Understanding Spray Drift

1
Understanding Spray Drift

• Robert E. Wolf
• Extension Specialist Application Technology

Biological and Agricultural Engineering
2
Why Interest in Drift?

• Spotty pest control
• Wasted chemicals
• Off-target damage
• More high value specialty crops
• Urban sprawl and.....
• Less tolerant neighbors
• Litigious Society
• More wind?? (Timing)
• Environmental impact
• Water and Air Quality
• Public more aware of pesticide
• concerns! (Negative) (Perceptions)
• Result-higher costs-

3
Productivity
The application triangle
Off-site protection
Efficacy
4
Status of EPA Label Guidance Proposal on Drift
5
Spray Drift Task Force

• April 1990
• 38 Companies
• 20 Million
• 21 Studies
• Airblast, Aerial,
• Ground, Chemigation
• 40 Reports
• Downwind!!!!
• Droplet size!!!!

6
SDTF Purpose

• To develop spray drift data required to fulfill
  data call-in requirements from the USEPA.
• Help formulate label language regarding
  application methods to reduce spray drift.
• Provide educational opportunities to develop best
  management practices which reduce spray drift.
• Formed National Coalition on Drift Minimization
  (NCODM) in 1995
• Straight Talk About Minimizing Spray Drift - A
  Guide for Applicators

7
Drift Labeling Guidance Issues
EPAs Proposal and Follow-up

• Draft Guidance for labeling statements for
  controlling spray and dust drift was published in
  the Federal Register (2001) and public comments
  have been received.

8
Major objections (5000 comments)

• Against zero tolerance
• 10 MPH wind limit
• 4-foot ground boom height limit
• 10-foot aerial boom height limit
• Need more restrictions!!!!!

9
When????
Proposed Implementation

• After considering all comments and further public
  listening sessions, EPA plans to issue a revised
  proposal for comments.
• Issue final guidance to registrants
• 200????

10
So Whats Happening Now??

• In the mean time, registrants can
• Go with the current draft labeling.
• Propose something else thats at least as
  protective that EPA will accept.
• Go with previous labeling guidelines.
• Go with old standard do not allow drift.
• Trial statements!!!!

11
EPA and Drift!
EPAs Bottom-line Message

• Concerns about spray drift and its adverse
  effects are taken seriously.
• Improvements in education/behavior, technology,
  and labeling are key issues
• Flexibility and openness to achieve goals

12
For more information contact
www.epa.gov/pesticides
www.epa.gov/pesticides/citizens/spraydrift.htm
13
Technical Aspects of Spray Drift
14
Definition of Drift

• Movement of spray particles and vapors
  off-target causing less effective control and
  possible injury to susceptible vegetation,
  wildlife, and people.
• Adapted from National Coalition on Drift
  Minimization 1997 as adopted from the AAPCO
  Pesticide Drift Enforcement Policy - March 1991

15
Types of Drift

• Vapor Drift - associated with volatilization
  (gas, fumes)
• Particle Drift - movement of spray particles
  during or after the spray application

16
Factors Affecting Drift

• Spray Characteristics
• chemical
• formulation
• drop size
• evaporation

• Equipment Application
• nozzle type
• nozzle size
• nozzle pressure
• height of release

• Weather
• air movement (direction and velocity)
• temperature and humidity
• air stability/inversions
• topography

17
Wind Direction

• Wind direction is very important
• Know the location of sensitive areas - consider
  safe buffer zones.
• Do not spray at any wind speed if it is blowing
  towards sensitive areas - all nozzles can drift.
• Spray when breeze is gentle, steady, and blowing
  away from sensitive areas.
• Dead calm conditions are never recommended.

18
However, Drift Potential May be High at Low Wind
Speeds

• Because
• Light winds (0-3 mph) tend to be
• unpredictable and variable in direction.
• Calm and low wind conditions may indicate
  presence of a temperature inversion.
• Drift potential is lowest at wind speeds between
  3 and 10 mph (gentle but steady breeze) blowing
  in a safe direction.

19
Spray Droplet Movement with Various Wind Speeds
20
Wind Speeds Gradients
Wind Speed
The relation between height above the canopy of a
crop like cotton or soybean and the speed of wind.
21
Wind Current Effects

• Wind currents can drastically affect spray
  droplet deposition
• Structures drastically affect wind currents
• Wind breaks
• Tree lines and orchards
• Houses and barns
• Hills and valleys

22
Wind Patterns Near Shelterbelts
Distance from shelterbelt (tree heights)
Generalized pattern of wind in the neighborhood
of a shelterbelt.
23
Wind Patterns Near Treelines
Adapted from Survey of Climatology Griffiths and
Driscoll, Texas AM University, 1982
24
Wind Patterns Around Buildings
Ground
Diagram of wind around a building. Adapted from
Farm Structures
H.J. Barre and L.L. Sammet, Farm Structures
(Wiley, 1959)
25
Wind Patterns Around Buildings
Diagram of Wind Around a Building Adapted From
Farm Structures
H.J. Barre and L.L. Sammet, Farm Structures
(Wiley, 1959)
26
Wind Meters and Compass
Prices for Wind Meters taken from Gemplers 2002
Master Catalog Plastimo Airguide Inc., 1110
Lake Cook Road, Buffalo Grove, IL
60089(708-215-7888)
27
Inversions
Under normal conditions air tends to rise and mix
with the air above. Droplets will disperse and
will usually not cause problems.
28
Temperature Inversions
Under these conditions the temperature increases
as you move upward. This prevents air from
mixing with the air above it. This causes small
suspended droplets to form a concentrated cloud
which can move in unpredictable directions.
29
Recognizing Inversions

• Under clear to partly cloudy skies and light
  winds, a surface inversion can form as the sun
  sets.
• Under these conditions, a surface inversion will
  continue into the morning until the sun begins to
  heat the ground.

30
Courtesy George Ramsay, Dupont
31
Precautions for Inversions

• Surface inversions are common .
• Be especially careful near sunset and an hour or
  so after sunrise, unless
• There is low heavy cloud cover
• The wind speed is greater than 5-6 mph at ground
  level
• 5 degree temp rise after sun-up
• Use of a smoke bomb or smoke
• generator is recommended to
• identify inversion conditions.

32
Spray Droplet Size
33
Efficacy and Drift Potential is Influenced by

• Size of the Spray Droplets -
• Volume Median Diameter (VMD)
• Droplet Spectrum (Range - big to small)

Volume in droplets less than 200 microns in
size
34
Relationship of Drift to Drop Size
One micron (?m) 1/25,000 inch
35
Comparison of Micron Sizes for Various Items
(approximate values)

• pencil lead 2000 (?m)
• paper clip 850 (?m)
• staple 420 (?m)
• toothbrush bristle 300 (?m)
• sewing thread 150 (?m)
• human hair 100 (?m)

150
36
1/2 of spray volume smaller droplets
VMD
1/2 of spray volume larger droplets
37
Cutting Droplet Size in HalfResults in Eight
Times the Number of Droplets
250 Microns
250 Microns
500 Microns
250 Microns
250 Microns
250 Microns
250 Microns
250 Microns
250 Microns
38
Important Droplet Statistics
VMD (50)
Operational Area
VD0.9 (90)
VD0.1 (10)
39
Evaporation of Droplets
High Relative Humidity Low Temperature
Low Relative Humidity High Temperature
Fall Distance
Wind
40
Spray Characteristics are Important to Understand
Demonstrates Turbo Flat vs TurboDrop-5 MPH Wind
41
ASAE S-572 Droplet Size Standard
42
Coverage

• Need knowledge of the product being used.
• Systemic
• Contact
• What is the target?
• Soil
• Grass
• Broadleaf (smooth, hairy, waxy)
• Leaf orientation time of day

43
ASAE DSC and Volume Median Diameter (DV0.5) From
PMS Laser Spectrometer
Droplet Spectra Classification (DSC)
Droplet Size Range

• Very Fine (VF) lt 182µm
• Fine (F) 183-280µm
• Medium (M) 281-429µm
• Coarse (C) 430-531µm
• Very Coarse (VC) 532-655µm
• Extremely Coarse (XC) gt656µm

USDA ARS College Station, TX
44
(No Transcript)
45
Computer Models
46
AgDRIFT Program Map
47
Example of Model Use Aerial Applicators
Standard Operation
48
Strategies to Reduce Drift

• Select nozzle to increase drop size
• Increase flow rates - higher application volumes
• Use lower pressures
• Use lower spray (boom) heights
• Avoid high application speeds/rapid speed changes
• Avoid adverse weather conditions
• High winds, light variable winds, calm air
• Consider using buffer zones
• Consider using new technologies
• drift reduction nozzles
• drift reduction additives
• shields, electrostatics, air-assist

49
Drift Reduction Additives

• Many available!
• Not EPA regulated
• Long chain polymers
• New-soluble powders
• 50 - 80 reduction in off-target movement
• Pump shear problems
• Effect on the pattern?

50
Goodland Drift Project

• 8 Companies
• 19 Drift Reduction/Deposition Aids
• Water
• X-77 _at_ .25
• 2 Airplanes
• AT 502 - Hawkeye Bill and Dave
• Cessna Ag Husky w/wing tips Cary
• 3 reps with the drift tower
• 1 pass over a canopy top and bottom
• 260 flight passes each
• 4600 cards

51
Participants in the Study
Companies
Products

• 41-A
• Formula One
• AMS 20/10
• Border EG 250
• Control
• INT VWZ
• Inplace
• Garco Exp-3
• INT YAR
• Border XTRA 8L

• HM2005-C
• HM0226
• Liberate
• Target LC
• HM2052
• INT HLA
• HM 0230
• Valid
• Double Down

• United Suppliers
• Helena Chemical
• Garco
• Loveland
• Wilber-Ellis
• Rosens
• Precison Labs
• SanAg

52
Some Other Things to Keep in Mind when Planning a
Spray Application

• Allow enough time for
• Scheduling and planning the application
• Obtaining the products
• Setting up the application date
• Weather delays or maintenance problems, if
  necessary.

Try not to fall into the trap of declaring I
need to spray RIGHT NOW!. Forcing a job under
poor conditions almost always leads to drift or
other errors.
53
In Conclusion
Minimizing spray drift is in the best interests
of everyone. Do your part to keep applications
on target.
54
Thank You
55
For more information contact
rewolf_at_ksu.edu
www.bae.ksu.edu/rewolf/
