a service reservoir for Misilyah village.
  • Design the water distribution network for the
    village of Misilyah using EPANET
  •
  •

4
Study areaGeographical
Location
  • Misilyah is a Palestinian village in the West
    Bank, located 14 km in the South-east of Jenin
    city in the north of the West bank.

5
Geographical location
6
Climate
  • Hot and dry in summer and cool and rainy in
    winter
  • The temperature of the air is moderate
  • it has an average of 20.3 C

7
Rainfall
Rainfall 52.8 mm
8
Methodology
1- collecting information and reliable data. 2-
Drawing network using AutoCAD.
9
Drawing the Network
10
3- Convert the network into EPANET. 4-
Calculations using both Excel GIS
11
Population using Excel
12
Conversion into GIS
13
Thiessen Polygon Areas
14
5- Make EPANET run. 6- Problems such -ve
pressures , having nodes pressure head which less
than acceptable(20m). 7- Solving above problems
make successful run.
15
Design Constrains 1- Velocities range (0.3 2)
m/s. 2- Pressure head above 20m.
16
- ve pressure problem
17
Changing Nodes Diameters
Nodes Dia Modified Dia
78 50.8 76.2
79 25.4 50.8
18
Final Shape
19
(No Transcript)
20
Results 1- Pipes diameters such 6
(1-4). 2- Velocities pressures are both
within the acceptable range.
