Your Drinking Water A 21st Century Challenge and Solutions

1
Your Drinking WaterA 21st Century Challenge and
Solutions

• J. Alan Roberson, P.E.
• Director of Security and Regulatory Affairs
• American Water Works Association

2
Presentation Outline

• Drinking Water Basics
• Water Use Data
• Safe Drinking Water Act (SDWA) Basics
• Drinking Water Data
• Water System Inventory Data
• Violation Data
• Challenges Ahead
• Critical Issues Identified by Others
• AWWA State of Industry Report
• Possible Solutions

3
Transmission
Source USEPA
4
Drinking Water Basics

• Approximately 350 billion gallons used per day in
  the U.S.
• Most used for power generation irrigation
• Public water supply--42 billion gallons per day
• 125 to 200 gallons per person per day design
  basis (varies on a regional basis)
• But only drink about ½ gallon per day
• Most used for outdoor irrigation
• Other indoor use (showers, toilets, dishwashers,
  clothes washers, etc.) can be significant
• Dont forget about fire protection

5
USGS Water Use Data
6
Drinking Water Regulatory History

• 1925 and 1942--U.S. Public Health Service (USPHS)
  adopts standards for coliform, water quality
  parameters, and inorganics (IOCs)
• 1962--USPHS sets maximum concentrations for 5
  IOCs, 2 organic chemicals, fluoride, and
  radionuclides
• Requirement for qualified operators
• 1970--U.S. Environmental Protection Agency (EPA)
  established
• 1974--Safe Drinking Water Act passed
• Shifted from state setting standards based on
  USPHS to national enforceable standards developed
  by EPA

7
Basic SDWA Regulatory Framework

• Maximum Contaminant Level Goal (MCLG)
• Health-based goal based strictly on health
  effects
• allows for an adequate margin of safety
• Maximum Contaminant Level (MCL)
• Enforceable standard set as close to the MCLG
  as is feasible
• Analytical methods and treatment feasibility
  considered
• Benefit-cost analysis (BCA) an important
  component
• Treatment Technique (TT) can be used in lieu of a
  MCL
• Analytical methods, indicators, surrogates, etc.

8
SDWA Reg. Framework (cont.)

• EPA delegates regulatory and enforcement
  authority to states through Public Water Supply
  Supervision (PWSS) Program
• States have to adopt standard at least as strict
  as the federal standard
• EPA reviews state regs. if approves, then gives
  states primacy
• EPA gives to states for their programs thru
  PWSS program
• States have some discretion in enforcement
• Informal actions can achieve compliance with less
  resources
• Formality of actions increases with continued
  non-compliance
• How do you measure reg. program effectiveness?
• Violation data is the only program performance
  metric

9
SDWA History

• 1974 SDWA increased federal role
• EPA regulates 23 contaminants from 1974-1986 (not
  really a whole lot)
• 1986 Safe Drinking Water Act
• Prescriptive regulatory schedule
• 83 contaminants to be regulated in first 3 years
• Additional 25 contaminants every 3 years
• EPA increased the number of regulations, but had
  difficulties in meeting these schedules
• Resulted in increased burden to States with
  limited resources pressure to retain primacy

10
Legislative History Leading to 1996 SDWA
Amendments

• Problems with the 1986 SDWA
• Regulatory schedule very prescriptive
• EPA missing deadlines
• Court cases
• Regulation for the sake of regulation
• Major risks might not be addressed

• New regulatory concepts
• Relative risk reduction
• Cost-benefit analysis
• Good science
• Not everyone can agree with the definition of
  good science

11
1996 SDWA Amendments

• 1996 SDWA Amendments fundamentally revised the
  standard-setting process
• The 3 criteria for identifying potential regs
• Additional reg. considerations
• Other major new provisions
• Drinking Water SRF
• Source water protection
• Operation certification
• Consumer Confidence Report

12
EPAs 3 SDWA Regulatory Processes from 1996 SDWA
Amendments

• Priority regulations (specific deadlines in 1996
  SDWA)
• Microbial/Disinfection By-Product (M/DBP) Cluster
• Information Collection Rule (ICR), Stage 1 DBPR,
  Interim Enhanced Surface Water Treatment Rule
  (IESWTR), LT1ESWTR, Stage 2 DBPR, and LT2ESWTR
• Groundwater Rule (GWR)
• Arsenic
• Sulfate
• Radon
• Filter Backwash

13
The Last 2 SDWA Regulatory Processes

• Contaminant Candidate List (CCL)
• Regulatory determination, then proposal and final
• Only after positive determination
• Unregulated contaminant monitoring can be used to
  generate occurrence data
• Review of existing regulations every six years
  (Six-Year Review)

14
SDWA and Contaminant Identification

• EPA Administrator shall determine to regulate a
  contaminant if, based on the best available
  science,
• The contaminant may have an adverse health
  effect
• The contaminant is known or likely to occur with
  a frequency and at levels of public health
  concern and
• (National) regulation presents a meaningful
  opportunity for health risk reduction

Note that costs are not a part of this
determination
15
SDWA and Contaminant Regulation

• Contaminant Candidate List (CCL)
• First in 1998 and then every 5 years
• Regulatory Determination (RD)
• First in 2003 and then every 5 years (at least 5)
• Determinations regulate, not regulate, issue
  health advisory, needs more research
• If a determination is made to regulate, then
  proposal 24 months after and final 36 months
  after determination
• Six-Year Review of existing regulations

16
CCL/UCMR/RD Decision Sequence/Timeline
Draft CCL
Preliminary Regulatory Determinations (RD)
Public Reviewand Comment
Final CCL
Draft UCMR
Proposed Rule (NPDWR)
Final Regulatory Determinations (RD)
Final UCMR
UCMR Monitoring Results
Six Year Review of Existing NPDWRs
Final Rule (NPDWR)
No further action or develop health advisory
17
CCL/UCMR/RD History

• Final CCL1 in 1998
• 60 contaminants 50 chemicals 10 microbes
• Developed primarily through expert judgment
  process
• UCMR1 in 1999
• 12 chemicals on List 1 for required monitoring
  for systems serving gt10,000 people2001 thru 2003
• List 2 Screening and List 3 Pre-Screen
• First Final Regulatory Determination (RD1) in
  2003
• Decided not to regulate 9 CCL1 contaminants

18
CCL/UCMR/RD History (cont.)

• Final CCL2 in 2005
• 51 remaining CCL1 contaminants
• 60 CCL1 contaminants minus 9 from RD1
• UCMR2 in 2007
• 10 chemicals on List 1 for systems serving
  gt10,000
• Monitoring ongoing (2008 to 2010)
• Draft CCL3 in Feb. 2008
• 93 chemicals and 11 microbials
• Final RD2 in July 2008Not regulate 11
• Proposed perchlorate RD in Oct. 2008

19
Water System Inventory

• Public water system defined as having gt15
  connections or serving gt25 people
• Approximately 155,000 regulated systems
• Approximately 52,000 community water systems
• Serve approximately 292 million people

20
Inventory (cont.)

• Most large systems use surface water and most
  small systems use groundwater
• Approximately 80 are municipal and 20 private

21
Where We Are TodayThe Number of Regulated
Contaminants
22
MCL and MRDL Violations
23
2008 MCL and MRDL Violations
24
The Challenges Ahead

• Previous work on critical issues
• Water Research Foundation (formerly AwwaRF)
  project on trends impacting water utilities by Ed
  Means and others
• Interviews by National Environmental Services
  Center (NESC) by Sandra Fallon
• 13 interviews, each representing approx. 100
  systems
• Annual report on State of Industry by Steve
  Maxwell of TechKNOWLEDGEy Strategic Group
• AWWA annual State of the Industry Report

25
Ten Trends in Foundation Report

• Population and demographics
• Politics
• Regulations
• Workforce
• Technology

• Total water management
• Customer expectations
• Utility financial constraints
• Energy
• Increased risk profile

Summaries of report in 6 issues of 2005-2006
JAWWA Trends in July 2005 JAWWA
26
NESC Security Issues

1. Aging Infrastructure (80 of systems facing this
   risk)
2. Lack of Planning (75)
3. Retiring Operator Workforce (60.7)
4. Natural Disaster (51)
5. Local Vandalism (41)
6. Groundwater Overpumping (19.3)
7. Source Water Contamination (25)
8. Climate Change (22.6)
9. Terrorism (7.3)

From Fall 2008 On Tap
27
TechKNOWLEDGEy Report

• Key Drivers
• Water quality and scarcity problems are reaching
  critical proportions
• Public awareness and understanding of water
  problems is increasing
• Regulation and enforcement will continue to
  intensity
• Huge economic (and human) capital investments are
  required

28
TechKNOWLEDGEy Report Trends

• Increasing regulation and government oversight
• Dilapidated infrastructure
• Conservation and efficiency
• Focus on recycling and reuse
• Better measurement and monitoring
• Technological solutions
• Residential water consumption
• Surge of investment in water
• Ownership changes and consolidation
• Consolidation in the private sector
• Controversy over privatization and out-sourcing

29
AWWA State of the Industry Report

• Comprehensive survey program started in 2004
• Developed to answer the need of AWWA members for
  information regarding key water industry trends
  and issues identified through the Member Tracking
  program
• SOI results is presented annually at ACE and more
  detailed information published in The Journals
  October issue
• Other articles are published in many different
  media based on SOI insights
• Data from the SOI have been used extensively by
  AWWA to drive fact-based strategic decisions, not
  just intuition
• SOI Reports are attracting increasing interest
  from others in the trade press, further
  broadening awareness of AWWAs leadership

30
Objectives

• Develop high value insights regarding the key
  issues facing the water industry
• Identify issues of importance not being
  adequately addressed to raise awareness and bring
  higher industry priority
• Identify and track important industry trends on a
  going basis
• Emerging critical issues
• Utility capital spending

31
Methodology

• 10,000 AWWA key members were mailed surveys in
  early March 2008
• Over-sample of MAC and Canada to boost returns in
  these important segments
• Over 1,900 surveys eventually returned
• Experienced and knowledgeable respondent base
• 53 have over 20 years experience in the water
  industry
• 53 have a four-year college degree or higher,
  with 30 having a Masters, PhD or other advanced
  degree

32
Overall Industry Soundness

• Please begin our survey by answering two
  broad questions about how "sound" you believe the
  industry to be. In other words, how do you
  perceive the overall health and vitality of our
  industry from your unique perspective?
• In your opinion, what is the current overall
  state of the water industry?
• Not At Very
• All Sound Sound
• Looking forward, how sound will the overall water
  industry be five years from now?
• Not At Very
• All Sound Sound

33
Methodology

• Next, respondents were asked to describe in their
  own words critical issues that are
• Facing the industry in the next 1-2 years (near
  term)
• Facing the industry in the next 3-5 years (long
  term)
• Inadequately addressed
• Then a wide range of scaled questions regarding
  specifically named issues, opinions and
  demographics

34
Summary of Findings

• Slow but steady decline in future soundness of
  the water industry
• For the first time, future soundness rated lower
  than current soundness
• Related in part to a spike in Source Water
  concerns regarding pharmaceuticals in water
• Mounting concerns about sufficient availability
  of treatable water contributed
• Infrastructure decay, financing infrastructure
  repair and regulatory compliance, and workforce
  issues continue to wear on future optimism
• Since the study was in the field in March/April
  2008, the current economic turmoil is not
  reflected in the data

35
Recommendations

• SOURCE WATER ISSUES
• AWWA should lead the way to develop research that
  helps manage emerging contaminant issues,
  particularly regarding understanding of true
  effects on health of emerging contaminants
• Address Source Water Supply issues
• Source water protection
• Sustainable sourcing to meet shifting/growing
  demand
• Water rights and planning for large geographies
• (e.g., how are the Great Lakes to be used as
  potable water resources in the future)

36
Recommendations

• INFRASTRUCTURE
• Awareness of the ticking time bomb of the
  declining infrastructure is viewed as being more
  apparent to industry insiders than stakeholders
  who control funding to rehabilitate and update
  the infrastructure
• AWWA should bring sound information to the
  political arena to overcome the out of sight,
  out of mind status quo
• Promote technology that helps assess underground
  infrastructure conditions as well as more
  cost-effective and long-lasting rehab solutions
• Bring balance to the funding picture for
  infrastructure vs. regulatory compliance

37
Recommendations

• BUSINESS FACTORS
• AWWA should continue to help utilities bring back
  into balance the gap between the cost and rates
• Smaller systems seem to need even more attention
  and tools due to their lower economies of scale
  and more scarce access to resources (monetary and
  workforce).

38
Recommendations

• WORKFORCE
• Workforce concerns continue to grow require
  attention
• The major action steps include
• Helping utilities manage the brain-drain
• Elevate the prestige of water industry careers,
  and help bring salaries in line (or close the
  gap) versus competing industries - tap into the
  idea of Public Service
• Help utilities develop retention strategies
  (including but in addition to higher salaries)
  for valued workers who are being attracted to
  other industries

39
Recommendations

• SECURITY
• Though Security concerns have declined there is a
  vocal minority advising continued vigilance and
  preparedness
• Key areas include
• Security of process chemicals (like chlorine)
• Real-time monitoring of water safety in
  distribution
• Emergency preparedness related to non-terrorist
  events (especially natural disasters)

40
Recommendations

• WATER TREATMENT
• Water treatment concerns were highly linked to
  source water protection
• Emerging Contaminant Mitigation
• Science to understand what treatments are truly
  required to keep water safe
• Technology to cost-effectively treat these now
  known contaminants and those yet but soon to be
  discovered and publicized

41
While current soundness ratings have flattened,
for the first time the industry is concerned the
future will not be as sound as today.
42
Source Water Issues soured to the 1 issue Near
Term, Longer Term and Most Inadequately
Addressed. Business Factors and Infrastructure
continue to be important and inadequately
addressed as well. Source Water, Infrastructure
and Workforce issues in particular are thought
even more concerning longer term.
43
In the short term (next 1-2 years) Source Water
concerns soared. This traces in part to
publicity about drugs in the water supply that
hit while the survey was in the field. But it
does follow the prior year trend and is also
driven by heightened concerns future supply will
not meeting future demand. Regulatory and
Security issues continued to have accelerated
declines while most other factors came in about
even with recent trends.
44
In the longer term (3-5 years out), Source Water
concerns again soared while Regulatory issues and
Security declined, with most other factors about
even with recent experience.
45
Source Water also climbed to be the most
inadequately addressed issue. The rest of the
issue areas declined a bit, except for Water
Treatment as treatment concerns for
pharmaceuticals and other emerging contaminants
raised concerns likely fueled by the publicity
issues this spring.
46
2008 Critical Issue Breakout US Base 1,709

• Near Longer
  Inadequately
• Term Term
  Addressed
• Source Water Supply 41 45 23
• Water Supply/Shortage 21 25 11
• Source water protection 9 8 5
• Drugs in Source Water 9 8 3
• Business Factors 30 28 23
• Financing repairs/replacements/upgrades 13 14
  12
• Rates/Cost Imbalance 12 10 7
• Finance regulatory compliance 4 4
  4
• Regulatory Factors 25 21 10
• Complying with new regulations 19 15
  4
• Infrastructure 23 27 19
• Aging infrastructure 19 21 15
• Failing infrastructure 3 3 2

47
When the financing components of Infrastructure
and Regulatory Issues are combined with the other
Infrastructure and Regulatory comments
(respectively), Source Water remains 1, but
Infrastructure rises to the 2 spot, and
Workforce rises to the 4 position. And
Infrastructure is clearly thought to be the most
inadequately addressed issue overall.
48
Focus On Workforce Issues

• Based on the growing concerns about Workforce
  issues in previous years, additional Workforce
  drill-down questions were included to provide
  deeper perspective

49
Executive and Management/ Supervisory personnel
are expected to experience the highest retirement
rates in the next five years (particularly at
Utilities), followed by Operators. The potential
organizational knowledge loss from these line
positions continues to be troubling.
50
In general, both Utilities and Service Providers
indicate a fair degree of concern about their
ability to cope with workforce retirement. 27
of Utilities and 22 of Service Providers gave a
rating below the midpoint of 4 on the 7-point
scale. Just over 10 of each group felt Very
Prepared.
51
Compounding difficulties with the large number of
Operators about to retire, Utility managers still
report it is increasingly difficult to recruit
and retain suitable replacements for Operators
leaving their organizations (due to retirement or
being recruited away to higher paying/more
prestigious positions).
52
Focus on Other Utility Perspective

• Capital Spending
• Infrastructure Failure Rates
• Technology Usage/Adoption

53
Utilities capital spending for Expansion in 2009
will be nearly half of all capital spent (47) -
up 11 from 2008. Infrastructure
Replacement/Upgrades will be 29, up 17 from
2008. New Source Water Supply (12) and Security
spending (2) will remain about flat, while
capital spending to meet Regulatory Requirements
(9) will fall slightly (-4). Total capital
spending is projected to rise about 14 in 2009
vs. 2008, slowing slightly from the 19 rise
reported between 2008 and 2007.
Capital Expense Area of 2009 Spending Change 2009 vs. 2008
Capital Expansion 47 11
Replace/Upgrade Infrastructure 29 17
New Source Water Supply 12 no change
Meet Regulatory Requirements 9 - 4
Meet Security Requirements 2 no change
Total Capital Spending 100 14
54
Utilities will rely on bonds and rate increases
for nearly half of their capital needs in 2008.
Operational savings and loans will comprise about
another quarter of capital funding, with grants
and other funding options rounding out the mix.
These proportions have remained very similar over
the past three years.
Source of Capital 2006 2007 2008
Bonds 23 23 22
Rate Increases 17 22 16
Operational Savings 13 16 15
Loans 17 13 16
Grants 11 8 10
Other 22 18 21
55
Overall, Utilities report major infrastructure
failures in 2007 occurred about as frequently and
about as severely as in 2006.
56
Water efficiency is the more likely of the three
options tested to be implemented for future
source water, with nearly a quarter of utilities
already using it and another 8 seriously
considering water efficiency. Nearly 35 of
utilities are not considering water
reclamation/reuse seriously at all, while about a
quarter are not considering desalination at all
(even though it might be applicable to their
region). About a third of utilities do not see
desalination as applicable to their area.
57
DemographicsOrganization
Utilities 63
Consulting 15
Government/Regulatory Agency 7
Water Wholesaler 5
Manufacturer 5
Distributor 1
Tech Services 1
Manufacturer's Rep 1
University/Education Institute 1
Other 2
58
DemographicsJob Responsibilities
Management 46
Executive 26
Operations 9
Engineer 8
Consultant 5
Marketing/Sales 2
Scientist 1
Regulator 1
Other 2
59
The Common Issues

• Infrastructure
• Regulations
• Total water management
• Funding

60
The Triad of Sustainability
Total Water Management
Funding
Workforce
61
Sustainability

• Sustainability is generally defined as the use
  of resources today so that there is no adverse
  impacts in the future
• For water, the focus is typically on water
  resources and/or total water management
• Utility adaptive management to be prepared for
  climate change is one part
• Management of carbon footprint and/or greenhouse
  gases (GHG) can be another part
• Energy/water nexus getting increased attention

62
Funding Sustainability

• Water has been under-priced and under-valued
• Public needs education on the value of water
• Utilities should be self-sustaining thru rates
• Local elected officials have to make tough
  decisions
• Federal role should focus on research and funding
  efficiences
• Treatment technologies exist to comply with the
  regulations, but rates have to raise the
• More and more old distribution system pipes needs
  rehabilitation and/or replacement and that will
  take more

63
Workforce Sustainability

• Utilities have an aging workforce
• Operators and technical staff are the two largest
  problem areas
• Two different approaches needed
• New AWWA public affairs effort to highlight the
  water and wastewater profession
• Get Into Water

64
Questions?

• American Water Works Association
• Government Affairs Office
• 1300 Eye Street NW, 701W
• Washington, DC 20005
• [phone]
• aroberson_at_awwa.org

a
