Machine Learning

1
Machine Learning
Approach based on Decision Trees
2

• Decision Tree Learning
• Practical inductive inference method
• Same goal as Candidate-Elimination algorithm
• Find Boolean function of attributes
• Decision trees can be extended to functions with
  more than two output values.
• Widely used
• Robust to noise
• Can handle disjunctive (ORs) expressions
• Completely expressive hypothesis space
• Easily interpretable (tree structure, if-then
  rules)

3
Training Examples
Attribute, variable, property
Object, sample, example
Shall we play tennis today? (Tennis 1)
decision
4

• Decision trees do classification
• Classifies instances into one of a discrete set
  of possible categories
• Learned function represented by tree
• Each node in tree is test on some attribute of an
  instance
• Branches represent values of attributes
• Follow the tree from root to leaves to find the
  output value.

Shall we play tennis today?
5

• The tree itself forms hypothesis
• Disjunction (ORs) of conjunctions (ANDs)
• Each path from root to leaf forms conjunction of
  constraints on attributes
• Separate branches are disjunctions
• Example from PlayTennis decision tree
• (OutlookSunny ? HumidityNormal)
• ?
• (OutlookOvercast)
• ?
• (OutlookRain ? WindWeak)

6

• Types of problems decision tree learning is good
  for
• Instances represented by attribute-value pairs
• For algorithm in book, attributes take on a small
  number of discrete values
• Can be extended to real-valued attributes
• (numerical data)
• Target function has discrete output values
• Algorithm in book assumes Boolean functions
• Can be extended to multiple output values

7

• Hypothesis space can include disjunctive
  expressions.
• In fact, hypothesis space is complete space of
  finite discrete-valued functions
• Robust to imperfect training data
• classification errors
• errors in attribute values
• missing attribute values
• Examples
• Equipment diagnosis
• Medical diagnosis
• Credit card risk analysis
• Robot movement
• Pattern Recognition
• face recognition
• hexapod walking gates

8

• ID3 Algorithm
• Top-down, greedy search through space of possible
  decision trees
• Remember, decision trees represent hypotheses, so
  this is a search through hypothesis space.
• What is top-down?
• How to start tree?
• What attribute should represent the root?
• As you proceed down tree, choose attribute for
  each successive node.
• No backtracking
• So, algorithm proceeds from top to bottom

9

• The ID3 algorithm is used to build a decision
  tree, given a set of non-categorical attributes
  C1, C2, .., Cn, the categorical attribute C, and
  a training set T of records.
• function ID3 (R a set of non-categorical
  attributes,
• C the categorical attribute,
• S a training set) returns a
  decision tree
• begin
• If S is empty, return a single node with
  value Failure
• If every example in S has the same value for
  categorical
• attribute, return single node with that
  value
• If R is empty, then return a single node
  with most
• frequent of the values of the categorical
  attribute found in
• examples S note there will be errors,
  i.e., improperly
• classified records
• Let D be attribute with largest Gain(D,S)
  among Rs attributes
• Let dj j1,2, .., m be the values of
  attribute D
• Let Sj j1,2, .., m be the subsets of S
  consisting
• respectively of records with value dj for
  attribute D
• Return a tree with root labeled D and arcs
  labeled
• d1, d2, .., dm going respectively to the
  trees

10

• What is a greedy search?
• At each step, make decision which makes greatest
  improvement in whatever you are trying optimize.
• Do not backtrack (unless you hit a dead end)
• This type of search is likely not to be a
  globally optimum solution, but generally works
  well.
• What are we really doing here?
• At each node of tree, make decision on which
  attribute best classifies training data at that
  point.
• Never backtrack (in ID3)
• Do this for each branch of tree.
• End result will be tree structure representing a
  hypothesis which works best for the training data.

11
Information Theory Background

• If there are n equally probable possible
  messages, then the probability p of each is 1/n
• Information conveyed by a message is -log(p)
  log(n)
• Eg, if there are 16 messages, then log(16) 4
  and we need 4 bits to identify/send each message.
• In general, if we are given a probability
  distribution
• P (p1, p2, .., pn)
• the information conveyed by distribution (aka
  Entropy of P) is
• I(P) -(p1log(p1) p2log(p2) ..
  pnlog(pn))

12

• Question?
• How do you determine which attribute best
  classifies data?
• Answer Entropy!
• Information gain
• Statistical quantity measuring how well an
  attribute classifies the data.
• Calculate the information gain for each
  attribute.
• Choose attribute with greatest information gain.


13

• But how do you measure information?
• Claude Shannon in 1948 at Bell Labs established
  the field of information theory.
• Mathematical function, Entropy, measures
  information content of random process
• Takes on largest value when events are
  equiprobable.
• Takes on smallest value when only one event
  hasnon-zero probability.
• For two states
• Positive examples and Negative examples from set
  S
• H(S) -plog2(p) - p-log2(p-)

Entropy of set S denoted by H(S)
14
Largest entropy
Entropy

Boolean functions with the same number of ones
and zeros have largest entropy
15

• But how do you measure information?
• Claude Shannon in 1948 at Bell Labs established
  the field of information theory.
• Mathematical function, Entropy, measures
  information content of random process
• Takes on largest value when events are
  equiprobable.
• Takes on smallest value when only one event
  hasnon-zero probability.
• For two states
• Positive examples and Negative examples from set
  S
• H(S) - plog2(p) - p- log2(p-)

Entropy
Measure of order in set S
16

• In general
• For an ensemble of random events
  A1,A2,...,An,occurring with probabilities z
  P(A1),P(A2),...,P(An)

If you consider the self-information of event, i,
to be -log2(P(Ai)) Entropy is weighted average
of information carried by each event.
Does this make sense?
17

• Does this make sense?

• If an event conveys information, that means its
  a surprise.
• If an event always occurs, P(Ai)1, then it
  carries no information. -log2(1) 0
• If an event rarely occurs (e.g. P(Ai)0.001), it
  carries a lot of info. -log2(0.001) 9.97
• The less likely the event, the more the
  information it carries since, for 0 ? P(Ai) ? 1,
  -log2(P(Ai)) increases as P(Ai) goes from 1 to
  0.
• (Note ignore events with P(Ai)0 since they
  never occur.)

18

• What about entropy?
• Is it a good measure of the information carried
  by an ensemble of events?
• If the events are equally probable, the entropy
  is maximum.
• 1) For N events, each occurring with probability
  1/N.
• H -?(1/N)log2(1/N) -log2(1/N)
• This is the maximum value.
• (e.g. For N256 (ascii characters) -log2(1/256)
  8 number of bits needed for characters.
  Base 2 logs measure information in bits.)
• This is a good thing since an ensemble of
  equally probable events is as uncertain as it
  gets.
• (Remember, information corresponds to surprise -
  uncertainty.)

19

• 2) H is a continuous function of the
  probabilities.
• That is always a good thing.
• 3) If you sub-group events into compound events,
  the entropy calculated for these compound groups
  is the same.
• That is good since the uncertainty is the same.
• It is a remarkable fact that the equation for
  entropy shown above (up to a multiplicative
  constant) is the only function which satisfies
  these three conditions.

20

• Choice of base 2 log corresponds to choosing
  units of information. (BITs)
• Another remarkable thing
• This is the same definition of entropy used in
  statistical mechanics for the measure of
  disorder.
• Corresponds to macroscopic thermodynamic
  quantity of Second Law of Thermodynamics.

21

• The concept of a quantitative measure for
  information content plays an important role in
  many areas
• For example,
• Data communications (channel capacity)
• Data compression (limits on error-free encoding)
• Entropy in a message corresponds to minimum
  number of bits needed to encode that message.
• In our case, for a set of training data, the
  entropy measures the number of bits needed to
  encode classification for an instance.
• Use probabilities found from entire set of
  training data.
• Prob(ClassPos) Num. of positive cases / Total
  case
• Prob(ClassNeg) Num. of negative cases / Total
  cases

22

• (Back to the story of ID3)
• Information gain is our metric for how well one
  attribute A i classifies the training data.
• Information gain for a particular attribute
• Information about target function,
• given the value of that attribute.
• (conditional entropy)
• Mathematical expression for information gain

Entropy for value v
entropy
23

• ID3 algorithm (for boolean-valued function)
• Calculate the entropy for all training examples
• positive and negative cases
• p pos/Tot p- neg/Tot
• H(S) -plog2(p) - p-log2(p-)
• Determine which single attribute best classifies
  the training examples using information gain.
• For each attribute find
• Use attribute with greatest information gain as a
  root

24
Using Gain Ratios

• The notion of Gain introduced earlier favors
  attributes that have a large number of values.
• If we have an attribute D that has a distinct
  value for each record, then Info(D,T) is 0, thus
  Gain(D,T) is maximal.
• To compensate for this Quinlan suggests using the
  following ratio instead of Gain
• GainRatio(D,T) Gain(D,T) / SplitInfo(D,T)
• SplitInfo(D,T) is the information due to the
  split of T on the basis of value of categorical
  attribute D.
• SplitInfo(D,T) I(T1/T, T2/T, ..,
  Tm/T)
• where T1, T2, .. Tm is the partition of T
  induced by value of D.

25

• Example PlayTennis
• Four attributes used for classification
• Outlook Sunny,Overcast,Rain
• Temperature Hot, Mild, Cool
• Humidity High, Normal
• Wind Weak, Strong
• One predicted (target) attribute (binary)
• PlayTennis Yes,No
• Given 14 Training examples
• 9 positive
• 5 negative

26
Training Examples
Examples, minterms, cases, objects, test cases,
27
14 cases
9 positive cases

• Step 1 Calculate entropy for all cases
• NPos 9 NNeg 5 NTot 14
• H(S) -(9/14)log2(9/14) - (5/14)log2(5/14)
  0.940

entropy
28

• Step 2 Loop over all attributes, calculate gain
• Attribute Outlook
• Loop over values of Outlook
• Outlook Sunny
• NPos 2 NNeg 3 NTot 5
• H(Sunny) -(2/5)log2(2/5) - (3/5)log2(3/5)
  0.971
• Outlook Overcast
• NPos 4 NNeg 0 NTot 4
• H(Sunny) -(4/4)log24/4) - (0/4)log2(0/4)
  0.00

29

• Outlook Rain
• NPos 3 NNeg 2 NTot 5
• H(Sunny) -(3/5)log2(3/5) - (2/5)log2(2/5)
  0.971
• Calculate Information Gain for attribute Outlook
• Gain(S,Outlook) H(S) - NSunny/NTotH(Sunny)
  - NOver/NTotH(Overcast) -
  NRain/NTotH(Rainy) Gain(S,Outlook) 9.40 -
  (5/14)0.971 - (4/14)0 - (5/14)0.971
  Gain(S,Outlook) 0.246
• Attribute Temperature
• (Repeat process looping over Hot, Mild, Cool)
• Gain(S,Temperature) 0.029

30

• Attribute Humidity
• (Repeat process looping over High, Normal)
• Gain(S,Humidity) 0.029
• Attribute Wind
• (Repeat process looping over Weak, Strong)
• Gain(S,Wind) 0.048
• Find attribute with greatest information gain
• Gain(S,Outlook) 0.246,
  Gain(S,Temperature) 0.029
• Gain(S,Humidity) 0.029, Gain(S,Wind) 0.048
• ? Outlook is root node of tree

31

• Iterate algorithm to find attributes which best
  classify training examples under the values of
  the root node
• Example continued
• Take three subsets
• Outlook Sunny (NTot 5)
• Outlook Overcast (NTot 4)
• Outlook Rainy (NTot 5)
• For each subset, repeat the above calculation
  looping over all attributes other than Outlook

32

• For example
• Outlook Sunny (NPos 2, NNeg3, NTot 5)
  H0.971
• Temp Hot (NPos 0, NNeg2, NTot 2) H
  0.0
• Temp Mild (NPos 1, NNeg1, NTot 2) H
  1.0
• Temp Cool (NPos 1, NNeg0, NTot 1) H
  0.0
• Gain(SSunny,Temperature) 0.971 - (2/5)0 -
  (2/5)1 - (1/5)0
• Gain(SSunny,Temperature) 0.571
• Similarly
• Gain(SSunny,Humidity) 0.971
• Gain(SSunny,Wind) 0.020
• ? Humidity classifies OutlookSunny instances
  best and is placed as the node under Sunny
  outcome.
• Repeat this process for Outlook Overcast Rainy

33

• Important
• Attributes are excluded from consideration if
  they appear higher in the tree
• Process continues for each new leaf node until
• Every attribute has already been included along
  path through the tree
• or
• Training examples associated with this leaf all
  have same target attribute value.

34

• End up with tree

35

• Note In this example data were perfect.
• No contradictions
• Branches led to unambiguous Yes, No decisions
• If there are contradictions take the majority
  vote
• This handles noisy data.
• Another note
• Attributes are eliminated when they are assigned
  to a node and never reconsidered.
• e.g. You would not go back and reconsider Outlook
  under Humidity
• ID3 uses all of the training data at once
• Contrast to Candidate-Elimination
• Can handle noisy data.

36
Another Example Russells and Norvigs
Restaurant Domain

• Develop a decision tree to model the decision a
  patron makes when deciding whether or not to wait
  for a table at a restaurant.
• Two classes wait, leave
• Ten attributes alternative restaurant
  available?, bar in restaurant?, is it Friday?,
  are we hungry?, how full is the restaurant?, how
  expensive?, is it raining?,do we have a
  reservation?, what type of restaurant is it?,
  what's the purported waiting time?
• Training set of 12 examples
• 7000 possible cases

37
A Training Set
38
A decision Treefrom Introspection
39
ID3 Induced Decision Tree
40
ID3

• A greedy algorithm for Decision Tree Construction
  developed by Ross Quinlan, 1987
• Consider a smaller tree a better tree
• Top-down construction of the decision tree by
  recursively selecting the "best attribute" to use
  at the current node in the tree, based on the
  examples belonging to this node.
• Once the attribute is selected for the current
  node, generate children nodes, one for each
  possible value of the selected attribute.
• Partition the examples of this node using the
  possible values of this attribute, and assign
  these subsets of the examples to the appropriate
  child node.
• Repeat for each child node until all examples
  associated with a node are either all positive or
  all negative.

41
Choosing the Best Attribute

• The key problem is choosing which attribute to
  split a given set of examples.
• Some possibilities are
• Random Select any attribute at random
• Least-Values Choose the attribute with the
  smallest number of possible values (fewer
  branches)
• Most-Values Choose the attribute with the
  largest number of possible values (smaller
  subsets)
• Max-Gain Choose the attribute that has the
  largest expected information gain, i.e. select
  attribute that will result in the smallest
  expected size of the subtrees rooted at its
  children.
• The ID3 algorithm uses the Max-Gain method of
  selecting the best attribute.

42
Splitting Examples by Testing Attributes
43
Another example Tennis 2 (simplified former
example)
44
Choosing the first split
45
Resulting Decision Tree
46

• The entropy is the average number of bits/message
  needed to represent a stream of messages.
• Examples
• if P is (0.5, 0.5) then I(P) is 1
• if P is (0.67, 0.33) then I(P) is 0.92,
• if P is (1, 0) then I(P) is 0.
• The more uniform is the probability distribution,
  the greater is its information gain/entropy.

47

• What is the hypothesis space for decision tree
  learning?
• Search through space of all possible decision
  trees
• from simple to more complex guided by a
  heuristic information gain
• The space searched is complete space of finite,
  discrete-valued functions.
• Includes disjunctive and conjunctive expressions
• Method only maintains one current hypothesis
• In contrast to Candidate-Elimination
• Not necessarily global optimum
• attributes eliminated when assigned to a node
• No backtracking
• Different trees are possible

48

• Inductive Bias (restriction vs. preference)
• ID3
• searches complete hypothesis space
• But, incomplete search through this space looking
  for simplest tree
• This is called a preference (or search) bias
• Candidate-Elimination
• Searches an incomplete hypothesis space
• But, does a complete search finding all valid
  hypotheses
• This is called a restriction (or language) bias
• Typically, preference bias is better since you do
  not limit your search up-front by restricting
  hypothesis space considered.

49
How well does it work?

• Many case studies have shown that decision trees
  are at least as accurate as human experts.
• A study for diagnosing breast cancer
• humans correctly classifying the examples 65 of
  the time,
• the decision tree classified 72 correct.
• British Petroleum designed a decision tree for
  gas-oil separation for offshore oil platforms/
• It replaced an earlier rule-based expert
  system.
• Cessna designed an airplane flight controller
  using 90,000 examples and 20 attributes per
  example.

50
Extensions of the Decision Tree Learning Algorithm

• Using gain ratios
• Real-valued data
• Noisy data and Overfitting
• Generation of rules
• Setting Parameters
• Cross-Validation for Experimental Validation of
  Performance
• Incremental learning

51

• Algorithms used
• ID3 Quinlan (1986)
• C4.5 Quinlan(1993)
• C5.0 Quinlan
• Cubist Quinlan
• CART Classification and regression trees
  Breiman (1984)
• ASSISTANT Kononenco (1984) Cestnik (1987)
• ID3 is algorithm discussed in textbook
• Simple, but representative
• Source code publicly available

Entropy first time was used

• C4.5 (and C5.0) is an extension of ID3 that
  accounts for unavailable values, continuous
  attribute value ranges, pruning of decision
  trees, rule derivation, and so on.

52
Real-valued data

• Select a set of thresholds defining intervals
• each interval becomes a discrete value of the
  attribute
• We can use some simple heuristics
• always divide into quartiles
• We can use domain knowledge
• divide age into infant (0-2), toddler (3 - 5),
  and school aged (5-8)
• or treat this as another learning problem
• try a range of ways to discretize the continuous
  variable
• Find out which yield better results with
  respect to some metric.

53
Noisy data and Overfitting

• Many kinds of "noise" that could occur in the
  examples
• Two examples have same attribute/value pairs, but
  different classifications
• Some values of attributes are incorrect because
  of
• Errors in the data acquisition process
• Errors in the preprocessing phase
• The classification is wrong (e.g., instead of
  -) because of some error
• Some attributes are irrelevant to the
  decision-making process,
• e.g., color of a die is irrelevant to its
  outcome.
• Irrelevant attributes can result in overfitting
  the training data.

54
Overfitting learning result fits data (training
examples) well but does not hold for unseen data
This means, the algorithm has poor
generalization Often need to compromise fitness
to data and generalization power Overfitting is a
problem common to all methods that learn from data

• Fix overfitting/overlearning problem
• By cross validation (see later)
• By pruning lower nodes in the decision tree.
• For example, if Gain of the best attribute at a
  node is below a threshold, stop and make this
  node a leaf rather than generating children
  nodes.

55
Pruning Decision Trees

• Pruning of the decision tree is done by replacing
  a whole subtree by a leaf node.
• The replacement takes place if a decision rule
  establishes that the expected error rate in the
  subtree is greater than in the single leaf.
• E.g.,
• Training eg, one training red success and one
  training blue Failures
• Test three red failures and one blue success
• Consider replacing this subtree by a single
  Failure node.
• After replacement we will have only two errors
  instead of five failures.

56
Incremental Learning

• Incremental learning
• Change can be made with each training example
• Non-incremental learning is also called batch
  learning
• Good for
• adaptive system (learning while experiencing)
• when environment undergoes changes
• Often with
• Higher computational cost
• Lower quality of learning results
• ITI (by U. Mass) incremental DT learning package

57
Evaluation Methodology

• Standard methodology cross validation
• Collect a large set of examples (all with correct
  classifications!).
• Randomly divide collection into two disjoint
  sets training and test.
• 3. Apply learning algorithm to training set
  giving hypothesis H
• 4. Measure performance of H w.r.t. test set
• Important keep the training and test sets
  disjoint!
• Learning is not to minimize training error (wrt
  data) but the error for test/cross-validation a
  way to fix overfitting
• To study the efficiency and robustness of an
  algorithm, repeat steps 2-4 for different
  training sets and sizes of training sets.
• If you improve your algorithm, start again with
  step 1 to avoid evolving the algorithm to work
  well on just this collection.

58
Restaurant ExampleLearning Curve
59
Decision Trees to Rules

• It is easy to derive a rule set from a decision
  tree write a rule for each path in the decision
  tree from the root to a leaf.
• In that rule the left-hand side is easily built
  from the label of the nodes and the labels of the
  arcs.
• The resulting rules set can be simplified
• Let LHS be the left hand side of a rule.
• Let LHS' be obtained from LHS by eliminating some
  conditions.
• We can certainly replace LHS by LHS' in this rule
  if the subsets of the training set that satisfy
  respectively LHS and LHS' are equal.
• A rule may be eliminated by using metaconditions
  such as "if no other rule applies".

60
C4.5

• C4.5 is an extension of ID3 that accounts for
  unavailable values, continuous attribute value
  ranges, pruning of decision trees, rule
  derivation, and so on.
• C4.5 Programs for Machine Learning
• J. Ross Quinlan, The Morgan Kaufmann Series
  in
  Machine Learning, Pat Langley,
• Series Editor. 1993. 302 pages.

  paperback book 3.5" Sun

  disk. 77.95. ISBN 1-55860-240-2

61
Summary of DT Learning

• Inducing decision trees is one of the most widely
  used learning methods in practice
• Can out-perform human experts in many problems
• Strengths include
• Fast
• simple to implement
• can convert result to a set of easily
  interpretable rules
• empirically valid in many commercial products
• handles noisy data
• Weaknesses include
• "Univariate" splits/partitioning using only one
  attribute at a time so limits types of possible
  trees
• large decision trees may be hard to understand
• requires fixed-length feature vectors

62

• Summary of ID3 Inductive Bias
• Short trees are preferred over long trees
• It accepts the first tree it finds
• Information gain heuristic
• Places high information gain attributes near root

• Greedy search method is an approximation to
  finding the shortest tree
• Why would short trees be preferred?
• Example of Occams Razor
• Prefer simplest hypothesis consistent with the
  data.
• (Like Copernican vs. Ptolemic view of Earths
  motion)

63

• Homework Assignment
• Tom Mitchells software
• See
• http//www.cs.cmu.edu/afs/cs.cmu.edu/project/theo-
  3/www/ml.html
• Assignment 2 (on decision trees)
• Software is at http//www.cs.cmu.edu/afs/cs/proje
  ct/theo-3/mlc/hw2/
• Compiles with gcc compiler
• Unfortunately, README is not there, but its easy
  to figure out
• After compiling, to run
• dt -s ltrandom seedgt lttrain gt ltprune gt lttest
  gt ltSSV-format data filegt
• train, prune, test are percent of data to be
  used for training, pruning testing. These are
  given as decimal fractions. To train on all data,
  use 1.0 0.0 0.0
• Data sets for PlayTennis and Vote are include
  with code.
• Also try the Restaurant example from Russell
  Norvig
• Also look at www.kdnuggets.com/ (Data Sets)
• Machine Learning Database Repository at UC
  Irvine - (try zoo for fun)

64
Questions and Problems

• 1. Think how the method of finding best variable
  order for decision trees that we discussed here
  be adopted for
• ordering variables in binary and multi-valued
  decision diagrams
• finding the bound set of variables for Ashenhurst
  and other functional decompositions
• 2. Find a more precise method for variable
  ordering in trees, that takes into account
  special function patterns recognized in data
• 3. Write a Lisp program for creating decision
  trees with entropy based variable selection.

65

• Sources
• Tom Mitchell
• Machine Learning, Mc Graw Hill 1997
• Allan Moser
• Tim Finin,
• Marie desJardins
• Chuck Dyer
